CHEMOMETRICS IN VIRTUAL CELL
Analytical/Radio/Nuclear (ARN) Seminar

• NILESH RAUT

DEPARTMENT OF CHEMISTRY UNIVERSITY OF KENTUCKY
2
OVERVIEW

• Chemometrics basics.
• Virtual cell basics.
• Components of virtual cell model.
• Use of virtual cell model in Ca2 transport.
• Use of chemometrics in virtual cell modeling of
  Ran transport.
• Results.
• Conclusions.

3
The Need

• To understand the overall design principle of
  complex biological systems.
• To understand transport phenomenon within cell.
• To aid in genomics and proteomics studies.
• To develop full understanding of mechanisms
  underlying a cell biological event.
• To overcome communication problem between
  chemists and chemometricians

4
Chemometrics

• Extracting chemically relevant information from
  data produced in chemical experiments.
• Makes use of mathematical model.
• Structure the chemical problem to a form that can
  be expressed as a mathematical relationship.
• A chemical model (M) relates experimental
  variables (X) to each other, and it also has a
  statistical model (E) associated with it.

5
Chemometrics

• The statistical model also describes variability,
  noise of the data obtained from chemical model.
• X M E.
• i.e. Data Chemical Model Noise.
• More imphasis is to be given on the chemical
  model representing a situation.

6
Virtual Cell What is it? And How is it done?

• Computational framework for modeling cell
  biological processes.
• Models are constructed from biochemical and
  electrophysical data.
• Couples chemical kinetics, membrane fluxes and
  diffusions.
• Resultant equations are solved numerically.

7
System architecture for virtual cell
8
System architecture for virtual cell

• Modeling framework gives biological abstractions
  necessary to model and simulate cellular
  physiology
• Mathematics framework Provides a general purpose
  solver for mathematical problems in the
  application domain of computational cellular
  physiology.

9
Components of Physiological Model 1. Cellular
Structure

• Represents mutually exclusive regions in cell.
• Compartments 3D volumetric regions.
• Membranes 2D surfaces separating compartments
  and filaments.
• Filaments 1D contours lying within single
  compartment.
• Can also contain molecular species and reactions
  describing those species.

10
Components of Physiological Model 2. Molecular
Species

• Within cellular structures.
• Behavior of molecular species
• Diffusion within compartments, membranes, etc.
• Directed motion along filaments.
• Flux between compartments through membranes.
• Advections between cellular structures.

11
Components of Physiological Model 3. Reactions
and Fluxes

• Complete description of stoichiometry and
  kinetics of biochemical reactions.
• Associated with a single cellular structure.
• Stoichiometry in terms of reactants, products
  and catalysts related to species in a cellular
  structure.
• Kinetics specified as mass action kinetics.

12
Specifications of Cellular Geometry

• Describes the behavior of cellular system.
• Defines morphology of the cell, and its spatially
  resolvable organelles.
• Taken directly from experimental images (from
  pixel density).

13
Design of Virtual Cell
Interplay between model development and
experiment during modeling process
14
Design of Virtual Cell

• Inputs to the model can be derived from the
  users own experiments as well as the literature.
• Physiology includes the topological arrangements
  of compartments and membranes, the molecules
  associated with each of these, and the reactions
  between the molecules.
• Geometry can be derived from either analytical
  expressions or from an experimental image
  acquired from a microscope.
• Numbers represent the relative surface densities
  of the BKR.

15
Use of Virtual Cell in Ca2 transport
The pathway for bradykinin-induced calcium
release in differentiated neuroblastoma cells.
16
Use of Virtual Cell in Ca2 transport

• Bradykinin (BK) binds to its receptor (BKR) in
  the plasma membrane.
• Sets off a G-protein cascade, activates
  phospholipase C (PLC), hydrolyzes the
  glycerolphosphate bond in phosphatidylinositol
  bisphosphate (PIP2), releases IP3 from the
  membrane.
• IP3R is a calcium channel that is triggered to
  open when IP3 is bound and when calcium itself
  binds to an activation site.
• Calcium released binds to calcium buffers (B) in
  the cytosol including the fluorescent calcium
  indicator.
• Finally, calcium is pumped back into the ER via a
  calcium ATPase (SERCA).

