Title: Bunched Copper Wires -Ruling Roost in the Segment of High-End gadgets


1
Bunched Copper Wires Ruling Roost in the Segment
of High-End gadgets
2
Copper wires are the quintessential electricity
carriers of the modern era. It has been in use
for most of the 20th century and the 21st century
looks equally promising. The size of the machines
and electrical gadgets may have diminished but
the stature of the copper wires especially the
stranded copper wires and the bunched copper
wires have risen by more than 150 per cent in the
last decade alone.
3
Copper Wires and the Long-Distance Dilemma
  • Like most cables carrying electricity over
    long-distance, the copper wires too experience
    energy losses. The amount of insulation and the
    tire of stranded copper wire minimize the energy
    losses to a significant value.
  • For instance, a hundred meter long stranded
    copper wire will be rated with corresponding
    energy losses as EU loss per block of hundred
    metres.

The EU loss for the shorter length of stranded
copper wires and bare copper wires is rated zero
owing to the negligible heat dissipation.
4
The Magic of Tinned Bunched Copper Wires
  • Markets are full of cope wires that showcase
    shiny bunched copper wires rolled over wooden
    logs. The Bunched Copper Wires coated with tin
    have many benefits over the bare copper wires.
    Most noticeable of them is the reduced EU loss
    even across longer distances.
  • The benefits of the bunched copper wires coated
    with tin are as follows.

5
Better Conductivity
  • Tin is a good conductor itself. When the bunched
    copper wires coated with tin are used in
    electrical appliances and transformers, the
    efficiency of the gadget rises significantly. The
    heat dissipation from the bunched copper wires
    coated with tin is also lower as compared to that
    of the bare copper wires.

6
Best for Designing High-End Gadgets Installed in
Corrosive Conditions
  • The bunched copper wires lined by tin coating are
    an ideal for use in high-end gadgets installed in
    different mediums. It is a convenient option for
    the marine transformers and motors dipped in hot
    oil.
  • The bunched copper wires work well even in highly
    corrosive mediums of saline water and mildly
    acidic conditions.

7
Spin as Much you Want
  • The bunched copper wires with tinned coating have
    greater ductility. It makes them it for use in
    smaller circuits. Owing to the higher ductility,
    the Bunched Copper Wires are very much
    responsible for bringing the size of the gadgets
    considerably down by more than 400 percent.
  • Just grab your MP3 player and compare it with the
    cassette players 10 years back! Even the
    transformers are getting smaller with each
    passing day.

8
Easy Welding and Repair
  • Copper wires do snap at times. The sagging of the
    wires and breakage causes disruption in power
    supply and high-cost operations. The broken wires
    can be welded with stronger metals like Silver,
    Tin and Nickel.

9
Contact Ganpati Engineering
  • GANPATI ENGINEERING INDUSTRIES
  • Contact Person Mr. Gupta
  • Address Gokul Path, Vaishali Nagar, Jaipur -
    302021 (Rajasthan) India
  • Phone 91-141-2211977 (Office)
  • TeleFax 91-141-2219147 (Office)
  • Mobile 91-94140 48492 (Mr. Gupta)
  • Email ganpati_at_ganpatiengineering.com Web
    www.ganpatiengineering.com
