Types of Socket weld Fittings
Presented By
www.naturalsteels.com
2
About Socket weld Fittings
  • Threaded Socket Weld Fittings is generally used
    for ordinary piping in steam, water, oil, gas,
    etc and many other applications. Socket weld
    fittings are available in Class 3000, Class 6000
    and Class 9000 and can be made in a variety of
    sizes and shapes to match exact customer
    specification.

www.naturalsteels.com
3
45 Degree Elbow
  • Socket Weld 45 Degree Elbows are utilized to
    change the direction of flow in a piping system.
    The function of the 45 degree elbow is same as
    that of the 90 degree long radius elbow except
    that their centre to face dimensions is unequal.
    These 45 degree elbows are applied in areas where
    there is more spacing between the pipe
    orientation.

www.naturalsteels.com
4
90 Degree Elbow
  • A 90 Degree Socket Weld Elbow is used when a pipe
    is to be connected to a valve with a break
    in between. Socket weld 90 degree elbow fittings
    are used in a lot of different industries such as
    chemical processing, petrochemical, oil
    refineries, electronics, power plants, and many
    other sectors wherever a high-quality socket is
    required.

www.naturalsteels.com
5
Bushing
  • We have gained vast expertise in offering a
    better-quality range of Forged Socket Weld
    Bushing that is manufactured using top quality
    raw materials to be applied in various industrial
    applications. Our socket weld pipe fittings are
    made up of high-grade raw materials that are rust
    resistant and used for all mechanical sectors and
    workshop areas.

www.naturalsteels.com
6
Cross
  • Socket Weld Cross fittings are a pipe attachment
    in which a pipe is inserted into a recessed area
    of a valve, fitting or flange. These Socket Weld
    Crosses provide benefits like high leakage
    integrity and great structural strength. A team
    of diligent workforce is assembled to carry out
    the manufacturing process of this socket weld
    cross.

www.naturalsteels.com
7
Caps
  • Socket Weld End Caps is a type of pipe fitting is
    defined as a part used in a piping system.  They
    are widely used to close the ends of hydraulic or
    pneumatic pipes tubes. These socket weld
    fittings can be accessible in different
    stipulations of thickness and measurement. Our
    clients can take these end tops at ostensible
    rates.

www.naturalsteels.com
8
Tee
  • ASME B16.11 Socket Weld Tee is a good choice
    wherever the benefits of high leakage integrity
    and great structural strength are an important
    design consideration. Fatigue resistance is lower
    due to using of fillet welds and abrupt fitting
    geometry, but it is still the best choice as
    compared to other mechanical joining methods.

www.naturalsteels.com
9
Full Couplings
  • All couplings are rigorously tested to ensure the
    highest quality and endurance under extreme
    conditions. It is basically, a mechanical device
    that acts as a connector between the adjacent
    parts of an object. Full Couplings are without
    stops or ridges and they can be fixed anywhere
    along the pipe length for preventing any kind of
    leakage.

www.naturalsteels.com
10
Half Couplings
  • Socket Weld Half Coupling Fittings is a connector
    used to screw two pieces of pipe together using
    threaded rings. Socket Weld Half Coupling
    fittings are only threaded on one end and the
    other end is welded or otherwise fastened to the
    piping. They find various applications in the
    aerospace industry as connectors to pressurized
    fuel piping.

www.naturalsteels.com
11
Nipples
  • Nipples are inserted from the interior and passed
    out through the aperture and then welded to the
    outside of the chamber by an annular seam. Socket
    Weld Pipe Nipple are widely used in piping
    systems across major industries like
    petrochemicals, power generation, shipbuilding,
    dairy industry, breweries, wastewater treatment,
    pharmaceuticals.

www.naturalsteels.com
12
Union
  • Socket Weld Union is exported by us throughout
    the global market in different sizes, shapes,
    grades and specifications. It is a pipe
    attachment detail in which pipe is inserted into
    a recessed area of a Valve, fitting or flange. It
    used in low-pressure piping where it is required
    to dismantle the pipe often. A Socket Weld
    Union is a screwed joint design.

www.naturalsteels.com
13
