Model Repositories (XMI, JMI, EMF)

1
Model Repositories(XMI, JMI, EMF)

• by
• Luciana de Paiva Silva
• lps_at_cin.ufpe.br
• www.cin.ufpe.br/lps
• Disciplina IN0980-MDA, Components and Software
  Reuse
• Professor Jacques Robin

2
OUTLINE

• Model repositories
• Requirements and services
• Model manipulation formats
• Programming objects
• XML document
• Exemplos (ZoooMM, AM3, ReMoDD)
• Existing tools
• XMI
• JMI
• EMF

3
What is a model repository?

• Ideally combine services from project artifact
  management system and model base management
  system
• Services
• Persistence and fault tolerance
• Concurrent and authenticated access control
• Version control
• Model query
• Model conformity to meta-model
• Model creation through meta-model instantiation
• API to connect a variety of model manipulation
  tools
• Graphical editors
• Indented embedded vertically listed items
  editors
• Transformation engines
• Formal verification
• Code generation
• Test generation

DiVinE
4
Model Manipulation Formats Programmable Objects

• One programming language class for each
  meta-model meta-class
• One programming object for each model element
  (i.e., meta-class instance)
• Advantages
• Model manipulation services can be directly
  programmed in same language
• To the point gt succinct, concise
• Paradigm alignment (object-orientation)
• Disadvantages
• Intermediate software needed for both
  persistence and human reading
• Conventional OO platform do not support
  meta-circularity

5
XML Language family

• XML
• Flexible language to encode documents or data
  using sequences of elements containing
  attribute-value pairs and delimited by opening
  and closing tags defining an open-ended set of
  categories
• An XML document is well-formed conforms to XML
  syntax
• XML Schema
• XML encoded metadata language to encode XML
  document schemas
• 44 built-in data types
• Specifies type, cardinality and ordering
  constraints on the elements and attributes of an
  XML document
• An XML document is valid with respect to a
  schema if it satisfies the constraints specified
  in the schema
• XSLT
• XML encoded language to specify and apply
  transformation on XML documents

6
Model Manipulation Formats XML Document

• One XML tag for each meta-model meta-class
• One XML Schema for each graph to tree ordering
  projection of one MOF meta-model
• One XML element or attribute for each model
  element
• Thus, one XML document for each model
• Advantages
• Persistent and human understandable
• Shared meta-circularity representation principle
• XML Schema is meta-level description reusing
  base level language (XML)
• MOF2 is meta-level description reusing base
  level language (UML2 Infra-structure)
• Disadvantages
• Verbose
• Paradigm mismatch makes robust parsing
  challenging

7
Examples

• There are several projects that have been started
  some time ago on model repositories ZoooMM, AM3,
  ReMoDD, etc.
• http//www.cs.york.ac.uk/puml/puml-list-archive/

8
Zooomm project
ZOOOMM is the International ZOO of MetaModels,
Schemas, Grammars and Ontology for Software
Engineering.

• Megazoo (zoo of megamodels)
• Textual megamodels.
• Megamodels in UML.
• Megamodels in sciences art.

• Metametazoo (zoo of metametamodels)
• UML, MOF, XMI, EMF, KM3, Emphatic, GXL, USE,
  ODMG, Xschema, GXL, RSF, TA, Telos, EXPRESS, OWL,
  RDFS, DAML, OIL, GXL, RSF, TA, Telos, EXPRESS,
  OWL, RDFS, DAML, OIL.

Metazoo (zoo of metamodels) We have already a
few hundreds of metamodels collected over years
from more than 2000 papers in software
engineering.
9
Planet MDE
10
AM3 - ATLAS MegaModel Management

• The goal of AM3 (ATLAS MegaModel Management) is
  to provide a practical support for modeling in
  the large. The objective is to deal with global
  resource management in a model-engineering
  environment. We base this activity on the concept
  of a "megamodel".
• Features
• Management of various artifacts
• Management of various relations between artifacts

• Sharing and exchange of megamodel elements
• User interfaces for viewing (browsing, creating,
  changing, etc.) megamodel elements

11
ReMoDD

• On May 24 at ICSE, - ReMoDD (ReMoDD A Repository
  for Model Driven Development)
• Create a community resource of model-driven
  development artifacts to provide infrastructure
  to improve the use of model-based development.

