3 Axis Selective Coating Machine – things that you need to know

1
3 Axis Selective Coating Machine things that
you need to know
www.1clicksmt-conformalcoating.com
2
Know About us
For the electronics of the present days, it can
be said that they are much more used in the
present day environments. With the fast growth
and usage of the outdoor electronic applications,
there has been an increment in the volume of
electronic circuits that need to be coated.
During the design of the PCB in the initial days,
there was no attention to the coating ability of
the circuit boards. And this is what resulted in
the problem areas for the selective conformal
coating. This is where the importance of 3-axis
selective coating machine comes into play.
3
Benefits
The flexibility of the 3 axis selective coating
machine needs to be considered. The flexibility
is the function of the types of coating materials
it can handle, the sizes of boards it can coat
and how easily it will change between them. The
flexibility is one of the primary concerns of a
contract manufacturer since they need to coat a
wide range of boards while using different
materials. Integrated solutions and system
flexibility are extremely important.
4
Some Key Points
Safety is a very serious concern of the coating
process. The usage of solvent-based materials
needs proper safety procedures that need to be
followed for preventing the hazardous condition.
The fact that selective coating process includes
the use of robot and conveyors ensures the
requirement of approved guards and also interlocks
5
The 3 axis selective coating machines are
classified into two forms, they are either
atomized deposition or they are a non-atomized
deposition. Air-spray technology is an example of
the atomization process. During the atomization,
breaking material into the particles, there will
be some droplets that drift. There are a lot of
particles in the center of the pattern that land
in the desired area but a few particles land
outside.
3 axis conformal coating machine
6
In a Nutshell
The non-atomizing dispensers are in the form of a
dispenser or film coater. The needle dispenser
applies the coating in the narrow thick band and
is perfectly useful for the small areas. The
needle will tend to drip a bit because the
shut-off point is far from the tip. Dripping will
cause a lot of issues if the coating lands in the
connector or any other undesirable location.
7
Contact Us
Bld 1, Hua Ke Bao Chuang Industry zone, Shi Da
Road, Daling Shan Town, DongGuan, China - 523825
86-13537273006 / 86-0769-85303739
amy_at_1clicksmt.com
