Title: A History of Ford Farm Tractors!


1
A History of Ford Farm Tractors! Please click
mouse to advance slides.
A Lyle V. Johnson Production May 12, 2014
2
Ford Farm Tractors Started with this Man!
Henry Ford, founder of the Ford Motor Company,
and the man known to have put many Americans into
an inexpensive Ford automobile, also started the
Ford Farm tractor line.
Ford grew up on a Michigan farm himself. He
had visions of building an affordable farm
tractor for small farmers, because WWI was
raging in Europe in the early 1900's, and there
were growing concerns about farmers being able to
supply adequate world-wide food supplies.
3
A Quick Summary of Ford Tractor History! It
all started with Henry Ford's personal interest
to provide an affordable tractor to the small
American farmer. An experimental tractor was
built as early as 1907. The first mass produced
tractor was the Fordson F which began production
in 1917. Henry Ford stopped tractor production
in the US in 1928, but the production of Fordson
tractors continued in England up until 1964.
In 1938, Henry Ford and Harry Ferguson, in a
hand-shake agreement, decided to build tractors
with the Ferguson 3-point hitch system. This
led to the famous Ford N-Series tractors built
from 1939 to 1952. In 1985 Ford purchased
New-Holland, but was soon looking for a way out
of the tractor business. In 1991, the Ford-New
Holland tractor business was sold to FIAT. That
deal required FIAT to stop using the Ford name on
any tractors beginning in 2000. As a result, the
New Holland name replaced the long-time Ford name
of farm tractors.
4
Henry Ford's first experimental Farm Tractor
built around 1907, and now on display at the
Henry Ford Museum in Dearborn, Michigan.
5
Early Concerns About Henry Ford Starting a Ford
Farm Tractor Line! In the early days, some of
the other shareholders of the Ford Motor Company
were concerned that the experimental expenses
associated with Henry Ford's efforts to built
farm tractors could dilute the Company's rich
corporate profits and shareholder dividends.
These concerns continued even though Henry Ford
had established a separate company (The Henry
Ford Son Company) for that purpose. These
other stockholder concerns were finally resolved
on February 2, 1916, at a Ford Motor Company
board of directors meeting. The Ford Motor
Company agreed to give up any claims to tractor
designs and patents. In turn, Henry Ford agreed
to pay Ford Motor 46,810.76 for previous
development work on tractors and to not use just
the name Ford on tractors, because the Ford
Motor Company might want to enter into the
tractor business in the future and use the Ford
name itself.
6
The Start of Ford Tractor Production! The
Henry Ford and Son Company started tractor
production in October 1917 by building 6,000
tractors for England and 1,000 tractors for
Canada to assist those countries with food
production during World War I. There was no
identification on those tractors and they became
known as MOM tractors because they were built
for Englands Ministry of Munitions. In April
1918, Henry Ford began producing this tractor for
the U.S. market with the Fordson name on the
upper radiator tank and the Henry Ford Son name
stamped into the end of the fuel tank. The
Fordson name was some what of a contraction of
the company name, but it had been registered as a
trademark by January 1918.
7
The Fordson Model F Tractor! The Fordson Model
F was the first mass produced Tractor built by
the Henry Ford Son Company. It was named the
Fordson Model F tractor because Henry Ford's
agreement with Ford Motor Company not to use the
Ford name on tractors. Factories were set up
at Dearborn, Michigan, USA, and produced Model
F's from 1917-1928. A European factory was set
up in Cork, Ireland producing them from
1919-1922. However, because of the farming
recession of the 1920s, tractor production was
suspended in the United States, although
production of Fordson spare parts continued.
8
Fordson Model F. Yrs. Built 1917 1928. No.
Built 755,278 (Built in USA, except for
7,597 built in Cork, Ireland). Engine 4.1L
4-Cylinder Distillate Fuel. HP 12 Drawbar
22 Belt. Plow Rating 2-14.
9
In 1918, Henry Ford (center) visits a Fordson
Model F at work!
10
Another New Company? In March 1919, Henry Ford
announced plans to form a new company to build
both cars and tractors. This news caused other
stockholders of the Ford Motor Company to sell
their stock on the market to an unknown buyer.
It was was later revealed that the buyer was
Henry Ford himself, which then made him the sole
owner of the giant Ford Motor Company. As a
result, the Henry Ford and Son Company was folded
into the Ford Motor Company and the name on the
end of the fuel tank was changed to Fordson. In
February 1921, production of the Fordson was
moved from the Dearborn tractor factory to the
new massive Rouge factory which received iron ore
from Fords mines, delivered in Fords ships, at
one end and delivered assembled tractors and
Model T car parts at the other end. Also, at
about that time, Ford started building its own
engine to be used in the Fordson tractors.
11
Fordson F Tractor Production! The Fordson F
dominated the U.S. tractor market from 1921 to
1926, and was many farmers first tractor, but it
also had faults. It was often hard to start,
especially if the operator forgot to switch back
to starting fuel (gasoline) before shutting off
the engine. Often water would boil in the
radiator of a Fordson F tractor, especially when
the tractor was working under heavy load
conditions. This required frequent replenishing
of the radiator with water. Although an
engineer developed a magneto and a water pump to
correct these problems, Henry Ford chose not to
adopt them. By 1927, the Fordson tractor was
encountering sales resistance and the production
of Fordson Model F ended in the U.S. in 1928.
12
Why Production of Fordson Tractors
was Discontinued in the United States!
