Title: Quick Guide to FRP Square Cooling Tower and Its Parts


1
Quick Guide to FRP Square Cooling Tower and Its
Parts
  • Submitted By Tower Tech Cooling Systems Pvt.
    Ltd

2
  • One of the most significant components of any
    industrial process is cooling towers. These
    open-topped, cylindrical, square, and tall
    structures bring down the water temperature used
    for industries or residential process.

SOURCE
3
How Cooling Tower Works?
  • At the inlet of the FRP square cooling tower, hot
    water enters and pump up to the header. This
    header has sprinklers and nozzles, which spray
    water and increase the surface area of water.
    Next, water enters PVC filling to reduce its
    speed. Simultaneously, at the top of the cooling
    tower, fans are used, which lift air from bottom
    to top.
  • Now, due to this slow speed and more water
    contact area, a good connection is formed between
    hot water and air. As a result, the water
    temperature is reduced through evaporation and
    cooled water is accumulated at the bottom of the
    tower, which is again used in the boiler.
  • For better comprehension, lets explore different
    types of cooling towers available today

4
Mechanical draft cooling towers
  • Mechanical draft cooling towers are equipped with
    fans or other similar mechanics that circulate
    air throughout the tower. Some of the usual fans
    used in these towers are centrifugal fans and
    propeller fans. Moreover, as these towers are
    more effective than natural draft towers, they
    can be used even inside the building.
    Unfortunately, they consume and cost more power
    compared with natural draft cooling towers.
  • The mechanical draft-cooling tower is categorized
    in further two types

5
Counter Flow Towers
  • These towers let the water flows downward with
    air moving upward to cool the air. Additionally,
    they are often more compact in footprint than
    their counterpart towers and are capable of
    saving energy in the end.
  • Cross Flow Towers
  • In the cross-flow tower, the hot water flows
    downward from distribution basins while the
    airflows horizontally through the cooling towers
    structure. Also referred to as tall towers,
    theyre less efficient and more prone to freezing.

6
Natural draft cooling towers
  • The name itself explains that the FRP cooling
    tower depends on natural convection. Responsible
    for circulating air throughout the tower, the air
    movement inside the system occurs due to
    different density of internal air and the air
    entering the system.

7
Different Parts of Cooling Tower
  • Eliminator It does not allow the water to pass,
    as its located at top of the tower, from which
    only hot air can cross.
  • Float Valve It is used to maintain a level of
    water.
  • Spray Nozzles and Header Responsible for
    increasing the rate of evaporation, the component
    increases water surface area.
  • Body made up of fiber reinforced plastic, its
    outer surface often protects the internal parts
    of the cooling tower.

8
  • PVC Falling Similar to a beehive, it reduces the
    falling speed of hot water.
  • Mesh It uses atmospheric air containing dust
    particles when a fan is switched on. Stopping the
    particles from entering the cooling tower, the
    mesh makes the functioning smooth.
  • Bleed Valve It is used to control the
    concentration of minerals and salt.

9
Experts Advice
  • To wrap up, if you are aiming for a long time
    investment in cooling towers with reasonable
    rates, consult great cooling tower suppliers and
    get the service worldwide.

SOURCE
10
  • Tower Tech Cooling Systems Pvt. Ltd

11
Thankyou
