Title: National Sun Yat-Sen University


1
National Sun Yat-Sen University
2
System Support for Scalable, Reliable and Highly
Manageable Internet Services
  • Chu-Sing Yang
  • Department of Computer Science and
    EngineeringNational Sun Yat-Sen University

3
Outline
  • Introduction
  • Proposed System
  • Request Routing Mechanism
  • Management System
  • Content-aware Intelligence
  • Work in Progress
  • Conclusion

4
Background
  • The Internet has become the most important
    client-server application platform
  • More and more Internet services emerge
  • The trend toward exponential growth of Internet
    users at higher speed continues
  • The Internet is becoming a mission-critical
    business delivery infrastructure
  • The desire for using the Web to conduct business
    transactions or deliver services is increasing at
    an amazing rate.
  • Huge demand for high performance, scalable,
    highly reliable Internet servers

5
Meeting the challenge
  • New Moores law?
  • Servers capacity doubles every 18 month for
    meeting the explosive growth

More contents, more servers, faster feeds
Providers increase the network capacity
More users, more demand, faster modems
6
Web has new requirements
  • Before
  • An economical platform for Information sharing
    and publish (non-critical information)
  • 90 percents of information represented by text
    and images
  • Unfrequent maintenance and updates
  • Security is not important
  • No guarantee on service availability
  • Highly available performance
  • Now
  • An important platform for critical services
  • More sophisticated content, e.g., larger
    percentage or dynamic content or streaming data
  • Content change frequently
  • Security becomes great concern
  • Companies are evaluated even on the basis of
    their websites
  • Explosive growth of user population

7
Meeting the challenge
  • The first-generation Web infrastructure was never
    designed to handle the unique traffic patterns of
    the Web, which today accounts for 80 of Internet
    usage.
  • Most current medium large Web service providers
    are suffering from server overload
  • Yahoo, Google, Altavista, CNN, Microsoft,..
  • A single monolithic server system is difficult to
    cope with these challenges.
  • We need a scalable Internet Service Architecture
    guaranteeing the service expectation of all Web
    services!

8
Essential Requirements of Internet Server
  • High Performance
  • Scalability
  • High reliability
  • Robustness
  • QoS

9
Scalable Server Architecture
  • Feasible solution Server Cluster (server farm)
  • Collection of independent computer systems
    working together as if a single system.
  • Advantages
  • Scalable grow on demand
  • Highly available redundancy
  • Cost-effective
  • Most current medium large Web service providers
    take this architecture.
  • This trend is accelerating!

10
Design Issues
  • We need an integrated system to support a
    successful Internet service on such a distributed
    server system

Clients
HTTP request
Router
Request Routing
Communication
Server farm
System Management
11
Our Solutions--Content-aware Web Cluster System
  • Content-aware Distributor (Server Load Balancer)
  • Content-aware routing (Layer-7 routing)
  • Sophisticated load balancing
  • Service Differentiation
  • QoS
  • Fault resilience
  • Transaction support
  • Distributed Server Management System
  • System management
  • Intelligent Content placement and management
  • Supporting differentiated service
  • Supporting QoS
  • Fault management

12
Outline
  • Introduction
  • Proposed System
  • Request routing mechanism
  • Management System
  • Content-aware Intelligence
  • Work in Progress
  • Conclusion

13
Motivation
  • Key Challenge how to dispatch and route incoming
    requests to the server best suited to respond

14
Desirable Properties
  • User transparency
  • Backward compatible
  • Fast Access
  • Scalability
  • Robustness
  • Availability
  • Reliability
  • QoS Support

15
Client-side Approach
  • Customized browser (e.g. Netscape)
  • Java applet
  • HAWA (From ATT)
  • Smart client (From U.C. Berkeley)
  • Advantage
  • low overhead
  • Global-wide solution
  • Problems
  • create increased network traffic
  • applet transmission
  • extra querying between applet and servers for
    state information
  • insensitive to servers state

16
DNS-based Approach
DNS
Who is www.nsysu.edu.tw ?
IP address of www.nsysu.edu.tw
Database
Router
Router
Database
Customized DNS
Server Farm
17
DNS-based Approach
  • Advantage
  • Ease of implementation
  • Low overhead
  • Global-wide solution
  • Problems
  • Hostname to IP address mapping can be cached by
    DNS server
  • lead to significant load imbalance
  • change in DNS information propagate slowly
    through the Internet. That is, if the backend
    sever is failure or removed, Internet as a whole
    may not aware it.
  • It is difficult to detect failure and load
    information of back-end nodes