The main reason Henry Ford stopped tractor
production in the U.S. in 1928, was probably to
give the Ford Motor Company the time necessary to
focus on the development and sales of the new
Ford Model A car which would replace the Ford
Model T car. Sales facts in the next two
slides show that the Ford's Model A car quickly
became huge success, and no doubt, it was
probably a much more profitable course of action
for the Ford Motor Company to pursue at the
time.
13
Ford Model A. Sales of this car began in late
1927. By February 4, 1929, one million had
sold, by July 24, 1929, two million had sold, and
by 1932, 20 million had been made!
14
Henry Ford drives his twenty millionth car off
the assembly line a 1931 Model A.
15
The Ford Motor Company Did Continue the Fordson
Tractor in England up until 1964!
Eight Fordson tractor models were produced by
Ford's England branch up until 1964, when the
U.S. and England branches of Ford Motor Company
merged. That also became the time when the
Fordson name ended for tractors built
thereafter by the Ford Motor Company. Those
eight Fordson tractor models produced by Ford in
England up until 1964 are shown in the next
eight slides. It was not until 1939 when the
production of Ford Farm tractors resumed in the
United States.
16
Fordson Model N. Yrs. Built 1929 1945.
No. Built NA. Built only in Cork,
Ireland and Dagenham, England. Engine 4.4L
4-Cylinder gasoline or kerosene fuel. HP 18
Drawbar 29 Belt.
17
Fordson All Around (Row Crop). Yrs. Built
1937 1945. Built in Dagenham, England.
Engine 4.4L 4-Cylinder Gasoline or Kerosene.
HP 25 Engine 15 Drawbar. Plows 2-14
18
Fordson E27N Major. Yrs. Built 1945 1952.
Built in Dagenham, England. Engine 4.4L
4-Cylinder Gasoline or 4.7L Perkins 6-Cylinder
Diesel. Engine HP 45.
19
Fordson E1A New Major. Yrs. Built 1951
1964. Built in Dagenham, England. Engine
3.3L 4-Cylinder Gasoline or 4.6L 4-Cylinder
Diesel. HP 34 Drawbar 35 PTO. Cost 3,417.
20
Fordson Power Major. Yrs. Built 1958 1961.
Built in Dagenham, England. Engine 3.6L
4-Cylinder Diesel or 3.3L 4-Cylinder Gasoline.
HP 42 Drawbar 47 PTO.
21
Fordson Dexta. Yrs. Built 1958 1961.
Built in Dagenham, England. Engine
2.4L 3-Cylinder Diesel or 2.2L 4-Cylinder
Gasoline. HP 27 Drawbar 31 PTO. Plows
3-14.
22
Fordson Super Dexta. Yrs. Built 1962 1964.
Built in Dagenham, England. Engine 2.5L
3-Cylinder Diesel. HP 32 Drawbar 38 PTO.
23
Fordson Super Major. Yrs. Built 1961
1964. Built in Dagenham, England. Engine
3.6L 6-Cylinder Diesel or 3.3 L 4-Cylinder
Gasoline. HP 40 Drawbar 47 PTO. Sold as
a Ford Tractor Model 5000 in the USA.
24
USA Production of Ford Farm Tractors Resumed
in 1939! Model 9 N 1939 - 1942 Model 2 N
1942 - 1947 Model 8 N 1947 - 1952
25
Photo Courtesy of Ron and Pam Wynne!
Ford 9N Tractor. Yrs. Built 1939 1942. No.
Built 99,002. Engine 2.0L 4-Cylinder
Gasoline. HP 16 Drawbar 23 Belt. Plows
2-14. Cost 585 in 1939.
26
The Model 2N came out when there were shortages
due to WWII. The electrical system (battery and
generator) was eliminated and replaced in this
model by a magneto and hand crank.
Ford Model 2N. Yrs. Built 1942 1947. No.
Built NA. Engine 2.0L 4-Cylinder
Gasoline. Built in Dearborn, Michigan. HP 12
Drawbar 23 PTO. Cost 1,120.
27
The Most Popular Farm Tractor Ever Built in North
America!
Ford 8N. Yrs. Built 1947 1952. No. Built
524,000. Engine 2.0L 4-Cylinder Gasoline.
HP 21 Drawbar 23 PTO. Cost 1,404 in
1952.
28
The Popular Ford Model 8N Tractor! Ford's 8N
Model Tractor (1947 -1952) was credited with
being the most popular farm tractor ever built in
North America. In its five years of production,
524,000 of the Model 8N Ford Tractors were
built. The Model 8N out sold North America's
next most popular farm tractor, the Farmall H
produced by the International Harvester Company
(IHC), but it took 13 years from 1939 to 1952
for IHC to produce its 392,227 Model H Farmall
tractors. The popularity of the Ford Model 8N
tractor was attributed to the Ferguson
three-point hitch and hydraulic system that gave
farmers convenience and safety in the attachment
and use of farm implements. Henry Ford had
acquired this feature in a hand-shake agreement
with his friend, Harry Ferguson in the late
1930's.
29
The 50-Year Anniversary Golden Jubilee Ford
Tractor!
Model NAA . Yrs. Built 1953 1954. No.
Built 128,965. 2.2L 4-Cylinder Gasoline.
HP 26 Drawbar 31 Belt. Plows 2-16.
Cost 1,560 in 1954
30
The Ford 600 Series of Farm Tractors! (Five
Models 1954 to 1958) Model 620 1955
-1957 Model 630 1955 -1957 Model 640
1954 -1957 Model 650 1955
- 1958 Model 660 1954 - 1957
31
Ford 620 (600 Series). Yrs. Built 1955
1957. Engine 2.2L 4-Cylinder Gasoline or
LPG. HP 30 Belt. Plow rating 2-14.
