Rotary Blast Hole Drills

1
(No Transcript)
2

• C750
• EL DM DH

BUILT FOR MAXX PERFORMANCE
3
C750D Series THE DRILL OF CHOICE

• Originally Designed in the US
• First Unit sold in India in 1982
• The most preferred 10 Inch Class Drill in Indian
  Mines
• Over 100 Units Operating
• Proven Performer in Coal Iron Ore Mines

4
Why REL C750 Series Drill ?

• Proven Product with History of 38 years
• Designed based on your application
• Low cost of Ownership Higher Productivity
• High Fuel Efficiency
• Robust heavy-duty Main Frame, Crawler Frame
  Mast designed to withstand the rigors of mines
• Open Loop Hydraulic System for better life of
  Components
• Easy to use Easy to maintain
• Optimum safety and Service Factor

5
PRODUCT OVERVIEW

• C750 EL DM DH
• Nominal Hole Diameter 8 7/8 inch 225 mm to 11
  inch 279 mm
• Pull Down Capacity (Lbs.) 70,000 ( Coal OB )
  80,000 ( Metal ), Infinitely Variable
  Controlled
• Max. Bit Loading 85,000 Lbs.
• Rpm 0 to 150
• Compressor 1900 Cfm _at_ 100 psi.
• Engine CAT C18 700 HP _at_ 2100 Rpm

6
MAXIMUM DRILLING DEPTH

• EL - Single Pass 25 Feet 7.62 Meters
• - Multi Pass 100 Feet 30 Meters
• DM - Single Pass 35 Feet 10.67 Meters
• - Multi Pass 140 Feet 42.68
  Meters
• DH - Single Pass 55 Feet 16.76 Meters
• - Multi Pass 220 Feet 67 Meters

7
Rotary Head

• Rotary Head Max. Torque 0 - 9000 ft-lbs (0 -
  12200 Nm)
• Rotary Head RPM 0 150
• 2 Nos Axial piston hydraulic motors (6.0
  in3/rev)
• Planetary gear reduction 71 and spur gear
  reduction 2.081 with a total gear reduction of
  14.561
• Total Horsepower developed by Rotary head 285.2
  HP (212.8kW)
• Head guides made of Nyla Tron material

7
8
Rotary Head
8
9
Engine

• REL C750D CAT C18 700 Hp
• Avg Fuel Consumption 80 to 85 ltr/hr.
• Fuel Consumption for
• 20 Hrs. 1700 ltr.
• 4500 Hrs. - 382,500 ltr.

10
Mast Structure
11
Design change-2
Mast Structure FEA Analysis
11
Quand Steel used at High stress Level region for
Improved Strength and Longevity
11
12
MAST TESTED AT MAXIMUM LIMIT TILL DISTORTION
Animation visible in slide mode. Scale factor
120
13
Mainframe

• I Beam construction (81 lb/ft)
• Made of IS2062 E350 High Tensile strength
  material
• Designed with Finite Element Analysis
• Fabricated by certified welders
• Better Section modulus of 164 in3 to withstand
  higher loads.

14
HYDRAULIC SYSTEM

• REL C750D uses an Open Loop Hydraulic System by
  Integrating only the best components sourced from
  USA, UK and Italy.

• Open Loop Hydraulic Circuit
• 100 of the Oil returns to the Hyd. tank passes
  thru strainers and filters and gets back to the
  system
• System can be put through lower levels of
  contamination
• Longer change cycle of components
• Optimum temperature of Oil
• Reduced cost of maintenance and higher
  availability

15
TOP DECK MAIN FRAME PIPING
16
BOTTOM DECK MAIN FRAME PIPING
17
Wrap around deck for 360 Degree Mast Access
deck
18
CABIN

• Falling Object Protective Structure -
• FOPS Certified Cabin as per ISO 3449 .
  .Level 2
• Ergonomically designed rugged operator seat
• 15 Monitor with on board Computer
• Pressurized Air condition and Heater
• Less than 80db Cabin
• Buddy seat
• Sound suppressed, thermally insulated
• Clear visibility to drilling
• Windshield wipers on drilling propelling glass
  panes

19
CABIN
20
AIR RECEIVER

• Air oil receiver was tested as per ASME Sec.IX
  for working pressure of 150 PSI

20
21
UNDERCARRIAGE

• Triple grouser track group
• Total length 19 8 (6 mtrs)
• Ground contact length 16 4 (5 mtrs)
• Track shoe width 35.5 (900mm)
• Oscillating walking beam, 5? each side

21
22
DRILL ROD
PIN JOINT
BOX JOINT
DRILL ROD DIMENSION

• OUTER DIAMETER 8-5/8 in
• INNER DIAMETER 6-7/8 in
• THICKNESS 7/8 in
• WEIGHT 1300 Kgs

23
Tank Capacities
Tank Capacities
Hydraulic Oil receiver 315 Gallons (1195 Litres)
Fuel Tank 650 Gallons (2460 Litres)
Water tank 790 Gallons (3000 Litres)
23
24
Online Realtime Drill Monitoring System
25
Online Realtime Drill Monitoring System
26
Online Realtime Drill Monitoring System
27
Online Realtime Drill Monitoring System
28
Condition based Monitoring

