Data Mining in the Pharmaceutical Industry

1
Data Mining in the Pharmaceutical Industry

• By Jerry Swartz

2
Introduction

• Since I am a remote student, if there are
  questions, feel free to e-mail jswartz_at_ligand.com

3
Pharmaceutical Development

• Four Stages of Drug Development
• Research finds new drugs
• Development tests and predicts drug behavior
• Clinical trials test the drug in humans
• Commercialization takes drug and sells it to
  likely consumers (doctors and patients)
• Ill show an example for the Research,
  Development, and Clinical Trials stages

4
Research Stage

• Huge user of data mining tools and techniques
• Scientists run experiments to determine activity
  of potential drugs
• Uses high speed screening to test tens, hundreds,
  or thousands of drugs very quickly this
  generates microarray data

5
Research Stage

• Bioinformatics is a general term for the
  information processing activities on data
  generated in Research Stage, especially
  microarray data
• General goal is to find activity on relevant
  genes or to find drug compounds that have
  desirable characteristics (whatever those may be)

6
Research Stage

• Data mining techniques used
• Clustering
• Classification
• Neural networks

7
Research Stage Example 1

• Goal Determine compounds with similar activity
• Why Compounds with similar activity may behave
  similarly
• When
• Have known compound and are looking for something
  better
• Dont have known compound but have desired
  activity and want to find compound that exhibits
  this activity

8
Research Stage Example 1

• Sample data

Structure\Activity Alpha Beta Delta Gamma
CO2 0.07 0.88 0.62 0.09
H2O 0.80 0.54 0.32 0.79
H2O2 0.34 0.91 0.44 0.40
9
Research Stage Example 1

• Cluster compounds that have similar activity
• We like behavior of H2O and want to see what
  compounds have similar activity
• Example derived from Application of
  Nearest-Neighbor and Cluster Analyses in
  Pharmaceutical Lead Discovery
• Clustering takes place based on similar activity
  using Euclidean distance.

10
Research Stage Example 1

• For simplicity, distance in example is simply
  difference between Beta and Delta values, not
  Euclidean
• Distances

CO2 H2O H2O2
CO2 0.00 0.65 0.16
H2O 0.65 0.00 0.49
H2O2 0.16 0.49 0.00
11
Research Stage Example 1

• Dendrogram

0.49
0.16
0.00
H2O2
CO2
H2O
12
Research Stage Example 1

• Conclusion
• H2O2 and CO2 are most alike but,
• H2O2 behaves more like H2O than CO2 behaves like
  H2O

13
Research Stage Example 1

• Variations
• Example clustering performed on activity
• Clustering could have been performed on structure
  (i.e. find chemically similar compounds)
• Clustering could have been performed on both
  structure and activity (called SAR Structure
  Activity Relationship, see next slide)

14
Research Stage Example 1
15
Development Stage

• Company thinks drug might have some benefit
• Undergoes testing in animals, human tissue to
  observe effect maybe limited human tests
• Determine how much drug to consume for desired
  effect
• How dangerous is drug?

16
Development Stage

• Data mining techniques used
• Classification
• Neural networks

17
Development Stage Example 2

• Goal Predict if treatment will aid patients
• Why If drug will not aid patients, what purpose
  does drug serve?
• When
• Have data supporting use of drug
• Have training data that shows effects of drug
  (positive or negative)
• Want to be able to predict which patients will
  benefit

18
Development Stage Example 2

• Will treatment help sickle cell anemia patients?
• We have information like gender, body weight,
  disease state, etc.
• Feed these into neural network and predict
  whether patient will benefit from drug.
• Example derived from Prediction of Sickle Cell
  Anemia Patients Response to Hydroxyurea
  Treatment Using ARTMAP Network

19
Development Stage Example 2

• Uses ARTMAP network which is similar to neural
  network
• Instead of activation function, uses choice
  function which compares two values
• Basically matches input to template and
  generates output
• If input is similar enough to template it
  generates the corresponding output

20
Development Stage Example 2

• Imagine training data has one of two
  classifications (Yes and No)
• Network is trained for the Yes classifications
  and a snapshot is taken of the neural network.
• Network then trained for the No classifications
  and another snapshot is taken.
• Output is Yes or No, depending on whether the
  inputs are more similar to the Yes or the No
  training data.

21
Development Stage Example 2

• ARTMAP

Imagine array of weights, one for each template
Template closest to input chosen.
Weight
Height
Patient Benefits?
Gender
Blood Pressure
Path of least resistance chosen for output.
22
Clinical Trials Stage

• Company tests drugs in actual patients on larger
  scale
• Must keep track of data about patient progress
• Government wants to protect health of citizens,
  many rules govern clinical trials
• In USA, Food and Drug Administration oversees
  trials.

23
Clinical Trials Stage

• Data mining techniques used
• Neural networks

24
Clinical Trials Stage

• Data is collected by pharmaceutical company but
  undergoes statistical analysis to determine
  success of trial
• Data reported to FDA inspected closely. Too many
  negative reactions might indicate drug is too
  dangerous these are adverse events
• Adverse event might be medicine causing
  drowsiness
• Data mining performed by FDA, not as much by
  pharmaceutical companies

25
Clinical Trials Stage Example 3

• Goal Detect when too many adverse events occur
  or detect link between drug and adverse event
• Why Too many adverse events linked to a drug
  might indicate drug is too dangerous or health of
  patient is at risk
• When
• As adverse events are reported to FDA
• Or when link is suspected

26
Clinical Trials Stage Example 3

• Is a drug causing too many adverse events?
• We have number of reports of adverse events
  pertaining to drugs.
• Feed these into neural network and let network
  lead us to what is too many.
• Example derived from Data mining in the US
  Vaccine Adverse Event Reporting System (VAERS)
  early detection of intussusception and other
  events after rotavirus vaccination

27
Clinical Trials Stage Example 3

• Sample data cells contain number of reports
  linking drug and adverse event

Adverse Event\Drug Tylenol Motrin Rotovirus
Coughing 1 2 1
Fever 4 5 2
Intussusception 1 3 5
28
Clinical Trials Stage Example 3

• Uses Bayesian neural network
• Prior probability is probability that any report
  contains reference to adverse event
• Posterior probability is probability that report
  has link between drug and adverse event
• Determines strength of link between adverse
  event and drug (called Information Component or
  IC)
• More complicated than appears patient may
  consume multiple drugs which one caused adverse
  event?

29
Clinical Trials Stage Example 3

• Bayesian Neural Network

Adverse Event
Strength of link between adverse event and drug
Drug
30
Clinical Trials Stage Example 3

• Could be solved using Bayes Theorem and
  correlation techniques
• Number of possible drug/adverse event
  combinations is very, very, large
• Training data is from FDA, WHO databases
• Neural network hides statistical complexity
• Unfortunately details of NN like activation
  function and hidden nodes are unknown

31
Data Mining Benefits

• Research Stage instead of trial and error, data
  mining can help find drugs that have desirable
  activity
• Development Stage data mining can help predict
  who will benefit from drug
• Clinical Trials Stage data mining protects
  patients and helps regulate drug testing
• Commercialization Stage data mining can
  optimize use of sales resources like manpower,
  advertising
