Kernighan and Lin partition algorithm Fideccia and Mattheyses partition algorithm

1
Kernighan and Lin partition algorithmFideccia
and Mattheyses partition algorithm

• Presented by Bhanu Rekapalli.

2
Papers

• An Efficient Heuristic procedure for Partitioning
  Graphs.
• By B.W.KERNIGHAN and S.LIN
• ( Bell Systems Technical Journal, 49(2)
  291-307, 1970.)
• A Linear-Time Heuristic for Improving Network
  Partitions.
• By C.M.FIDUCCIA and R.M. MATTHEYSES
• (Proceedings of the Design Automation
  Conference, pp
• 175-181, 1982.)

3
TERMS TO UNDERSTAND

• Network-circuit modules
• Terminals-connectors or pins
• Graph
• Vertices-nodes or points
• Edges-net or signal
• Cutset

4
(No Transcript)
5
Algorithms

• Minimize the costs.
• Effective in finding the optimal partitions.
• Fast enough to be practical in solving large
  problems.

6
Definition of the problem

• Connection between the FPGAs or modules
  (external) have high cost compared to connections
  within them(internal).
• The object is to minimize the number of external
  connections.

7
Mathematically

• G is a graph of n nodes of weights wi gt0,i1.n
• Let p be a positive number,such that 0lt wi ltp
  for all i.
• Partition the nodes of G into k subsets
• Weighted Connectivity matrix C(cij),i,j1,.n
  describing the edges of G.
• A k-way partition of G is a set of nonempty
  pairwise disjoint subsets of G,v1,..,vk such
  that Uk i1 viG.
• A partition is admissible if mod vi ltp for all
  i.
• The partitioning problem, is to find the
  minimal-cost admissible partition of G.

8
Exact Solutions

• Graph G has n nodes of size 1 to be partitioned
  into k subsets of size p.
• kpn.
• ways to to chose the first subset
• ways to chose the second subset
• The number of cases is 1/k!
• This expressions yields a very large number
• Examplen40, p10 (k4), it is gt1020

9
False Starts

• Random Solutions
• Simply generate random solutions, keeping the
  best seen to date, and terminating after some
  predetermined time or value is reached.
• Fast,although it is an n2-procedure
• This approach is unsatisfactory for moderate
  size,since few optimal solutions, which appear
  randomly with very low probabilities.
• Egmatrix of 32X32 there are 3 to 5 optimal
  solutions out of partitions giving
  probability lt10-7

10
Max Flow-Min Cut

• Theorem The maximum flow between any pair of
  nodes the minimum cut capacity of all cuts which
  separate the two nodes
• Cut is a 2-way partition and the cut capacity is
  the cost of the partition.
• The most severe difficulty of the algorithm is
  that the algorithm has no provision for
  constraining the sizes of the resultant subsets.
• notefor 2-way unconstrained partition,the
  minimal cost it produces is a lower bound for
  solutions produced by any method.

11
Clustering

• Identifying the natural cluster in the given
  cost matrix.
• Again satisfying constraints on the sizes of the
  subsets is a problem
• Systematic assignment of the stragglers is not
  provided.

12
Two-Way Uniform Partitions

• Consider the set S of 2n points,with an
  associated cost matrix C(cij), i,j1,.,2n.
• Assume C is symmetric and that cii 0 for all i.
• We want to partition S into two subsets A and B,
  each with n points, such that the external cost
  is minimized.
• Start with any arbitrary partition A,B of S and
  try to
• decrease the initial cost T by a series of
  interchanges of subsets of A and B
• When no further improvement is possible, the
  resulting partition A,B is a local minimum
  and has a fairly high probability of being a
  global minimum with this scheme
• This process is repeated with another arbitrary
  partition,to obtain many locally minimum
  partitions we desire.

13
KL-algorithm

• Let A ,B be any arbitrary 2-way partition
• Subsets with XY
• such that interchanging X and Y produces A and
  B as shown below
• ?

X
Y
Y
X
B
A
B
A
AX-XY BB-YX
14
KL-algorithm
15
Phase 1 optimization Algorithm

• Compute the D values for all elements of S
• Choose ai and bi such that gain
  giDaiDbi-2caibi is maximum.
• Set ai and bi aside, and call them ai and bi.
• Recalculate the D values for the elements of

16

• Choose a pair a2 and b2 from A-(a1) and
  B-(b1) such that the gain is maximum.
• Continue until all the nodes have been
  exhausted,identifying (a3,b3)..(an,bn) and
  the corresponding gains g3,..gn.
• If Xa1,.,ak, Yb1,bk, then the decrease in
  cost when the sets X and Y are interchanged is
  precisely g1g2 gk
• Choose k to maximize the partial sum
• If Ggt0,a reduction in cost of value G can be made
  by interchanging X and Y, and the resulting
  partition is treated as initial partition and the
  procedure is repeated.
• G0?locally optimum partition is reached called
  phase 1 optimal partition.

