Mining For Lost Treasure

1
Mining For Lost Treasure

• National Geospatial Data Clearinghouse
• Archibald Warnock
• U.S. Federal Geographic Data Committee
• A/WWW Enterprises

2
What is Clearinghouse?

• A distributed service to locate geospatial data
  based on characteristics expressed in metadata
• Clearinghouse allows a user to pose a query of
  all or a portion of the community in a single
  session
• Like a spatial AltaVista

3
National Geospatial Data Clearinghouse

• Distributed data producers and users.
• Key components
• Data documentation (metadata)
• Networking (Internet)
• Serving, searching, and accessing software
• Z39.50 Search and Retrieve Protocol
• WWW - World Wide Web

4
Components of Clearinghouse

• There are three functional areas that interact to
  create the Clearinghouse
• Metadata preparation and indexing
• Metadata service
• User Access via Gateway forms

5
Clearinghouse Method
Metadata preparation
6
Clearinghouse Design

• The Clearinghouse in its distributed form
  includes a registry of servers, several
  WWW-to-Z39.50 gateways, and many Z39.50 servers
• A primary goal of Clearinghouse is to provide the
  ability to find spatial data throughout the
  entire community, not one site at a time

7
Essential Configuration
Clearinghouse Sites
Gateways
Node
Node
FGDC
Web Client
Node
Node
8
User downloads query form
Clearinghouse Sites
Gateways
Node
Node
FGDC
Web Client
Node
Node
9
User sends query to web server
Clearinghouse Sites
Gateways
Node
Node
FGDC
Web Client
Node
Node
10
Gateway passes query to Clearinghouse Servers
Clearinghouse Sites
Gateways
Node
Node
FGDC
Web Client
Node
Node
11
Gateway receives and collates hits
Clearinghouse Sites
Gateways
Node
Node
FGDC
Web Client
Node
Node
12
Client receives results summary as HTML
Clearinghouse Sites
Gateways
Node
Node
FGDC
Web Client
Node
Node
13
Client can request a specific metadata record for
viewing
Clearinghouse Sites
Gateways
Node
Node
FGDC
Web Client
Node
Node
14
Node in More Detail
Metadata
Index/DB
15
Data

• The most expensive investment for an organization
• Created by many different organizations
• To solve many different problems
• Using many different methods and technologies

16
But . . .

• Data are hard to find
• Data are difficult to access
• Data are hard to integrate
• Data are not current
• Data are undocumented
• Data are incomplete

17
The uses of metadata

• Provides documentation of existing internal
  geospatial data resources within an organization
  (inventory)
• Permits structured search and comparison of held
  spatial data by others (advertising)
• Provides end-users with adequate information to
  take the data and use it in an appropriate
  context (liability)

18
Metadata Solutions

• Numerous software solutions available
• Commercial and free-ware
• Standalone, DB-linked, GIS-linked
• Permit collection and structuring of
  FGDC-compatible metadata
• Present metadata as HTML, XML, or text

19
GILS, Dublin Core and Others

• Dublin Core is a minimal (15 fields) generic
  metadata scheme for virtually any kind of
  document
• GILS represents a more detailed approach,
  including most of DC, providing greater
  interoperability
• GILS is less bibliographically oriented than
  (Z39.50) BIB-1
• GILS is lightweight compared to GEO (FGDC) and
  EOS/CIP (which have specific functional
  requirements)

20
What Structured Metadata Means -1

• GILS - Fewer fields
• More documents
• More metadata records
• Skinnier metadata records
• Easier abstraction

• FGDC - More fields
• Fewer documents
• Fewer metadata records
• Fatter metadata records
• Less abstraction

GILS is a good, general compromise
21
What Structured Metadata Means - 2

• A Z39.50 profile as defines a language
• At some level, Z39.50 is a detail
• Protocols are about communication, profiles are
  about abstraction and GILS is about content
• Z39.50 guarantees that the users query can be
  unambiguously decoded - no guarantees about
  content
• We could implement the profile over any protocol
  - http, CORBA, etc.
• Do we have to use Z39.50?
• No, but the abstraction is required
• Z39.50 already includes the abstraction model

22
How much metadata is enough?

• Internal documentation for local use (local
  inventory)
• Basic documentation for discovery of information
  holdings (catalog/search)
• Detailed documentation to provide end-users with
  adequate information for re-use (asset management)

23
Server Solutions

• Z39.50 Protocol is used
• GEO Geospatial Metadata Profile is published
  for Z39.50 implementors to understand FGDC
  metadata structures
• Supports search across numeric, text, date, and
  spatial extent and full-text
• Freeware and commercial solutions

24
Gateway in more detail
Nodes
Gateway
25
User Interfaces

• HTML-based forms hosted at Gateways are the
  primary access method
• Java map-based interface from MEL allows more
  sophisticated search
• Inclusion of search capabilities in GIS client
  software is possible

26
Whos in Clearinghouse?

• 109 Nodes (servers) online as of 3/1/99
• 28 Federal, national scope
• 35 State/University state-wide scope
• 28 International scope or location
• 18 Local or Regional scope

27
US Federal Participation

• National Park Service
• Army Corps of Engineers
• Tri-Services Center
• National Wetlands Inventory
• Census (sampler)
• Minerals Management Service

• NOAA (10)
• USGS (6)
• FEMA (sampler)
• NRCS climate and soils
• CIESIN/EPA
• CIESIN/NASA
• DOT NTAD

28
State Participation

• West Virginia
• Washington
• Wisconsin
• Wyoming (2)
• Florida
• Alabama
• New Mexico
• Arizona

Georgia Illinois Minnesota Alaska California Delaw
are Nebraska (2) New Jersey

• New York (2)
• North Carolina
• Oklahoma
• Kansas
• Texas
• Montana (3)
• Vermont
• Pennsylvania

29
Regional/Local Participation

• Olympic Peninsula, WA
• Greater Yellowstone
• Helena NF
• Ecological Reserves, KS
• MIT/Mass Boston DOQs
• Great Lakes EIS
• Eastern Sierra

• McKinley Co, NM
• City of Santa Fe, NM
• North Texas GIS
• Research Planning
• Sabine R Authority, TX
• San Francisco Bay
• S Florida Ecosystem
• SW Natural Resources

30
International Participation

• NOAA/Japan GOIN
• South Africa (2)
• ESA AVHRR sampler
• GELOS, Italy
• PAIGH, Mexico
• S57 Hydrography, Canada
• NRL MEL
• Africa DDS
• Inter-American Geospatial Data Network
• Hong Kong
• CIESIN/USDA Global Environmental Change
• Australia (10)
• Costa Rica
• Caribbean CEPNET, Jamaica

31
Planned or Funded Nodes

• Mt Desert Island, ME
• SW Washington COG
• NASA GCMD
• CODEPLAN, Brazil
• Iowa
• Missouri
• Kentucky
• South Dakota
• Oregon
• Louisiana
• Ohio
• Connecticut MAGIC
• Colorado
• NW Ecosystems

32
Clearinghouse provides...

• Discovery of spatial data
• Distributed search worldwide
• Uniform interface for spatial data searches
• Advertising for your data holdings

33
For more information
Visit the FGDC website http//www.fgdc.gov Conta
ct the Clearinghouse Coordinator, Doug Nebert
(ddnebert_at_usgs.gov) or Archie Warnock
(warnock_at_awcubed.com)
