Title: Structured Cabling Passive Components Manufacturer India


1
(No Transcript)
2
END-TO-END SOLUTIONS INTEGRATED PORTFOLIO
HIGH PERFORMANCE PRODUCTS
COPPER SOLUTIONS
FIBER SOLUTIONS
HIGH DENSITY SOLUTIONS
FTTH SOLUTIONS
3
TABLE OF CONTENTS
ABOUT US 4 Category 6 4Pair UTP Slim Patch Cord 34
CATEGORY 6A Traceable Patch Cord 34
Cat 6A S/FTP SF/UTP Bare Copper Cable LSZH 7 HIGH DENSITY / DC SOLUTIONS (FIBER)
Category 6A Shielded Keystone Jack 8 Pre Terminated Fiber Optic Assemblies 35
Category 6A F/F Twisted Pair Patch Cords LSZH 8 High Density 1U 144 Fibre Patch Panel 36
Category 6A Shielded Jack Panel 9 High Density Fiber Optic Patch Panels (Rack Mountable) 38
Category 6A Staggered Shielded Jack Panel 9 High Density Fiber Optic Adapter Plate 38
Category 6A Screened Inline Coupler 9 MTP to LC Fiber Cassettes (40G/100G Cassette) 39
Category 6A Field Terminate Plug 10 High Density Fiber Optic Patch Cords 40
Fiber Optic MPO to LC Breakout Cable (40G/100G Cable) 41
CATEGORY 6 Category 6 U-UTP Bare Copper Cable LSZH / PVC 11 MPO-MPO Patch Cord (40G/100G Patch Cables) 42
Category 6 RJ45 Keystone Jack 12 DATA/TELECOM CABLE CRIMPING/TERMINATION TOOLS
Category 6 UTP/STP Patch Cord LSZH 13 UTP/STP Cable Stripper with IDC Punch Down Tool 43
Category 6 UTP Jack Panel 14 Universal Cable Jacket Stripper (UTP/STP) with Cable Cutter 43
Category 6 UTP 60 Angled Jack Panel 14 UTP/STP Cable Stripper 43
Category 6 RJ45 Lockable Keystone Jack 15 Non-Impact Punch Down Tool (Use on 110 Type) 43
Category 6 UTP/STP Lockable Patch Cord LSZH 16 RJ45 Professional Crimping Tool 43
Splitter (1 UTP Cable Supports 2 Data Ports) 17 Cable Bunching Tool 43
Cat 6 Cable Inline Coupler Using IDC Termination 17 WorkbenchTermination Kit 44
Cat 6 Cable Inline Coupler Using Patch Cord 17 UTP Tool Kit 44
Category 6 Field Terminate Plug 18 COPPER TESTING TOOLS
CATEGORY 5E POE Tester 45
Category 5e U-UTP Bare Copper Cables 19 LAN Tracker 45
Category 5e RJ45 Keystone Jack 19 LAN Tester 45
Category 5e UTP/STP Patch Cord 20 Net Toner Probe Kit (Cable Tracer) 46
Category 5e UTP Jack Panel 20 Data Cable Length Measuring Fault Locator With Toner 46
TELECOM ACCESSORIES FIBER INSTALLATION TOOLS
10 Pair Connection / Disconnection (Krone Style) Modules / Label Holder 21 Splicing Machine OFS-108 47
Wall/Rack Mountable MDFs (Krone Style) 21 High Precision Fiber Cleaver 47
3 x 3 Face Plate 21 Fiber Stripper 48
3 x 3 Back Box 21 Fiber Kevlar Yarn Cutter 48
Fiber Tubing Cutter 48
FIBER OPTIC SOLUTIONS Fiber Optic Fusion Splicing Tool Kit 48
Outdoor Armoured Fiber Optic Cable 22 Fiber Cable Slitter 48
Outdoor Armoured Fiber Optic CableDirect Burial 23
Indoor Fiber Optic Cable 24 FIBER TESTING TOOLS
Fiber Optic Patch Cords 25 Optical Power Source 49
Fiber Optic Pigtails 25 Optical Power Meter 49
Fiber Optic Sliding Patch Panel 2 Cut out (Rack Mountable) 26 Visual Fault Locator 49
Fiber Optic Sliding Patch Panel (Rack Mountable) 27 OTDR 50
Fiber Optic Patch Panel (Wall Mountable) 28 Fiber Optic Fault Locator (Fiber Ranger) 50
Fiber Optic Adapters 28
Fiber Optic Connectors 29 FIBER CLEANING TOOLS
Fiber Optic Attenuators 29 Fiber Cassette Cleaner 51
Fiber Optic Outdoor Joint Enclosure 30 One Click Cleaner SC/LC 51
IP65 Rated Fiber Optic Enclosure 30 MPO/MTP Connector Cleaner 51
DIN Rail Patch Panel 30
Media Converter 31 FTTH / OUTDOOR SOLUTIONS
Industrial Media Converter 31 FTTH Indoor / Outdoor Drop Cable 52
Fiber Distribution Box 52
HIGH DENSITY / DC SOLUTIONS (COPPER) Plannar Light Wave Circuit (PLC) Splitters 53
Pre-Terminated Copper Harness Cable 32 FTTH Customer Outlet 54
Category 6/6A High Density Snap-In 1U Jack Panel 33 SC Fast Field Assembly Connector 54
Category 6/6A 0.5U 24 Port Jack Panel 33
4
About Us
A Make-In-India, Quality-Driven Organization
Producing High Quality Products in Passive
Networking Solutions in both Copper and Fiber
ounded in 2013 and Headquartered at Bengaluru,
India, 3C3 is a structured cabling manufacturer
with factory locations in Bengaluru. With over
two decades of manufacturing experience and
customer service, we strive to be the most
innovative provider of communication products.
If you can envision it, we can create it from the
design stage to the initial prototype to final
production and testing. 3C3 products are
designed to provide features and installation
simplicity, resulting in cost effective, reliable
solutions in any networking environment. We have
a State of the Art Manufacturing and
Infrastructure Facility in Bengaluru with more
than 50 Employees in Production, Quality Control
Engineers and a strong technical support team
ably supported by an experienced Marketing
team. 3C3 offers full range of Structured
Cabling products which exceeds the EIA/TIA
standards specified for performance character-
istics in Copper, Fiber portfolios. 3C3 offers
end-to-end, integrated portfolio of
high-performance copper and fiber cable
connectivity solutions for applications from the
data centre to the desktop. All products have a
25-Year Performance guarantee, a 5-Year Product
Warranty and come with a no-ques- tions-asked
refund/replacement policy for faulty
products. Over the years, we have catered to all
market segments like IT, ITES, Government
Sectors (Central and State), PSUs, Educational
Institu- tions, Hospitality Organisations and
International Clients. With our Experienced
Marketing team in place, we have been able to
make in-roads into these industries and have
supplied 3C3 products to some of the most
prestigious projects and organiza- tions. Over
these years, we have developed a strong support
base (System Integrators).
5
WHO WE ARE We specialize in top-of-the-line
Structured Cabling System solutions which feature
high-performance copper and fiber cable
connectivity capabilities for applications
varying from the Data Center to the desktop. We
follow the Make-In-India policy and offer a full
range of products which exceed the EIA/TIA
standards specified for performance
characteristics in Copper and Fiber portfolios
for our customers in India and abroad. We are
headquartered in Bangalore, with a manufacturing
facility at KIADB Industrial Area, Kumbalgodu,
Bangalore
  • MISSION
  • 3C3 is constantly focused on innovation with
  • high performance and high quality products,
    agility and integrity thereby enabling all Core
    Communication needs.
  • We operate with Core Connexions integrity to
  • Deliver a strategic growth opportunities
  • for our customers,
  • Provide value to our stakeholders, and
  • Ensure a thriving, collaborative culture for our
    diverse employees.

