Beginner Guide - How to Fly a DJI Phantom Drone Camera

1
(No Transcript)
2

•

In the past few years, many professionals
have started flying drone cameras for aerial
photography and videography. But flying a drone
is not easy for beginners one should follow
instructions carefully while flying a drone
camera. So, here are few very important
instructions enlisted
3
Step 1 connect your propeller with a drone

• Insert the black propeller with the black ring
  the white propeller with the
• white ring. Dont push too hard while inserting
  propeller in drone ring. If
• youre using much force while pushing, it may
  result in damaging the
• motor.

4
Step 2 Insert battery in your quadcopter/Drone

• Always check that your battery pin has bottom end
  switch on/off button
• towards right hand side. Charge your battery 100
  before flying a drone
• camera because the life cycle of charged battery
  would be 15-20 minutes
• only, so be careful.

5
Step 3 Insert memory card in your Drone camera

• Always remember, your card pin must be upper side
  dont forget to
• format your memory card before you start to
  flying drone. You can format
• memory card through your phone using the app. It
  is always advisable to
• carry spare memory cards.

6
Step 4 Install DJI App in your iPad/android
mobile phone

• Firstly, connect your iPad/mobile phone with
  remote. Before using drone,
• always put your mobile on aeroplane mode. If you
  dont do that, you might
• get a call while flying and consequently
  connection could be lost.

7
Step 5 Now choose a takeoff location (preferably
open area/ground)

• Always remember cameras face should be opposite
  to your position.
• Keep in mind, if in any case, the camera faces
  the operator all the
• controls of remote will be reversed. Avoid
  accident by not flying drone in a
• closed space or stormy weather. Always look for
  an open space for flying.

8
Step 6 Switch ON the drone power by pressing the
battery button twice

• Always check twice that your phone and drone
  remote work properly
• before you start to flying drone. Dont take risk
  of flying a drone if battery
• isnt fully charged. Uncharged batteries often
  result in crash landing.

9
Step 7 Pull both the joysticks downwards to
start the propeller

• Your rotary wings spin in opposite direction.
  Now, you are ready to fly your
• drone camera. Once the drone has started flying
  make sure, there is no
• sound other than motors. Also, check if there is
  any error message on the
• phone screen.

10
Step 8 To go up down, push left joystick up
down

• To fly a drone, keep moving the joystick to the
  left side. Avoid pushing
• joystick with jerk. If there are jerks while
  using joystick, there can occur
• problem with motor system. To move/rotate drone
  camera towards left
• right, push left joystick left right.

11
Step 9 To go front back side, push right
joystick up down. For left right movement,
push the right joystick left right

• Make sure, drone is there in front of your eyes.
  Its direction shouldnt be
• changed at any point of time.

12
Step 10 For landing, pull down the left joystick
slowly

• Always avoid high-speed landing. Before the drone
  touches the surface,
• release the joystick to the center gently pull
  down the left joystick for a
• smooth landing. To turn off the motor/propeller,
  pull down the left joystick
• hold for 3 seconds. After rotary wings are
  stopped, switch off the battery
• remote by pressing their button.

13
