CD and Fluorescence

1
CD and Fluorescence

• Overview of the theory, technique and its
  applications

2
Overall

• Three take home messages
• What is the theory behind the technique?
• What is the basic technique?
• What are the applications?
• Real life examples
• What are the question(s)?
• How they used the techniques?
• What were the answers?

3
Plane-polarized waves

• If the vector of the electric field (measured at
  a fixed point of space) oscillates along a
  straight line then the waves are called
• plane-polarized or linearly polarized waves
• The following animation presents a wave that is
  plane-polarized in a vertical plane.

(Attention! The two animations are not
synchronized!)
4
Plane-polarized waves

• Same thing horizontal plane
• If the vector of the electric field (measured at
  a fixed point of space) oscillates along a
  straight line then the waves are called
• plane-polarized or linearly polarized waves
• The following animation presents a wave that is
  plane-polarized in a vertical plane.

(Attention! The two animations are not
synchronized!)
5
Circular polarized waves

• Superposition of two waves that have the same
  amplitude and wavelength and are polarized in two
  perpendicular planes but there is a phase
  difference of 90 between them
• A phase difference of 90 means that when one
  wave is at its peak then the other one is just
  crossing the zero line.

(Attention! The two animations are not
synchronized!)
6
Circular polarized waves

• At any fixed point in space that is in the line
  of the propagation of this wave, the electric
  field vector rotates in a circle while its length
  remains constant.
• Such waves are called circularly polarized
  waves.

(Attention! The two animations are not
synchronized!)
7
Circular polarized waves

• Same thing different direction
• At any fixed point in space that is in the line
  of the propagation of this wave, the electric
  field vector rotates in a circle while its length
  remains constant.
• Such waves are called circularly polarized
  waves.

(Attention! The two animations are not
synchronized!)
8
Circular Dichorism

• Clockwise

• Counter-clockwise

(Attention! The four animations are not
synchronized!)
9
Superposition of circularly polarized waves

• Any linearly polarized light wave can be obtained
  as a superposition of a left circularly polarized
  and a right circularly polarized light wave,
  whose amplitude is identical.

red and green colors indicate the two superposing
components and light blue indicates the resulting
wave
10
The interaction of light and matter

• If light enters matter, its properties may
  change.
• Namely, its intensity (amplitude), polarization,
  velocity, wavelength, etc. may alter.
• The two basic phenomena of the interaction of
  light and matter are absorption (or extinction)
  and a decrease in velocity.

11
Plane-polarized waves in a medium showing
circular dichroism
12
Plane-polarized waves in a medium showing
circular dichroism

• Any linearly polarized light can be obtained as
  the superposition of a left circularly polarized
  and a right circularly polarized light wave.

• Some materials possess a special property they
  absorb left circularly polarized light to a
  different extent than right circularly polarized
  light.
• This phenomenon is called circular dichroism.

13
Circular Dichroism

• Theory of the technique
• Optically active matter (proteins/DNA/RNA/
• carbohydrates/etc) absorbs left and right hand
  circular polarized light differently

14
Circular Dichroism

• Far UV-CD of random coil
• Positive at 212 nm (pgtp)
• Negative at 195 nm (ngtp)
• Far UV-CD of ß-sheet
• Negative at 218 nm (pgtp)
• Positive at 196 nm (ngtp)
• Far UV-CD of a-helix
• Coupling of the pgtp transitions leads to
  positive (pgtp) perpendicular at 192 nm and
  negative (pgtp) parallel at 209 nm
• Negative at 222 nm is red shifted (ngtp)

15
Circular Dichroism

• Basics of the technique
• Small sample volumes
• 200mL
• 5-30 minute data collection
• Short data collection time
• 5-30 minute analysis time
• Short analysis time
• Recovery of sample

• Near UV spectrum
• Probe changes in tertiary structures
• No standards available
• Every protein is slightly different
• Probe overall global changes

16
Circular Dichroism

• Applications
• CD has an important role in the structural
  determinants of proteins or DNA or RNA, etc
• The real power of CD is in the analysis of
  structural changes in a protein or DNA or RNA
  upon some perturbation, or in comparison of the
  structure of an engineered protein or DNA or RNA
  to the parent protein or DNA or RNA.
• CD is rapid and can be used to analyze a number
  of candidate proteins from which interesting
  candidates can be selected for more detailed
  structural analysis like NMR or X-ray
  crystallography.