VALUES 3C3 respects its employees and makes
ethical decisions that ensure our companys
success in all forms. 3C3 values innovative
thinking, collabora- tion, and ideas that help
our customers and 3C3 achieve long-term
success. 3C3 adapts quickly to change to ensure
profitable growth for our business.
VISION To be the global leader in the
manufacturing of networking /structured cabling
products and to be recognized as the providers
of world-class products in the market.
WHAT WE DO Our three decades of experience in
designing and implementing the Fiber Optic and
Structured Cabling solutions/projects and many
years in the OEM/ODM business both in India and
abroad - have qualified us to become one of the
leaders in designing unique products with inhouse
expertise.
QUALITY Committed to delivering quality with
speed.
INNOVATIVE Innovative design and manufacturing
LOGISTICS Speedy response, production in
Bangalore
INSTALLATION First to start installation and
testing tools
QUALIFIED BACKUP Experienced RD and support
teams
CUSTOMIZED Design and develop for
client-specific needs
  • OUR QUALITY POLICY AND CERTIFICATIONS
  • Our commitment to quality is to
  • Maintain and enhance our customers trust by
    providing products and solutions that are
    inherently safe and of the highest quality.
  • Embrace best-in-class practices that are
    consistently integrated into our operations for
    both internally produced and procured products
    and services.
  • Ensure that all associates actively support a
    culture of continuous improvement.

Allow us to show off our certifications
014
6
CE RT I F I CAT E O F CO M P L I ANCE
Certificate Number 20171025-E496392 Report
Reference E496392-20171016 Issue Date
2017-OCTOBER-25
CE RT I F I CAT E O F CO M P L I ANCE
Certificate Number 20180115-E497297 Report
Reference E497297-20180103 Issue Date
2018-JANUARY-15
Issued to COM CORE CONNEXIONS PVT LTD Ujjni
Pegasus, 1557 2nd floor, B Wing 8th Cross,
ChandraLayout Bangalore Karnataka ININ 560040
Issued to COM CORE CONNEXIONS PVT LTD UJJNI
PEGASUS, 1557, 2ND FLOOR, B WING, 8TH CROSS,
CHANDRA LAYOUT, BANGALORE, KARNATAKA 560040 INDIA
This is to certify that COMMUNICATIONS
CABLE representative samples of ModelsCM, CMX,
CMG
This is to certify that COMMUNICATIONS-,
AUDIO/VIDEO-, DATA- AND representative samples of
OTHER SIGNALING-CIRCUIT ACCESSORIES See Addendum
page for Models/Product
Have been investigated by UL in accordance with
the Standard(s) indicated on this Certificate.
Have been investigated by UL in accordance with
the Standard(s) indicated on this Certificate.
Standard(s) for Safety Communications Cables, UL
444 Additional Information See the UL Online
Certifications Directory at www.ul.com/database
for additional information
Standard(s) for Safety UL 1863 -
Communications-Circuit Accessories CSA C22.2 No.
182.4-M90 - Plugs, Receptacles and Connectors
for Communication Systems Additional Information
See the UL Online Certifications Directory
at www.ul.com/database for additional information
Only those products bearing the UL Certification
Mark should be considered as being covered by
UL's Certification and Follow-Up Service.
Look for the UL Certification Mark on the product.
Only those products bearing the UL Certification
Mark should be considered as being covered by
UL's Certification and Follow-Up Service. Look
for the UL Certification Mark on the product.
Bruce Mahrenholz, Director North American
Certification Program
Bruce Mahrenholz, Director North American
Certification Program
UL LLC
UL LLC
Any information and documentation involving UL
Mark services are provided on behalf of UL LLC
(UL) or any authorized licensee of UL. For
questions, please contact a local UL Customer
Service Representative at http//ul.com/aboutul/lo
cations/
Any information and documentation involving UL
Mark services are provided on behalf of UL LLC
(UL) or any authorized licensee of UL. For
questions, please contact a local UL Customer
Service Representative at http//ul.com/aboutul/lo
cations/
Page 1 of 1
Page 1 of 2
3933 US Route 11 Cortland, New York 13045 USA
Phone Number (800) 345-3851 Fax Number (607)
758-6637 Web www.intertek.com
ETL Verified Certificate of Conformance Number
102926978CRT-001 On the basis of the tests
undertaken, the sample(s) of the below product
have been found to comply with the essential
requirements of the referenced specifications at
the time the tests were carried out. Rendered
to Com Core Connexions Pvt. Ltd. GF1, 172, 7th
Cross, Tricon Vista Opp BDA Complex, Nagarabhari
Bangalore 560072, India Contact Mr. Sunil Kumer
M Product Tested 4-Connector Channel
  • Component ID Manufacturer
  • 1, 8 Com Core Connexions
  • Com Core Connexions
  • Com Core Connexions
  • Com Core Connexions
  • 5, 7 Com Core Connexions
  • 6 Com Core Connexions

Part Number 3C-C6-U-MT-YY-3M 3C-C6NJ-XX 3C-C6US23G
Y-3 3C-SC-C6 3C-C6UT-XX 3C-C6-U-MT-YY-3M
Description Equipment Cord Wall Outlet
Horizontal Cable 110 Block Patch Panel
Equipment Cord
Standard(s)/Specification ANSI/TIA-568-C.2
Category 6 with the applicable electrical
transmission characteristics Product(s)
Literature ETL Verified 4-Connector Channel to
ANSI/TIA-568-C.2 Category 6, along with May
Include channel illustration, and parts
numbers. Continuing compliance to this
specification is monitored through production
testing, ongoing inspections by Intertek at the
production facility and random sample
testing. Date Issued March 18, 2017 Approved
By Antoine Pelletier, Project Engineer This
verification supersedes all previous
verifications with the noted Verification/Report
number(s) dated before this verification
notice. NOTE This verification is part of the
full test report(s) and should be read in
conjunction with it. This Verification is for the
exclusive use of Intertek's Client and is
provided pursuant to the agreement between
Intertek and its Client. Intertek's
responsibility and liability are limited to the
terms and conditions of the agreement. Intertek
assumes no liability to any party, other than to
the Client in accordance with the agreement, for
any loss, expense or damage occasioned by the
use of this Verification. Only the Client is
authorized to copy or distribute this
Verification. Any use of the Intertek name or one
of its marks for the sale or advertisement of
the tested material, product or service must
first be approved in writing by Intertek. The
observations and test results referenced from
this Verification are relevant only to the
sample tested. This Verification by itself does
not imply that the material, product, or service
is or has ever been under an Intertek
certification program.
7
COPPER SOLUTIONS
CATEGORY 6A
Cat 6A S/FTP SF/UTP Bare Copper Cable LSZH
  • FEATURES
  • Cable Characterized up to 500 MHz,
  • Full Power Sum Performance.
  • Overall Mylar tape Screened core.
  • ATC overall braid with Drain wire.
  • Excellent Shielding performance.
  • Flame Properties
  • Operating Temperature -20C up to 70C

Category 6A S/FTP SF/UTP Cable is Produced
using 4x23 AWG-500MHz Solid Bare Annealed
Copper Conductors.
Cat6A SF/UTP Twisted 4 Pairs, Overall Polyester
tape, Overall AL-PET Foil (Mylar Tape) Braid
Screen, Drain Wire and then LSZH Outer Sheath.
  • CONFORMANCE
  • Category 6A
  • IEEE 802.3an
  • IEC 60332-1-2
  • ANSI/TIA- 568- C.2-2009
  • ISO/ IEC 11801 2.0

