eGauge Energy Monitor

• Solar energy monitoring

2
eGauge Energy Monitor

• The eGauge Energy Monitor is a flexible, secure,
  web-based electric energy meter that measures up
  to 12 circuits on up to 3-phases (120V-480V,
  50-60Hz). You can use the eGauge to measure and
  record building electrical consumption, solar,
  wind and other electricity generation, and
  consumption of individual circuits, such as
  equipment, pumps, motors, EV charging and
  heaters. The data can be viewed on any web device
  through the in-built web-server. The display
  updates every second, giving direct feedback on
  any load or generation changes. It records the
  most recent 30 years of data in the built-in
  solid-state memory.

3
As eGauge's distributor for Australia, BCJ
Controls supplies the eGauge as a stand alone
unit. It can also be embedded within one of
our Grid Protection Units. Call 02 9534 8465 for
details.
4
Benefits

• Monitor Performance of a Solar Installation
• Consumption vs. Production
• Monitor system health
• Operation and Maintenance Contracts

5
Monitor Performance of a Solar Installation

• Track your production and compare it to your
  expected renewable energy generation, helping
  users achieve lower energy consumption, maximize
  payback, and lower their monthly electricity bill.

Monitor system health

• Using an eGauge to monitor your installations,
  you can observe a change in production over time.
  This allows you to contact your users when they
  require panel cleaning, or if there is some
  reason the system can be maintained (tree shade,
  faulty inverter etc.).

6
Consumption Vs Production

• With CTs installed on the site load, you can see
  how much power is being consumed and compare it
  against the solar production. Up to 12 CTs can be
  installed so other circuits can be monitored.

Operation and Maintenance Contracts

• Using an eGauge to monitor your installations,
  you can observe a change in production over time.
  This allows you to contact your users when they
  require panel cleaning, or if there is some
  reason the system can be maintained (tree shade,
  faulty inverter etc).

7
eGauge Web Interface

• With the eGauge you can login remotely through
  the app. The interface shows current consumption
  and generation info with a live, high-res graph.
  The left segment of the graph displays recent
  historical data (most recent 24 hours in the
  example below), whereas the right segment is a
  gauge that is updated each second and shows
  current generation (green) and consumption (red).

8
(No Transcript)
9
EGAUGE EG3000-016 SPECificationS

• 1 Accurate (Compliant to ANSI C12.1)
• Solid State Memory Records
• 1 second granularity for 10 minutes
• 1 minute average for 1 year
• 15 minute average for 30 years
• Up to 12 Circuits on 3-phases (120V-480V,
  50-60Hz).
• 3 N Voltage Inputs to measure reactive power.

10
EGAUGE EG3000-016 SPECifications

• Data can be accessed on a remotely through the
  in-built web-server. The online display is
  updated every second, giving instant data on any
  load or generation changes. It records the most
  recent 30 years of data in the built-in
  solid-state memory.
• Web connection - ethernet required (another model
  is available which uses ethernet over power -
  call for details)
• This unit requires specific CTs to function. Get
  in contact for advice on the ideal set up.

11
For cost/pricing and support call us on 02 9534
8465 or Email contact_at_bcjcontrols.com.au