Cost NA.
32
Ford 630 (600 Series). Yrs. Built 1955
1957. Engine 2.2L 4-Cylinder Gasoline or
LPG. HP 30 Belt. Plow rating 2-14.
Cost NA.
33
Ford 640 (600 Series). Yrs. Built 1954
1957. Engine 2.0L 4-Cylinder Gasoline or
LPG. HP 28 Drawbar 31 Belt. Plow
rating 2-14. Cost 2,056 in 1957.
34
Ford 650 (600 Series). Yrs. Built 1955 1958.
Engine 2.2L 4-Cylinder Gasoline or LPG. HP
30 Belt. Plow rating 2-14.
Cost NA.
35
Ford 660 (600 Series). Yrs. Built 1954
1957. Engine 2.2L 4-Cylinder Gasoline or
LPG. HP 28 Drawbar 34 Belt. Plow
rating 2-14. Cost 2,266 in 1957.
36
The 601 Workmaster Series of Ford Farm
Tractors! Ford 611 1957 - 1961 Ford
621 1957 - 1962 Ford 631
1957 - 1961 Ford 641 1957 - 1962
Ford 651 1957 - 1961 Ford 661
1957 - 1961 Ford 671
1957 - 1961 Ford 681 1957 -
1961
37
Ford 611 (601 Workmaster). Yrs. Built 1957
1961. Engine 2.2L 4-Cylinder Gasoline or
2.4L 4-Cylinder Diesel. HP 48 Engine 32
Belt. Plow rating 2-14 Cost 3,222 in
1961.
38
Ford 621 (601 Workmaster). Yrs. Built 1957
-1962. No. Built NA. Engine 2.2L
4-Cylinder Gasoline or LPG or 2.4L 4-Cylinder
Diesel. HP 48 Engine 32 Belt. Plows
2-14. Cost 3,222 in 1961. Built in
Highland Park, Michigan.
39
Ford 631 (601 Workmaster Series). Yrs. Built
1957 1961. Engine 2.2L 4-Cylinder Gasoline or
2.4L 4-Cylinder Diesel. Plow rating 2-14.
Cost 3,222 in 1961.
40
Ford 641 (Workmaster Series). Yrs. Built
1957 1962 Engine 2.2L 4-Cylinder
Gasoline or 2.4L 4-Cylinder Diesel. HP 29
Drawbar 31 PTO. Plow rating 2-14.
Cost 3,096 in 1961.
41
Ford 651 (Workmaster Series). Yrs. Built
1957 1961. Engine 2.2L 4-Cylinder Gasoline
or 2.4L 4-Cylinder Diesel. HP 29 Drawbar 35
Belt. Plow rating 2-14. Cost 3,222 in
1961.
42
Ford 661 (Workmaster Series). Yrs. Built 1957
1961. Engine 2.2L 4-Cylinder Gasoline or
2.4L 4-Cylinder Diesel. HP 48 Engine 32
Belt. Plow rating 2-14. Cost 3,222 in
1961.
43
Ford 671 (601 Workmaster Series). Yrs.
Built 1957 1961. Engine 2.2L
4-Cylinder Gasoline or 2.4L 4-Cylinder Diesel.
HP 48 Engine 32 Belt. Plow rating
2-14. Cost 3,222 in 1961
44
Ford 681 (601 Workmaster Series). Yrs.
Built 1957 1961. Engine 2.2L
4-Cylinder Gasoline or 2.4L 4-Cylinder Diesel.
HP 26 Drawbar 34 PTO. Plow rating 2-14.
Cost 3,231 in 1961
45
The 700 Series of Ford Farm Tractors! There
was only one tractor in the 700 Series of Ford
Farm Tractors the Ford Model 740 shown in the
next slide. It was designed as a row crop
tractor with a tricycle configuration, and was
built from 1954 to 1957.
46
Ford 740 (700 Series). Yrs. Built 1954
1957. Engine 2.2L 4-Cylinder Gasoline or
LPG. HP 28 Drawbar 34 Belt. Plow rating
2-14. Cost 2,671 in 1954.
47
The Ford 800 Series! Ford 820 No
photo 1955 1957 Ford 850
1954 1957 Ford 860
1954 1957
48
Ford 850 (800 Series). Yrs. Built 1954
1957. Engine 2.8L 4-Cylinder Gasoline or
LPG. HP 35 Drawbar 39 Belt. Plow rating
3-14. Cost 2,273 in 1957.
49
Ford 860 (800 Series). Yrs. Built 1954
1957. Engine 2.8L 4-Cylinder Gasoline or
LPG. HP 39 Drawbar 45 Belt. Plow rating
3-14. Cost 2,407 in 1957.
50
The 900 Series of Ford Farm Tractors! Ford
940 1954 - 1957 Ford 950 1954 -
1957 Ford 960 1954 - 1957
51
Ford 940 (900 Series) with front-loader and
single front wheel. Yrs. Built 1954 1957.
Engine 2.8L 4-Cylinder Gasoline or LPG. HP
40 Belt. Plow rating 3-14. Cost
2,561 in 1957.
52
Ford 950 (900 Series). Yrs. Built 1954
1957. 2.8L 4-Cylinder Gasoline or LPG. HP 40
Belt. Plow rating 3-14. Cost NA.
53
Ford 960 (900 Series). Yrs. Built 1954
1957. Engine 2.8L 4-Cylinder Gasoline or
LPG. HP 38 Drawbar 46 Belt. Plow rating
3-14. Cost 2,561 in 1957.