Cat6A S/FTP Twisted 4 Pairs, Overall Polyester
tape, Individual AL-PET Foil (Mylar Tape)
Braid Screen, Drain Wire and then LSZH Outer
Sheath.
It supports 10/100/1000Base-T and 10GBase-T high
speed Ethernet network applications.
PARAMETERS VALUE VALUE
S/FTP S/FTP SF/UTP
Conductor AWG 23 23
Material Solid Annealed Bare Copper Conductor Solid Annealed Bare Copper Conductor
Insulation Material Foamed Polyethylene Halogen free low capacitance PE
Diameter 1.05 0.03 mm 1.05 0.03 mm
Pairs Two insulated core twisted together Two insulated core twisted together
Twisting 4 pairs laid up over polyethylene cross separator 4 pairs laid up over polyethylene cross separator
Overall Polyester tape, Individual AL-PET Foil Overall Polyester tape, Overall AL-PET Foil
(Mylar Tape) Braid Screen, Drain Wire (Mylar Tape) Braid Screen, Drain Wire
Outer Sheath LSZH LSZH
Cable Diameter 7.5 0.4 mm 7.1 0.03 mm
Insulation Resistance Min. 5000 Mfi.KM Min. 5000 Mfi.KM
Conductor Resistance Max. 93.8 fi/KM Max. 93.8 fi/KM
Conductor Resistance Unbalance Max 5 Max 5
Bending radius 8 x overall diameter (min) 8 x overall diameter (min)
Capacitance Earth Unbalance Max. 3300 pF/100m Max. 3300 pF/100m
Propagation Delay _at_ 1, 10, 100 250 MHz Max. 570, 545, 538 536 ns/100 m Max. 570, 545, 538 536 ns/100 m
Propagation Delay Skew _at_100 MHz Max. 45 ns/100m Max. 45 ns/100m
Operating Temperature -20C to 70C -20C to 70C
PART CODE DESCRIPTION
3C-6ASF23GY-3 Category 6A S/FTP 4 pair copper cable 23 AWG Grey (Roll of 305M) 3C-6ASF23GY-3 Category 6A S/FTP 4 pair copper cable 23 AWG Grey (Roll of 305M)
3C-6ASFU23GY-3 Category 6A SF/UTP 4 pair copper cable 23 AWG Grey (Roll of 305M) 3C-6ASFU23GY-3 Category 6A SF/UTP 4 pair copper cable 23 AWG Grey (Roll of 305M)
7
8
COPPER SOLUTIONS
CATEGORY 6A
Category 6A Shielded Keystone Jack
  • FEATURES
  • New press fit technology with fully RoHS
    Compliant ( No Solder
  • No Leads)
  • No punch down tool required.
  • 180 degree design

Category 6A Shielded Keystone Jacks confirm to
class EA perfor- mance. The Press-Fit technology
is able to complete the insertion of the IDC
and RJ-45 contacts into a PTH (Plated-Through
Hole) on a PCB (Printed Circuit Board). The
connec- tion is established without using
  • Die-cast housing provide EMI, RFI and excellent
    AXT suppression.
  • Provides excellent work in suppressing internal
    magnetic coupling up to bandwidth of 500MHz.

CONSTRUCTION VALUE
Shield Material Zinc alloy
Plastic Housing ABS UL94V-O
Contact Material Phosphor Bronze, Tin (8Pins- Gold Plating)
RJ45 Contacts 750 Times MIN
IDC life 250 Times MIN
Operation -10 C to 60C
solder. Press-Fit technology connections avoid
quality problems such as cold spots, voids,
splatters, and cracks and its highly reliable
than soldering. Press-Fit technology does not
use solder, it uses no lead (Pb) and there is no
extra heat on the connections, it makes the
connec- tions clean, reliable, and meets RoHS
standards.
DESCRIPTION
PART CODE
3C-6ANJSH
Category 6A Shielded Keystone Jack
Category 6A F/F Twisted Pair Patch Cords LSZH
  • Category 6A F/FTP Patch Cords delivers optimal
    transmission and networking performance with
    reduced insertion loss and Alien Cross Talk.
    They are high performance components available
    in broad range of lengths and designed to meet
    or exceed all Cat6A specifica- tions. 26 AWG
    conductors are secure- ly mated with shielded
    RJ45 plug design to deliver superior
    performance.
  • FEATURES
  • Quality 26 AWG standards flexible cable
  • High grade 50µ gold Plated RJ45 connecters
  • Injection molded boot for improved strain relief
  • Soft latch-cover design for easy depression
  • CONFORMANCE
  • Category 6A
  • ANSI/EIA/TIA 568B22002
  • RoHS/REACH
  • IEC 61156-6 edit 2.0

CONSTRUCTION CONSTRUCTION VALUE
Conductors AWG 26
Size mm 7/0.150.01
Material Stranded Bare Copper
Insulation Diameter mm 1.010.05
Material PE
Thickness mm 0.26
Jacket External OD 5.90.3
Material LSZH
PART CODE DESCRIPTION
3C-6AS-GY-XX Category 6A F/F Twisted Pair Patch Cords LSZH 3C-6AS-GY-XX Category 6A F/F Twisted Pair Patch Cords LSZH
XX - Length (1M - 1 meter, 2M - 2 meter, 3M - 3 meter, 5M - 5 meter) XX - Length (1M - 1 meter, 2M - 2 meter, 3M - 3 meter, 5M - 5 meter)
Customized length is also available Customized length is also available
8
9
COPPER SOLUTIONS
CATEGORY 6A
Category 6A Shielded Jack Panel
Category 6A Shielded Jack Panel offers fast and
reliable installation of shielded cables, a rear
cable management bar is supplied which acts as
stress reliever of terminated cables. Each port
of the panel is numbered and as a designated
label area for clear port identification.
  • FEATURES
  • 19" RJ-45 Patch Panel with 24 ports on 1U
  • Strain relief and cable manage- ment
  • Universal wiring - T568 A or B wiring pattern
  • Including grounding bolt

PART CODE DESCRIPTION
3C-6AST-XX Category 6A Shielded Jack Panel 3C-6AST-XX Category 6A Shielded Jack Panel
XX-(UL-Unloaded / LD-Loaded) XX-(UL-Unloaded / LD-Loaded)
Category 6A Staggered Shielded Jack Panel
Category 6A Staggered Shielded Jack Panel offers
fast and reliable installation, designed for 10G
transmission requirement. The staggered design
reduces Allien Crosstalk to support IEEE 803.ab
and TIA/EIA 568B.2-10.
  • FEATURES
  • Staggered design reduces Allien Crosstalk
  • 19 RJ-45 Patch Panel with 24 ports on 1 U
  • Strain relief and cable manage- ment
  • Universal wiring - T568 A or B wiring pattern
  • Including grounding bolt
  • Testing condition of transmitting capability
    500MHz

PART CODE DESCRIPTION
3C-6ASST-XX Category 6A Staggered Shielded Jack Panel 3C-6ASST-XX Category 6A Staggered Shielded Jack Panel
XX-(UL-Unloaded / LD-Loaded) XX-(UL-Unloaded / LD-Loaded)
Category 6A Screened Inline Coupler
Category 6A Screened Inline Coupler avoid the
need for rear termination and allow two patch
cables to be connected directly, no tools
required. This standard keystone jack fits any
keystone wall plate, patch panel, or surface
mount box. Rated for Cat6a network this jack
allows for bandwidth up to 10 gigabytes per
second.
  • FEATURES
  • 4 Connector Channel with at least 4dB Head Room
  • Die-Cast housing eliminates Alien Crosstalk.
  • Tool-less Design.
  • Innovative Press fit technology with fully RoHS
    Compliant (No solder - No Leads)
  • Cat 6A feed through solution for 10G data Centre
    Solutions.
  • User Friendly and excellent transmission
    Performance.

MECHANICAL VALUE VALUE
Coupler Housing Coupler Housing Polycarbonate 94V-0 Plastic
Shell Shell Brass with Nickel Plated
Contact Holder Contact Holder High-Impact 94V-0 Plastic
Spring Wire Spring Wire Phosphor Bronze with Gold Plated on Contact Area
Locking Latch Locking Latch SUS 304
DESCRIPTION
PART CODE
3C-BI-6A
Category 6A Screened Inline Coupler
9
10
COPPER SOLUTIONS
CATEGORY 6A
Category 6A Field Terminate Plug
Category 6A Field Terminate Plugs are designed
for use on patch cable assemblies and therefore
are designed to terminate to strand conductors
of wire sizes from AWG 23 through AWG 26.
  • Compatible with EN 50173 / ISO IEC 11801
  • Qualified Screened Class 6A Component
  • Permanent Link Channel ANSI/TIA-568-C.2
  • IEC 60603-7-51
  • ISO/IEC 11801 2.2 Edition
  • CENELEC EN 50173-12011
  • FEATURES
  • IP20 rated Field Terminable Plug

