SOEN 6011Software Engineering Processes

• Section SS Fall 2007
• Dr Greg Butler
• http//www.cs.concordia.ca/gregb/home/soen6011-f2
  007.html

2
Week 9

• Design patterns

3
Gang Of Four

• Gamma, Helm, Johnson, Vlissides
• Some patterns in Larman, Chap. 23,
• All patterns in XDE
• As documentation.
• As dynamic templates.

4
Overview of Patterns
5
Design Repeat Successes

• Has a (successful) similar product been built?
• Yes, then reuse domain specific
• Architectural
• Style (e.g. client/server, database, process
  control)
• Patterns.
• Design Patterns ( idioms).
• Use Domain model as source of inspiration.

6
Design New Application Area?

• Has a (successful) similar product been built?
• No, then choose among general
• Architectural
• Style (e.g. client/server, database, process
  control)
• Patterns.
• Design Patterns ( idioms).
• Use Domain model as source of inspiration.

7
GoF Pattern Classification

• Behavioral Patterns
• Creational Patterns
• Structural Patterns

8
GoF Pattern Summary Relationships
9
GoF Behavioral Patterns

• Chain of Responsibility
• Command
• Interpreter
• Iterator
• Mediator
• Memento

• Observer
• State
• Strategy
• Template Method
• Visitor

10
GoF Creational Patterns

• Abstract Factory
• Builder
• Factory Method
• Prototype
• Singleton

11
GoF Structural Patterns

• Adapter
• Bridge
• Composite
• Decorator
• Facade
• Flyweight
• Proxy

12
Command Pattern(for Front Controller)

• Problem How to allow the same command to be
  invoked by
• Menu selection
• Alt-ctrl shortcut
• Commandline text entry, etc
• How to allow (unlimited) undo/redo
• How to keep a log/audit/history of commands
  invoked
• How to allow macro commands to be defined

13
Command Pattern (for Front Controller)

• You have commands that need to be
• executed,
• undone, or
• queued
• Command design pattern separates
• Receiver from Invoker from Commands
• All commands derive from Command and implement
  do(), undo(), and redo()
• Also allows recording history, replay

14
Adapter

• Context / problemHow to resolve incompatible
  interfaces, or provide a stable interface to
  similar components with different interfaces?
• SolutionConvert the original interface of a
  component into another interface, through an
  intermediate adapter object.

15
Adapter

• Suppose we have a tax calculation class (or
  external library) but the interface is not well
  suited for our application.

16
Adapter

• Adapter providesan interface suitedto the
  application

17
Adapter (For More than One Class)

• What if more than one class (library) needs to be
  adapted?

18
Adapter
19
Singleton Pattern

• Notice
• Constructor is no longer public.
• To access the instance use getUniqueInstance().
• All other attribute and method declarations of C
  stay the same.

20
Facade
21
Facade
22
Factory

• Context / problemWho should be responsible for
  creating objects when there are special
  considerations, such as complex creation logic, a
  desire to separate the creation responsibilities
  for better cohesion, and so forth?
• SolutionCreate a Pure Fabrication object called
  a Factory.

23
(Abstract) Factory Example (GoF)
24
Factory (in EAs)
FrontControllerServlet
FrontCommand
processRequest ( )
init ( )
- getCommand ( ) FrontCommand
processRequest ( )
- getCommandClass ( )
ViewStudInfoCommand
RemoveStudentCommand
processRequest ( )
processRequest ( )
25
Strategy

• Context / problemHow to design for varying, but
  related, algorithms or policies? How to design
  for the ability to change (even dynamically)
  these algorithms or policies?
• SolutionDefine each algorithm/policy/strategy
  in a separate class with a common interface

26
Strategy
27
How Do We Create a Strategy?
28
Composite (Larman05, 26.8)

• Context/problem
• How do you treat a group or composite structure
  of objects the same way (polymorphically) as a
  non-composite (atomic) object?
• Solution
• Define classes for composite and atomic objects
  so that they implement the same interface.

29
Composite Ex. Class Diagram
30
Composite Ex. Objects
31
Must add be implemented by Line?

• In C add declared virtual subclass need not
  implement it.
• In Java if add is abstract, then subclasses must
  implement it.
• String add(Graphic g)
• throw new UnsupportedOperationException()
• Can you think of a better solution?

32
Composite Clients point-of-view
33
Composite Pricing Strategies

• Interface
• Realization

34
Observer Pattern
35
Observer

• How shall we have the display be updated?
• Why not have the Sale inform the display when
  it changes value.

36
What is Wrong With This?
37
Observer Pattern

• Context / ProblemDifferent kinds of subscriber
  objects are interested in the state changes or
  events of a publisher object, and want to react
  in their own way when the publisher generates the
  event.

38
Observer Pattern

• SolutionDefine a subscriber or listener
  interface. Subscribers implement this interface.
  The publisher can dynamically register
  subscribers who are interested in an event, and
  notify them when an event occurs.
• Clarification Publisher can dynamically process
  registration requests from subscribers.

39
Observer Pattern (GoF book)
40
Observers Illustration