12
XML Metadata Interchange (XMI)

• XML Metadata Interchange (XMI) provê o mecanismo
  para implementar a distribuição de modelos entre
  ferramentas de diferentes empresas e entre
  repositórios, ou seja, intercâmbio de metadados
  entre ferramentas de modelagem.
• Integra três padrões XML, UML, MOF
• Padrão OMG para codificar modelos de documentos
  XML em conformidade com o padrão MOF meta-model
• Permits automated generation of
• An XML schema document from a MOF meta-model and
  vice-versa
• An XML document from a model and vice-versa
• XML document generated from model is valid with
  respect to the XML schema document generated from
  the models meta-model
• Model generated from XML document conforms to the
  meta-model generated from the XML schema of the
  XML document

13
XMI Simplified
XML Streams (Models) (Many - based on each
metamodel DTD
XML Syntax and Encoding
X MI
MOF Metadata Definitions Management
Validate
XML Schema (MetaModels) (1 per metamodel used
for validation)
UML Metamodel Analysis Design
14
XMI Document

• Every XMI document consists
• An XML version processing instruction. Example
  lt? XML version1.0 ?gt
• An optional encoding declaration that specifies
  the character set, which follows the ISO-10646
  (also called extended Unicode) standard. Example
  lt? XML version1.0 ENCODINGUCS-2 ?gt
• Any other valid XML processing instructions.
• A schema XML element.
• An import XML element for the XMI namespace.

15
Example of MOF meta-models serializationas XML
Schema using XMI
extends
extends
0 ..
includes

• ltxsdschema xmlnsxsdhttp//www.w3.org/2005/XMLS
  chemagt
• ltxsdcomplexType name umlModelgt
• ltxsdcomplexType name actorgt
• ltxsdsequencegt ltxsdelement name name
  type xsdstring/gt lt/xsdsequencegt
• lt/xsdcomplexTypegt
• ltxsdcomplexType name useCasegt
  ltxsdsequencegt ltxsdelement name title type
  xsdstring/gt lt/xsdsequencegt
• lt/xsdcomplexTypegt
• ltxsdcomplexType name systemgt
• ltxsdsequencegt ltxsdelement name name
  type xsdstring/gt lt/xsdsequencegt
• lt/xsdcomplexTypegt
• ltxsdcomplexType name actor2useCase
  isDirected true isAggregation false
  isGeneralization falsegt
• ltxsdsequencegt
• ltxsdelement from actor minOccurs
  1 maxOccurs 1/gt ltxsdelement to
  useCase minOccurs 1 maxOccurs 1/gt
  lt/xsdsequencegt
• lt/xsdcomplexTypegt
• ltxsdcomplexType name system2useCase
  isDirected true isAggregation true
  isGeneralization falsegt
• ltxsdsequencegt
• ltxsdelement name from ref system
  minOccurs 1 maxOccurs 1/gt
• ltxsdelement name to ref useCase
  minOccurs 1 maxOccurs unbounded/gt
• lt/xsdsequencegt

16
XMI Specification
17
Projeto UFPE
18
Projeto UNIOESTE

• Objetivos principais
• Estudo de diagramas i gerados pela ferramenta
  OME na linguagem TELOS
• Estudo da tecnologia XML e o padrão XMI
• Estudar o padrão XMI para implementar uma
  ferramenta computacional que possa mapear
  diagramas SD e SR (i) para Diagramas de Caso de
  Uso UML.
• Coordenador Victor Francisco Araya Santander

19
Java Metadata Interface - JMI

• Enables the implementation of a dynamic,
  platform-independent infrastructure to manage the
  creation, storage, access, discovery, and
  substitute of metadata.
• JMI is based on the Meta Object Facility (MOF)
• For any MOF model, JMI defines the templates for
  generating the Java APIs.

20
Application Areas

• Data warehousing and BI
• Integration of DW/BI tools frameworks
• Component-based development and deployment (UML)
• Integration of tool suites/component frameworks
• Enterprise information portals
• Integration of disparate data sources
• Systems Management
• Hardware/software inventory, storage management

21
JMI Use-Cases

• Data warehousing applications
• Different data sources, data warehouse formats,
  and analytical tools
• Community requires common interchange
  infrastructure to provide a common programming
  model and a common interchange format

22
JMI Use-Cases

• The Software Development Scenario
• Different tool for each task
• Different tools for the same task
• JMI as a platform for integrating heterogeneous
  software development tools to provide a complete
  software development solution
• Large Enterprise JavaBeans (EJB) application
  (UML tools, Integrated Development Environments
  (IDEs), EJB deployment tools)
• EJB development solution - built around JMI using
  three metamodels that represent the domains of
  the different tasks
• Each tool participate integrated solution
  through an adapter that maps the tool specific
  APIs to the JMI APIs for the respective model.
• Reduce integration complexity

23
Java Metadata Interface(JMI) Specification
24
Eclipse Project

• Provide open platform for application development
  tools
• Run on a wide range of operating systems
• GUI and non-GUI
• Language-neutral
• HTML, Java, C, JSP, EJB, XML, GIF,
• Facilitate perfect tool integration
• At UI and deeper
• Add new tools to existing installed products
• Attract community of tool developers
• Including independent software vendors (ISVs)
• Capitalize on popularity of Java for writing tools