17
Output of Virtual Cell

• Left column shows the experimental
• calcium changes following addition of
• BK at time 0 s in a differentiated
• N1E-115 neuroblastoma cell.
• Center column displays the output
• of the Virtual Cell simulation.
• Right column displays the output of
• the simulation for IP3.
• Hence permits simulation permits
• estimation of the spatiotemporal
• distribution of molecules that are not
• accessible experimentally.

18
Chemometric Studies of Ran Transport Setup

• Ran is guanine nucleotide triphosphatase.
• Two cellular compartments cytosol and nucleus.
• Behavior under consideration Flux of Ran.
• Flux rate is calculated as a product of
  permeability constant and concentration
  difference across nuclear envelope.
• For visualization aid, recombinant protein was
  modified with a fluorescent maleimide.

19
Kinetic Studies of Ran Transport
Fine solid lines denote reversible interactions,
dashed lines indicate enzyme-mediated reactions,
and bold, double-headed arrows indicate flux.
20
Kinetic Studies of Ran Transport

• NTF Nuclear transport factor. RCC Ran exchange
  factor.
• In the cytosolic compartment, RanGDP associates
  with NTF2 to form the NTF2RanGDP complex.
• Nuclear NTF2RanGDP decomposes to NTF2 and
  RanGDP.
• Interaction of RCC1 with NTF2 or RanGDP produced
  25 RanGDP and 75 RanGTP, to account for the
  estimated GTP/GDP ratio in the cell.
• RanGTP associates with transport cargo Carriers
  to form a CarrierRanGTP complex.
• Cytosolic Carrier RanGTP associates with RanBP1
  to form a CarrierRanGTPBP1 complex. RanGAP
  interacts with CarrierRanGTPBP1 complex to form
  BP1, RanGDP, and Carrier.

21
Kinetic Studies of Ran Transport

• Results of injection of FL-Ran

Nuclear accumulation of FL-Ran in BHK-21 cells
after cytosolic injection.
22
Virtual Cell Modeling of Ran Transport

• 3D geometry from experimental images is used.
• Microinjection is modeled as a brief localized
  increase of the cytosolic FL-Ran concentration.
• Result 3D simulation resembles experimental
  FL-Ran nuclear import and diffusion through
  cytosol.

23
Comparison of Virtual Cell Modeling and
Experimental Result
Comparison of Ran transport in a time series for
an FL-Ran nuclear import at initial cytosolic
conc. 1µM (in gray) with a sample plane from a 3D
spatial model of Ran transport (In color)
24
Analysis of Compartmental model for Ran Transport
Transients for simulated endogenous nuclear
species concentrations, followed over time during
recovery from addition of 1µM FL-Ran to cytosol
compartment.
25
In Vivo Analysis of Ran Import and Shuttling
A Time courses for nuclear accumulation of wild
type FL-Ran for the indicated initial cytosolic
concentrations. B Fluorescence loss in
photobleaching (FLIP) on FL-Ran at steady-state
in micro-injected BHK-21 cells. Boxed area was
repetitively photobleached.
26
Conclusions

• Virtual cell has broad applicability in
  biological systems.
• Chemometric methods are an important tool in
  predicting the results.
• It serves as a confirmative test for a particular
  biological reactions.
• Failures in obtaining results using chemometric
  methods, insures that the thought process is not
  yet perfect.

27
References

• Alicia E. Smith, Boris M. Slepchenko, James C.
  Schaff, Leslie M. Loew, Ian G. Macara Science
  295, 488-491 (2002).
• Svante Wold Chemometrics and Intelligent
  Laboratory Systems 30, 109-115 (1995).
• Stanislaw Gorski, Tom Misteli Journal of Cell
  Science 118(18), 4083-4092 (2005).
• Boris M. Slepchenko, James C. Schaff, Ian Macara,
  Leslie M. Loew TRENDS in Cell Biology 13(11),
  570-576 (2003).
• Leslie M. Loew and James C. Schaff TRENDS in Cell
  Biology 19(10), 401-406 (2001).
• Zoltan Szallasi TRENDS In Pharmacological
  Sciences 23(4), 158-159 (2002).
