Ways to Carry Out a Clutch Repair in a BMW

1
Ways to Carry Out a Clutch Repair in a BMW
2
In BMW cars, clutch is either made of plastic or
thin metal, which do not withstand pressure and
friction.
3
So, there is more chance that you may be facing a
catch-22 with your BMW clutch.
4
Replacing clutch parts
5
A common cause of this catch-22 is the shift
fork pivot plastic pin which breaks easily,
leaving you with an inoperable clutch.
6
The logical solution to this is to replace it
with a brass AGA pin and be careful of the
fragile housing unit.
7
10 Steps for replacing the clutch
8
If you cannot merely repair parts, the clutch
needs to be entirely replaced. So, have a new
clutch kit ready and new transmission bolts
before beginning.
9
Step-1 After lowering the transmission from the
engine, remove the six 6mm Allen bolts from the
pressure plate in an alternating pattern.
10
Step-2 In the same way, unbolt the six T60 Torx
bolts from the flywheel and if the flywheel
surface is in good shape, you can leave it
installed avoiding a replacement.
11
Step-3 Remove and replace the pilot bearing by
using a bearing driver.
12
Step-4 Install and center the clutch disc by
removing the center bolt using the alignment tool.
13
Step-5 Next, install the pressure plate on the
alignment dowels which requires six new Allen
fasteners, tightened until pressure plate is
flush with the flywheel.
14
Step-6 And then remove the SAC lock by rotating
counterclockwise using a 14mm Allen and if the
SAC moves, use additional special tools to reset
the SAC feature of the pressure plate.
15
Step-7 Next, torque six new Allen fasteners
specified for your vehicle and then remove the
clutch disc alignment tool from the clutch disc.
16
Step-8 Then remove the throwout bearing, sliding
it off the transmission output shaft and release
the spring retaining clip to remove the clutch
fork from the bell housing.
17
Step-9 Next, replace the throwout guide bushing
by removing the four 10mm fasteners. Then install
a new clutch fork and throwout bearing with
proper alignment.
18
Step-10 Finally, reinstall the transmission by
sliding the transmission shaft into the clutch
until the bell housing is lined up flush with the
engine and tighten the bell housing fasteners.
19
If You Need Help
20
Repairing and replacing the clutch in a BMW is
not a simple task and you might need someone for
help.
21
If are in the San Fernando Valley or Los Angeles
County, CA, near Canoga Park or Woodland Hills,
be sure to check in with Euro Plus Automotive for
your BMW clutch repair.
22
We have years of experience working on European
vehicles, so our service technicians can provide
you the expert assistance and service.
