THERMO HYGROMETER by Meco (1) - PowerPoint PPT Presentation
Title:
THERMO HYGROMETER by Meco (1)
Description:
THERMO HYGROMETER is a portable easy use and compact digital designed for simple one hand operation. It uses thermistor as temperature sensor, and a digitalized humidity sensor as the hygrometer sensor with excellent long term stability.Humidity measurement is shown on upper display and temperature in lower display. know more about this product visit – PowerPoint PPT presentation
Number of Views:47
Title: THERMO HYGROMETER by Meco (1)
1
Thermo Hygrometer
http//www.mecoinst.com/
2
Thermo Hygrometer
3
MODELS 920 - Thermo Hygrometer
- Sensor Digital Capacitive Humidity Sensor
- Accuracy 2.5 for 10 - 90 RH, 5 for 0-10
RH, 90-100 RH - Sensor Hysteresis 1 RH Typical
- Range -20C to 60C (-4F to 140F)
- Resolution 0.1C / F
- Sp. Function HOLD / MAX / MIN / MAX-MIN / AVG /
APO - Range 0 to 100 RH
- Sensor Response Time for 90 of Total Range 60
Sec Typical - Sensor Thermistor Temperature Senso
- Accuracy
- 0.5C for 0C to 45C,
- 1.0C for -20C to 0C, 45C to 60C,
- 1.0F for 32F to 113F,
- 2.0F for -4F to 32F, 113F to 140F
4
Contact Us
- MECO INSTRUMENTS PVT. LTD
- Plot No. EL-60, MIDC Electronic Zone,
- TTC Industrial Area, Mahape,
- Navi Mumbai - 400710 (INDIA)
- Tel 0091-22-27673311-16,(Board)
- Fax 0091-22-27673310, 27673330
- E-mail sales_at_mecoinst.com
- Web www.mecoinst.com
5
Thank You!
