Title: All you need to know about v belt lathe machine


1
All you need to know about the V-Belt Lathe
Machine
http//www.jkmachinetools.com/
2
V-Belt lathe machines are ideally designed to
meet the specific requirements of different
industrial applications. These machines are
highly versatile and ideal for precise machining
of relatively hard objects. Moreover, the
unsurpassable performance and unmatched quality
has attracted various industrial sectors to place
repeated orders for the V-Belt driven lathe
machines.
http//www.jkmachinetools.com/
3
There are four types of V-belt lathe machine
  • Light Duty V-Belt
  • Medium Duty V-Belt
  • Heavy Duty V-Belt
  • Extra Heavy Duty V-Belt

http//www.jkmachinetools.com/
4
Some security facts of V-belt lathe machine
  • Store the belt in low humidity.
  • If water, oil, chemical, dust sticks to belt, its
    power transmission could deteriorate and the belt
    may fail.
  • Do not expose belts to direct sunlight.
  • Do not modify a belt, or its quality and
    performance could deteriorate.

http//www.jkmachinetools.com/
5
  • Install a safety cover over rotating components
    including belt.
  • Do not use a belt as a lifting or towing tool.
  • Pay special attention to bore processing which
    generates heat easily.
  • Use a soundproof cover if the cogged belt makes
    louder noise during high-speed rotation

http//www.jkmachinetools.com/
6
  • Safety to be considered while maintaining or
    replacing a belt
  • Turn off power and wait until the belt and
    pulley have stopped completely.
  • Secure machinery so that it may not move during
    belt removal.
  • Use caution do not unintentionally turn on
    power.
  • Take the following precautions to modify the
    pulley in use
  • Secure accurate dimensions after modification.
  • Remove burrs and maintain proper pulley angle.
  • Maintain the pulley strength after modification.

http//www.jkmachinetools.com/
7
http//www.jkmachinetools.com/
8
Benefits of V-belt lathe machine
  • The drive can be scuttled at high speeds on
    sheaves with velocity.
  • The drive is almost positive in nature since the
    slip is negligible due to wedging action.
  • Drive capability from 1 HP to over 1000 HP.

http//www.jkmachinetools.com/
9
  • Power transmission capacity of V-belt drive is
    more than that of a flat belt.
  • drive, for the same general characteristics.
  • As V-belt is endless, the drive is smooth and
    quite in operation, even at high speeds.
  • Manufactured to RMA standards.
  • In multiple V-belt drive failure of one belt will
    not cause the entire unit to stop.

http//www.jkmachinetools.com/
10
J.K. Machine Tools is a leading lathe machine
manufacturers in India. We are DGSD rate
contract holder in India provides lathe machines
to our clients at industry leading rates.
We are lathe machine exporter in India. We are
here in machinery industry since the last 17
years. If you want to get lathe machines for
your business, call us on (91 9374102450). You
can also email us at info_at_jkmachinetools.net.
FOR MORE INFORMATION
http//www.jkmachinetools.com/blog/
11
THANK YOU
http//www.jkmachinetools.com/
