water and wastewater treatment plant products

1
(No Transcript)
2
Dear Sir/ Madam we are an ISO 9001-2008
certified manufacturer.Supplier Exporter of
Environmental Plant products.For Sewage,
Effluent Ro plant products.1) BIO PAC MEDIA
(FAB MEDIA)( MBBR MEDIA). 2) FINE BUBBLE TUBE
DIFFUSERS (63DIA 90 DIA)3) COARSE BUBBLE DISC
DIFFUSER (80 DIA 150 DIA) 4) TUBE SETTLERS
(HEXAGONL SHAPED)5) FILL PAC MEDIA (FLOWER
MEDIA)6) FINE BUBBLE DISC DIFFUSERS (250 DIA
300 DIA) 7) FILTER PRESS8) AIR BLOWER9)
PRESSURE VESSELS Dear sir / madam are in
requirement of these Media's and DiffusersPlease
give our company a chance to serve you the
bestWith good Quality and good price.THANKING
YOUMr. MUNNI RAAJBAJRANG ENVIRO ENGINEERS (An
ISO 90012008 Certified Company) BALANAGAR
HYDERABAD 500042(M) 09912607343, 09296406158FAX
PHONE [phone]MAIL bajrangenviro_at_yahoo
.comWeb www.airson-ad.com
www.bajrangenviro.co.in
www.mbbr2diffuser.com
3
MBBR MEDIA,FAB MEDIA,BIO PAC MEDIA

• We are the leading manufacturer and supplier of
  MBBR Media. Our quality made us a leading
  company in india. We offer the 100 best quality
  products and with very competitive price.

MBBR MEDIA, BIO PAC MEDIA, (FAB MEDIA) MBBR MEDIA, BIO PAC MEDIA, (FAB MEDIA)
Type of Media MBBR, BIO PAC (FAB Media)
MOC OF MEDIA Polypropylene
SPECIFIC GRAVITY 0.9
SHAPE CYLINDRICAL
HEIGHT DIAMETER Dia 22mm x 16 mm height
PROTECTED SURFACE AREA 400 (M2)
TOTAL SURFACE AREA 450-475 (M2)
COLOUR Black
THICKNESS 1.0mm
MAX. CONTINUOUS WORKING TEMP 55C
4
TUBE SETTLERS

• With the use of excellence tested material and
  higher technology, we offer hexagonal shaped
  tubesettlers. Owing to their tongue groove
  arrangement, the products can be simply installed
  into the water treatment plants.These components
  are easy to install and offer a long service life.

TUBE SETTLERS (HEXAGONAL) SHAPE TUBE SETTLERS (HEXAGONAL) SHAPE
CROSS SECTIONAL AREA HORIZONTEL -120MM VERTICAL44MM
MOC OF MEDIA PVC
SHAPE OF TUBE HEXAGONAL
TUBE FITTING TONGUE AND GROOVE
THICKNESS 1.0MM (/- 0.1 MM)
MAX CONTINUOUS OPERATING TEMP 55 DEG. C
COLOUR Black
PLAN SETTLING AREA 11M2/M3 (AT 60 DEG. SLOPE)
HEIGHT OF MEDIA 750mm, 1000mm
MEDIA MUST BE STORED IN A COVERED PLACE WITH ADEQUATE VENTILATION MEDIA MUST BE STORED IN A COVERED PLACE WITH ADEQUATE VENTILATION
5
FILL PAC MEDIA

• We are the leading manufacturer and supplier of
  FILL PAC MEDIA.Our quality made us leading
  company in india. These components have
  cylindrical shape with internal ribs. Our range
  is used for trickling filter, anaerobic and SAFE
  reactors.

FLOWER MEDIA WHEEL MEDIA, FILL PAC MEDIA FLOWER MEDIA WHEEL MEDIA, FILL PAC MEDIA
Type of Media WHEEL (FLOWER) MEDIA
MOC of Media POLYPROLYLENE
Structure cylindrical shape, with internal ribs
Media Size 187Ømm X 51mm
Specific Gravity 0.9
Surface Area/unit bulk volume 100 m 2/m3 bulk volume
Max continuous Operating temp 80c
Color Black
Media usage trickling filter/Anaerobic./SAFF Reactor
6
COARSE BUBBLE DISC DIFFUSER AIRSON-AD

• With the brilliant team of professionals, we are
  providing a broad assortment of Coarse Bubble
  Disc Diffusers. Coarse Bubble Disc Diffusers is
  available with us in different sizes and
  specifications. The offered range is widely used
  in industries where waste water is generated.
  These are manufactured using quality tested
  material and latest techniques in accordance to
  meet with the international quality standards.

BUBBLE SIZE 4mm to 5 mm
MOC of diffuser Epdm Silicon
MOC of diffuser support ABS
Sizes Ø80 mm
Type of bubble Course bubble
Bubble temperature Tolerance 85 deg Celsius
End connection ¾BSP male thread
Operating temperature 35 deg Celsius
Type of air discharge Top air discharge
No of Air Discharge Ports 10Nos
Air Flow Rate per Diffuser 3-4m³/hr
Shape of Diffuser DISC TYPE
7
COARSE BUBBLE DISC DIFFUSER AIRSON-AD

• With the brilliant team of professionals, we are
  providing a broad assortment of Coarse Bubble
  Disc Diffusers. Coarse Bubble Disc Diffusers is
  available with us in different sizes and
  specifications. The offered range is widely used
  in industries where waste water is generated.
  These are manufactured using quality tested
  material and latest techniques in accordance to
  meet with the international quality standards.