18
HTTP Redirection
  • One special response codes called redirection
    defined in the HTTP protocol can be used for
    directing a request.
  • Through HTTP redirection, we can make a server to
    instruct the client to send the request to
    another location instead of returning the
    requested data.
  • Problems
  • a request may require two or more connections for
    getting the desired service, thus this approach
    will increase the response time and network
    traffic.
  • the node serving this mechanism may become the
    impediment to scaling the server.

19
Single IP address
client
http//pds.cse.nsysu.edu.tw/job/
Server Farm
Router
SVR.1
SVR.2
Web Switch
Virtual IP address
SVR.n
20
Layer-4 based approach
  • Route request based on Source and destination IP
    address, port number, TCP flag (SYN/FIN)
  • Packets pertaining to the same connection must be
    routed to the same server
  • Fine grained control on request routing
  • Scalability limited by the Internet access
    bandwidth
  • Based on simple algorithms
  • Round-Robin, Weighted Round-Robin, Least
    connection.....
  • Examples
  • Cisco LocalDirector
  • IBM Network Dispatcher
  • Foundry ServerIron
  • F5 network
  • HydraWeb

21
Issues Ignored by Existing Schemes
  • Session Integrity
  • Sophisticated Load Balancing
  • Quality of Service
  • Fault Resilience
  • Content Deployment and Management
  • These observations lead to the inevitable
    conclusion the request routing mechanism should
    factor in content of request in making decisions
  • Yang and Luo, IWI99.

22
Design of Content-aware Distributor
  • Basic idea route requests based on its URL
  • Major challenge connection-oriented semantics of
    TCP
  • Our design
  • Bridge two TCP connection
  • client to distributor
  • distributor to selected server
  • Pre-fork and re-use server-side connection
  • seamlessly relay HTTP request from client
    connection to the server connection

23
Operation of Content-aware Distributor
24
Make Routing Decision
  • Parse HTTP Request
  • Make routing decision
  • Select a destination server
  • Select a pre-forked connection

25
Content-aware Distributor
26
Implementation Status
  • The content-aware distributor is implemented as
    kernel loadable module
  • The distributor module inserts itself between
    network interface (NIC) driver and TCP/IP stack.
  • We have extended the Linux kernel (Version
    2.2.16) with this module.
  • Because ideas and mechanisms adopted in
    content-aware distributor are generic, so it
    should be applicable to other system (e.g. BSD or
    Windows NT) as well.

27
Challenges of Content-aware Routing
  • How can we build the content-aware intelligence
    into the distributor for making routing decision?
  • Content type,size,priority,location,
  • Should be configurable,extensible,comprehensive
  • How can the distributor perfom request
    distribution based on the content-aware
    intelligence?
  • Parsing HTTP header of each request
  • Should be fast,efficient

28
The idea of URL table
client
http//www.nsysu.edu.tw/pds/
Server Farm
Router
SVR.1
SVR.2
Distributor
URL Table
URL
priority
http//www.yahoo.com
Low
High
http//www.nsysu.edu.tw
SVR.2
SVR.2
http//www.nctu.edu.tw
SVR.n
29
Design of URL Table
  • URL table holds the content-related information
    that enables the distributor to make intelligent
    routing decisions.
  • E.g., content type, size, priority, location
  • The URL table is a multiple level hash tree that
    model the content tree
  • Such an idea is based on the observation that
    people generally organize content using a
    directory-based hierarchical structure.
  • The files in the same directory usually possess
    the same attributes.
  • For example, the files underneath the /CGI-bin/
    directory generally are CGI scripts for
    generating dynamic content
  • To reduce the search time and the size of the
    table,we use an aggregation mechanism to specify
    a set of items that own the same properties

30
Modeling the Content Tree
  • Ex http//foo.com/special/dancer/img/main/01/21.j
    pg

31
Request Routing
  • An example of incoming HTTP request
  • http//www.pds.nsysu.edu.tw/nsysu/personal/enginee
    ring/8834601/index_logo2.jpg
  • The problem is..