17
(No Transcript)
18
Effectiveness of the Procedure

• The procedure sequentially finds an approximation
  to the best exchange of lambda pairs.
• This technique sacrifices a certain amount of
  power for a considerable gain in speed.
• The procedure finds the maximum partial sum, the
  process does not terminate immediately when gain
  is negative.
• The probability that it finds an optimal solution
  in a single trial p(n)2-n/30,eg30X30 matrix p
  is 0.5, 0.2 to 0.3 for 60X60 and .05 to .1 for
  120X120.

19
Running time of the Procedure

• The upper bound is n2logn.
• The lower bound with fast scan method is
  proportional to
• This function grows as

20
Plot of Running times
21
Drawbacks

• It minimizes the number of edges cut not the
  number of nets cut.
• It does not allow logic cells to be of different
  sizes.
• It is expensive in computation time.
• It does not allow partition to be unequal.
• It does not allow for selected logic cells to be
  fixed in place.
• The results are random.
• It does not directly allow more than two
  partitions.

22
Fiduccia and Mattheyses algorithm

• To deal with cells of various sizes , the
  algorithm progresses by moving one cell at a time
  between the blocks of the partition while
  maintaining a desired balance based on the size
  of the blocks rather than the number of cells per
  block.
• Two cells which share atleast one net are said to
  be neighbors.
• Each cell is assumed to have a size s(i).Number
  of pins p(i).
• Given a fraction 0ltrlt1 partition the network in
  to two blocks A and B such that A/(AB)r,
  and such that the size of the resulting cutset is
  minimized.

23
The Basic Idea

• The main idea of the algorithm is to move a cell
  at a time from one block of the partition to the
  other in an attempt to minimize the cut set of
  the final partition.
• Base cellthe cell to be moved.
• Gain g(i)no. of nets by which the cutset would
  decrease if cell i were moved from partition A to
  partition B (may be negative).integer range
  p(i)ltg(i)ltp(i).
• Keep in mind the balance criterion to prevent all
  cells from migrating to one block of the
  partition.
• To prevent thrashing, once a cell is moved it is
  locked for an entire pass
• Only O(N) passes are possible since the cutset is
  bound by the number of nets

24
steps

• Choose a base cell having the largest gain in its
  block.
• Move it.
• Adjust the gains of its free neighbors.
• The total work required to perform one pass is
  O(P).

25
Cell Gain

• Each cell has its gain in the range pmax to
  pmax, pmaxmax(p(i)cell(i) is initially free).
• The total amount of work required to maintain
  each Bucket array is O(P)/Pass.

26
Establishing Balance

• Move the Cell
• Find the first cell of highest gain that is not
  locked and such that moving it would not cause an
  imbalance
• Break tie by choosing the one that gives the best
  balance
• Choose this as the base cell. Remove it from the
  bucket list and place it on the LOCKED list.
  Update it to the other partition.

27
Computing and Maintaining Cell Gains

• Critical net
• Given a partition (A,B), define the distribution
  of net n, relative to this partition, as an
  ordered pair of integers (A(n),B(n)) which
  represents the number of cells the net n has in
  blocks A and B respectively. These can be
  computed in O(P) time for all nets.
• Net is critical if there exists a cell on it such
  that if it were moved it would change the nets
  cut state (whether it is cut or not).
• Gain of cell depends only on its critical nets
• If a net is not critical, its cut state cannot be
  affected by the move
• A net which is not critical either before or
  after a move cannot influence the gains of its
  cells
• This observation, and previous locked base
  cell,leads to the basis of linear-time claim.

28
Net is critical if either A(n) or B(n) is equal
to 0 or 1
29

• Let F be the from partition of cell i and T the
  to partition i.e. its complimentary block, FA
  and TB or vice versa.
• The gain of the cell(i) is g(i)FS(i)-TS(i)
• FS(i) no. of nets which have cell i as their
  only F cell
• TE(i) no. of nets which contain i and have an
  empty T side
• Requires O(P) work to initialize
• net is critical before the move if F(n)1 or
  T(n)0 or T(n)1
• F(n) 0 does not occur because base cell on F
  side before
• net is critical after the move if T(n)1 or
  F(n)0 or F(n)1
• T(n) 0 does not occur because base cell on T
  side before

30
Propositions

• 1)The total amount of work required to maintain
  each bucket array is O(P) per pass.
• 2)Initialization of all cell gains requires O(P)
  work.
• 3)No more than four update operations per net are
  performed during one pass of the algorithm.
• 4)The total work required to initialize and
  maintain cell gains is O(P) per pass.
• Theoremthe minimization algorithm requires O(P)
  time to complete one pass.

31
The interactive, visual bi-partitioning
environment

• Developed and tested in Java
• Netlists are loaded in two formats-.net and
  .mon(my own netlist)
• The .mon format retains partition and clustering
  information not available in .net files
• The control panel provides several methods by
  which to view the netlist and the current state
  of the partitioning
• controls for aborting, suspending, and resume
  algorithm execution

32
Control panel
33
Cutsize and the Partition size over time
34
The number of nets connected to each node. The
number of nodes connected to each net.
35
References

• Lecture notes from eecs244 course of Prof.Kurt
  Keutzer from berkley.
• Interactive Visual Environment for Bipartitioning
  Algorithm Development . CS294-7 Project Report,by
  James S. Young
• ASIC by smith.