BUBBLE SIZE 4mm to 5 mm
MOC of diffuser Epdm Silicon
MOC of diffuser support ABS
Sizes Ø150 mm
Type of bubble Course bubble
Bubble temperature Tolerance 85 deg Celsius
End connection 1BSP male thread
Operating temperature 35 deg Celsius
Type of air discharge Peripheral air discharge
No of Air Discharge Ports 8Nos
Air Flow Rate per Diffuser 6-8m³/hr
Diffuser support Color BLUE
8
FINE BUBBLE DISC DIFFUSER AIRSON-AD

• Matching to the requirements of clientele, we are
  involved in providing most excellent quality of
  Fine Bubble Disc Diffusers. The products
  obtainable by our company are extremely tested
  for their quality and manufactured using elevated
  grade raw material. Installed in a grid layout
  mode covering the entire tank floor, these are
  also installed as in-line configuration for cross
  or spiral rotation of the tank contents.

BUBBLE SIZE 1mm to 2 mm
MOC of diffuser Epdm Silicon
MOC of diffuser support Poly propylene
Sizes 220 mmX 220mm/ 9X9
Type of bubble Fine bubble
Bubble temperature Tolerance 85 deg Celsius
End connection 1BSP male thread
Operating temperature 35 deg Celsius
Type of air discharge Top air discharge
Air Flow Rate per Diffuser 2-6m³/hr
Diffuser support Color BLUE
Shape of Diffuser DISC TYPE
9
FINE BUBBLE DISC DIFFUSER AIRSON-AD

• we are involved in providing most excellent
  quality of Fine Bubble Disc Diffusers.The
  products obtainable by our company are extremely
  tested for their quality and manufactured using
  elevated grade raw material. Installed in a grid
  layout mode covering the entire tank floor, these
  are also installed as in-line configuration for
  cross or spiral rotation of the tank contents.

BUBBLE SIZE 1mm to 2 mm
MOC of diffuser Epdm Silicon
MOC of diffuser support Poly propylene
Sizes 320 mmX320mm/12X12
Type of bubble Fine bubble
Bubble temperature Tolerance 85 deg Celsius
End connection 1BSP male thread
Operating temperature 35 deg Celsius
Type of air discharge Top air discharge
Air Flow Rate per Diffuser 6-12m³/hr
Diffuser support Color BLUE
Shape of Diffuser DISC TYPE
10
FINE BUBBLE TUBE DFFUSER AIRSON-AD

• We are the leading manufacturer of Tube Diffusers
  Fine Bubble. Our product range requires fewer
  header pipes, less support stands and less
  installation time than disc diffusers. These tube
  membranes are extruded from low extractable oil
  content EPDM polyurethane, Silicon or Nitrate.

FINE BUBBLE TUBE DIFFUSER Ø63MM X 610MM FINE BUBBLE TUBE DIFFUSER Ø63MM X 610MM
Shape of Diffuser Tube Type
Type of Bubble Fine bubble
MOC of Membrane EPDM / silicon
MOC of Membrane Support PVC PIPE
MOC of Membrane Clips SS
MOC of Diffuser Male Adapter ABS
Operating Temperature of Membrane 85 deg. Celsius
Nipple attached to diffuser ¾x3
Dimensions of Bubble gt1mm
Air put through rate 4 to 6m3/hr
11
FINE BUBBLE TUBE DIFFUSER AIRSON-AD

• We bring forth fine bubble tube diffusers A
  available with pipe support. S.S. membrane clips
  and S.S. membrane clips. Our products are
  manufactured using high quality material that are
  procured from trusted vendors of the market.
  Owing to its optimum quality, the average
  temperature of the membrane is 85 deg. celsius.

FINE BUBB FINE BUBBLE TUBE DIFFUSER Ø63MM X 1000MM FINE BUBB FINE BUBBLE TUBE DIFFUSER Ø63MM X 1000MM
Shape of Diffuser Tube Type
Type of Bubble Fine bubble
MOC of Membrane EPDM / silicon
MOC of Membrane Support PVC PIPE
MOC of Membrane Clips SS
MOC of Diffuser Male Adapter ABS
Operating Temperature of Membrane 85 deg. Celsius
Nipple attached to diffuser ¾x3
Dimensions of Bubble gt1mm
Air put through rate 8 to 10m3/hr
12
FIN E BUBBLE TUBE DIFFUSER AIRSON-AD

• We bring forth fine bubble tube diffusers A
  available with pipe support. S.S. membrane clips
  and S.S. membrane clips. Our products are
  manufactured using high quality material that are
  procured from trusted vendors of the market.

FINE BUBBLE TUBE DIFFUSER Ø90MM X 1000MM FINE BUBBLE TUBE DIFFUSER Ø90MM X 1000MM
Shape of Diffuser Tube Type
Type of Bubble Fine bubble
MOC of Membrane EPDM / silicon
MOC of Membrane Support PVC PIPE
MOC of Membrane Clips SS
MOC of Diffuser Male Adapter ABS
Operating Temperature of Membrane 85 deg. Celsius
Nipple attached to diffuser 1x3
Dimensions of Bubble gt1mm
Air put through rate 11 to 14m3/hr
13
FILTER PRESS

• Our quality products are developed using the
  optimum quality raw materials and components that
  are purchased from authentic vendors of the
  industry. All the raw materials are properly
  checked for their compliance with the
  international quality standards, before being
  used in the production process.
• SIZE 18 X 18(450mm X 450mm)
• 24 X 24(600mm X 600mm)
• 30 X 30 (750mm X750mm)
• 36 X 36 (900mm X 900mm)
• 48 x 48 (1200mm X 1200mm)


•


•