32
(No Transcript)
33
URL Parsing is expensive!!
  • Performing content-aware routing implies that
    some kind of string searching and matching
    algorithm is required.
  • Such a time-consuming function is expensive in a
    heavy traffic web site.
  • Our experience showed that the system performance
    would be severely degraded if we implement some
    URL parsing functions in the distributor.
  • You will loss 7/8ths of your Web switchs
    performance if you turn on its URL parsing
    function.
    F5 Lab

34
The Idea of the URL Formalization
  • Generally, the reason for using the
    variable-length string to name a file or
    directory is just because it is mnemonic, thereby
    making it easier for humans to remember..
  • In most cases, an HTTP request is issued when
    the browser follows a link either explicitly,
    when the user clicks on an anchor, or implicitly,
    via an embedded image or object.
  • Most URLs are invisible to the users,they dont
    care about what name it has.
  • The name is only meaningful to the content
    provider. Therefore,we can convert the original
    name to a formalized form.

35
click
36
URL Formalization
  • Convert user-friendly names to routing-friendly
    name.
  • Basic idea convert the original name of each
    file or directory to a fixed-length and
    formalized name.
  • The procedure of URL formalization
  • Convert the original name of every directory and
    file into a fixed length and formatted name.
  • Parse all html files and modify the embedded
    hyperlinks to conform to the new name.
  • The new path name of each embedded link will be
  • /preamble/formalized host name/formalized
    path name/..

37
After URL Formalization
38
(No Transcript)
39
Content Placement
40
Content Management
41
click
42
(No Transcript)
43
Advantages of URL Formalization
  • The fixed-length formalized names are easier for
    the distributor to process.
  • We even can implement the routing function in
    hardware for performance boosting.
  • Placing the host name in the first level of the
    path name can further speed up the routing
    decision.
  • Combined with the well-designed URL table, the
    dispatcher can quickly retrieve related
    information to make routing decision.
  • Be particularly useful in Web hosting service
    environment

44
Outline
  • Introduction
  • Proposed System
  • Request Routing Mechanism
  • Management System
  • Content-aware Intelligence
  • Work in Progress
  • Conclusion

45
Why need a Management System?
  • Load management? Configuration? Content
    management? Failure? Monitoring...

Web servers
Web Content
46
Required Functions
  • System configuration
  • ease to configure
  • status visualization
  • Content placement and management
  • be able to deploy content on each node according
    to its capability
  • service differentiation
  • Dynamically change the content placement
    according to the load
  • Support the content-aware routing
  • Monitoring
  • real-time statistics
  • log analysis
  • site usage statistics

47
Required Functions (cont)
  • Performance management
  • monitoring
  • analysis and statistics
  • event (poor performance or overloaded)
  • automatic tuning
  • Failure management
  • diagnosis
  • server failure identification
  • network analysis and protocol analysis
  • content verification (object/link analysis)
  • monitoring and alarm

48
Our Management System (Overview)
49
Our Management System (Implementation)
50
Our Management System
  • Controller(Java Application)
  • Communicate with the distributor
  • control center
  • Broker(Java Application)
  • running on Web server node
  • monitoring
  • execute downloading agent
  • Agent (Java class)
  • Each administrative function is implemented in
    the form of a Java class termed agent
  • Remote console (Java Applet)
  • an easy-to-use GUI for web site manager to
    maintain and manage the system.

51
Web Server Configuration
52
Content Management
53
Performance Monitor Options
54
Performance Monitor
55
Performance Monitor (cont)
56
Performance Monitor (cont)
57
Features of Our Management System
  • Platform independent
  • Implementing the daemon in Java can relieve the
    concerns related to heterogeneity of the target
    platforms
  • Support comprehensive management functions
  • Enables the complete management of a web site via
    a standard browser (from any location)
  • Support tracking and visualization of the
    systems configuration and state
  • Produce a single, coherent view of the
    partitioned content
  • Extensibility
  • Support URL Formalization

58
Outline
  • Introduction
  • Proposed System
  • Request Routing Mechanism
  • Management System
  • Content-aware Intelligence
  • Work in Progress
  • Conclusion

59
Current Status
  • We have implemented the following content-aware
    intelligence in our system
  • Affinity-Based request routing
  • Content placement and management
  • Dispersed Content Placement
  • Content Segregation
  • Fault Resilience

