RF Connectors Audio Video Connectors

1
Different Types Connectors
2
Twin lead
Mono AUDIO
VIDEO
Vinyl Cover
Copper Conductor
Spade Connector
Spade Connector Low Capacity - 6 Channels
Separate signals - Video and Audio
3
Coaxial Cable

• CharacteristicsHigh Capacity - 100
  channelsCarries Video and Audio signal together
• This cable is used to send the WIRO signal to all
  the Iroquois classrooms.

4
Coaxial Cable - Connectors
F -Connector Standard in Cable Industry
F -Coupler Connects two coaxial plug
ends BNC Used to adapt composite and coaxial
Locking mechanism
5
RCA Cable

• Wire carries only one signal
• Video, Audio Left or Audio Right
• Higher quality picture and audio than coaxial
  cables

White
Yellow
Red
6
S-Video S-Connectors
7
S-Cable
8
Audio Connectors

• 1/4 and 1/8 Plug Provides either Mono or
  Stereo sound
• Use for headphones

1/8 Plug
1/4 Plug
9
Audio Connectors (Stereo vs. Mono)
Two rings Stereo two speakers
One ring Mono one speaker
10