25
Plataforma Eclipse
the major components, and APIs, of the Eclipse
Platform
26
Eclipse Plug-in Architecture

• Plug-in - smallest unit
• Big example HTML editor
• Small example Action to create zip files
• Extension point - named entity for collecting
  contributions
• Example extension point for workbench preference
  UI
• Extension - a contribution
• Example specific HTML editor preferences

27
Eclipse Plug-in Architecture

• Each plug-in
• Contributes to 1 or more extension points
• Optionally declares new extension points
• Depends on a set of other plug-ins
• Contains Java code libraries and other files
• Lives in its own plug-in subdirectory
• Details spelled out in the plug-in manifest
• Manifest declares contributions
• Code implements contributions and provides API
• plugin.xml file in root of plug-in subdirectory

28
Plug-in Manifest
plugin.xml
ltplugin id com.example.tool" name
Example Plug-in Tool" class
"com.example.tool.ToolPlugin"gt ltrequiresgt
ltimport plugin "org.eclipse.core.resources"/gt
ltimport plugin "org.eclipse.ui"/gt
lt/requiresgt ltruntimegt ltlibrary name
tool.jar"/gt lt/runtimegt ltextension
point "org.eclipse.ui.preferencepages"gt
ltpage id "com.example.tool.preferences"
icon "icons/knob.gif" title Tool
Knobs" class "com.example.tool.ToolPrefe
renceWizard/gt lt/extensiongt ltextension-point
name Frob Providers id
"com.example.tool.frobProvider"/gt lt/plugingt
29
Eclipse
30
Eclipse Modeling Framework (EMF)

• EMF is a modeling framework and code generation
  facility for building tools and other
  applications based on a structured data model.
• From a model specification described in XMI, EMF
  provides tools and runtime support to produce a
  set of Java classes for the model, a set of
  adapter classes that enable viewing and
  command-based editing of the model, and a basic
  editor.
• In a nutshell it is to exchange models into Java
  code

31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
Here is the complete class hierarchy of the Ecore
model (shaded boxes are abstract classes)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
EMF homepage
47
EMF Capítulo 2
48
Summary

• Há 20 anos atrás
• estruturada, procedimentos, dados, função.
• Atualmente
• Avanço tecnológico novas perspectivas
• Business intelligence, onlogogies .
• Futuro
• federal global model repository
• web semantica

49
References Model Repositories

• http//www.tdan.com/i013fe04.htm - The Data
  Administration Newsletter (TDAN.com) Robert S.
  Seiner - Publisher
• http//www.cin.ufpe.br/if710/slides/ModelReposito
  riesTransformations.ppt
• http//www.cs.york.ac.uk/puml/puml-list-archive/
• http//www.sciences.univ-nantes.fr/lina/atl/www/pa
  pers/eTX2006/03a-FreddyAllilaireRev1.pdf
• http//www.cs.york.ac.uk/puml/puml-list-archive/
• http//zooomm.org/
• http//planetmde.org/
• http//www.eclipse.org/gmt/am3/
• http//planetmde.org/gamma2006/
• Bézivin, J, Jouault, F, and Valduriez, P On the
  Need for Megamodels. In Proceedings of the
  OOPSLA/GPCE Best Practices for Model-Driven
  Software Development workshop, 19th Annual ACM
  Conference on Object-Oriented Programming,
  Systems, Languages, and Applications. 2004.
  Disponível em www.sciences.univ-nantes.fr/lina/atl
  /www/papers/OOPSLA04/bezivin-megamodel.pdf

50
References XML and XMI

• www.omg.org/technology/documents/formal/xmi.htm
• www.jeckle.de/xmi.htm
• www.omg.org/technology/xml/
• http//www.idealliance.org/proceedings/xml05/slide
  s/borensteinfox.ppt
• http//homepages.inf.ed.ac.uk/perdita/XMI/

51
References - JMI

• http//java.sun.com/products/jmi/
• http//www.cs.kent.ac.uk/events/conf/2001/eebw/sli
  des/sjcSlides.pdf
• http//www.openmdx.org/documents/v1.1/tutorials/jm
  i/htmlsingle/JMI-Binding.htmlS-JMI-MAPPING-OVERVI
  EW
• http//java.sun.com/products/jmi/pres/preso1/text0
  .htm

52
References - EMF

• http//www.eclipse.org/emf/docs.phppresentations
• Eclipse EMF Help - overviews, tutorials, API
  reference - EMF Project Web Site
• http//www.eclipse.org/emf/ - documentation,
  newsgroup, mailing list, Bugzilla
• Eclipse Modeling Framework by Frank Budinsky et
  al.
• Addison-Wesley 1st edition (August 13, 2003) -
  ISBN 0131425420.
• IBM Redbook
• publication number SG24-6302-00

53
Thanks
