Title: PCB Assembly


1
PCB Assembly
2
Prototypes and NPI Assembly
  • Here to get a successful
    prototype assembly often requires a greater
    attention to detail than a production build.
  • Our dedicated NPI team works are very closely
    with the project manager.
  • And customers throughout the entire process that
    is to ensure on a exact time delivery.

3
  • Here our stand alone prototype and very low
    volume surface mount production line is
    configured for very rapid production of all the
    batches.
  • Here they are utilizing specially designed for
    the cut tape.
  • All the components do not have to be supplied on
    the reels.
  • Whether it is complex double side SMT board or
    the conventional through hole technology.

4
(No Transcript)
5
  • PCB Manufacturer

6
  • In only a day or two triode can subject to
    material availability and capacity to produce one
    off and 50 off.
  • From the time we receive the bare PCBs and
    components in less than eight hours.
  • In triode our team of skilled individuals,have
    been known to complete prototype boards.

7
  • Here Flexibility to do a machine loading versus
    hand loading is also very important.
  • At a times it may be very easier, very faster and
    more cost effective to partially hand load the
    project. In this way the fine pitch devices and
    the high component count parts are placed the
    coordinates and the orientations.

8
  • Here you can get the PCBs fabricated on a panel
    sharing service.
  • We can also perform a stencil sharing also.Which
    you may only use once rather than paying full
    price for a stencil.
  • According to the area required this will be
    charged.Here we keep your development costs to a
    minimum this is just one of the way.

9
  • Thank YOU
