Title: Quality for Safety Critical Software Case Study from OPG


1
Quality for Safety Critical Software Case Study
from OPG
  • CFICSE
  • October 2002
  • Diane Kelly

2
References
  • 1. Ontario Hydros Experience with New Methods
    for Engineering Safety Critical Software
    M.Viola, Proceedings Safecomp 1995, Italy
  • 2. CE-1001-STD Rev. 1, January 1995, OHN
    P.Joannou et al.
  • 3. Safety Critical Software - Then and Now
    N.Ichiyen et al. October 2, 1995, COG CANDU
    Computer Conference
  • 4. David Parnas, Inspection of Safety-Critical
    Software using Program Function tables, Chapter
    19, Software Fundamentals, Collected Papers,
    Addison-Wesley, 2001

3
Background (1)
  • 1987 Darlington reactor safety shutdown system
    (SDS) (systems 1 and 2) designed entirely in
    software (first time)
  • regulator (AECB) concerns
  • not properly engineered
  • software functional but not of high quality
  • uncertain risk
  • lack of confidence in product, process, and
    people
  • software already written
  • two independent systems (physically and
    logically)
  • designed differently to reduce common mode errors
  • 7000 lines of FORTRAN
  • 13000 lines of PASCAL

4
Background (2)
  • regulator requirements
  • software be verified before put into use
  • formal verification of specification to code
  • random testing program
  • hazard analysis program
  • underlying problems
  • no agreed upon, measurable definition of
    acceptability for the engineering of safety
    critical software
  • no widely accepted common practices for
    specification, design, verification, and testing
    of safety critical software
  • not possible to quantify the achieved reliability
    of software component of a safety system

5
Background (3)
  • David Parnas hired by regulator to advise on
    process
  • documentation based on Parnas Tables
  • rendered code into tabular format
  • rendered requirements into tabular format
  • proofs to show code and requirements the same
  • took about 1 year to complete
  • about 60 people involved on FORTRAN side
  • AECB allowed software to go into production
  • Darlington Nuclear Generating Station brought
    on-line January 1990
  • OHN agreed to redesign and rewrite software
  • had to establish standards and rigorous process
  • standard issued at the end of 1990

6
Comments from the trenches ...
  • Hydro agreed reluctantly to the verification
    exercise - why …
  • If you borrow a lot of money someone usually
    wants it back
  • Energy Probes estimate of the cost of building
    Darlington NGS
  • 14B or 3972/kWe
  • From an estimate posted on the McMaster website
    (engphys.mcmaster.ca)
  • 2000/kWe
  • At 8 this works out to about 1.8M per day in
    interest using the lower figure
  • If the reactor is running, in one day you could
    earn 6,343,200 _at_ 75/Mwhr
  • Cost of the formal verification was on the order
    of 60 X 60 X 52 X 100 (personhours/week
    weeks/year /hour/person) 18M - as long as it
    didnt hold up the license to operate
  • Hydro hired Nancy Leveson and the AECB hired
    David Parnas

7
Comments from the trenches … (contd)
  • From a paper by Parnas 4
  • Inspectors ...need quiet time to think
  • ..inspections must be interrupted by breaks,
    evenings, and weekends
  • ..results of inspections must be scrutinized
    carefully in open discussions
  • Typical hours were 7am to 8pm plus some
    over-nights - no holidays or weekends off for a
    year

8
Comments from the trenches … (contd)
  • Typical sample of code from SDS1
  • Sample is 433 lines
  • 328 lines are comments
  • 68 lines are declaration (one variable per line)
  • 34 lines are executable (6K/line)?
  • This would be considered reasonably complex
  • The corresponding program function tables would
    be about 21 pages.
  • The complete set of function tables was
    twenty-four 2 binders

9
Comments from the trenches … (contd)
  • Misconceptions and issues (quotes from 4)
  • Misconception the SDS software initiates the
    shutdown
  • shutdown of the reactor is poised to trigger
    based on a timer
  • on each successful execution cycle, the software
    prevents the shutdown from automatically
    triggering
  • failsafe system design
  • An increase in reliability results in an increase
    in safety
  • safety and reliability are not the same
  • ..safety requires correctness..
  • the software can be incorrect and still safe
  • safety and correctness are disjoint
  • There was a coding error that did affect
    safety...
  • not aware of any coding error that affected
    safety
  • ..hazard analysis should not have been performed
    on the code
  • hazard analysis focuses on the safety critical
    aspect of the code

10
Comments from the trenches … (contd)
  • Final comments
  • The formal verification process grinds incredibly
    fine
  • Upwards of 30M was spent with no increase in
    safety and possibly a decrease
  • There was extensive focus on meeting requirements
    but not on meeting safety objectives
  • The degree of rigor applied to the symbolic code
    was disproportionate to the risk
  • the formal process ignores issues such as kernel,
    compiler, timing