54
The 501 Workmaster Series of Ford Farm
Tractors! The Ford 541 offset tractor is the
only model in this series. Not very many of this
Ford Tractor model were ever sold, due to the
offset, high clearance feature which caused too
many tip-over accidents for farmers.
55
Ford 541 Offset (501 Workmaster Series). Yrs.
Built 1958 1962. Engine 2.2L
4-Cylinder Gasoline or 2.4L 4-Cylinder Diesel
HP 34 PTO. Built in Highland Park, Michigan.
56
Ford 541 Offset (Close-Up) with cultivator.
Yrs. Built 1958 1962.
57
Ford 541 (501Workmaster) Offset. Yrs. Built
1958 1962. No. Built NA. Engine 2.2L
4-Cylinder Gasoline or 2.4L 4-Cylinder Diesel.
HP 34 PTO. Built in Highland Park, Michigan.
58
The 701 Workmaster Series of Ford Farm Tractors!

Ford 741 1958 - 1962 Ford 771
1958 - 1962
59
Ford 741 (701 Workmaster Series). Yrs. Built
1958 1962. Engine 2.4L 4-Cylinder Gasoline
or Diesel. HP 48 Engine 32 Belt.
Plow rating 2-14. Cost NA.
60
Ford 771 (701 Workmaster Series). Yrs. Built
1958 1962. Engine 2.2L Gasoline or 2.4L
Diesel, with 4-Cylinders. HP 48 Engine 32
Belt. Plow rating 2-14. Cost NA.
61
The 801 Powermaster Series of Ford Farm
Tractors! Ford 811 1958 - 1962 Ford
821 1958 - 1962 Ford 841 1957 -
1962 Ford 851 1957 - 1961 Ford 861 1958
- 1962 Ford 871 1958 - 1962 Ford
881 1958 - 1962
62
Ford 811 (801 Powermaster). Yrs. Built 1958
1962. Engine 2.8L Gasoline or Diesel. HP
Engine 62 Belt 40. Plow rating 3-14.
Cost NA.
63
Ford 821 (801 Powermaster Series). Yrs. Built
1958 1962. Engine 2.8L 4-Cylinder Gasoline
or Diesel. Plow rating 3-14. Cost NA.
64
Ford 841 (801 Powermaster Series). Yrs.
Built 1957 1961. Engine 2.8L
4-Cylinder Gasoline or Diesel. HP 41
Drawbar 44 Belt. Plow rating 3-14. Cost
3,080 in 1957.
65
Ford 851 (801 Powermaster Series). Yrs.
Built 1957 1961. Engine 2.8L 4-Cylinder
Gasoline or Diesel. HP 41 Drawbar 48 Belt.
Plow rating 3-14. Cost 3,206 in 1957.
66
Ford 861 (801 Powermaster Series). Yrs. Built
1958 1962. Engine 2.8L 4-Cylinder
Gasoline or Diesel. HP 62 Engine 40 Belt.
Plow rating 3-14. Cost NA.
67
Ford 871 (801 Powermaster Series). Yrs. Built
1958 1962. Engine 2.8L 4-Cylinder Gasoline
or Diesel. HP 62 Engine 40 Belt. Plow
rating 3-14. Cost NA.
68
Ford 881 (801 Powermaster Series). Yrs. Built
1958 1962. Engine 2.8L 4-Cylinder Gasoline
or Diesel. HP 37 Drawbar 46 PTO. Plow
rating 3-14. Cost NA.
69
The 901 Powermaster Series of Ford Farm
Tractors! Ford 941 1958 - 1962 Ford
951 1958 - 1962 Ford 961 1958
- 1962 Ford 971 1958 - 1962
Ford 981 1958 - 1962
70
Ford 941 (901 Powermaster Series). Yrs. Built
1958 1962. Engine 2.8L 4-Cylinder Gasoline
or Diesel. HP Engine 62 Belt 40. Plow
rating 3-14. Cost NA.
71
Ford 951 (Powermaster). Yrs. Built 1958
1962. Engine 2.8L 4-Cylinder Gasoline or
Diesel. HP 62 Engine 40 Belt. Plow
rating 3-14. Cost NA.
72
Ford 961 (901 Powermaster Series) Yrs. Built
1958 1962. Engine 2.8L 4-Cylinder Gasoline
or Diesel. HP 62 Engine 40 Belt. Plow
rating 3-14, Cost NA.
73
Ford 971 (901 Powermaster Series). Yrs. Built
1958 1962. Engine 2.8L 4-Cylinder Gasoline
or Diesel. HP 62 Engine 40 Belt. Plow
rating 3-14. Cost NA.
74
Ford 981 (901 Powermaster Series). Yrs. Built
1958 1962. Engine 2.8L 4-Cylinder Gasoline
or Diesel. HP 62 Engine 40 Belt.
Plow rating 3-14. Cost NA.
75
  • The Big Four-Wheel Drive Tractors Built for Ford
    by Steiger!
  • Ford FW-20 1977 - 1982
  • Ford FW-30 1977 - 1982
  • Ford FW-40 1977 - 1979
  • Ford FW-60 1977 - 1982

76
Ford FW 20 (Built by Steiger). Yrs. Built
1977 1982. Engine 9.1L 8-Cylinder Cummings
Diesel. HP 210 Engine 150 Drawbar. Cost
70,699 in 1982.
77
Ford FW-30 (Built by Steiger). Yrs. Built
1977 1982. Engine 14.8L Cummings V-8
Diesel. HP 265 Engine 205 Drawbar. Cost
85,166 in 1982.