• Periodic assessment of structures and major
  components
• Steel Structure
• Mast Crown, Drill Table, Rectangular Tubes
• Main frame Beams and Cross Members
• Jack Mounting, Mast pedestal and resting stand
• Hydraulic Pump
• Pump Discharge ( Flow )
• System Pressure
• Oil Temperature
• Component Temperature and Vibration

29
Condition based Monitoring

• Hydraulic Motor
• RPM
• Case Drain
• Temperature and Vibration
• External leakage due to shaft shaft seal wear
• Hydraulic Valves
• External Leakage
• Sound, Temperature and Vibration
• Wear on spool and Plunger
• Change in Pressure setting

30
Condition based Monitoring

• Compressor oil cooler and Lube Oil System Checks.
• Temperature across oil inlet and outlet.
• Cooler fan speed and deflection of fan blades.
• Abnormal vibration and sound.
• Mounting and alignment.
• Discharge check valve seating and spring.
• Oil stop valve for movement of spool and spring.
• High-temperature shutdown switch for functioning.
• Thermostat valve for proper opening and closing
  in relation to temperature.
• Compressor Loading and unloading system.

31
Safety Features

• Obstacle, Personnel and Void detection and
  collision avoidance system
• FOPS Cabin
• AFDSS Auto Fire Detection and Suppression
  System ANSUL Make
• Interlock between Propelling and Drilling
• Emergency Stop provision on Cabin, Remote Pendant
  pull wire around the drill
• Starter and Battery Isolator
• Over Centre Chuck Valve on all cylinders
• Whip Socks and Whip Checks
• Flame proof Jacket for Engine Exhaust Muffler

32
Obstacle, Personnel and Void detection and
collision avoidance system
33
Obstacle, Personnel and Void detection and
collision avoidance system
34
Standard Options

• Auto Power Break Out Wrench
• Auto Centralized Lubrication System
• Thread Lubrication System
• Drill Monitoring System Air Pressure
  Temperature, Fuel Tank, Hydraulic Tank and Water
  tank Level, Rotation RPM Torque, Hydraulic Oil
  Temperature, Realtime ROP, Vibration, Motor Case
  Drain, Depth Counter, Cylinder engagements.
• Pressurized and Air- Conditioned Heated Cabin
• Wrap around deck for 360 Degree Stairway with
  swing gate
• Wiggins Fast fuel System
• NVE - Dust Collector and Water Injection System

35
Standard Options

• 1 set of Drill String ( Shock Sub, 4 Nos Drill
  Rods, 2 Nos RR Bit, Roller Deck Bushing )
• Camera and Monitoring System
• LED Light Package Qty 12 Nos.
• Auto level of Drill Machine
• High Precision GPS and Geo Fencing
• Winch 2 Tons Capacity
• Obstacle, Personnel Void Detection System

36
Declutching Optional

• Declutching mechanism to
• disengage the compressor

36
37
Pull Down Pressure and Rotary RPM restriction
based on your Bit Size and IADC code

• Bit Size 9 7/8 Inch 250 mm
• IADC code and Max Bit Bearing Load
• 532 64,000 lbs. , 150 RPM ( Preferred for Soft
  to medium hard with higher ROD )
• 622, 642 70,000 lbs. , 120 RPM ( Preferred for
  Medium hard )
• 712, 732 80,00 lbs. , 90 RPM ( preferred for
  hard and heterogenous Formation )
• This setting is carried to
• Reduce the HP requirement, resulting in further
  reducing fuel consumption.
• Reduce the pre-mature failure of RDT, reducing
  your cost of drilling tools.

38
REL Support

• 1 Service Engineer from REL India will be
  deployed on site along with machine for a period
  of 6 Months to provide initial support and
  training to client.
• Post 6 Months REL Service Engineer will be
  available working out from our partner facility
  at Middleburg, along with the artisan support
  provided by Paramount Equipment.
• One set of service exchange parts of all the
  major components will be stocked in Middleburg.
• 5000 Hrs. spare parts stock will always be
  maintained at Middleburg
• REL will facilitate the stay of the 1 service
  artisan for 1 month at REL India and provide all
  necessary training.