60
Affinity-Based Request Routing
  • An important factor to consider serving a
    request from the disk is far slower than serving
    the request from the memory cache.
  • With the content-aware mechanism, it is possible
    to direct requests for a given item of content to
    the server that already have data cached in main
    memory.
  • Achieving load balancing and locality

61
Benefits of Affinity-Based Routing -- Test
Environment
  • Heterogeneous servers cluster
  • 4 Pentium-2 machines
  • 350MHZ CPU
  • 128M RAM
  • 8G SCSI hard disk
  • 100 Mbps Fast Ethernet
  • Windows NT IIS 4.0
  • 3 Pentium-pro machine
  • 200MHZ CPU
  • 64M RAM
  • 4G SCSI hard disk
  • 100 Mbps Fast Ethernet
  • LINUX Apache
  • 2 Pentium-pro machine
  • 150 MHZ CPU
  • 64M RAM
  • 4G IE hard disk
  • 100 Mbps Fast Ethernet
  • LINUX Apache
  • Workload generated by WebBench
  • 8 Pentium-2 machines serve as WebBench Client
  • 350MHZ CPU
  • 128M RAM
  • 100 Mbps Fast Ethernet
  • Windows NT
  • Each machine runs four WebBench client programs
    that emit a stream of Web requests, and measure
    the system response
  • The stream of requests is called the workload

62
Benefits of Affinity-Based Routing -- Workload
description
  • Workload
  • Total size of documents set gtgt memory size in
    each server node

63
Benefits of Affinity-Based Routing --Results
(1/3)
  • Layer-4 based dispatcher Weighted Round Roubin

64
Benefits of Affinity-Based Routing --Results
(2/3)
  • Layer-4 based dispatcher Weighted Least
    Connection

65
Benefits of Affinity-Based Routing --Results
(3/3)
  • Affinity-Based Routing

66
Content Placement and Management
  • An important factors in efficient utilization of
    a distributed server and achieving better
    performance is to be able to deploy content on
    each node according to its capability, and then
    direct clients to the best suited server.
  • Challenge how to place and manage content in
    such a distributed server system, in particular,
    such servers tend to be more heterogeneous

67
Existing Content Placement Schemes
  • Place all content on a shared network file system
  • Advantage
  • ease to maintain
  • Disadvantage
  • suffer from the single-point-of-failure problem
  • increase user perceived latency
  • inability to support dynamic content
  • Replicate all content on each server node
  • Advantage
  • avoid the significant overhead associated with
    the previous scheme
  • high availability due to data redundancy
  • Disadvantage
  • expensive in terms of disk utilization
  • pose great administrative burden on content
    management

68
Issues Ignored by Existing Schemes
  • Variety of Web content
  • Heterogeneity of server configuration
  • Variety of access pattern (e.g., flash crowd)
  • Need for differentiate content according
    different priority or importance
  • Neither of the two schemes is a satisfactory
    solution for a heterogeneous distributed
    Web-server

69
Our Solution
  • Basic idea content-aware routing a content
    placement and management system, which enable
    the administrator to be free on deciding which
    node does what
  • content partition
  • partial replication for performance or
    availability
  • incorporate with two traditional scheme
  • Advantage
  • better resource utilization and scalability
  • ability to specialize some node to host certain
    content type
  • content segregation for preventing interference
    between different type of requests
  • ability to exert explicit control over resource
    allocation policies

70
Features of Content Management System
  • Support tracking and visualization of the
    systems configuration and state
  • Produce a single, coherent view of the
    partitioned content
  • Implementing the daemon in Java can relieve the
    concerns related to heterogeneity of the target
    platforms
  • Ability to be tailored or extended for the
    different requirements of different system
  • Automatic content rearrangement facility to
    further ensure an even load distribution
  • Skew of access pattern may cause load imbalance

71
Benefits of Content Management System --
Workload description
  • Workload 2 (static content dynamic content)

72
Benefits of the Content Partition--Configuration
  • We used WebBench with workload 1 to perform the
    experiment on the following three configurations
  • the entire set of files was replicated on each of
    the servers
  • the entire set of files shared using NFS
  • the document sets was dispersed with the content
    aware routing
  • We roughly partitioned the document tree by
    content type in the configuration 3.
  • We also place large video file in the nodes with
    large volume and fast disk.

