Snus packing machine manufactured by sidsam group

1
SIDSAM GROUP

• TOBACCO PACKING
• Machine

2
Snus Packing Machine (Smokeless tobacco in Filter
pouch)
Product Details Standard Bag Width 12mmBag
Length 25mm to 35mmFiling volume per
bag approx. 0.2g to 0.4g, (single setting only
with the machine)Lane  SingleFilm Reel
Diameter maximum 400mmFilm Reel Core
Diameter 72mmAir Connection 8 barStandard
voltage 400V/50hz 3ph NEPower
Supply 3KWMachine Body Stainless SteelMachine
Dimension L-75xH-70xW-36 inchStandard
Color Steel Grey/ Stainless SteelPackaging
Material Non woven filter paper
3
Automatic Line for Packing Snus in Plastic Cans
4
Capping Machine
Product Details Production rate SFSCA-50 up to
50 Cans per min.(Depending on Can and cap sizes
and shapes.)Can diameter 35mm to 80mm.Can
Height 20mm to 60mm. Cap diameter 20 to 45mm
with suitable change parts.Power requirement
0.75KW Utilities required  The utilities
required are as follows. These are to be provided
by the customer. 1. Electric Power   400 V, 3
ph, 4 wire 50 C/s. 2. Compressed air- 135
Liters Per Minute _at_ 5 Bar pressure
5
L Sealer with Shrink Tunnel
Product Details Can diameter  35mm. to
100mm.Can height  20mm. to 100mm.Output  up
to 20 per minute depending on the container size
and the label sizeEletric Power 400 V, 3 ph, 4
wire 50 C/s.16 KWCompressed Air 170 LPM, _at_ 7
bar constant pressure Electric Power  400 V, 3
ph, 4 wire 50 C/s. Compressed air - 135 Liters
Per Minute _at_ 5 Bar pressure
6
Servo Snus Portioning Machine
7
Tobacco Grinding machine
Product Details Capacity  200 kg/h for small
tobacco particlesOutputs size (mm)  0.520 (by
changing screens)Motor (kw)  5.5Speed (rpm)
 960Overall size (LWH)(mm)  9007001400Weig
ht (kg)  300Material  Stainless steel 304
8
Wrap Around Labeling Machine For Snus Cans
Product Details Can diameter  35mm. to 100mm. Ca
n height- 20mm. to 100mm.Output  up to 50 per
minute depending on    the container  size and the
 label sizeLabel size  Length 30mm to
150mm, width 16mm to 100mm. Max. Roll dia. 300mm.
Electric Power  400 V, 3 ph, 4 wire 50 C/s Compr
essed  air  135 Liters Per  Minute _at_ 5
 Bar pressure