17
Conformational Changes

• Here is our system
• Calbindin D28k
• Involved in apoptosis regulationwhich is highly
  expressed in brain tissue
• Question they are asking
• Can a Ca2 binding protein bind Zn2?

18
CD Results

• Far UV Near UV
• 2o structure 3o structure

19
Conclusion

• What they found out
• Zn2-bound state is structurally distinct from
  the Ca2-bound state

20
Just one

• That is just one example
• There are many things you can do with CD
• kinetic measurements, melting curves

21
Fluorescence

• Theory of the technique
• Excitation at a specific wavelength
• Excitation of a fluorophore at three different
  wavelengths
• (EX 1, EX 2, EX 3) does not change the emission
  profile
• but does produce variations in fluorescence
  emission intensity (EM 1, EM 2, EM 3) that
  correspond to the amplitude of the excitation
  spectrum.

22
Fluorescence

• Basics of the technique
• Very simple
• Light source excites sample
• Emission is detected and record
• What is difficult?
• Choice of probes

23
Fluorescence

• Basics of the technique
• Small sample volumes
• 200mL 1mL
• 5-30 minute data collection
• Short data collection time
• 5-30 minute analysis time
• Short analysis time
• Recovery of sample
• Menable to many different types of expt setup
• Kinetic expts, titration expts, etc

24
Intrinsic Fluorescence

• Tryptophan, the dominant intrinsic fluorophore,
  is generally present at about 1mol in proteins.
• Trp is very sensitive to its local environment.
• It is possible to see changes in emission spectra
  in response to
• Conformational changes, subunit association,
  substrate binding, denaturation, and anything
  that affects the local environment surrounding
  the indole ring.
• Also, Trp appears to be uniquely sensitive to
  quenching, either by externally added quenchers,
  or by nearby groups in the protein.
• Trp fluorescence can be selectively excited at
  295-305 nm. (to avoid excitation of Tyr)

25
Fluorescence

• Applications
• Fluorescence has an important role in the
  structural determinants of proteins, DNA or RNA,
  etc
• Binding studies
• Structural perturbation upon binding
• Unfolding studies
• Determine intermediate states of folding
• Orientation of molecules
• Binding occurs on the N-terminal or C-terminal
• Analysis of hydrophobic surfaces
• Upon binding ligand, hydrophobic surfaces exposed
  to bind another molecule

26
Conformational Changes

• Here is our system
• Historically two types of Ca binding proteins
• Buffers
• Bind extra-cellular Ca
• Calbindin D9K
• Sensors
• Bind Ca then bind targets
• Calmodulin

27
Extrinsic Probes
28
Extrinsic Probes

• ANS fluorescence
• 385 nm excitation
• 400 600 nm scan
• Calbindin D9K standard
• Ca2 buffer no conformational change
• Calmodulin standard
• Ca2 sensor conformational change
• Calbindin
• This is our known

29
Extrinsic Probes

• Effect of pH on the ANS binding to Ca2 -free and
  Ca2 - loaded calbindin D28k.
• Fluorescence spectra of 60 µM ANS in the presence
  of 12 µ M human recombinant calbindin D28k.
• Probe structural changes due to pH changes

30
Just one

• Fluorescence Resonance Energy Transfer
• A donor chromophore in its excited state can
  transfer energy by a nonradiative, long-range
  dipole-dipole coupling mechanism to an acceptor
  chromophore in close proximity (typically lt10nm).