PARAMETER VALUE
Housing Color Zinc-alloy fully shielded
Plug-housing PCB holder Polycarbonate(PC), UL 94V-0. Plug-housing PCB holder Polycarbonate(PC), UL 94V-0.
Plug-Contact T0.35mm phosphor bronze, Contact area gold over nickel plating
IDC-Contact T0.4mm phosphor bronze, Sn over nickel plating
Current Rating 1.5 Amps maximum.
Insulation resistance 500 Mohms minimum, at 500V DC.
DESCRIPTION
PART CODE
3C-FTP-6A
Category 6A Field Terminate Plug
10
11
COPPER SOLUTIONS
CATEGORY 6
Category 6 U-UTP Bare Copper Cable LSZH / PVC
  • Category 6 Unshielded Twisted Pair (UTP) Data
    Cable consists of 4X23AWG 250Mhz Solid Annealed
    Bare Copper Conductors, PE Insulated twisted 4
    Pair, PE Cross Separator, and LSZH/PVC outer
    jacket with rip cord. These structure cable
    suitable for 10Gigabyte Ethernet Applications
    and compati- ble with all known connection
    Systems, Ideal for high performance workstation
    applications including voice/data systems,
    Digital video, Broadband and Voice over internet
    protocol etc.
  • FEATURES
  • Bare Solid Copper Conductor
  • Color-Coded PE insulation
  • Center Cross PE
  • Enhanced performance specification up to 250 MHZ
  • CONFORMANCE
  • Category 6
  • ETL Verified
  • RoHS
  • TIA/EIA 568 C.2
  • ISO/IEC 11801
  • IEC 60332-1
  • IEC 60754-1

OUTER JACKET RIP CORD SEPARATOR HDPE
INSULATION BARE COPPER CONDUCTOR
CONSTRUCTION VALUES
Conductors AWG 23 23
Size mm 0.55 0.010 0.54 0.02
Material Solid Bare Copper Solid Bare Copper
Insulators Diameter 1.02 0.03 1.02 0.03
Material High Density Polyethylene High Density Polyethylene
Jacket External OD 6.0 0.30 mm 6.20 0.50 mm
Material LSZH PVC
Pairs Two insulated conductors twisted together to form pair
Twisting 4 pairs laid together and separated by cross element
Conductor Resistance Max. 9.38 ohms/100m Max. 9.38 ohms/100m
Conductor Resistance Unbalance Max 4 Max 4
Bending Radius 4 x overall diameter (Min) 4 x overall diameter (Min)
Capacitance Earth Unbalance Max. 330 pF/100m Max. 330 pF/100m
Propagation Delay _at_ 1, 10, 100 250 MHz Max. 570, 545, 538 536 ns/100 m Max. 570, 545, 538 536 ns/100 m
Propagation Delay Skew 1-250 MHz Max. 45 ns/100m Max. 45 ns/100m
Operating Temperature -20C to 70C -17C to 60C
PART CODE DESCRIPTION
3C-C6USZ23GY-3 Category 6 U-UTP Bare Copper Cable 23AWG Grey Roll of 305m LSZH 3C-C6USZ23GY-3 Category 6 U-UTP Bare Copper Cable 23AWG Grey Roll of 305m LSZH
3C-C6USP23GY-3 CCategory 6 U-UTP Bare Copper Cable 23AWG Grey Roll of 305m PVC 3C-C6USP23GY-3 CCategory 6 U-UTP Bare Copper Cable 23AWG Grey Roll of 305m PVC
11
12
COPPER SOLUTIONS
CATEGORY 6
Category 6 RJ45 Keystone Jack
Category 6 RJ45 Keystone Jacks conform to class
E performance. Due to their small form design,
they are prefect for high-density applica-
tions. The Press-Fit technology is able to
complete the insertion of the IDC and RJ-45
contacts into a PTH (Plated-Through Hole) on a
PCB (Printed Circuit Board). The connec- tion
is established without using solder.
ONE PUNCH KEYSTONE TOOL
Press-Fit technology connections avoid quality
problems such as cold spots, voids, splatters,
and cracks and its highly reliable than solder-
ing.
Press-Fit technology does not use solder, it
uses no lead (Pb) and there is no extra heat on
the connections, it makes the connections clean,
reliable, and meets RoHS standards.
  • FEATURES
  • Innovative press-fit technology to be fully RoHS
    compliant ( No Solder No Leads)
  • Integrate with T568A and T568B wiring Diagram.
  • Fast Termination with One punch Keystone Tool.
  • Meets and exceeds EIA/TIA Performance
    requirements.

MECHANICAL VALUE
Housing ABS, UL94V-0
IDC PC,UL94V-0
Contact Gold Plated with Nickel Undercoat
PCB FR-4, UL94V-0
Insulation Resistance 500M ohms (min.)
DC Current 1.5 Amps
PART CODE DESCRIPTION
3C-C6NJ-XX Category 6 RJ45 Keystone Normal Jack 3C-C6NJ-XX Category 6 RJ45 Keystone Normal Jack
3C-FTT-200 One Punch Keystone Tool 3C-FTT-200 One Punch Keystone Tool
XX BK-Black color, WT-White Color, BL-Blue, YL-Yellow XX BK-Black color, WT-White Color, BL-Blue, YL-Yellow
12
13
COPPER SOLUTIONS
CATEGORY 6
Category 6 UTP/STP Patch Cord LSZH
  • FEATURES
  • Quality 24 AWG standards flexible cable
  • High grade 50µ gold Plated RJ45 connectors
  • Injection molded boot/Strain Relief Boot for
    improved strain relief
  • Soft latch-cover design for easy depression
  • CONFORMANCE
  • Category 6
  • ANSI/EIA/TIA 568B22002
  • RoHS/REACH

Cat6 UTP/STP Patch Cords are manufactured using
high quality un-shielded/Shielded 4 Pair
Stranded cable and features cable strain relief
boot with plug latch protection cap. These high
performance components available in broad range
of lengths. They are designed to meet or exceed
Cat6 specifications. Conductors are securely
mated with shielded/un- shielded RJ45 plug
Design to deliver superior performance.
CONSTRUCTION CONSTRUCTION VALUE
Conductors AWG 24
Size mm 7/0.1950.01
Material Stranded Bare Copper
Insulation Diameter mm 0.940.05
Material PE
Thickness mm 0.155
Jacket External OD 5.990.3
Material LSZH
Central Element PE Cross Separator
Minimum Bending Radius (mm) 50
Operating Temperature -10C to 60C
PART CODE DESCRIPTION
3C-C6W-XXYY-ZZ Category 6 Patch Cord 3C-C6W-XXYY-ZZ Category 6 Patch Cord
W (U-Un Shielded, S-Shielded) W (U-Un Shielded, S-Shielded)
XX Boot Type (MT-Molded Boot, BT-Boot) XX Boot Type (MT-Molded Boot, BT-Boot)
YY- Color (WT-White, YL-Yellow, RD-Red, BL-Blue, GR-Green) YY- Color (WT-White, YL-Yellow, RD-Red, BL-Blue, GR-Green)
ZZ- Length (1M - 1 meter, 2M - 2meter, 3M - 3meter, 5M 5meter) ZZ- Length (1M - 1 meter, 2M - 2meter, 3M - 3meter, 5M 5meter)
Customized length is also available Customized length is also available
13
14
COPPER SOLUTIONS
CATEGORY 6
Category 6 UTP Jack Panel
  • FEATURES
  • 19" RJ-45 Patch Panel with 24 ports on 1U
  • Strain relief and cable manage- ment
  • Universal wiring - T568 A or B wiring pattern
  • Snap-in type
  • Printed label for port identifica- tion

