Conveyor Belt Accessories - Some Basic Facts

1
CONVEYOR BELT ACCESSORIES SOME BASIC FACTS
2

• Belt Conveyor Systems have been recognized as one
  of the most reliable and cost effective ways to
  transport bulk materials from one point to
  another. However a poorly designed and maintained
  conveyor system can quickly erode those savings,
  with excessive spillage which consequentially
  leads to a number of perils within the conveyor
  system resulting in lower efficiency as well as
  monetary losses.
• At TEGA, our history of relevant experience and
  technical competence provides a systematic
  approach to improve the efficiency of your
  operations by reducing both direct indirect
  operational costs and further solving complex
  material spillage issues. Our trained team can
  recognize the visible as well as non-visible
  factors that cause the material spillage and then
  provide the solutions superior engineering
  products through our SMP program.

3
Application Area

• Loading Zone of Conveyor  For leakage from the
  chute walls, improper dust suppression system and
  improper Sealing at Skirt Area.
• Skirt Sealing System Spill-Ex
• Impact Pads Friflo
• Ceramic Pulley Lagging
• Universal Support Pad
• During Conveying  For spillage due to sway of
  belt and overloading of conveyor.
• TruTrac Rollers
• At the Discharge Location  For chocking and
  overflowing of chute and Ineffective removal of
  carryback from return belt.
• Belt Scrapers HOSCH

4
Design Excellence

• 3D Modeling of all the product
• Design optimization using FE analysis.
• Weight Power optimization.
• Failure analysis
• Stress analysis in the conveyor structure because
  of any modification made to make it Spillage
  free.
• Identification of construction and design
  deficiencies in conveyor systems and catalyze
  fresh improvements in existing design to make it
  Spillage Free, Maintenance Free Power Optimized.

5
Calculation
6
(No Transcript)
7
(No Transcript)
8
Products
Tracker Roller
Universal Support System
Ceramic Pulley Lagging
Spill-Ex Skirt Sealing System
Friflo Impact Pad
9

• Thank You..
