English NEWAREEM

1
True Control for System Owners
2
The only true on-site system owner software

• Designed for the end user
• Forget keypads, a maze of menus and cryptic codes
• Simple, graphical management of the DigiplexNE
  system from a computer

3
Manage multiple users effortlessly

• Program hundreds of users quickly and easily
• Personalize system with labeling of names and
  titles for user codes
• Create users based on another users options

4
(No Transcript)
5
Janitor
6
(No Transcript)
7
Easy copypaste programming

• Copy user options
• Then paste to format others

8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Point-and-click management of the DigiplexNE
system

• Manage users, access rights and schedules
• Search, retrieve and manage system information
  via reports

13
Assign doors to up to 15 access levels
14
(No Transcript)
15
Convenient storage of access card numbers

• Read card numbers at a nearby reader to store in
  NEware for later use
• Simply click to assign each user code to a stored
  access control card

16
Live monitoring of your entire system

• Monitor the status of all areas and zones
  graphically or by list of selected events
• Get instant notice of troubles and alarms even
  when software is not active
• View alarm memory

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Create custom reports

• Filter reports by specific date, event or other
  criteria
• Save or print out reports for archives

22
(No Transcript)
23
True multitasking

• True independent operation without interrupting
  communication with central station or
  upload/download with WinLoad
• In alarm situation, panel sends alarm code to
  central station and NEware simultaneously

24
Fast, secure connection to panel

• Changes made instantly
• 38.4k baud connection
• Connection up to 1000ft (300m) from panel with
  DNE-CONV1
• Connection up to 25ft (8m) with 306 adapter

25
Advanced security features

• Use the security systems user access code to
  logon with NEware
• User rights are same as for security system
• Inactivity timer for automatic exiting of
  software
• Hide feature with PIN reactivation of software

26
Work offline

• All actions performed are downloaded to panel
  next time you go online
• Access all functions except system monitoring,
  storing access card numbers, and synchronizing
  time and date between panel and computer

27
Software editions

• Demo DNEWARE-DM
• Security NEW-SEC
• SecurityAccess Control NEW-ACC

28
Demo edition

• Includes all features of the SecurityAccess
  Control edition
• May be used to program a maximum of 5 user codes
• Available free from Paradox Web site

29
Security edition

• Manages all security features of the DigiplexNE
  system such as
• programming 999 users
• monitoring and controlling system
• setting schedules
• printing reports
• Requires a unique registration code otherwise
  runs as a Demo edition

30
SecurityAccess Control edition

• Same as Security edition plus
• Set schedules and access levels
• setting access control user options
• viewing live events
• convenient card number storage
• Requires a unique registration code otherwise
  runs as a Demo edition

31
System requirements

• Pentium 200MHz
• Compatible with Windows 95/98/2000/ME or
  Windows NT service pack 5 or higher
• 32MB RAM (64MB recommended)
• 20MB hard disk space (35MB recommended)

32

• Thank you for choosing Paradox