Category 6 UTP Jack Panel offers fast and
reliable installation of un-shielded cables, a
rear cable management bar is supplied which
acts as stress reliever of terminated cables.
Each port of the panel is numbered and as a
designated label area for clear port
identification. Patch Panel comes with mini
cable ties, cage nuts and rear cable manage-
ment has standard.
PART CODE DESCRIPTION
3C-C6UT-XX Category 6 UTP Jack Panel - 24 Port 3C-C6UT-XX Category 6 UTP Jack Panel - 24 Port
XX (UL - Un Loaded / LD - Loaded) XX (UL - Un Loaded / LD - Loaded)
Category 6 UTP 60 Angled Jack Panel
JACK PANEL INSTRUCTIONS
PART CODE DESCRIPTION
3C-C6SG-XX-1 Category 6 UTP 60 Angled Jack Panel 3C-C6SG-XX-1 Category 6 UTP 60 Angled Jack Panel
XX-(UL - UN Loaded / LD-Loaded) XX-(UL - UN Loaded / LD-Loaded)
  • Category 6 UTP 60 Angled Jack Panel offers fast
    and reliable installation of un-shield-
    ed/Shielded cables, a rear cable management bar
    is supplied which acts as stress reliever of
    terminated cables. Staggered port position
    designed to reduce alien cross talk.
  • FEATURES
  • 19 RJ-45 Patch Panel with 24 ports on 1 U
  • Strain relief and cable management
  • Universal wiring - T568 A or B wiring pattern
  • Snap-in type
  • Printed Port Number White Writing labeling
  • Rotatable cable manager
  • Compactable with Regular Information Outlets
  • Straight Jack Panel with Angled IO Slots

14
15
COPPER SOLUTIONS
CATEGORY 6
Category 6 RJ45 Lockable Keystone Jack
INSTRUCTIONS INSERT THE PLUG
  • Category 6 RJ45 Lockable Keystone Jacks conform
    to class E performance, each jack is available
    with a 90 termination design, wiring diagram
    and conductor protection cap. It has a key lock
    protection to avoid loop connectivity and it is
    highly recommended for Data Center Solutions.
    These lockable tool less Jacks allows all 8
    conduc- tors to be terminated simultaneous- ly,
    when the termination cap is pressed in to place.
  • FEATURES
  • Small form RJ45 foot print design
  • Easy termination Tool not required
  • Wiring diagram and conductor cap supplied
  • Direction marks on the side of the Keystone Jack
    with lock protection
  • Compactable with all RJ45 patch cords


INSTRUCTIONS PULL OUT THE PLUG
MECHANICAL VALUE
Housing Material Fire Proof ABS UL94V-0
IDC Material Bronze and Tinned
Contact Material 8P8C 50micron inches Gold plated
Jack Insertion Cycle Min 2000 Insertions
IDC Punch Down Cycle Min 250 Terminations
PART CODE DESCRIPTION
3C-C6LK-WT Category 6 RJ45 Lockable Keystone Jack, White Color 3C-C6LK-WT Category 6 RJ45 Lockable Keystone Jack, White Color
3C-C6LK-KY Key 3C-C6LK-KY Key
15
16
COPPER SOLUTIONS
CATEGORY 6
Category 6 UTP/STP Lockable Patch Cord LSZH
Category 6 UTP/STP Lockable Patch Cords are
manufactured using high quality unshield-
ed/shielded four pair Category 6 standard cable,
and feature cable strain relief boots with a
plug latch
protection cap. Additionally its having Key
lock protection to avoid the link connectivity
Its highly recommendable for datacenter
Solution. This patch cord when used with high
performance modern
Category 6 connectivity (solid UTP/STP cable,
patch panels and work area outlets), provide
superior performance capabilities of high
bandwidth (Gigabit 1000Base-T and 1000Base-Tx)
applications support.
LOCK PLUG INSTRUCTIONS


PARAMETER
DESCRIPTION
Conductors
AWG 24
Size mm 7/0.1950.01
Material Stranded Bare copper
Insulation
Material PE
Thickness mm 0.155
Jacket
External OD 5.990.3
Material LSZH
DESCRIPTION
PART CODE
Cat6 UTP/STP Lockable Patch Cord
3C-C6L-WXX-YY-ZZ
3C-C6L-W-KY Key W - (U-Unshielded,
S-Shielded) XX - Boot Type (MT-Molded Boot,
BT-Boot) YY - Color(WT-White, YL-Yellow, RD-Red,
BL-Blue, GR-Green) ZZ - Length(1M-1 Meter, 2M-2
Meter, 3M-3 Meter, 5M -5 Meter) Customized
Length also available. 3C-RJ45-PB RJ45 Port
Blocker
16
17
COPPER SOLUTIONS
CATEGORY 6
Splitter (1 UTP Cable Supports 2 Data Ports)
  • FEATURES
  • Housing Fireproof ABS UL 94V-0
  • Jack 8P8C with 50µ inches gold plated
  • Cable Copper/PVC
  • Plug RJ45 8P8C with 50µ inches gold plated

T-Adapters are great cost saving devices that
help to reduce the number of lines needed to
connect two distant points. T Adapter is
printed circuit design
provides high performance and flexibility in
different wiring applica- tion. It is an RJ45
8-Position Plug with 0.5ft round cable into two
RJ-45 8-Position different wiring.
PART CODE DESCRIPTION
3C-TM-XX Splitter (1 UTP Cable Supports 2 Data Ports) 3C-TM-XX Splitter (1 UTP Cable Supports 2 Data Ports)
XX (C5cat5e, C6-cat6) XX (C5cat5e, C6-cat6)
Cat 6 Cable Inline Coupler Using IDC Termination
Cat 6 Cable Inline Coupler Using IDC
Terminationare used use to connect two RJ45
terminated cables, while maintaining signal
strength. These are useful for extending the
length of your CAT6 cable a few extra feet for a
quick and easy installation. CAT6 inline
couplers are available in both shielded and
unshielded varieties. CAT6 inline couplers
include a keystone latch, making it easy to
install.
MECHANICAL VALUE
Housing Material Fire Proof ABS UL94V-0
IDC Material Phosphor , Bronze and Tinned
IDC Punch Down Cycle Min 250 Terminations
PART CODE DESCRIPTION
3C-SIC-6 Cat 6 Cable Inline Coupler Using IDC Termination 3C-SIC-6 Cat 6 Cable Inline Coupler Using IDC Termination
Cat6A Compliance also available Cat6A Compliance also available
Cat 6 Cable Inline Coupler Using Patch Cord
  • Cat 6 Cable Inline Coupler Using Patch Cord
    are available in both Shielded and unshielded
    type. These keystone style RJ45 coupler are
    easy to mount in patch panel and face plate
    application. These RJ45 couplers solutions are
    engineered to bring high performance in a
    compact design.
  • FEATURES
  • New press fit technology with fully RoHS
    Compliant ( No Solder
  • No Leads)
  • Slim Housing design enables High-Density
    mounting.
  • Fits wall Plates, Surface mount box patch
    panels.

MECHANICAL VALUE
Coupler Housing PC, UL94V-0
Contact Gold Plated with Nickel under coat
PCB FR-4, UL94V-0
Insulation Resistance 500M ohms (min.)
DC Current 1.5 Amps
PART CODE DESCRIPTION
3C-BI-XX Cat 6 Cable Inline Coupler Using Patch Cord 3C-BI-XX Cat 6 Cable Inline Coupler Using Patch Cord
XX (C5Cat5e, C6-Cat6) XX (C5Cat5e, C6-Cat6)
17
18
COPPER SOLUTIONS
CATEGORY 6
Category 6 Field Terminate Plug
Category 6 Field Terminate Plugs are designed
for use on patch cable assemblies and therefore
are designed to terminate to strand conductors
of wire sizes from AWG 23 through AWG 26.
  • Compatible with EN 50173 / ISO IEC 11801
  • Qualified Screened Class 6A Component
  • Permanent Link Channel ANSI/TIA-568-C.2
  • IEC 60603-7-51
  • ISO/IEC 11801 2.2 Edition
  • CENELEC EN 50173-12011
  • FEATURES
  • IP20 rated Field Terminable Plug

PARAMETER VALUE
Housing Nylon 10 GF
Plug-housing PCB holder Polycarbonate(PC), UL 94V-0. Plug-housing PCB holder Polycarbonate(PC), UL 94V-0.
Plug-Contact T0.35mm phosphor bronze, Contact area gold over nickel plating
IDC-Contact T0.4mm phosphor bronze, Sn over nickel plating
Current Rating 1.5 Amps maximum.
Insulation resistance 500 Mohms minimum, at 500V DC.
DESCRIPTION
PART CODE
3C-FTP-C6
Category 6 Field Terminate Plug
18
19
COPPER SOLUTIONS
CATEGORY 5E
Category 5e U-UTP Bare Copper Cables
Category 5e Unshielded Twisted Pair (UTP) Cable
using 4X24 AWG-250Mhz solid bare copper
conductor insulated with polyole- fin structure,
it confirms to
ANSI/TIA/EIA-854-2001 standard. More than
capable of supporting protocols up to 250 MHz
for horizontal and backbone installa- tions.
  • FEATURES
  • Bare solid copper Conductor
  • Color-coded PE insulation
  • Center Cross PE
  • Operating temperature -10C to 60C

