Title: Basics Details About PCC Panel & MCC Panel


1
Basics Details About PCC Panel MCC Panel
  • By Accu-panels Energy Private Limited

2
MCC Panel
  • A motor control center (MCC Panel) is an assembly
    of one or more enclosed sections having a common
    power bus and principally containing motor
    control units.
  • Motor control centers are in modern practice a
    factory assembly of several motor starters.
  • A motor control center can include variable
    frequency drives, programmable controllers, and
    metering and may also be the electrical service
    entrance for the building.

3
MCC Panel
4
Voltage ranges
  • MCC Panel are generally utilized for low voltage
    three-stage substituting current motors from 208
    V to 600 V.
  • Medium-voltage motor control centers are made for
    substantial motors running at 2300 V to around
    15000 V, utilizing vacuum contactors for
    exchanging and with isolated compartments for
    power exchanging and control.

5
Usage
  • Motor control centers have been utilized since
    1950 by the vehicle manufacturing industry which
    utilized extensive quantities of electric motors.
  • Today they are utilized as a part of numerous
    modern and business applications.
  • Where exceptionally dusty or destructive
    procedures are utilized, the motor control center
    might be introduced in a different aerated and
    cooled room, yet regularly a MCC will be on the
    factory floor adjacent to the machinery
    controlled.

6
PCC Panel
  • The PCC panel will experience pretreatment for
    Decreasing, Water washing and De-rusting/Phosphati
    ng, It will be Painted with Powder Coated or
    Synthetic veneer according to the prerequisites.

7
Specifications
  • Rated Current up to 4000 A
  • Fault Level up to 65 kA for 1 Sec.

8
Construction of PCC Panel
  • Construction of Panel Form 3B/4A/4B
  • Bus bar Aluminum or Copper
  • Type of Starter DOL Starter / Soft starters
    /Star Delta Starters / ATS Starters / VFD's /
    Single Front / Double Front
  • Construction of panel including 4a (types 1, 2
    and 3) and 4b (types 5, 6, 7 and 8)

9
Contact Us For More Details
Office Works. Plot No.67/1, Road No.-6,Kathwada
GIDC,Odhav, Ahmedabad-382430. Ph 079
22900057 M 91-9099927392 Mail
us  panels_at_accupanels.com
goni2014_at_gmail.com        www.accupanels.com
10
Presentation By Accu-panels Energy Pvt. Ltd.
