ESS 202 - Earthquakes

1
ESS 202 - Earthquakes

• Profs. John Ken
• TA Josh

Bolt, 5-17
2
Overall outline

• Plate tectonics
• Earthquakes
• Structure of the the Earth
• Measuring intensity
• Seismometers, magnitude
• Where are west coast faults?
• Some famous quakes
• More Tsunamis
• Rest of quarter - Hazards of quakes

Light at the end of the tunnel
3
Plan for this lecture

• Faults on the west coast

4
You are here
Pacific and North American plates are main players
Press, 20-12
5
Where are faults, exactly?

• Well swing down the coast
• Alaska
• British Columbia, Oregon, Washington
• California
• Wasatch Fault Zone
• Utah, Idaho, Montana, Wyoming

(Yanev,Appendix A)
6
North America map
Show Movie 01
USGS Prof. Paper, 1-2
7
Subduction under Alaska Aleutian Is.

• 8 cm/yr of plate convergence
• almost strike-slip in Aleutian Is.
• Site of large underthrusting earthquakes
• 1964 Alaska Earthquake MW9.2
• Volcanic arc eruptions

8
Alaska - Pacific boundary
Not subduction! Embarrassing. (UT Austin)
Strike-slip
9
Queen Charlotte Fault System
10
Alaska

• Most dangerous faults in US
• 8 quakes over M8 in last 100 years
• Sparsely populated
• Main fault is subduction thrust
• Only surfaces on ocean floor
• Many secondary faults
• Also has volcanoes, tsunamis

11
1899-1979 Alaska quakes
6.7 8 quakes in 2002
Stars - M gt 7.5 Triangles - 6.5 to 7.5
Yanev, p. 175
12
Tectonic Settingof N. America

• Old stable interior
• East coast passive margin
• West coast active margin
• Pacific - N. Am. plate interactions
• Transform motion at SAF
• Subduction under Alaska Aleutian Is.
• Juan de Fuca - N. Am. interactions
• Subduction under Northern California, Oregon,
  Washington, and British Columbia

13
USGeology
14
US Topography
Topographic action mark tectonic activity
15
Continental collision iscause of Appalachian Mts
Press, 20-6c
16
Now
Rifting
Europe
US
Passive margin
17
USA seismicity

• Notice that all the action is in the West
• most dramatic topography in the West
• Yosemite, Cascade Mts., Big Sur coast, etc.
• few earthquakes in the East
• Some faults as far east as Yellowstone
• No action to west in Pacific plate either
• Hawaii is special case - hot spot volcano

18
US Seismicity
19
Geology of western US - Fabric related
to deformation
20
Western boundary of North American Plate

• Type of boundary depends on orientation
• Plate boundaries move and change in time
• Past 30 My saw major changes development of San
  Andreas Fault
• From 80 to 30 My Farallon plate subducted under
  west coast.
• Juan de Fuca Cocos plates are remnants of
  Farallon plate

21
Cartoon ofWesternN. Americatectonics
Vidale
22
Details US and Mexico coast

• Three little plates subducting offshore Oregon,
  Washington, and B. Columbia
• Juan de Fuca Plate
• Gorda Plate
• Explorer Plate
• Spreading ridge splitting Gulf of California
• Separating Baja from N. America
• Oblique because ridges are combined with
  transform faults
• Cocos Plate subducting to the south

23
Exoticterrainplacement
Accretion of fragments to continent
24
Exotic terrains
Western N. Am (Cordillera) assembled from small
pieces over past 200 My
25
Changes in west coast

• A mid-ocean ridge subducted
• Before that, just subduction on coast
• First hit near LA 25 Mya
• San Andreas fault system started then
• As ridge is subducting, two triple junctions are
  moving apart on coast
• Mendocino Triple Junction moving north
• NA-Pacific-Juan de Fuca junction
• NA-Pacific-Rivera junction off Baja California

26
(No Transcript)
27
Note present San Andreas fault
Show movie 02
28
Oregon-Washington