11
OASES
  • Ontario Hydro/ AECL Software Engineering and
    Standards
  • prepared high-level standard for safety critical
    software
  • methodology independent
  • define requirements for the software engineering
    process
  • define the outputs from the process
  • define the requirements that must be met by each
    output
  • developed a process for categorization of
    software according to impact on safety
  • developed procedures for development of safety
    critical software
  • developed tools to support software engineering
    process

12
Safety Critical Software Process
13
Features of this Process
  • formal specification
  • behaviour of software described using
    mathematical functions in a notation with well
    defined syntax and semantics
  • review and verification
  • outputs from each process must comply with inputs
    to that process
  • outputs written using mathematical functions must
    be systematically verified against inputs using
    mathematical verification techniques
  • manual reviews against standards, checklists

14
Features of this Process (contd)
  • reliability testing
  • uses statistically valid random testing
  • software hazard analysis
  • analyses performed to identify and evaluate
    potential unsafe failures in the computer system
    and in the software component of the system
  • eliminate or assist in reduction of risks to an
    acceptable level

15
Experience with the Process (1)
  • trial use of process
  • microprocessor based digital trip meter for
    Pickering B NGS
  • temperature detectors send current back to trip
    meter
  • trip action initiated if signal exceeds setpoint
  • 1500 lines of C code
  • 25 of entire development cost was in two formal
    verifications
  • 27 of entire development cost was in four levels
    of testing
  • 5 of entire development cost was writing the code

16
Experience with the Process (2)
  • SDS rewrite
  • new software installed in the field
  • field installation started February 1999 ended
    December 1999
  • 5-year project
  • kept existing hardware
  • redeveloped software according to step-wise
    refinement and information hiding
  • about 40 to 50 people overall on project
  • largest group was formal verification group at 20
    people
  • have some tool support
  • prototype verification system (PVS) (theorem
    prover) from Stanford Research
  • other in-house tools for formatting and
    consistency checking
  • input to one tool had to be produced by hand
  • 600 pages with word processor

17
Strengths
  • formal tabular notation
  • provides for more complete specifications
  • errors eliminated earlier in lifecycle
  • facilitates formal verification
  • precise specifications leads to code with few
    errors
  • hazard analysis provides confidence in safety
    objectives of software
  • SRS and SDD used to generate test cases
  • achieved known test coverage
  • validation tests using DID
  • done by individual outside development process
  • identified problems both during test case
    creation and during testing

18
Weaknesses
  • lack of tool support
  • in particular, code review manually intensive
  • checklist with 154 questions
  • for creating and verifying test cases
  • hazard analysis done too late in design cycle
  • changes may have to be done back at SDD or SRS
  • unit testing did not find any functionality
    errors not already identified through other
    verification processes

19
Standard CE-1001-STD Rev. 1 January 1995
  • Still in use
  • Specifies requirements for the engineering
    characteristics of safety critical software for
    nuclear generating stations
  • Not for all types of applications
  • Purpose is to provide confidence that the safety
    critical software product is developed with an
    acceptable level of quality

20
Structure of Standard (1)
  • covers
  • requirements definition and verification
  • software design and verification,
  • code implementation,
  • verification and testing,
  • planning,
  • configuration management and training.

21
Structure of Standard (2)
  • Minimum set of software engineering tasks
  • Minimum set of outputs for each task
  • Quality of outputs for each task must meet
    defined quality objectives, quality attributes
    and fundamental principles.
  • To be acceptable, a software product must meet
    all these requirements.

22
Three categories of tasks
  • development
  • verification
  • support

23
Software Engineering Development Tasks, Outputs
and Sample Requirements.
  • Next slide

24

25
Software Engineering Verification Tasks, Outputs
and Sample Requirements.
  • Next 3 slides

26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
Software Engineering Support Tasks, Outputs and
Sample Requirements.
  • Next 2 slides

30

31
(No Transcript)
32
Quality Objectives
  • Functionality
  • Maintainability
  • Reliability
  • Reviewability and
  • Safety.
  • These quality objectives are supported by a set
    of quality attributes.

33
Quality Attributes
  • Completeness
  • Consistency
  • Correctness
  • Modifiability
  • Modularity
  • Predictability
  • Robustness
  • Structuredness
  • Traceability
  • Understandability and
  • Verifiability.

34
Fundamental Principles
  • Set of high level guidelines on which the
    software engineering principles in this standard
    are based.
  • Measures of the presence or the degree of
    adherence to a quality attribute are derived from
    the fundamental principles
  • When measures are satisfied, the quality
    objectives are met and the product is fit for
    use.

35
(No Transcript)
36
Need measures Many measures are subjective out
of necessity.
About PowerShow.com