39
Lead Time to Deliver

• Machine dispatch from REL India 3 to 4 months
  from date of Purchase Order
• Freight Time 6 to 7 Weeks
• Total Delivery time 6 Months

40
Warranty Terms

• REL will provide a standard warranty of 6000 Hrs.
  or 1 year which ever occurs first.
• Warranty terms will be as per Annex - III

41
LIFE CYCLE COST

• 1st Year 5000 Hrs. R 10,08,574.08
• 2nd Year 10000 Hrs. R 12,41,223.80
• 3rd Year 15000 Hrs. R16,28,810.74
• 4th Year 20000 Hrs. R21,94,446.55
• 5th Year 25000 Hrs. R 56,05,664.53
• 6th Year 30000 Hrs. R17,21,314.38
• 7th Year 35000 Hrs. R 10,08,574.08
• 8th Year 40000 Hrs. R22,51,544.13
• 9th Year 45000 Hrs. R15,71,713.16
• 10th Year 50000 Hrs. R 12,98,321.39

42
Trial Proposal

• REL along with its distributer proposes
• Trial of 1 No. Drill for a period on mutually
  agreeably KPIs or Std. REL KPI.
• Trial Period will be for 3 Months from the date
  of commissioning.
• During the Trial Period Fuel and RDT will be
  provided by the Client

43
REL KPI MATRIX
Key Performance Indicators C750 Performance Tracker
Key Performance Indicators Target
AVAILIBILITY 85 - 87
MTBF 60Hrs
MTTR 4Hrs
AVG. METERS DRILLED 40 to 60 M/Hrs.
Fuel Consumption 80 - 85 litters/hr
44

• REL FLANDERS
• Semi Autonomous One-Touch Drill System
• This System, converts a manually operated machine
  to a Semi Autonomous at the touch of a button
• Results with increased productivity averaging
  22.
• Operator positions the Drill on the desired hole
  position
• Provided 15 daylight readable touch screen to
  view the automated drilling process
• The automated drilling process
• Auto-Levels the machine
• Auto-Collars the hole
• Auto-Drills to desired depth
• Auto-Retracts bit
• Auto-Resets jacks in preparation for the next
  propel cycle

45

• REL FLANDERS
• FULL - Autonomous REMOTE DRILL OPERATION
• A fully automated drilling solution allows the
  operator to monitor drilling operations from a
  safe distance and offers
• Complete automated drilling Operation
• Accurate, precise autonomous machine positioning
  on the design blast hole
• Safety monitoring of the surrounding area for
  obstacles and hazards using HazCam 3D imaging
  system and GeoFencing
• Productivity gains up to 30
• Automated rod handling
• Reduced premature failure of Components.
• Increased GET life

46
Why opt for an Autonomous Drill ?For the drill
Operator

• Increased Safety
• Fully autonomous Drill Operation removes the
  driller from the Drill rig Face, to a safe and
  controlled environment.
• Avoids catastrophic disasters caused by Operator
  Fatigue and Negligence.
• Machine productivity is not affected by Human
  Interference ( Shift change Fatigue Break )
• Improved Operator Health condition
• Better Environment for the Operator

47
Why opt for an Autonomous Drill ?For the Key
Decision Makers

• Data Support for Tactical Decision Making
• Real time data collection generates relevant
  reports that arm management with better
  decision-making tools.
• Data generated helps in
• Improved spare parts inventory planning
• Improved Asset Management
• Quicker Troubleshoot Time
• Machine Reliability ( History )

48
Why opt for an Autonomous Drill ?Cost of
Drilling

• Improved Machine Health
• -- The Autonomous package on the Drill Machine
  enables it to look after itself, preventing it
  from loading beyond desired limits.
• Improved RDT life
• The Autonomous package on the Drill machine
  controls the pull down, rotary and torque forces
  within specified limits, giving you an increased
  RDT life.

49
Why opt for an Autonomous Drill ?Improved Hole
Quality and Accuracy

• Improved Hole Pattern Quality
• By eliminating the human induced variance from
  the drilling process, pattern accuracy and hole
  quality increase while re-drills decrease.
• Superior Bench Control
• Automation of the drilling sequence,
  auto-leveling and drilling to exact elevation,
  creates more level benches, resulting in
  operational efficiency
• not depth

50
REL FLANDERS C750 Autonomous brings regularity to
your hole production equations
One-half inch (12mm) variance out of spec on the
hole radius can cost you plenty in terms of
volume in a 50 blasthole (use your own figures
to modify these typical volume distortions)
Bit Dia IN. Vol. change
6.75 31.82

7.875 27.01

9 23.46

9.875 21.28

10.625 19.71

11 19.01

12.25 16.99

16 12.89
ARDVARC Control Regular, straight, reliable
Manual Control Irregular, arc bent,
appears oversized, dusty/dirty
51
Why opt for an Autonomous Drill ?Better
Fragmentation

• The Autonomous system enables the machine to
  drill the blast pattern exactly as designed by
  drastically reducing operator induced variance
  within the pattern and the blast hole itself.
• By introducing increased quality assurance and
  control (QA/QC) into drilling and blasting,
  operations can maintain a higher degree of
  control over fragmentation.
• Improving fragmentation at the mining face will
  result in improved shovel productivity, faster
  loading times, reduced truck cycle-time,
  increased throughput at the crusher and greater
  yield.

52
Fragmentation

• Down the hole data, used to generate a 3-D
  subterranean view of the mine site

Recorded at .3M (1 foot) intervals during the
drill cycle
53

• THANK YOU