• M 9 every 1000 years, last in 1700
• Recent quakes
• M 7.0 in 2000, 6.5 in 1965 in Seattle
• M 7.1 in 1949 in Olympia
• Main fault is subduction zone
• Also volcanoes (like Mt. St. Helens)
• Not adequately prepared
• Weve looked at these faults before
• But biggest surface offshore

29

• Cascadia subduction zone
• 4 cm/yr convergence rate

30
Pacific - Juan de Fuca spreadingSubduction of
J. de F. under N. Am.
Iacopi, 27
Note Plate motions Triple Junctions
31
Cartoon view
Show movie 09
32
Also smaller faults in Seattle
33
Oregon-Wash.Close-up
Note Volcanoes San Andreas Triple Junctions
Mt. Hood From Portland
Yeats, 5-2
34
Mt Rainier and Seattle
35
Subduction under Pacific Northwest

• 4 cm/yr of plate convergence
• like small convection cell - up at ridge down at
  subduction zone
• Site of great underthrusting earthquakes
• None in historic record
• But evidence for magnitude 9 quake in 1700
• Tsunami sands in buried marsh
• Tsunami in Japan in 1700
• Volcanic arc eruptions
• Mt. St. Helens, Mt. Rainier, Mt. Shasta

36
Oregon-Washington X-sect
Cascadia cross-section
Cascade Mts
Olympic Mts
Ridge
Keller, 7-5
37
Tsunami sand associated with the 1700 earthquake
covering a Native fire pit on the banks of the
Salmon River in Oregon. Fire-cracked rocks,
charcoal and ashes delineate the fire pit that
was dug into the sandy beach.
38
Last 30 Mya of west coast tectonics
Cape Mend.
39
Quakes in California

• The highest concentration is near the big faults
  San Andreas, Cape Mendocino
• Other areas also have many little quakes
• Mammoth Mts. - 1000s of quakes per year
• Coso Hot Springs - geothermal activity
• Probably no area in California is safe from
  occasional little quakes

40
California

• Last 150 years, 2-3 quakes of M8
• Main fault is strike-slip, on land
• San Andreas fault zone
• Easy to map in detail
• Many secondary faults
• Some offshore, most farther East

41
QuakesandSan Andreasfault
Mammoth
Coso
42
San Andreas Fault

• Right-lateral slip - LA moving northwest
• 3.5 cm/yr
• Segments
• 1906 San Francisco quake
• Creeping section (gradual aseismic slip)
• Parkfield segment
• 1857 Fort Tejon quake
• Southern segment
• Big Bend
• causes N-S compression in So. Cal.

Big ones M 7.9
43
Faultsegments
44
Activefaults andsegments
Big bend
45
Officialfaults
Special Studies Zone Act of 1972 (Alquist-Priolo
Act)
San Andreas, Garlock, SoCal and Bay Area branches
Yanev, p. 42
46
Alquist-Priolo Map Detail
47
Fault zones and Faults

• The ideal fault

San Gabriel Fault Photo Matt DAllessio
48
Complication 1

• Faults can splay (split near surface)

49
Complication 2 Gouge zones
50
Northern California

• San Andreas
• Runs through Point Arena, Point Reyes, San
  Francisco, San Jose, Watsonville
• East Bay Faults
• Calaveras-Hayward-Rodgers Creek
• Some farther east
• Offshore faults?

51

• Bay Area faults
• San Andreas
• Hayward
• Calaveras

52
GPS viewof Bay Area
53
Location of Loma Prieta break
54
Bay Area faults
Notice relation of faults and topography
55
MarinCountySanAndreas
Iacopi, 42
Point Reyes
56
More Point Reyes
57
SanFran
58
OaklandProblemswith theHaywardFault
Yanev, 32
59
SF to Salinas
San Andreas
Hollister
Yanev, 180
From AAA map
60
(No Transcript)
61
(No Transcript)
62
Hollister - city on a creeping fault
63
Hollisterproblemswith faultcreep
1
3
64
Sierra Nevada Mts.