78
Ford FW-40 (Built by Steiger). Yrs. Built
1977 1979. Engine 14.8L 8-Cylinder
Diesel. HP 295 Engine 227 Drawbar. Cost
66,572 in 1979.
79
Ford FW-60 (Built by Steiger). Yrs. Built
1977 1982. Engine 14.8L 8-Cylinder Diesel.
HP 335 Engine 270 Drawbar. Cost
99,394 in 1982.
80
The 10 Compact Series of Ford Farm Tractors!
Ford 1110 1983 - 1986 Ford 1210 1983 -
1986 Ford 1310 1983 - 1986 Ford 1510 1983
- 1986 Ford 1710 1983 - 1986 Ford
1910 1983 - 1986 Ford 1710 Offset 1985 -
1986
81
Ford 1110 (10 Compact Series). Yrs. Built
1983 1986 by Shibaura of Japan. Engine
0.7L 2-Cylinder Diesel. HP 13 Engine 11
PTO. Plows 1-12. Cost 6,231 in 1986.

82
Ford 1210 4WD (10 Compact Series). Yrs. Built
1983 1986 by Shibaura in Japan. Engine 0.9L
3-Cylinder Diesel. HP 16 Engine 13 PTO.
Plows 1-12. Cost 6,952 in 1986.
83
Ford 1310 4WD (10 Compact Series). Yrs. Built
1983 1986 by Shibaura in Japan. Engine 1.0L
3-Cylinder Diesel. HP 19 Engine 16 PTO.
Cost 8,000 in 1986.
84
Ford 1510 (10 Compact Series). Yrs. Built 1983
1986 by Shibaura in Japan. Engine 1.1L
3-Cylinder Diesel. HP 16 Drawbar 19 PTO.
Cost 8,000 in 1986.
85
Ford 1710 4WD (10 Compact Series). Yrs. Built
1983 1986 by Shibaura in Japan. Engine
1.4L 3-Cylinder Diesel. HP 20 Drawbar 23
PTO. Cost 8,859 in 1986.
86
Ford 1910 4WD (10 Compact Series). Yrs.
Built 1983 1986 by Shibaura in Japan.
Engine 1.7L 3-Cylinder Diesel. HP 24
Drawbar 28 PTO. Cost 10,000 in 1986.
87
Ford 1710 Offset. Yrs. Built 1985 1986 by
Shibaura of Japan. Engine 1.4L 3-Cylinder
Diesel. HP 26 Engine 23 PTO. Cost
10,604 in 1986.
88
The 20 Compact Series of Ford Tractors!
Ford 1120 Ford 1220 Ford 1320 Ford 1520 Ford
1720 Ford 1920 Ford 2120
1987 - 1993 1987 - 1999 1987 - 1998 1987 -
1998 1987 - 2000 1987 - 2000 1987 - 1991
89
Ford 1120 (20 Compact Series). Yrs. Bult
1987 1993 by Shibaura of Japan. Engine
0.7L 2-Cylinder or 0.9L 3-Cylinder Diesel.
HP 14 Engine 12 PTO. Cost 9,000 in 1993.
90
Ford 1220 (20 Compact Series). Yrs. Built 1987
1999 by Shibaura of Japan. Engine 1.0L
3-Cylinder Diesel. HP 16 Engine 14 PTO.
Cost 12,000 in 1999.
91
Ford 1320 (20 Compact Series). Yrs. Built
1987 1998 by Shibaura of Japan.
Engine 1.3L 3-Cylinder Diesel. HP 20
Engine 16 PTO. Cost 12,200 in 1998.
92
Ford 1520 (20 Compact Series). Yrs. Built
1987 1998 by Shibaura of Japan.
Engine 1.3L 3-Cylinder Diesel. HP 22
Engine 19 PTO. Cost 13,000 in 1998.
93
Ford 1720 4WD (20 Compact Series). Yrs.
Built 1987 2000 by Shibaura of Japan.
Engine 1.5L 3-Cylinder Diesel. HP 28
Engine 23 PTO. Cost 14,000 in 2000.
94
Ford 1920 (20 Compact Series). Yrs. Built
1987 2000 by Shibaura of Japan.
Engine 2.0L 4-Cylinder Diesel. HP 32
Engine 28 PTO. Cost 15,500 in 2000.
95
Ford 2120 4WD (20 Compact Series). Yrs.
Built 1987 1991 by Shibaura of Japan.
Engine 2.3L 4-Cylinder Diesel. HP 40
Engine 34 PTO. Cost 21,200 in 1991.
96
The TW Series of Ford Farm Tractors! Ford TW -
5 1983 1986 Ford TW-10 1979
1983 Ford TW-15 1983 1990 Ford TW-20
1979 1983 Ford TW-25 1983 1989 Ford
TW-30 1979 1983 Ford TW-35 1983
1986
97
Ford TW-5. Yrs. Built 1983 1986.
Engine 6.6L 6-Cylinder Diesel. HP 92
Drawbar105 PTO. Plow rating NA.
Cost NA.
98
Ford TW-10. Yrs. Built 1979 1983.
Engine 6.6L 6-Cylinder Diesel. HP 94 Drawbar
110 PTO. Cost 36,160 in 1983.
99
Ford TW-15. Yrs. Built 1983 1990.
Engine 6.6L 6-Cylinder Diesel. HP 105
Drawbar 121 PTO. Plow rating 4. Cost
41,000 in 1990.
100
Ford TW-20. Yrs. Built 1979 1983.
Engine 6.6L 6-Cylinder Diesel. HP
126 Drawbar 140 PTO. Plow rating NA.
Cost 40,648 in 1983.
