Varieties of Ultrasonic Hardness Tester at Sinowon

1
Welcome to Sinowon Innovation Metrology
Manufacture Limited
2
About Us
Founded in 2010, we Sinowon Innovation Metrology
Manufacture Limited devote ourselves to material
testing with quality from start to finish.
Integrated with brilliant Research Development
talents, and productive stuff, SINOWON team comes
to a formation full of ambition as well as
responsibility, committed to Sales and Marketing,
Technical Service. We think with customer as the
start point, manage corporation with motto
Satisfaction, Innovation, Norm, Obligation,
Worth, Openness, Nimble, focus on R D and
management to provide excellent quality and
service.
Sinowon.com
3
SINOWON is specialized in Optical Instant Video
Measuring Machine, Profile Projector, Manual /
Fully-auto Video Measuring Machine, Toolmaker
Microscope, Video Measuring Microscope,
Metallurgical Microscope, Stereo Microscope, etc
as well as Digital Rockwell Hardness Testers,
Automatic Vickers Hardness Tester, Digital
Brinell Hardness Tester, Non-destructive
Ultrasonic Hardness Tester, Portable Universal
Dynasonic Hardness Tester, etc. All of our
products get ISO9001 certified, CE EU
certification, widely used in machinery, mold,
metal, rubber, , connectors, household
appliances, printed circuit boards, medical
equipment, so on.
Sinowon.com
4
Hardness Testing Instrument
SINOWON offers wide range of Hardness Testing
Instrument like benchtop and portable durometer,
like Rockwell hardness tester, Brinell hardness
tester, vicker hardness tester and Micro hardness
tester and Ultrasonic hardness tester,UCI and
portale Leeb hardness tester.
Sinowon.com
5

• Accessories of Hardness Tester
• Hardness Indenter
• Clamps Of Hardness Tester
• Standard Hardness Blocks
• Others Accessories

Sinowon.com
6
Vision Measuring Machine
Checkout wide range of CNC Vision Measuring
Machine including 2.5D Laser-Scanning Auto Vision
Measuring Machine MVL Series, Super Large Travel
Automatic Vision Measuring Machine, Automatic
Vision Measuring Machine, 3D Fully Auto Vision
Measuring Machine MVH Series and more.
Sinowon.com
7
2.5D Laser-Scanning Auto Vision Measuring Machine
MVL Series
MVL is a Fully Auto Vision Measuring Machine for
vision measurement with laser scanning function,
it has four-axis auto motorized control, the
standard coaxial motorized detent zoom lens and
laser scanning probe is able to meet with
different applications. It is widely used in
Metal mold, electronic industry, medical
equipment and flat panel display industry, as
well as 3C research institutes, colleges and
universities, metrology institutions and
dimension inspection on production line.
Sinowon.com
8

• Super Large Travel Automatic Vision Measuring
  Machine
• Moving gantry structure, measurement workpiece is
  fixed
• Four-axis CNC fully auto close loop control, auto
  measurement
• 00 grade JINANQINGmarble base and pillar,
  stable and reliable
• Imported open type linear scale, resolution is
  0.001mm, high accuracy, great stability
• Imported P grade linear guide, precision grinding
  ball screw and AC servo motor, ensure accuracy
  stability of system  position
• Imported high definition color industry camera,
  ensure clear observation and stable measurement
  requirement
• 6.5X continue auto zoom lens, precision auto
  zoom, only need to make pixel calibration once
  time

Sinowon.com
9

• Programmable 5-ring 8-division LED surface
  illumination, contour parallel LED illumination,
  can realize 256 grade brightness adjustment
  intelligently
• With proprietary fully auto measuring software
  iMeasuring 4.1, powerful function, simple
  operation
• Optional laser probe, it can also be customized
  according to customer request
• Optional FexQMS Measuring Data Analysis and
  Real-time monitoring software which enhance
  program control and reduce material consumption.

Sinowon.com
10
Our New Products
Sinowon.com
11
Ultrasonic Hardness Tester
Get Ultrasonic Hardness Tester and more Hardness
Testing Instruments like Worm UCI hardness
Tester, Extended Manual Probe Ultrasonic Hardness
Tester, Roller Ultrasonic Hardness Tester,
Motorized Ultrasonic Hardness Tester and more
online.
Worm UCI Hardness Tester SVR-110 SVR-110H
specialized to test worm, screws, threaded rod,
bolts, etc with the hardness scales of HRC and
HV.

• High AccuracyHV 3 HV,HR1.5HR, Conform
  internal standard ASTM A1038.
• Microscopic IndentationNeed 500X metallurgical
  microscope to observe indentation.
• Qucik MeasurementIn 2 seconds to get hardness
  value, working efficiency is 60 times higher than
  normal bench hardness testers.

Sinowon.com
12
Roller Ultrasonic Hardness Tester This is used
to determine hardness of chrome which painted on
rotogravure cylinders with simple, fast and
accurately method. Hardness test in Vickers have
the advantage that are supposed to be
non-destructive as the lasting surface
indentation is microscopically small.
Sinowon.com
13

• Perfect Accuracy3 HV, 1.5HR, 3HB.
• Microscopic Indentation Only high-power
  microscope can observe the indentation.
• Quick MeasurementResult in 2 seconds.
• Large LCD DisplayDirectly display measurement
  result, times count, maximum, minimal, average
  and deviation.
• Friendly OperationOperate well after short
  training.
• Promised Warranty2-Year warranty for main unit
  (Excludes Probe).
• Mass StorageSave 1000 groups measurement data.
• Simple CalibrationSave 20 groups calibration
  data for invoking, improve calibration efficiency.

Sinowon.com
14
2.5D Laser-Scanning Auto Vision Measuring Machine
MVL Series

• Introduced latest ultrasonic sensor technology
• Obtain accurate hardness value without auxiliary
  devices
• Excellent human engineering design easy to hold
• Quick and accurate measuring for edge and fixed
  position of specimen
• Micro indentation, non-destructive for specimen
• Motorized control, one key fast measuring
• Eliminate hand shake error by manual probe,
  higher accuracy and repeatability
• More suitable for thin pieces, coating layer
  hardness

Sinowon.com
15
Contact Us
A1, KaiSong Park, 2 Baima Xianfeng Road, South
District, DongGuan, Guangdong, China (523080)