73
Benefits of the Content Partition--Results
  • Due to content partition, each server only poses
    part of the content, so that each server sees a
    smaller set of distinct requests and the working
    set size is reduced ?Improve cache hit rate

74
Benefits of Content Segregation-- Configuration
  • We used WebBench with workload 2 to perform the
    experiment on the following two configurations
  • the entire set of files was replicated on each of
    the servers
  • the document sets was dispersed with the content
    aware routing
  • In our content-smart cluster (configuration 3)
  • separate dynamic content and static content on
    different servers.
  • place dynamic content (CGI scripts and ASP) on
    the servers with powerful CPU, plain html content
    on the nodes with slow processor and disk.
  • separate large file (e.g., video file) on the
    server nodes with fast disk.

75
Benefits of Content Segregation--Result
  • Full-replication placement scheme does not take
    the heterogeneity on the capability of each node
    into consideration
  • ? result in poor performance

76
Benefits of Content Segregation--Result
  • The result shows the throughput when the server
    was saturated by 120 concurrent WebBench clients.
  • This experiment serves as a proof of the
    performance benefits of content-aware routing
    incorporated with content segregation.

77
Fault Resilience
  • The existing server-clustering solutions are not
    highly reliable, but merely highly available.
  • They offer no guarantee about fault resilience
    for the service.
  • Although the server failure can be easily
    detected and transparently replaced with the
    available redundant component, however, any
    ongoing requests on the failed server will be
    lost.
  • In addition to detecting and masking the
    failures, an ideal fault-tolerant Internet server
    should enable the outstanding requests on the
    failed node to be smoothly migrated and then
    recovered on another working node.

78
Analysis
  • To support fault resilience, we think the routing
    mechanism should be extended to support two
    important capabilities checkpointing and
    fault-recovery.
  • Challenges
  • the cost is very expensive if we log every
    incoming request for checkpointing
  • The request routing mechanism should be
    content-aware, so that it can differentiate
    varieties of requests and provide a corresponding
    fault-resilience guarantee.
  • how to recover a Web request from a failed server
    node to continue execution in another working
    node
  • Request and its TCP connection should be smoothly
    and transparently migrated to another node

79
FT-capable Distributor
  • Goal enable the outstanding requests on the
    failed node to be smoothly migrated to and then
    recovered on another working node.
  • We think the request routing mechanism, needed in
    the sever cluster, is the suitable position to
    realize the fault-resilience capability.
  • We combine the capabilities of content-aware
    routing, checkpointing, and fault recovery to
    propose a new mechanism named Fault-Tolerance
    capable distributor.

80
Fault Recovery
  • We divide web requests into two types, stateless
    and stateful request, and then provide
    corresponding solution to each category.
  • Stateless requests
  • static content
  • dynamic content
  • Stateful requests
  • transaction-based services
  • the heart of a large number of important web
    services (e.g., E-commerce)

81
Fault RecoveryStatic Requests
  • A majority of Web requests are to static objects,
    such as HTML files, images, and videos.
  • If one server node fails in the middle of a
    static request, we use the following mechanism to
    recover this request on another node.
  • select a new server
  • select an idle pre-forked connection connected
    with the target server
  • infer how many bytes has been successfully
    received by the client (from information in the
    mapping table)
  • issues a range request on the new server-side
    connection to the selected server node.

82
Fault RecoveryDynamic Requests
  • Dynamic content response pages are created on
    demand (e.g., CGI scripts, ASP), mostly based on
    client-provided arguments.
  • Distributor will log user arguments conveyed in
    the dynamic requests.
  • Recovery mechanism
  • select a new server
  • select an idle pre-forked connection connected
    with the target server
  • replay with the logged arguments

83
Fault RecoveryDynamic Requests(cont)
  • We found the previous approach is problematic in
    some situations.
  • The major problem is that some dynamic requests
    are not idempotent.
  • the result of two successive requests with the
    same arguments is different.
  • It is needed to force the client to give up the
    data that it has received and then re-receive the
    new response page.
  • it will not be user-transparent and compatible
    with the existing browser.
  • We tackle this problem by making the distributor
    node to be a reverse proxy and store-and-then-for
    ward the response page.

