Title: Palletizing System


1
Variety Of Palletizing Systems In Singapore
2
Feige Filing has been certified as per DIN EN ISO
9001 since April 1993. Before that, since
beginning of 2002, they have been certified as
per EN ISO 90012000. Also, all their machines
systems bear the CE sign to specify the
compliance with European guidelines. They offer a
wide variety of liquid and pastry filing
products. One of which is the Palletizing System.
3
Under this system, they provide a range of
products that have been particularly designed to
meet the requirements of their customers. The
filing machines are available in a semi-automatic
and fully automatic variety. They offer complete
systems of automatic packaging which may consist
of a combination of filling equipment, conveyor
and palletizing system.
4
Some of the available palletizing systems offered
by Feige Filling are Push palletizer for drums
type FP-S, Vacuum palletizer for drums type
FP-VH, Push palletizer for containers type FP-SB,
Palletizing robot for drums, pails and containers
and Empty pallet magazines type LPM.
5
In Push palletizer for drums type FP-S, a motor
driven pusher pushes the containers on the plates
of the pallet row by row. These plates move above
and below the pallet. The pusher pushes the 1st
row of containers to the plate to its palletizing
position. The plate withdraws all containers by
the size of one row. The pusher returns to its
initial position.
6
In another type of the palletizing system called
the Vacuum palletizer for drums type FP-VH, a
gripper equipped with vacuum pads lifts up the
filled drums from the roller conveyor, row by
row, moves them over the pallet and then places
them down as per the pallet arrangement scheme.
7
Feige Filling offers a special palletizing
product called the Palletizing robot for drums,
pails and containers. This robot is useful for
palletizing containers of different sizes,
changing the pallet schemes, pallet sizes and
container arrangement on the pallet. This robot
is useful for arrangement of containers even on a
multi layered pallet system. The robot has 4 axes
and a sturdy base and is mounted on the floor
using the same.
8
It is flexible, forward-looking and an extremely
efficient solution which can perform about 500
cycles per hour. The demands of any palletizing
application can be met by just mounting different
palletizing tools onto the robot's wrist. The
required software will be configured as per the
application. The robot comprises of control
cables and compressed air hoses connected to
their wrist and base. As per the process, a
conveyor chain stores pallets with three layers
of empty drums.
9
Then the robot takes a pallet out of the magazine
and places it on the out-feed conveyor.
Similarly, the oval pails are filled and closed
on the filling line. Later, the robot palletizes
the pails as per pre-set pallet scheme. In this
system, combination tools with clamps, grippers,
suction pads and dedicated sensor technology
handle most of the different containers and
pallets.
10
The Empty Pallet Magazines Type LPM-2 is a system
on which 2-way pallets are placed. Of these. The
top pallet is lifted using forks and separated
from the bottom pallet. This bottom pallet is
then ready for transportation to the palletizer.
Similarly, in Type LPM-4 system, 4-four way
pallets are placed in the magazine.
11
To Order Find Out More Information On Palletizing
System Please Come And Visit Us Today Onwards..!
Feige Asia Pte Ltd. Contact Us No. 6 Loyang
Lane, 02-03 Singapore - 508920 Tel
6565464955 Fax 6565468870 Email
feigesgp_at_singnet.com.sg Web
http//www.feigeasia.com.sg/
