Title:

Importance of Cable Verification, Qualification and Certification

Description:

Verification testing answers this question. For copper cabling, these simple-to-use, low cost tools perform basic continuity functions such as wire map and toning. Wire mapping will tell you that each pair is connected to the right pins at plugs and jacks with good contacts in the terminations, while toning is used to help identify a specific cable in a bundle or at the remote end. Some verification testers like Fluke Networks' MicroScanner2 Cable Verifier include a Time Domain Reflectometer (TDR) feature to help determine the distance to the end of a cable or a trouble spot. It can also detect if a switch is connected to the cable under test.  – PowerPoint PPT presentation
