Hydro Optimization

1
Hydro Optimization

• Tom Halliburton

2
(No Transcript)
3
(No Transcript)
4
Variety

• Stochastic
• Deterministic
• Linear, Non-linear, dynamic programming
• Every system is different
• Wide variety of physical constraints
• Studied for many years - lots of legacy systems.

5
Time Scales

• Long term expansion planning
• Long / medium term operational planning
• Week / day ahead ahead planning
• Market clearing
• Short term operations planning
• Real time economic dispatch
• Real time unit loading

6
(No Transcript)
7
Large Lake
Transmission system
Penstock
Small headpond
Power house
Concrete or earth dam
Tailwater
8
Water Value

• Value of an extra increment of water
• If lake full, extra spilled ? Value 0
• If empty, extra replaces combustion turbine or
  avoids blackout ? high value
• Expected marginal value of water Emarginal
  cost of thermal station displaced by generation
  from this water
• Dual value of flow balance equation in LP
• Use water so that Marginal Value of water used
  this period EMV of water in storage

9
Merit Order Dispatch
MW
Peakers
Flexible plant
Base load plants
Zero cost resources
Must run
Hours
10
Long Term Planning

• 10 to 30 year horizon, 1 to 4 week time step
• Hydro, thermal, transmission system
• Transmission important especially with hydro
• Some aggregation of chains of stations
• Model large reservoirs only
• Stochastic load, inflows, thermal plant
  availability
• Load duration curve load representation

11
Long Term Planning

• Simulation of a specified set of conditions
• Optimization to get a reasonable hydro operating
  pattern
• Thermal dispatch models (eg Henwood) use rule
  based dispatch. Hydro operating patterns
  specified by user
• Stochastic inflows, energy limitation problematic
• Use of mean flows risky

12
Stochastic DP with Heuristic

• 30 year hydro-thermal planning with HVDC
  constraint in New Zealand
• Determine reservoir levels at which EMV
  marginal cost of each thermal plant
• 60 simulations of detailed operation using
  historical inflows
• Major impact on electricity planning in NZ
• Used for long term planning, medium term
  operations

13
Reservoir Guidelines
Lake Level
0/MWh
5/MWh
15/MWh
30/MWh
100/MWh
Time
14
SDDP - by Mario Pereira

• Stochastic Dual Dynamic Programming
• 1 to 10 year horizon, weekly / monthly time steps
• Used in numerous countries
• Stochastic DP with a sampling strategy to enable
  multi reservoir optimization
• Hydro, thermal, with detailed transmission
  system, area interchange constraints
• Solves an LP for each one period sub problem

15
SDDP

• Simulate forward with 50 inflow sequences, using
  a future cost function gives upper bound on
  objective function
• DP backward optimization considering only storage
  states that the simulation passed through -
  gives lower bound on objective
• Each optimization iteration adds hyper planes to
  the future cost function, improving the
  approximation

16
SDDP Subproblems
At each state pointSolve one LP for each inflow
outcome
State (storage)
t
t1
Time
17
SDDP Future Cost
Future Cost
One hyper plane per state point Slope average
dual of water balance Height average cost to go
from that state
Storage Level
18
Medium Term Planning

• 1 or 2 year horizon, weekly time steps
• Load duration curve
• Norwegian power pool model - successive
  approximations DP
• Hydro Quebec Gesteau - stochastic dynamic
  program
• Acres International, Charles Howard, PGE
  stochastic linear programming solved by CPLEX.
• SDDP Central America, Colombia,

19
Medium Term Planning

• Stochastic DP or Stochastic LP gaining due to
  increased LP solver power
• Key output water values from large lakes
• Maintenance planning
• Permitting studies
• Plant upgrade studies

20
Day or Week Ahead

• 24 to 168 hour horizon
• One hour, ½ hour time steps - chronological
• Deterministic
• Link to medium term model by water values
• Maybe with bid curve generation strategy
• LP, sometimes with successive linearizations,
  sometimes MIP
• Detailed model of waterways, lakes, hydro units

21
Day or Week Ahead

• Send output to market operator or real time
  control center
• Nasty features
• Overflow spill weirs
• Rate of change of flow constraints
• Non convex unit characteristics
• Unit prohibited zones
• Spinning reserve

22
Unit Modeling
MW
Maximum efficiency
Full load
Rough running ranges
Water Flow
23
Market Clearing

• 24 hour horizon, 1 or ½ hour steps
• Bids and offers can be specific to each bus
• Optimize accounting for transmission system
  losses and constraints for optimal clearing price
  at each bus.
• CEGELEC ESCA (NZ, Australia)
• Simple price / quantity stack Cal PX
• Ignore coupling of time periods problems for
  hydro operators

24
Hydro Economic Dispatch

• 30 to 120 minutes horizon, 10 minute steps
• Used in control center with SCADA
• Takes system status from SCADA (lake levels,
  flows, current set points)
• Time step short, run frequently, 10 minutes
• Given a load change, what should be done
• Answer needed quickly
• Feasibility essential, optimality desirable

25
Hydro Economic Dispatch

• Input water values, overall strategy from day
  ahead model
• Models whole system of stations, canals, lakes,
  gates, spillways
• Individual units, stop / start costs
• Environmental constraints, operating rules
• Issue new set points automatically, with operator
  review

26
Optimal Unit Loading

• Static optimization, solve on demand
• Objective Minimize water use for given station
  output how many units should be on-line what
  load on each unit
• Run by operator or within a SCADA system
• Simple, quick, clearly defined payoff
• Every unit is a unique individual even more so
  with age cavitation repairs

27
Optimal Unit Loading

• Tailrace and headrace geometry, penstock losses,
  interaction between units.
• Calibrate unit performance using ultrasonic flow
  measurement, accurate MW meters
• Rough running zones
• Non symmetrical station layout different
  tailwater levels, penstock losses.

28
(No Transcript)
29
Optimal Unit Loading
Two unit loads
Three unit loads
One unit loads
Desired station load
30
Decision making

• Year ahead to set water values
• Week/day ahead using water values to generate
  market bids
• Market clearing model to determine day ahead
  results
• Day ahead model to plan implementation
• Real time instructions issued to control center
  by grid operator

31
Decision making

• Economic Dispatch determines allocation of grid
  operator requests
• Station receives set points
• Unit loading algorithm adjusts unit set points
• ED runs frequently
• AGC adjusts some unit set points to correct
  frequency or Area Control Error (Ace)