CONSTRUCTION CONSTRUCTION VALUE
Conductors AWG 24
Size mm 0.500.01
Material Solid Bare Copper
Insulation Diameter mm 0.880.05
Material PE
Jacket External OD 5.00.3
Material LSZH / PVC
DESCRIPTION
PART CODE
Category 5e U-UTP Bare Copper cable 24AWG White
Roll of 305mv
3C-C5US24GY-3
Category 5e RJ45 Keystone Jack
Category 5e Unshielded Keystone Jacks confirm to
class D perfor- mance. Due To their small form
design they are perfect for high-density
applications. Each keystone jack is available
with 180 termination design with wiring
diagram and conductor protection cap.
  • FEATURES
  • Compatible with Rapid Termina- tion Tool
  • Small form RJ45 foot print design
  • IDC punch down
  • 180 degree termination
  • Wiring diagram and conductor cap supplied
  • Direction marks on the side of the Keystone Jack

MECHANICAL VALUE
Housing Material Fire Proof ABS UL94V-0
IDC Material Bronze and Tinned
Contact Material 8P8C 50micron inches Gold plated
Jack Insertion Cycle Min 2000 Insertions
IDC Punch Down Cycle Min 250 Terminations
DESCRIPTION
PART CODE
Category 5e RJ45 Keystone Jack
3C-C5NJ-WT
19
20
COPPER SOLUTIONS
CATEGORY 5E
Category 5e UTP/STP Patch Cord
Cat5e UTP/STP Patch Cords are manufactured using
high quality un-shielded/Shielded 4 Pair
Stranded cable and features cable strain relief
boot with plug latch production cap. These high
performance components
  • FEATURES
  • Quality 24 AWG standards flexible cable
  • High grade 50µ gold Plated RJ45 connectors
  • Injection molded boot/Strain Relief Boot for
    improved strain relief
  • Soft latch-cover design for easy depression
  • CONFORMANCE
  • Category 5e
  • ANSI/EIA/TIA 568B22002
  • RoHS/REACH

available in broad range of lengths. They are
designed to meet or
exceed Cat5e specifications. Conductors are
securely mated with shielded/unshielded RJ45
plug Design to deliver superior perfor- mance.
CONSTRUCTION CONSTRUCTION VALUE
Conductors AWG 24
Size mm 7/0.1950.01
Material Stranded Bare Copper
Insulation Diameter mm 0.940.05
Material PE
Thickness mm 0.155
Jacket External OD 5.10.3
Material LSZH / PVC
PART CODE DESCRIPTION
3C-C5W-XXYY-ZZ Category 5e UTP Patch Cord 3C-C5W-XXYY-ZZ Category 5e UTP Patch Cord
W (U-Un Shielded, S-Shielded) W (U-Un Shielded, S-Shielded)
XX Boot Type (MT-Molded Boot, BT-Boot) XX Boot Type (MT-Molded Boot, BT-Boot)
YY Color ( WT-White, GY-Grey ) YY Color ( WT-White, GY-Grey )
ZZ Length (1M - 1 meter, 2M - 2meter, 3M - 3meter, 5M 5meter) ZZ Length (1M - 1 meter, 2M - 2meter, 3M - 3meter, 5M 5meter)
Customized length is also available Customized length is also available
Category 5e UTP Jack Panel
Category 5e UTP Jack Panel offers fast and
reliable installation of un-shielded cables, a
rear cable management bar is supplied which
acts as stress reliever of terminated cables.
Each port of the panel is numbered and as a
designated label area for clear port
identification. Patch Panel comes with mini
cable ties, cage nuts and rear cable management
has standard.
  • FEATURES
  • 19" RJ-45 Patch Panel with 24 ports on 1U
  • Strain relief and cable manage- ment
  • Universal wiring - T568 A or B wiring pattern
  • Snap-in type
  • Printed label for port identifica- tion

PART CODE DESCRIPTION
3C-C5UT-XX Category 5e UTP Jack Panel 3C-C5UT-XX Category 5e UTP Jack Panel
XX (UL - Un Loaded / LD - Loaded) XX (UL - Un Loaded / LD - Loaded)
20
21
COPPER SOLUTIONS
TELECOM ACCESSORIES
Wall/Rack Mountable MDFs (Krone Style)
10 Pair Connection / Disconnection (Krone
Style) Modules / Label Holder
  • FEATURES
  • Available in difference sizes.
  • Dustproof box suitable indoor wire distribution.
  • Fully lockable doors protect unauthorized
    access.
  • Includes mounting frame and label holder.
  • Available in rack and wall mount.

LSA Profile Connection/Disconnection Modules are
designed for telecommunication and data
communication networks, especially for use in
MDF, IDF and cross connection cabinets. It uses
unique IDC technique which clamps the wire at a
45 angle.
The MDF Cabinets are designed easy installation,
the metal bar/mounting frame can accommodate
connection or disconnection modules. Back mount
frames consist of U Shape stain less steel which
provides high degree of stabil- ity.
  • FEATURES
  • One Push wire insertion
  • 2 wires for contact
  • Gas tight connection with self-cleaning contact.
  • Only one inexpensive tool required.

PART CODE DESCRIPTION
3C-MDFXX-YY-ZZ Wall/Rack Mountable MDFs 3C-MDFXX-YY-ZZ Wall/Rack Mountable MDFs
XX (20, 50, 100 Pair) XX (20, 50, 100 Pair)
YY- (02, 05, 06 and 11 way Frames) YY- (02, 05, 06 and 11 way Frames)
ZZ- (WM-Wall Mount, RM-Rack Mount) ZZ- (WM-Wall Mount, RM-Rack Mount)
PART CODE DESCRIPTION
3C-XX-10P 10 Pair Connection/Disconnection (Krone Style) Modules 3C-XX-10P 10 Pair Connection/Disconnection (Krone Style) Modules
3C-MDF-LH Label Holder 3C-MDF-LH Label Holder
XX-(DM-Disconnection modules, CM-Connection modules) XX-(DM-Disconnection modules, CM-Connection modules)
3 x 3 Face Plate
3 x 3 Back Box
  • FEATURES
  • In-wall back box (UK Type)
  • Dimension (38x87x87)
  • FEATURES
  • Provision for accepting any Keystone Style RJ45
    Jacks
  • Data connectivity and phone connectivity.
  • Provision for Both RJ45/RJ11 type for accepting
    most computer
  • Label Holders with Plastic covers
  • Built-in Dust Covers
  • Single/Dual/Quad network faceplate
  • Material ABSPC
  • 1/2/4 RJ45 keystone jack

DESCRIPTION
PART CODE
3 x 3 Back Box
3C-BBWT
  • CONFORMANCE
  • Category 6A/6/5E

PART CODE DESCRIPTION
3C-FPSWT-X 3 x 3 Face Plate 3C-FPSWT-X 3 x 3 Face Plate
X ( 1- Single , 2-Dual, 4-Quad) X ( 1- Single , 2-Dual, 4-Quad)
21
22
FIBER OPTIC SOLUTIONS
Outdoor Armoured Fiber Optic Cable
Outdoor Armoured Cables is an outdoor use
optical fiber cable suitable for duct and aerial
applica- tions. We supply 2 fiber cores to 24
fiber cores. Both single mode type and multimode
types are available. Fiber cable is perfectly
suited for both gigabit ethernet and 10 gigabit
eternet campus and backbone applications. The
loose tube cable is gel filled and covered in
aramid strength members. Complies with
  • the latest industrial standards ie.
  • G652D, IEC-60793-1/60794-1-2,
  • Telecordia GR-20 core.
  • FEATURES
  • Excellent water proof layer and good moisture
    resistance.
  • Suitable for indoor / outdoor applications
  • Excellent consistence perfor- mance
  • Central core tube design
  • Standard 02-24 C

