Title: EDUMR Educational MRI System


1
EDUMR Educational MRI System
  • NMR Device for Physics, Medical imaging,
    Radiology Course

2
EDUMR desktop NMR device
  • EDUMR is a desktop NMR device designed for MRI
    experimental teaching. Courses to teach NMR
    principles and experiments through MRI
    demonstration can be created by including EDUMR
    in physical corresponding majors (modern physics,
    applied physics, radio physics, electronic
    engineering, etc.) or medical corresponding
    majors (large-scale medical apparatus, medical
    imaging technology, biomedical engineering,
    etc.). Extensive experimental courses and majors
    like NMR engineering related to hardware
    structure can also be established with through
    the use of EDUMR.

3
EDUMR
4
Basic parameters
  • 1.Permanent magnet
  • 2.Magnetic field intensity 0.50.08T
  • 3.Probe Size Ø15mm

5
MRI experiments
  • Spin-echo sequence MRIPD(portion density)/T1/T2
    weighted imaging(Spin-echo sequence)ID gradient
    encoding imagingInversion restoring sequence
    MRI2D gradient echo sequence MRIEffect of
    parameter setting on image size and shape3D echo
    sequence MRI

6
Application Case 1
7
Application Case 2
8
Contact Us
  • Email info_at_niumag.com
  • Phone 86 15618809683
  • Web www.nmranalyzer.com

9
  • Thank you!