101
Ford TW-25. Yrs. Built 1983 1989.
Engine 6.6L 6-Cylinder Diesel. HP 124
Drawbar 140 PTO. Plow rating NA. Cost
NA.
102
Ford TW-30. Yrs. Built 1979 1983.
Engine 6.6L 6-Cylinder Diesel. HP 142
Drawbar 163 PTO. Plow rating NA.
Cost 52,272 in 1983
103
Ford TW-35. Yrs. Built 1983 1986.
Engine 6.6L 6-Cylinder Diesel. HP 145
Drawbar 171 PTO. Plow rating 4.
Cost NA.
104
The 70 Genisus Series of Ford Farm
Tractors! Ford 8670 1993 - 2002 Ford
8770 1993 - 2002 Ford 8870 1993 -
2002 Ford 8970 1993 - 2002
105
Ford 8670 4WD (70 Genisus Series). Yrs. Built
1993 2002. Engine 7.5L 6-Cylinder Diesel.
HP 170 Engine 145 PTO. Cost 84,500
in 2000.
106
Ford 8770 4WD (70 Genisus Series). Yrs. Built
1993 2002. Engine 7.5L 6-Cylinder Diesel.
HP 190 Engine 160 PTO.
Cost 90,500 in 2000.
107
Ford 8870 4WD (70 Genisus Series). Yrs. Built
1993 2002. Engine 7.5L 6-Cylinder Diesel.
HP 210 Engine 180 PTO. Cost
103,000 in 2000.
108
Ford 8970 4WD (70 Genisus Series). Yrs. Built
1993 2002. Engine 7.5L 6-Cylinder
Diesel. HP 189 Drawbar 224 PTO. Cost
127,000 in 2000.
109
The 30 Series of Ford Farm Tractors! Ford
5630 Before 2002 Ford 6630 Before
2001 Ford 7630 Before 2002 Ford 7830
Before 2002 Ford 8030 Before 2002 Ford
8530 1990 - 1993 Ford 8630 1990 -
1993 Ford 8730 1990 - 1993 Ford 8830 1990
- 1993
110
Ford 5630 (30 Series). Yrs. Built Before
2002 in Curitiba, Brazil. Engine 4.4L
4-Cylinder Diesel. HP NA. Cost
NA.
111
Ford 6630 4WD (30 Series). Yrs. Built
Before 2001 in Curitiba, Brazil. Engine 5.0L
4-Cylinder Diesel. HP NA.
Cost NA.
112
Ford / New Holland 7630 (30 Series). Yrs
Built Before 2002 in Curitiba, Brazil.
Engine 5.0L 4-Cylinder Diesel. HP 100
Engine. Cost NA.
113
Ford 7830 (30 Series) became the New Holland
7830. Yrs. Built Before 2002 in Curitiba,
Brazil. Engine 6.6L 6-Cylinder Diesel.
HP 105 Engine. Cost NA.
114
Ford 8030 (30 Series). Yrs. Built Before 2002
in Curitiba, Brazil. Engine 7.5L 6-Cylinder
Diesel. HP 115 Engine. Cost NA.
115
Ford 8530 (30 Series). Yrs. Built 1990
1993 (Antwerp, Belgium). Engine 6.6L
6-Cylinder Diesel. HP 92 Drawbar 105 PTO.
Plow rating NA. Cost 46,000 in
1993.
116
Ford 8630 4WD (30 Series). Yrs. Built 1990
-1993 (Antwerp, Belgium). Engine 6.6L
6-Cylinder Diesel. HP 105 Drawbar 121 PTO.
Plow rating NA. Cost 52,000 in 1993
117
Ford 8730 2WD (30 Series). Yrs. Built 1990
1993 (Antwerp, Belgium). Engine 6.6L
6-Cylinder Diesel. HP 124 Drawbar 140 PTO.
Plow rating NA. Cost 56,500 in 1993.
118
Ford 8830 4WD (30 Series). Yrs. Built 1990
1993 (Antwerp, Belgium). Engine 6.6 L
6-Cylinder Diesel. HP 145 Drawbar 171 PTO.
Plow rating NA. Cost 63,000 in 1993.
119
The 30 Utility Series of Ford Farm
Tractors! Ford 3230 1990 - 1994 Ford 3430
1990 - 1998 Ford 3930 1990 -
2002 Ford 4630 1990 - 1999
120
Ford 3230 (30 Utility Series). Yrs. Built 1990
1994. Engine 3.1L 3-Cylinder Diesel. HP 26
Drawbar 32 PTO. Plow rating NA. 17,300
in 1994.
121
Ford 3430 (30 Utility Series). Yrs. Built
1990 1998. Engine 3.1L 3-Cylinder
Diesel. HP 31 Drawbar 38 PTO. Cost 20,500
2WD and 25,500 4WD in 1999.
122
Ford 3930 (30 Utility Series). Yrs. Built
1990 2002 (Basildon, England). Engine
3.3L 3-Cylinder Diesel. HP 38 Drawbar 52
PTO. Cost 24,400 2WD or 29,900 4WD in 1999.
123
Ford 4630 (30 Utility Series). Yrs. Built
1990 1999. Engine 3.3L 3-Cylinder
Diesel. HP 48 Drawbar 56 PTO. Cost 26,200
2WD or 31,700 4WD in 1999.
124
The Compact Utility Series of Ford Farm Tractors!
Ford 1000 Ford 1600 Ford 1620 Ford 1715 Ford
1215 Ford 3415
1973 - 1976 1976 - 1979 1992 - 1997 1992 -
1997 1993 - 1958 1993 - 2003
125
Ford 1000. Yrs. Built 1973 1976 by
Shibaura of Japan. Engine 1.3L 2-Cylinder
Diesel. HP 25 Engine 23 PTO.