OUT SHEATH STEEL TAPE FILLING COMPOUND STEEL
WIRE STRENGTH MEMBER FIBER LOOSE TUBE WATER
BLOCKING SYSTEM
ITEM SPECIFICATION SPECIFICATION
Fiber Count 6/12/24F
Single Mode Multi Mode
Tube Filling Compound Thixotrophic Jelly Thixotrophic Jelly
Central Strength Member FRP Rod Steel Wire
Cable Filling Compound Thixotrophic Jelly Thixotrophic Jelly
Core Wrapping Polyester Tape Polyester Tape
Armouring Corrugated, Chrome Plated (ECCS), Corrugated, Chrome Plated
Steel tape (ECCS), Steel tape
Outer Sheath HDPE Outer sheath, Black HDPE Outer sheath, Black
Rip Cords 3 Ply rip cord 3 Ply rip cord
Attenuation (dB/Km) At 1310 nm 0.36 dB/Km At 850 nm 3.0 dB/Km
At 1550 nm 0.23 dB/Km At 1300 nm 1.00 dB/Km
Cable Bending Radius 20 x Cable Diameter 20 x Cable Diameter
Repeated Bending 30 Cycle, r20 x D 30 Cycle, r20 x D
Tensile Force 1000 N Long Term 1000 N
Short Term 2000 N Short Term 2000 N Short Term 2000 N
Torsion Resistance 10 cycle (180), L2 Mtr 10 cycle (180), L2 Mtr
Crush Resistance 2000N/100mm x 100 mm for 60 secs. Long Term 1000 N / 10CM
Short Term 2000 N / 10CM Short Term 2000 N / 10CM Short Term 2000 N / 10CM
Operation Temperature (C) -40 to 70C -40 to 70C
Storage Temperature (C) -40 to 70C -40 to 70C
Laying and Installation Temperature (C) -20 to 60C -20 to 60C
Nominal Cable Weight (Kg/Km) 120 10 120 10
Nominal Cable Diameter (mm) 10.50 0.5 10.50 0.5
Standard Length per Drum (Mtr) 2000 10 2000 10
PART CODE DESCRIPTION
3C-XXYYY-LTTW-ZZ Outdoor Armoured Fiber Optic Cables-Loose Tube (Std Pkg-2Km/Reel)
3C-XXYYY-MTTS-ZZ Outdoor Armoured Fiber Optic Cables-Multi Loose Tube (Std Pkg-2Km/Reel)
XX-(SM or MM) ZZ-(02- 2 core, 06- 6 core, 12-12 core, 24- 24 core)
YYY-(OS2-9/125 micron single mode and OM1,OM2,OM3,OM4 50/125 micron multi mode YYY-(OS2-9/125 micron single mode and OM1,OM2,OM3,OM4 50/125 micron multi mode
22
23
FIBER OPTIC SOLUTIONS
Outdoor Armoured Fiber Optic CableDirect Burial
  • Single Mode/Multi-mode Multi Loose Tube, Double
    Sheath Armored optical fiber cable is suitable
    for direct Burial applications. We supply Loose
    Tube of 6 to 288 fiber cores. Fiber cable is
    perfectly suited for both gigabit Ethernet and
    10 gigabit Ethernet campus and backbone
    applications.
  • FEATURES
  • Excellent Anti-rodent perfor- mance
  • Excellent crush resistance
  • Direct-buried installation.
  • IEC 60794 -Compliant

TECHNICAL SPECIFICATION
ITEM CONTENTS VALUE VALUE VALUE VALUE VALUE
Fiber Count 6/12/24 48 72 96 144 288
Loose Tube No. of tubes fibers per tube 16, 26, 46 412 612 812 1212 2412
Outer Diameter (mm) 1.9 2.4 2.4 2.4 2.4 2.4
Central Strength Member Material Phosphate Steel Wire
Diameter (mm) 2.0 2.0 2.0 2.0 2.0 2.0
Coated CSM diameter (mm) - 2.6 2.6 4.2 7.4 4.8
Water Blocking Material Material Cable filling compound
Armor Material Corrugated steel tape
Anti-rodent armor Material Corrugated steel tape
Cable Diameter (mm) Approx 14.2 15.7 15.7 17.5 21.0 23.0
OPTICAL CHARACTERISTICS
PARAMETER PARAMETER G.652.D G.655 50/125 m 62.5/125 m
Attenuation _at_850nm - 3.0dB/Km 3.0 dB/Km
_at_1300nm - 1.0 dB/Km 1.0 dB/Km
_at_1310nm 0.35 dB/Km 0.40 dB/Km
_at_1550nm 0.22 dB/Km 0.23 dB/Km
Bandwidth _at_850nm - - 500 MHzKm 200 MHzKm
_at_1300nm - - 1000 MHzKm 600 MHzKm
Polarization mode dispersion Individual fiber 0.20 ps/vKm 0.20 ps/vKm - -
Design link value 0.1 ps/vKm 0.1 ps/vKm - -
PART CODE DESCRIPTION
3C-CTS53-WWXXX-MT-ZZ Fiber Optic Double Sheath, Direct Burial, Anti-rodent , Outdoor Armored Cable 3C-CTS53-WWXXX-MT-ZZ Fiber Optic Double Sheath, Direct Burial, Anti-rodent , Outdoor Armored Cable
C (F- FRP, S- Steel Wire) C (F- FRP, S- Steel Wire)
WW (SM-Single Mode, MM-Multi Mode) XXX (SM-OS2, MM-OM1, OM2, OM3, OM4) WW (SM-Single Mode, MM-Multi Mode) XXX (SM-OS2, MM-OM1, OM2, OM3, OM4)
ZZ (06-6 core, 12-12 core, 24-24 core, 48-48 core...) ZZ (06-6 core, 12-12 core, 24-24 core, 48-48 core...)
23
24
FIBER OPTIC SOLUTIONS
Indoor Fiber Optic Cable
  • FEATURES
  • Material of jacket Flame retardant polyvinyl
    chloride (PVC)
  • Low smoke zero halogen (LSZH) flame retardant
    polyolefin
  • Thermoplastic polyurethane (TPU)

Indoor Fiber Optic Cables are tight buffer
design, usually they consist of the following
components inside the cable, the FRP which is
non-me- tallic strengthen member, the tight
buffer optical fiber, the Kevlar which is used
to further strength the cable structure, making
it resist high tension, and the cable outer
jacket.
  • Environmental materials and mouse-proof
    materials are also used where there are environ-
    mental or special requirements, or other
    customized material.

ITEM SPECIFICATION SPECIFICATION
Single Mode Multi Mode
Core Diameter 9.0 0.2 50.0 0.2
Cladding Diameter 125.0 1.0 125.0 1.0
Coating Diameter 245 7um 245 7um
Fiber Count 6/12/24F 6/12/24F
Central Strength Member Kevlar Kevlar
Attenuation (dB/Km) At 1310 nm 0.4 dB/Km At 850 nm 3.0 dB/Km
At 1550 nm 0.3 dB/Km At 1300 nm 1.00 dB/Km
Cable Bending Radius 5 x Cable Diameter 5 x Cable Diameter
Repeated Bending 20D 20D
Tensile Force 200 N Long Term 200 N
Short Term 660 N Short Term 660 N Short Term 660 N
Crush Resistance 1000N Long Term 200 N / 10CM
Short Term 1000 N / 10CM Short Term 1000 N / 10CM Short Term 1000 N / 10CM
Operating Temperature -20C to 70C -20C to 70C
PART CODE DESCRIPTION
3C-XXYYY-TB-ZZ Indoor Fiber Optic Cables (Std Pkg-2Km/Reel) 3C-XXYYY-TB-ZZ Indoor Fiber Optic Cables (Std Pkg-2Km/Reel)
XX-(SM or MM) XX-(SM or MM)
YYY-(OS2-9/125 micron single mode and OM1,OM2,OM3,OM4 50/125 micron multi mode YYY-(OS2-9/125 micron single mode and OM1,OM2,OM3,OM4 50/125 micron multi mode
ZZ-(02- 2 core, 06- 6 core, 12-12 core, 24- 24 core) ZZ-(02- 2 core, 06- 6 core, 12-12 core, 24- 24 core)
24
25
FIBER OPTIC SOLUTIONS
Fiber Optic Patch Cords
Fiber Optic Patch Cord comprises of two tight
buffer fibers housed within a common outer
jacket in OM1, OM2, OM3, OM4 multimode and OS2
Single Mode variants. Both ends are terminated
with high performance hybrid or single
type connector comprising of SC, ST, FC, LC,
MTRJ, E2000 connector in simplex and duplex.
  • FEATURES
  • All Assemblies are machine polished providing
    highest quality
  • Compliant with telecordia GR-326 core, TIA/EIA
    IEC.
  • Available in PC, UPC, APC connectors with .9mm,
    2mm, 3mm sizes.
  • Duplex and Simplex versions, Uniform and hybrid
    patch cord versions available.
  • High return loss, Low insertion loss
  • High reliability, High temperature stability
  • All assemblies are factory testing
  • and comes with test reports.

