ZCOM MT-777 PORTABLE TWO WAY RADIO WALKIE TALKIE FM TRANSCEIVER MT777

1
Zcom MT-777 Walkie Talkie

• Portable Handheld FM Transceiver Two-way radio

2
Zcom MT-777 Walkie Talkie

• Zcom MT-777 Walkie Talkie is a 2 way
  communication device with high quality long
  distance wireless hand held radio functionality.
  This commercial MT 777 2 way radio operates
  respectively on UHF and VHF bands. Its by far the
  best two way radio communication device  as it
  offers vast range of technical specification and
  functions, This puts Zcom MT-777 at the top of
  the range of amateur units.

3
Main Features
50 CTCSS tones/105 DCS codes 3 display modes VFO, MR and CH
128 channels to store TOT (Time-out Timer) function
UHF 400-470MHz / VHF 136-174MHz Busy channel lockout (BCLO) function
Channel spacing 25 / 12.5KHz Squelch adjustable to 9 levels
1750Hz tone for repeaters Keypad lock
SOS emergency function High/Low power selection
Shift repeater Inverted frequency function
VOX and Scan function Function/channel reset
Back-lit display with 3 colors FM radio receiver
UHF 400-470MHz / VHF 136-174MHz Kenwood 2 Pin audio jack
4
Specification
Frequency Range 136-174/400-470MHz
Channel Spacing 12.5/25KHz
Channel capacity 128
Antenna Impedance 50O
Battery Type Lithium-ion, 1300mAh
Power Voltage Range 7.4V DC20
Temperature Range -2055?
Weights 210g With antenna battery
Dimensions(HWD) 1005833mm
5
Transmitter
RF Power 4W
Frequency Stability 1.5PPM
Max Frequency Deviation lt5KHz / 2.5KHz
Adjacent Channel Power European terms
Audio Distortion lt3
Occupied Bandwidth European terms
Spurious emissions -36dBmlt1GHz,-30dBmgt1GHz
6
Receiver
Sensitivity 0.3uV
Audio Distortion lt3
Audio Response 300Hz 3KHz
Adjacent Channel Selectivity European terms
Intermodulation Rejection European terms
Spurious Response European terms
Audio Output 500mW_at_8O For 5 THD
