Cable Tray Manufacturer In Pune (1)

1
Indmark Formtech Pvt. Ltd

• An ISO 9001-2008 Company
• (http//www.indmarkformtech.com/)
• Email sales_at_indmarkformtech.co.in
• Contact Us 9922920048

2
Product List

• Perforated Type Cable tray
• Perforated cable tray Accessories
• Ladder Type Cable Tray
• Ladder Cable Tray Accessories
• Cable Duct or Trunking
• Cable Duct Accessories
• G.I. Wire

• Cable Tray Covers
• Coupler Plates with Hardware(Nut, Bolt, Washer)
• Earthering Material
• Trefoil Clamps
• Cover Clamp
• Utility Channel

3
Technical Specification
Material According to Standard
Mild Steel IS 1079 / IS 2062
S
Stainless Steel SS 304 / SS 316

Aluminium IS 8011 / IS 1060

Pre-galvanized IS 277
Finishing Hot Dip Galvanizing,Painted
Galvanizing IS 2629 /4759, BS 729,ASTM 123
Enamel Painting IS 101-1988
Epoxy Painting IS 7348

Power Coating IS 7651
Aluminium Self Finish / Anodizing
Stainless Steel Self Finish / Mirror Finish
4
1.Perforated type Cable Tray

• Perforated Straight Cable tray
• Perforated Inward Bend Cable tray
• Perforated with Inward Inclined Bend Cable tray
• Perforated Outward Bend Cable tray

5
2. Perforated Cable tray Accessories

• Horizontal Bend
• Cross
• Vertical Bend Inside
• Center Reducer
• Vertical Bend Outside
• Left Hand reducer
• Tee , Right Hand Reducer

6
3. Ladder Type Cable Tray

• Ladder with Straight Run
• Ladder with inward Bend
• Ladder with Outward Bend
• Ladder Bolted Type

7
4. Ladder Cable Tray Accessories

• Horizontal Bend
• Cross
• Vertical Bend Inside
• Center Reducer
• Vertical Bend Outside
• Left Hand reducer
• Tee , Right Hand Reducer

8
5.Cable Duct or Trunking

• Cable Dust Straight tray
• Cable Dust Plain Cover Inward Bend (IB) Tray
• Cable Dust Plain Cover with collar (IB) Tray
• Cable Duct Multi-Compartment Tray

9
6. Cable Duct Accessories

• Horizontal Bend
• Cross
• Vertical Bend Inside
• Center Reducer
• Vertical Bend Outside
• Left Hand reducer
• Tee , Right Hand Reducer

10
7.Cable Tray Covers

• Flat Cover
• Sloppy Cover
• Dome Cover

11
8. Coupler Plates with Hardware

• CP 4090
• CP 25/40210
• CP 50210
• CP 65/70/100210
• Horizontal Hinged
• Vertical Hinged
• C Type Cover Clamp 1,2

12
9. Earthing Material

• Earthing Plate
• G.I Earthing Strip
• G.I Earthing Wire
• Trefoil Clamps

13
Thank You!!!