• From 80 to 30 My Farallon plate was subducting
  under west coast.
• Produced great range of volcanoes, like
  present-day Andes Mt.
• Sierras are the cooled, solidified, uplifted
  magma chambers of the volcanic arc (Yosemite
  granite)

65
Present Sierra mountainscooled, solidified,
uplifted magma chambers, whichformed during
Farallon subduction
66
Subduction of Farallon plate

• Subduction slows then ceases
• Erosion occurs
• Regional uplift and tilt
• exposes solidified magma chambers

67
(No Transcript)
68
Great Valley
San Andreas Fault
Grapevine
Garlock Fault
Mojave Desert
69
San Andreas Fault in the Carrizo Plain
Right-lateral slip LA moving northwest 3.5 cm/yr
70
Mojave Fault - the Garlock
Iacopi, 31
71
San Andreas Fault
Mojave Desert
Garlock Fault
Grapevine
Great Valley
72
Southern California Faults

• Complex system driven by Pacific-North America
  interaction and Big Bend
• Some faults dont reach surface
• NW-SE trending faults mostly right-lateral
  strike-slip
• E-W trending faults mostly thrust
• usually thrust faults, blind thrusts

73
BigBendbuildsmountains
Show Movie 03
74
Southern California

• San Andreas
• Runs 30 km north of LA, thru San Bernadino, Palm
  Springs, Salton Sea, into Mexico
• LA to San Diego - system of faults
• SAF, San Jacinto, Elsinore faults
• Faults under LA are hard to find
• Mostly not strike-slip
• Surface reworked by civilization

75
Southern Cal. Faults
76
Show movie 14
77
LA regional faults
Yanev, 195
78
Diblee Maps

• Tom Diblee single-handedly mapped large sections
  of California geology mainly on foot
• Tom often mapped in remote areas, camping out
  with enough food and water for a week, sleeping
  each night sheltered from the wind on the car
  seat with one door open and a board extending
  outward on which to rest his legs. This enabled
  him to cover a lot of ground at little expense.

79
Example of Geological Map
80
Southern LA faults
Yanev, 197
81
Newport-Inglewoodschools and hospitals
Yanev, 33
82
San Andreas near LA
Yanev, 187
83
San Andreas meets I5at Tejon Pass
Iacopi, 48
84
Northern LA faults
Yanev, 193
85
Faults in San Berdoo
Yanev, 191
86
Faultssouthof LA
Yanev, 187
87
San Andreas Indio Hills
Iacopi, 53
88
Imperial Valley 1940
Near Mexican border
Iacopi, 59
89
Earthquakes in SoCal
SCEC webpage
90
Earthquake depth on San Jacinto
USGS, 5.10
SB
LA
SD
91
Seismicity cross-section
Locked?
Salton Sea
surface
Continuously deforming
USGS, 5-10
92
Depth of California quakes

• Definite lower limit to seismicity that varies
  from 5-25 km
• Set by temperature and composition of rock
• Mostly temperature
• Shallowest under the Salton Sea
• Where it is the hottest
• Spots surrounded by seismicity with fewer quakes
  may be either creeping or locked
• Not so many earthquakes in top few km
• Rock is not so strong there?

93
Gulf of California

• Spreading center

94
Rest of US

• Wasatch fault zone
• Utah, Idaho, Montana, Wyoming
• About 10-25 as active as San Andreas
• Mainly normal faults
• New Madrid
• Had some big quakes
• We dont know how often they strike
• Every 5000 years? Every 500?
• Charleston, plus a few others
• Well talk about because of old quakes
• Next one of my lectures

95
Wasatch fault zone
Yanev, 203
96
Basin and Range Topography
http//geography.sierra.cc.ca.us/booth/California/
1_lithosphere/west_relief_map.jpg
97
US Seismicity
98
Where are the faults?

• Alaska
• Subduction and Queen Charlotte fault zone
• British Columbia, Oregon, Washington
• Subduction, Juan de Fuca,
• California
• Mendocino, San Andreas, Big bend
• Utah, Idaho, Montana, Wyoming
• Wasatch Fault Zone
