Diffrence Between 2D, 3D, 4D, and latest 5D Ultrasound Machine

1
Difference Between 2D, 3D, 4D and latest 5D
Ultrasound Machines
2
Introduction
Introduction

• Ultrasound scanning is an essential clinical
  tool which provides images of the fetal internal
  anatomy. Sometimes it is also referred to as
  Sonography because it relies on high-frequency
  sound waves to generate cross-sectional slices
  through the body. A probe or transducer is coated
  with a scant layer of conductive gel and placed
  directly on the skin. It emits ultrasound waves,
  and the gel ensures that the waves pass smoothly
  via the skin. Ultrasound waves are reflected by
  various structures that it encounters.

3
Introduction
Advantages

• It uses real-time visualization to view the
  organs and the fetus.
• It is non-invasive.
• It does not rely on ionizing radiation, which is
  harmful to the embryo.
• Ultrasound imaging is interactive because the
  operator can capture numerous viewing planes by
  maneuvering the probe.

4
Introduction
2D Ultrasound

• It is the traditional ultrasound scanning. It
  means the probe sends and receives ultrasound
  frequency waves in one plane. Waves which are
  reflected back are black-and-white images of the
  fetus in a flat plane. The ultrasound transducer
  Toshiba is moved across the stomach to enable
  numerous viewing planes.

5
Introduction
3D Ultrasound
More advanced development of imaging
technology has promoted volume data or differing
two-dimensional images which are created by
reflected waves at angles which differ from one
another. High-speed computing software then
integrates this information to create a 3D image.
6
Introduction
4D Ultrasound
This Ultrasound technology enables live
streaming of 3D images. In other words, patients
can view the live motion of the fetal valves,
heart wall blood flow, etc. 4D ultrasound
technology is 3D ultrasound in motion. A 3D
transducer is utilized. GEsVoluson E10 4D
ultrasound machine enables you to see moving
images of the various organs in the fetus.
7
Introduction
5D Ultrasound
Currently, Samsung is the main player in the 5D
ultrasound technology arena. Their ultrasound
portfolio includes the Samsung WS80A Elite. 2D
ultrasound captures axial images, whereas 3D
relies on volume. 4D images combine volume and
time while 5D attempts to bring a new level of
workflow, which borders on automation.
8
Introduction
Contact Us

• Enterprise Ultrasound
• Lake Forest, California , United States
• (949)3050683
• sales_at_enterpriseultrasound.com
• www.enterpriseultrasound.com