126
Ford 1600. Yrs. Built 1976 1979 by
Shibaura of Japan. Engine 1.3L 2-Cylinder
Diesel. HP 18 Drawbar 23 PTO.
Cost 5,425 in 1979.
127
Ford 1620. Yrs. Built 1992 -1997, by Shibaura
of Japan. Engine 1.3L 3-Cylinder Diesel. HP
27 Engine 22 PTO. Cost 17,000 in 1997.
128
Ford 1715 4WD. Yrs. Built 1992 1997 by
Shibaura of Japan. Engine 1.3L 3-Cylinder
HP 27 Engine 23 PTO.
Cost 11,500 in 1997.
129
Ford 1215. Yrs. Built 1993 1998 by Shibaura
of Japan. Engine 0.9L 3-Cylinder Diesel. HP
16 Engine 13 PTO. Cost 9,000 in 1998.
130
Ford 3415. Yrs. Built 1993 2003 by
Shibaura of Japan. Engine 2.2L 4-Cylinder
Diesel. HP 44 Engine 38 PTO. Cost 17,900
in 2000.
131
The Farm - Agricultural Class of Ford Farm
Tractors! Ford 4030 1992 - 1997 Ford
4130 1990 - 1991 Ford 4230 1992 -
1997 Ford 5030 1992 - 1999 Ford 7530 1992
- 1996
132
Ford 4030. Yrs. Built 1992 1997 (Built by
Fiat). Engine 2.9L 3-Cylinder Diesel. HP
51 PTO. Cost 23,500 in 1997.
133
Ford 4130. Yrs. Built 1990 1991.
Engine 3.3L 3-Cylinder Diesel. HP 63 Engine
55 PTO. Cost NA.
134
Ford 4230. Yrs. Built by Fiat 1992 1997.
Engine 3.6L 4-Cylinder Diesel. HP 62 PTO.
Cost 25,000 in 1997.
135
Ford 5030. Yrs. Built 1992 1999. Engine
4.2L 4-Cylinder Diesel. HP 53 Drawbar 63
PTO. Cost 25,500 in 1998.
136
Ford 7530 4WD. Yrs. Built 1992 1996 by
Fiat. Engine 5.4L 6-Cylinder Diesel. HP
91 PTO. Cost 40,000 in 1996.
137
Power Star 40 Series of Ford Farm
Tractors! Ford 5640 1991 - 1995 Ford
6640 1991 - 1995 Ford 7740 1991 -
1995 Ford 7840 1991 - 1995 Ford 8240 1992
- 1995 Ford 8340 1992 - 1995
138
Ford 5640 FWD (Pwr Star 40 Series). Yrs.
Built 1991 1995 (Basildon, England).
Engine 4.4L 4-Cylinder Diesel. HP 60
Drawbar 66 PTO. Cost 30,000 in 1998.
139
Ford 6640 (Pwr Star 40 Series). Yrs. Built
1991 -1995 (Basildon, England). Engine 5.0L
4-Cylinder Diesel. HP 67 Drawbar 77 PTO.
Cost 33,400 in 1998.
140
Ford 7740 4WD (Pwr Star 40 Series). Yrs.
Built 1991 1995 (Basildon, England).
Engine 5.0L 4-Cylinder Diesel. Cost
36,000 in 1998.
141
Ford 7840 (Pwr Star 40 Series). Yrs. Built
1991 1995 (Basildon, England). Engine 6.6L
6-Cylinder Diesel. HP 75 Drawbar 90
PTO. Cost 35,650 in 1996.
142
Ford 8240 (Pwr Star 40 Series). Yrs. Built
1992 -1995 (Basildon, England). Engine 7.5L
6-Cylinder Diesel. HP 84 Drawbar 100 PTO.
Cost 40,500 in 1997.
143
Ford 8340 4WD (Pwr Star 40 Series). Yrs.
Built 1992 1995 (Basildon, England).
Engine 7.5L 6-Cylinder Diesel. HP 96
Drawbar 110 PTO. Cost 43,500 in 1997.
144
The 10S Series of Ford Farm Tractors!
Ford 6610S 1994 - 2003 Ford 7610S 1994 -
2000 Ford 7810S 1994 - 1998 Ford 8010 1996
- 2000
145
Ford 6610S (10S Series). Yrs. Built 1994
2003 in Queretaro, Mexico. Engine 5.0L
4-Cylinder Diesel. HP 85 Engine 76 PTO.
Cost 28,500 in 2000.
146
Ford 7610S (10S Series). Yrs. Built 1994
2000 in Queretaro, Mexico. Engine 5.0 L
4-Cylinder Diesel. HP 95 Engine 86 PTO.
Cost 31,500 in 2000.
147
Ford 7810S (10S Series). Yrs. Built 1994
1998 in Queretaro, Mexico. Engine 6.6L
6-Cylinder Diesel. HP 100 Engine 90
PTO. Cost 33,000 in 1998.
148
Ford 8010 4WD (10S Series) Yrs. Built 1996
2000. Engine 7.5L 6-Cylinder Diesel. HP 96
PTO. Cost 40,000 in 2000.
149
Other Ford Utility Tractors and those not
Assigned to a Specific Tractor Series or
Class! Years 1961 1995
150
Ford 6000. Yrs. Built 1961 1964. Engine
3.7L 6-Cylinder Gasoline or 4.0L 6-Cylinder
Diesel. HP 59 Drawbar 66 PTO. Plow
rating 5. Cost 4,900 in 1964.