ITEMS ITEMS SINGLE-MODE MULTI-MODE
Insertion Loss (in dB) 0.2 0.3 0.2 0.3
Return Loss (in dB) 45dB ( PC ), 50dB (UPC), 60dB (APC) 35dB 45dB ( PC ), 50dB (UPC), 60dB (APC) 35dB
Temperature (C) -4085 -4085 -4085 -4085
Repeatability (dB) 0.1 0.1 0.1 0.1
Durability (dB) 0.2 (1000 mattings) 0.2(1000 mattings) 0.2 (1000 mattings) 0.2(1000 mattings)
Cable diameter (mm) 3.0mm, 2.0mm 3.0mm, 2.0mm
Ferrule Material Zirconium Ceramic Zirconium Ceramic
PART CODE DESCRIPTION
3C-PCU-VVV-WWW-XXX-Y-ZZ Fiber Optic Patch Cord 3C-PCU-VVV-WWW-XXX-Y-ZZ Fiber Optic Patch Cord
U - (S-Simplex, D-Duplex) U - (S-Simplex, D-Duplex)
VVV - (OS2-9/125 micron Single Mode and OM1, OM2, OM3, OM4 -50/125micron Multi Mode) VVV - (OS2-9/125 micron Single Mode and OM1, OM2, OM3, OM4 -50/125micron Multi Mode)
WWW / XXX - (SCA-SC/APC Connector, LCA-LC/APC Connector, STA-ST/APC Connector, STP-ST/PC Connector, FCP-FC/PC Connector, SCP-SC/PC Connector, LCP-LC/PC Connector) WWW / XXX - (SCA-SC/APC Connector, LCA-LC/APC Connector, STA-ST/APC Connector, STP-ST/PC Connector, FCP-FC/PC Connector, SCP-SC/PC Connector, LCP-LC/PC Connector)
Y - (2-2mm, 3-3mm) ZZ - (0199 meters) Y - (2-2mm, 3-3mm) ZZ - (0199 meters)
Fiber Optic Pigtails
Fiber Optic Pigtails are used in permanent
connection between patch panel and incoming
cables. Pigtails are pre constructed with
connectors. Connector options
include SC, FC, ST, LC, MTRJ, E2000.These are
based on 900mi- cron tight buffered cores and
suitable for internal use only.
ITEMS ITEMS SINGLE-MODE MULTI-MODE
Insertion Loss (in dB) 0.2 0.3 0.2 0.3
Return Loss (in dB) 45dB ( PC ), 50dB (UPC), 60dB (APC) 35dB 45dB ( PC ), 50dB (UPC), 60dB (APC) 35dB
Temperature (C) -4085 -4085 -4085 -4085
Repeatability (dB) 0.1 0.1 0.1 0.1
Durability (dB) 0.2 (1000 mattings) 0.2(1000 mattings) 0.2 (1000 mattings) 0.2(1000 mattings)
Cable diameter (mm) 0.9mm 0.9mm
Ferrule Material Zirconium Ceramic Zirconium Ceramic
  • FEATURES
  • All Assemblies are machine polished providing
    highest quality
  • Compliant with telecordia GR-326 core, TIA/EIA
    IEC.
  • Available in PC, UPC, APC

PART CODE DESCRIPTION
3C-PTXXX-YYY-ZZ Fiber Optic Pigtail - 1.5 meters 3C-PTXXX-YYY-ZZ Fiber Optic Pigtail - 1.5 meters
XXX - (OS2-9/125 micron Single Mode and OM1, OM2, OM3, OM4 -50/125micron Multi Mode) XXX - (OS2-9/125 micron Single Mode and OM1, OM2, OM3, OM4 -50/125micron Multi Mode)
YYY - (SCA-SC/APC Connector, LCA-LC/APC Connector, STA-ST/APC Connector, STP-ST/PC Connector, FCP-FC/PC Connector, SCP-SC/PC Connector, LCP-LC/PC Connector) YYY - (SCA-SC/APC Connector, LCA-LC/APC Connector, STA-ST/APC Connector, STP-ST/PC Connector, FCP-FC/PC Connector, SCP-SC/PC Connector, LCP-LC/PC Connector)
ZZ - (0102meters) ZZ - (0102meters)
25
26
FIBER OPTIC SOLUTIONS
Fiber Optic Sliding Patch Panel 2 Cut out (Rack
Mountable)
  • 19 Rack Mount Fixed Option Fibre Optic Panels
    in 1U are available in pre-loaded configurations
    in ST, SC and LC in both Singlemode and
    Multimode to economically connect, protect and
    manage high density fibre counts at data centre
    and floor distributors. The Fibre Panels feature
    adjustable mounting brackets, cable management,
    cage nuts, numbered ports, splice management,
    fibre service loop, label holder and cable tie.
  • FEATURES
  • Available either loaded or unloaded
  • High quality construction and finish
  • Simplex or Duplex variants
  • Panels with numbered ports
  • Complete with Fibre manage- ment kit
  • Available in MM and SM
  • Coupling options FC, SC, ST, LC
  • Available in different sizes 1U, 2U
  • APPLICATION
  • Optical Access Network (OAN)
  • Data processing centers
  • Cable television (CATV)
  • Local area network (LAN)
  • SPLICE TRAY
  • Splice Tray is made of molded plastic.
  • Layered structure, easy to operate.
  • The capacity of splice tray for 24 fibers.
  • Reel has two using ways, one is semicircle.
  • The other is round fight,small and simple.
  • ADAPTER PLATE
  • All adapter are having Low insertion loss.
  • Compliant with telecordia GR-326-core,IEC,TIA/EIA
  • High Precision of Mechanical Dimensions
  • Available in Ceramic or PB Sleeves
  • Available in 3-8 Holes ( Accord- ing to the type
    of adapters)
  • Suitable for SC, LC, FC, ST Adaptors)
  • BLANK PLATE
  • Covers unused openings
  • Provides a neat and clean appearance
  • Allows space for future expansion

PARAMETER SPECIFICATION
Working Temperature -25C 40C
Storage Temperature -25C 55C
Relative Humidity 85 (30C)
Atmospheric Pressure 70 Kpa 106 kpa
PART CODE DESCRIPTION DESCRIPTION
3C-PPRM-02-1U 3C-PPRM-02-1U Fiber Optic Patch Panel (Rack Mountable)
3C-ST-ZZ 3C-ST-ZZ Splice Tray
ZZ 6,12,24 ZZ 6,12,24 ZZ 6,12,24
3C-AP-WWX-YY-ZZ 3C-AP-WWX-YY-ZZ Fiber Optic Adaptor Plates
WW- (BL-Single mode, BG-Multi mode) WW- (BL-Single mode, BG-Multi mode) WW- (BL-Single mode, BG-Multi mode)
X- (S-Simplex, D-Duplex) X- (S-Simplex, D-Duplex) YY-SC/LC/ST/FC ZZ- Port (3,6,12)
3C-BP 3C-BP Fiber Optic Adapter Plate Blank