84
Stateful Requests
  • In some cases, the user does not browse a number
    of independent statically or dynamically
    generated pages, but is guided through a session
    controlled by a server-side program (e.g., a CGI
    script) associated with some shared states.
  • These session-based services are generally based
    on so-called three-tier architecture.
  • Recovering a session in the three-tier
    architecture is a more challenging problem.

85
Fault RecoveryStateful Requests
  • First of all, the web site manager should define
    a session for which fault resilience is required.
  • Via the GUI of a management system
  • the configuration information will be stored in
    the URL table
  • When the distributor finds a request belonging to
    a session, it will tag this client and then
    direct all consequent requests from the client to
    one of the twin servers, until it finds a
    request conveying the end action.

86
Protocol of Twin Server
87
Workload Description
  • We created a workload that models the workload
    characterization (e.g., file size, request
    distribution, file access frequency, etc.) of
    representative Web servers
  • About 6000 unique files of which the total size
    is about 116MB.

88
Fail-over Time
  • We implemented a fault-injection program
    executing on each server nodes, which will
    shutdown and restart the system or HTTP daemon to
    simulate failures and repairs.
  • Static requests

89
Fail-over Time (Cont)
  • We think that the measured fail-over time may be
    overestimated.
  • Instrumentation
  • Result of instrumentation

90
Overhead
  • Compared with a server system clustered by a
    Server Load Balancer (Layer-4 routing)
  • Distributor node
  • Pentium-II 350
  • 64M RAM
  • 100 Mbps fast ethernet
  • Overhead associated with the Fault-Tolerance
    Mechanism (User perceived latency)
  • Static content

91
Overhead (cont)
  • Dynamic content
  • In terms of session-based requests, our protocol
    introduces an overhead of about 8 over the
    baseline system that does not offer any
    guarantee.
  • The experiment was performed over a local area
    network, where high-speed connections are the
    norm, resulting in short observed response time
    and then large relative overhead.
  • The overhead would be insignificant when compared
    with the latency over wide-area networks

92
Overhead (Throughput)
  • Peak throughput
  • Layer-4 cluster 2489 requests/sec
  • Our system 2378 requests/sec
  • It shows that our fault tolerance mechanism does
    not cause significant performance degradation.
  • At the period of peak throughput, the CPU
    utilization of the distributor is 67, and the
    consumed memory of our system is slightly larger
    (only 2.3 Mbytes) than that of the layer-4
    dispatcher.
  • This means that our mechanism is not a
    performance bottleneck.
  • In fact, we found the performance bottleneck in
    our experiment is the network interface of the
    distributor node.

93
Long-running Test
94
Service Reliability
  • Our system guarantees service reliability at
    three levels
  • The management system provide a status detection
    mechanism that can detect and mask the server
    failures.
  • A request-failover mechanism enables an ongoing
    Web request to be smoothly migrated and recovered
    on another server node in the presence of server
    failure or overload.
  • A mechanism to prevent the single-point-of-failure
    .

95
Work in progress
  • Load Balancing
  • Sophisticated Load Balancing in distributor
  • Dynamically content rearrangement facility to
    further ensure an even load distribution or QoS
    requirement
  • Security
  • Quality of Service support
  • Service Level Agreement
  • enable the content owners to specify their
    specific requirements such as bandwidth usage,
    content type, number or placement of content
    replicas, or required degrees of service
    reliability.
  • We are implementing the related mechanisms to
    configure the management policy to meet the
    complex requirements of different customers.
  • Hardware Support

96
Contributions
  • Content-aware request routing mechanism
  • Java-based management system
  • Idea of URL table
  • Performance speedup by URL formalization
  • Enabling fault resilience for Web services
  • Enhance reliability for Internet services
  • Content-aware Load balancing algorithm
  • QoS support
  • Transaction-based services support
  • System robustness
  • Service Level Agreement and System policy

97
Conclusion
  • Web service providers must gradually move to more
    sophisticated services as the content of a Web
    site or e-business operations become more
    complex.
  • The Internet service supported by our system will
    be
  • Scalable
  • Cluster-based architecture
  • Efficient content-aware routing
  • Reliable
  • Failure detection
  • Request failover
  • System robustness
  • Highly manageable
  • Java-based management system
Write a Comment
User Comments (0)
About PowerShow.com
