Title: NXtension Expander Boards


1
NXtension Expander Boards
  • For NX241 NX242
  • Digital TDcontrollers

2
NXtension Expander Board
  • Doubling DSP Memory resources
  • 2 possible Communication interfaces
  • WinCAI for remote control only.
  • EtherSound for Digital Audio Network.

3
NXtension interfaces
  • WINCAI (-CAI)
  • Integration in CAMCO WINCAI remote control
    network
  • Ethernet RS485
  • NX241 NX242
  • Ethersound (-ES4)
  • 64 channel Digital audio network
  • Bi-directional remote control.
  • NX242

4
NXtension-CAI interface
  • Remote
  • Control potentials via WLAN and Internet, 100
    Ethernet and TCP/IP compatible.

5
NXtension-CAI interface
  • Network bridge between IP Network and CAI
    Network.

6
NXtension-CAI interface
  • Daisy Chain configuration
  • 32 Units (NX241 Vortex-Amplifiers) per Ethernet
    Node.

7
NXtension-CAI interface
  • Interface EtherCAI (Connect to a Laptop or
    switcher), RJ45 Connector.
  • Interface CAI (RS485 connection with other CAI
    equipment), RJ11 Connector.

8
NXtension-CAI interface
  • Star Configuration
  • Unlimited numbers of NX241 and Vortex-Amplifiers
    controlled on the EtherCAI Network.

9
EtherSound Network
  • Overview

10
EtherSound
  • High quality audio Network (push audio).
  • 64 channels 24bit/48kHz.
  • Very low latency transmission.
  • Standard Internet Hardware.
  • Infinite number of connected devices.
  • Bi-directional status control data.

11
EtherSound Network For Fixed Installations
  • Background/foreground music and live
    announcements multi-zone audio distribution.
  • Point-to-point signal transfer over long
    distances.
  • Lower installation costs than analog
    systems,standard Ethernet cabling, daisy-chain
    architecture, competitive cost per network node.
  • Increased flexibility for system
    re-configuration.

12
EtherSound Network for Live Sound
  • Audio distribution for mobile installations.
  • Near to real-time, very low latency (125µsec _at_
    48kHz).
  • Quick and easy system set up using standard
    Ethernet cables.
  • High-quality audio (24bit/48kHz).

13
EtherSound Network
  • Daisy chain Configuration

14
EtherSound Network
  • Star Configuration

15
  • Combined Daisy Chain Star Configuration

16
EtherSound NetworkSystem Architecture
17
EtherSound Input modules
  • AVY16-ES for YGDAI compatible equipment (Yamaha
    digital Mixers, DME32, A/D)
  • INNOVA SON Digital mixing desks
  • DIGIGRAM ES8IN ES8mic
  • NetCira Mi1..Mi5 (AESEBU Analogue)
  • NEXO NX242 DIGITAL TDcontroller

18
AVY16-ES
  • By AUVITRAN

19
AVY16-ES
  • Compatible with Yamaha YGDAI interface

20
NXtension-ES4
21
NXtension-ES4
  • Implement the EtherSound protocol in the NX242
    TDcontroller.
  • Remote Control potentials via WLAN and Internet,
    100 Ethernet and TCP/IP compatible.
  • Ethersound Master/Slave operation.

22
NXtension-ES4
  • 4 Digital audio inputs from 64 uncompressed
    channels of 24bit/48kHz of audio transmission
    over Ethernet.
  • 4 Digital NX242s processed audio outputs to 64
    uncompressed channels of 24bit/48kHz of audio
    transmission over Ethernet.

23
NXtension-ES4
  • Master mode
  • 2 high dynamic range Analogue inputs fed in the
    Ethersound Network through the NX242 A/D
    circuitry.

24
NXtension-ES4
  • Slave Mode
  • 4 high dynamic range outputs from the Ethersound
    Network, through NX242 D/A circuitry.

25
NXtension-ES4
  • Master/Slave operation
  • Retrieve up to 4 channel from the ES network.
  • Process the channels according to NEXO cabinets
    setups.
  • Feed back up to 4 channel on the ES network.

26
NX Remote Control Software
  • 32bit, Windows 2000, Windows XP
  • Multithreading operation

27
NX Remote Control Software
  • All NX241/NX242 parameters controlled through an
    user friendly window

28
NX Remote Control Software
  • Real time Protection Monitoring

29
NX Remote Control Software
  • vu-meter of all NX241/NX242 visible at the same
    time in the same window

30
NX Remote Control Software
  • Update Firmware through the control network on
    multiple NX simulteanouly

31
NX Remote Control Software
  • Groupe zone operation

32
NX242 DIGITAL TDcontroller
33
NX242 Digital TDcontroller
  • Full compatibility with NX241.
  • 110dB Dynamic Range.
  • Heavy Duty, high quality input stage.
  • Switch mode power Supply 90-250Vac continuous
    operation.
  • World Wide Certification (UL CB scheme)