151
Ford 2000. Yrs. Built 1962 1965. Engine
2.4L 4-Cylinder Diesel. HP 28 Drawbar 31
PTO. Cost NA.
152
Ford 4000. Yrs. Built 1962 1965.
Engine 2.8L 4-Cylinder Gasoline or
Diesel. HP 41 Drawbar 56 PTO. Plow
rating 4. Cost NA.
153
Ford 5000 Diesel. Yrs. Built 1962 1964 in
Dagenham, England offered in the USA as a larger
diesel tractor. Engine 3.6L 4-Cylinder.
HP 40 Drawbar 47 PTO. Plow rating 4.
154
Ford Commander 6000. Yrs. Built 1965
1967. Engine 4.0L 6-Cylinder
Diesel. HP 61 Drawbar 66 PTO. Plow
rating 5. Cost NA.
155
Ford 5000. Yrs. Built 1965 1976. Engine
3.8L 4-Cylinder Gasoline or Diesel. HP 50
Drawbar 60 PTO. Plow rating NA. Cost
5,400 in 1967.
156
Ford 2000. Yrs. Built 1965 1975. Engine
2.6L 3-Cylinder Gasoline or Diesel. HP 28
Drawbar 32 PTO. Plow rating NA. Cost
5,675 in 1975.
157
Ford 3000. Yrs. Built 1965 1975. Engine
2.6L 3-Cylinder Gasoline or 2.9L 3-Cylinder
Diesel. HP 35 Drawbar 40 PTO. Cost
6,300 in 1975.
158
Ford 8000. Yrs. Built 1968 1972.
Engine 6.6L 6-Cylinder Diesel. HP 92
Drawbar105 PTO. Plow rating NA.
Cost 10,000 in 1972.
159
Ford 4000 SU. Yrs. Built 1970 1976.
Engine 3.3L 3-Cylinder Gasoline or Diesel. HP
NA. Cost NA.
160
Ford 7000. Yrs. Built 1971 1975. Engine
4.2L 4-Cylinder Diesel. HP 66 Drawbar 83
PTO. Plow rating NA. Cost 12,260 in
1975.
161
Ford 9600. Yrs. Built 1972 1976.
Engine 6.6L 6-Cylinder Diesel. HP 111
Drawbar 135 PTO. Plow rating 4.
Cost 17,300 in 1976.
162
Ford 3600. Yrs. Built 1975 1981. Engine
2.9L 3-Cylinder Gasoline or Diesel. HP 34
Drawbar 40 PTO. Plow rating NA. Cost
7,200 in 1981.
163
Ford 7600. Yrs. Built 1975 1981. Engine
4.4L 4-Cylinder Diesel. HP 65 Drawbar 84
PTO. Cost 13,300 in 1981.
164
Ford 4600. Yrs. Built 1975 1981. Engine
3.3L 3-Cylinder Gasoline or Diesel. HP 44
Drawbar 52 PTO. Plow rating NA. Cost
9,700 in 1981.
165
Ford 4100. Yrs. Built 1975 1981. 3.0L
3-Cylinder Diesel. HP 39 Drawbar 45 PTO.
Plow rating NA. Cost 9,000 in 1981.
166
Ford 2600. Yrs. Built 1975 1981. Engine
2.6L 3-Cylinder Gasoline or Diesel. HP 28
Drawbar 34 PTO. Cost 6,436 in 1981.
167
Ford 8700. Yrs. Built 1977 1979. Engine
6.6L 6-Cylinder Diesel. HP 96 Drawbar 110
PTO. Plow rating NA. Cost NA.
168
Ford 6700. Yrs. Built 1977 1981.
Engine 4.4L 4-Cylinder Diesel. HP 56
Drawbar 70 PTO. Cost 22,000 in 1981.
169
Ford 4610. Yrs. Built 1982 1989. Engine
3.3L 3-Cylinder Gasoline or Diesel. HP 44
Drawbar 52 PTO. Plow rating 4. Cost
18,200 in 1989.
170
Ford 6610. Yrs. Built 1982 1993. Engine
4.4L 4-Cylinder Diesel. HP 61 Drawbar 72
PTO. Plow rating NA. Cost 24,500 in
1993.
171
Ford 4610 SU. Yrs. Built 1983 1989.
Engine 3.3L 3-Cylinder Gasoline or Diesel. HP
44 Drawbar 52 PTO. Plow rating NA.
Cost NA.
172
Ford 5900. Yrs. Built 1985 1993.
Engine 4.2L 4-Cylinder Diesel. HP 53
Drawbar 62 PTO. Cost 17,400 in 1993.
173
Ford 5110. Yrs. Built 1988 1991. Engine
4.2L 4-Cylinder Diesel. HP NA. Cost
NA.
174
Ford 7810. Yrs. Built 1988 1991. Engine
6.6L 6-Cylinder Diesel. HP 90 at PTO.
Cost 32,000 in 1990.
175
Ford 6410. Yrs. Built 1988 1991.
Engine 4.4L 4-Cylinder Diesel. HP 80
Engine. No other data available.
176
Ford 8340. Yrs. Built
1992 1995. Engine 7.5L 6-Cylinder Diesel.
HP 96 Drawbar
110 PTO. Cost 43,500 in 1997.
177
That Concludes This History of Ford Farm
Tractors! Unless otherwise noted, all photos
and data for this slide show were obtained from
internet sources, primarily from Tractor
Data.Com. Music Movie Theme of Quigley
Down Under! A Lyle V. Johnson Production May
12, 2014
About PowerShow.com
