Sheet metal Stamping Assembles | Violin Technologies

1
What Is Metal Stamping?
www.violintec.com
2

• Metal stamping is a process of pressing a
  customized metal sheet against a die of
  customized pattern, imprint letters, or texture
  to create exteriors for vehicles, a form of
  jewelry like pendants or pieces of art.
• Sheet metal and stamped parts suppliers  use
  sheet metal stamping and can produce desired
  sheet metal assemblies using aluminum, steel
  block, brass.
• The metal stamping process is high-speed and
  low-cost manufacturing, generating a high volume
  of identical sheet metal assemblies.

3

• Depending on the type of metal stamping of the
  sheet, the process involves the following stages
• Blanking
• Bending
• Punching
• Drawing
• Embossing
• Piercing
• Curling

4

• Metal Stamping Kit
• Metal stamping kit comprises a set of equipment
  depending on the customization of the product
  shape.
• A typical kit would contain the below-mentioned
  tools.
• Stamping hammer
• Metal stamps
• Stamping Block
• Stamping tape
• Metal blanks
• Marker pen
• Polishing cloth

5

• History of Metal Stamping
• The metal stamping process originated a hundred
  years ago in Germany during the 1880s.
• Bicycle manufacturers used the process
  extensively to create components like frames and
  handlebars

6

• The Inner Works of Metal Stamping
• Sheet metal and stamped parts suppliers  perform
  metal stamping using the following processes and
  tools.
• Types of stamping dies
• Dies used in metal stamping operations can be
  single-station dies or multiple-station dies.
• Types of stamping presses
• Various types of stamping presses include
  hydraulic, mechanic, and mechanical servo.

7

• Types of stamping operations
• Transfer die stamping
• Progressive die stamping
• Fine blanking
• Four-slide stamping

8
For more details please visit https//www.violint
ec.com/
9
Your Global Contract Manufacturing and Sourcing
Partner
Thak You
