Therma Trucks Products - Cool Storage

1
THERMA TRUCK

• Therma Trucks Products - Cool Storage

2
Our Cold Storage Products

• CY25T 2.5M 2 PALLETS.
• CY30N 3.0M NARROW.
• CY33N3 3.3M NARROW.
• CY33W3 3.3M 4 PALLETS.

3
Cool Club- CY25T 2.5M 2 PALLETS.

• Body Dimensions
• WIDTH 1850 mm
• INTERNAL HEIGHT 1200 mm
• PALLET LOADING 2 Pallets Capacity
• APPROX WEIGHT 561kg
• LENGTH 2495 mm
• Panels
• Side Door Single 750 x 1100 mm, Opens to left
• Rear Door Double Doors - left open first
• Rear Step 50mm deep rear step finished with
  checker plate
• Floor Heavy duty fully welded extruded
  aluminium H floor, 200 mm aluminium extruded kick
  plate

4
Cool Club- CY30N 3.0M NARROW.

• Body Dimensions
• WIDTH 2100 mm
• INTERNAL HEIGHT 1780 mm
• PALLET LOADING 2 Pallets Capacity
• APPROX WEIGHT 1000 kg
• LENGTH 3050 mm
• Panels
• Side Door Single 750 x 1100 mm, Opens to left
• Rear Door Double Doors - left open first
• Rear Step 150mm deep rear step finished with
  shoring bar in holder
• Floor Heavy duty fully welded extruded
  aluminium H floor, 200 mm aluminium extruded kick
  plate
• cargo track Stainless steel, 1 row of _at_ 750 mm
  with shoring bar in holder

5
Cool Club-CY33N3 3.3M NARROW.

• Body Dimensions
• WIDTH 2300 mm
• INTERNAL HEIGHT 2050 mm
• PALLET LOADING 2 Pallets Capacity
• APPROX WEIGHT 1110 kg
• LENGTH 3300 mm
• Panels
• Side Door Single 750 x 1100 mm, Opens to left
• Rear Door Triple Doors - Middle 750mm, opens to
  left
• Rear Step 150mm deep rear step finished with
  checker plate
• Floor Heavy duty fully welded extruded
  aluminium H- floor, 200mm aluminium extruded kick
  plate
• cargo track Stainless steel, 1 row of _at_ 750mm
  with shoring bar in holder

6
Cool Club-CY33W3 3.3M 4 PALLETS.

• Body Dimensions
• WIDTH 2500 mm
• INTERNAL HEIGHT 1900 mm
• PALLET LOADING 2 Pallets Capacity
• APPROX WEIGHT 1249 kg
• LENGTH 3300 mm
• Panels
• Side Door Double 1400x 1800 mm, Opens to right
• Rear Door Triple doors- Middle 800mm, opens to
  Left
• Rear Step 154mm deep rear step finished with
  checker plate
• Floor Heavy duty fully welded extruded
  aluminium H floor, 200mm aluminium extruded kick
  plate
• cargo track Stainless steel, 1 rows of _at_ 750mm
  with shoring bar and holder

7
CONTACT US

• Phone No- [phone]
• Email- info_at_thermatruck.net.au
• Address- 61 Long Street, Smithfield, NSW,
  2164
