Wired Media

1
Wired Media
2
Transmission Flaws

• Transmission signals are adversely affected by a
  number of factors two of which we will discuss
• Attenuation
• Distortion
• Noise

3
Attenuation

• Loss of signal strength as transmission travels
  away from source
• Analog signals may be boosted by an amplifier,
  which increases not only voltage of a signal but
  also noise accumulated
• Digital signals may be boosted by a repeater
  which regenerates the original signal without
  noise if possible

4
Attenuation and Noise
5
Combating Attenuation

• Repeaters are used to regenerate and retransmit
  digital signals
• Amplifiers are used to boost analog signals

6
Distortion

• Occurs because signals of different frequencies
  travel at different speeds
• The bits become more and more distorted the
  further the signal travels through the media

7
Distortion and Repeaters
8
Noise

• Electrical interference causes spurious
  electrical currents in the media that interfere
  with the signal
• Humans perceive noise during a telephone call
  call as static
• Three sources of noise
• Thermal noise
• Impulse noise
• Crosstalk

9
Effect of Noise on Analog SIgnal
10
Effect of Noise on Digital Signal
11
Thermal Noise

• Caused by the thermal agitation of electrons in
  metal
• Present in all electronic equipment and forms an
  upper bound on the potential capacity of a media
• Also called white noise
• Can be reduced by cooling media and equipment but
  this isnt usually practical

12
Impulse Noise

• Caused by electromagnetic interference (EMI) and
  radio frequency interference (RFI)
• Electromagnetic interference (EMI)
• Interference that may be caused by motors, power
  lines, television, copiers, fluorescent lights,
  or other sources of electrical activity
• Radiofrequency interference (RFI)
• Interference that may be generated by motors,
  power lines, televisions, copiers, fluorescent
  lights, or broadcast signals from radio or TV
  towers Unlike thermal noise, impulse noise is
  variable and is difficult to plan for
• Care must be taken when cables are laid to avoid
  sources of EMI/RFI

13
Impulse Noise
14
Impulse Noise and Data Rate
15
Crosstalk

• Crosstalk is interference caused in one wire by
  the legitimate signal in an adjacent wire
• Crosstalk can be detected as background
  conversations during phone calls
• Crosstalk is particularly a problem at the
  connectors that connect cables to network devices

16
Crosstalk and Attenuation
17
Effect of Increased Bandwidth

• Increasing the bandwidth of a signal increases
  throughput by increasing the number of bits that
  can be represented in a given time
• At higher frequencies the signal attenuates
  faster
• Smaller bits may be wiped more easily by noise
• Cant turn bandwidth up beyond what media can
  support
• Higher bandwidth signals travel shorter distances
  on a given medium

18
Signal Strength, Bandwidth and Noise
19
Wired Media Types
20
Media Characteristics

• Throughput
• Perhaps most significant factor in choosing a
  transmission medium is throughput
• Cost
• Cost of installation
• Cost of new infrastructure versus reusing
  existing infrastructure
• Cost of maintenance and support
• Cost of a lower transmission rate affecting
  productivity
• Cost of obsolescence

21
Media Characteristics

• Size and scalability
• Specifications determining size and scalability
• Maximum nodes per segment
• Maximum segment length
• Maximum network length
• Latency is the delay between the transmission of
  a signal and its receipt

22
Media Characteristics

• Connectors
• Connects wire to network device
• Noise immunity

23
Types of Wired Media

• Coax
• Twisted Pair
• Unshielded Twisted Pair (UTP)
• Shielded Twisted Pair (STP)
• Fiber Optics
• Multimode fiber (MMF)
• Singlemode fiber (SMF)

24
Coax
Metal Shield
Conductor
Insulation
Cover
25
BNC T-Connector
Terminator
26
BNC Connector and NIC
27
NIC with BNC Connector
28
Coaxial Cable
29
Coax

• Advantages
• Throughput Very good transmission
  characteristics
• Noise immunity High resistance of EMI/RFI
• Size and Scalability Can support large networks
• Cost Durable so is sometimes used in hostile
  environments
• Disadvantages
• Cost Can be difficult to work with and not used
  often so will need to be replaced if network
  changes
• Connectors Less reliable and more difficult to
  use than the RJ-45 used with twisted pair

30
Twisted Pair
Interference in one wire balances interference in
the other. A perfectly balanced pair of wires
with perfectly symmetrical twists would be
totally immune to noise.
31
Damaged Twisted Pair
Imperfections reduce the cables resistance to
noise. Imperfections may be due to poor
manufacturing or poor installation practices.
32
Four-Pair UTP
33
RJ-45 Connector
34
NIC with RJ-45 Port
35
Categories of UTP
36
PreStandard UTP
37
Unshielded Twisted Pair (UTP)

• Advantages
• Cost Easy to work with and inexpensive,
  supported by most network standards so can be
  used for many years as network evolves
• Connectors RJ-45 connector is extremely reliable
  when properly constructed
• Size and scalability Individual cable segments
  must be short but structured cabling methods
  support very large networks
• Disadvantages
• Throughput Capable of lower bandwidths than coax
  or fiber
• Noise immunity Have to be careful during
  installation to avoid noise

38
Shield Twisted Pair (STP)

• STP is similar to UTP except it has a shielding
  similar to coax around the cable
• Shielding must be grounded as with coax
• Imperfections in shielding can increase noise in
  cable

39
STP
40
Shield Twisted Pair (STP)

• Advantages
• Cost More expensive and difficult to work with
  than UTP
• Disadvantages
• Throughput Similar to UTP
• Noise Immunity Not significantly better in terms
  of noise resistance than UTP if not installed
  exactly right
• Connectors Reliable but not as easy as RJ-45
  since shielding must be grounded
• Size and scalability Not supported by as many
  standards as UTP

41
Fiber Optic Cable
42
Fiber Cable
Cladding
Core
Cladding and core are different types of glass
with different reflective indices. Light travels
down the core.
43
Fiber Connectors
ST Connector
SC Connector
Ends of cable must be polished smooth to
reduce light loss and fiber must be perfectly
aligned in connector.
44
Fiber NIC
ST Connector Port
Requires two fiber strands. One for send and
receive.
45
Multimode Fiber (MMF)

• Light bounces off boundary between cladding and
  core
• Causes light loss
• Uses short wavelength LEDs and lasers
• Short wavelength signals attenuate faster
• Comes in 62.5/125 µm and 50/125 µm

46
Single Mode Fiber (SMF)

• Light is focused down center of core
• Very little light lost
• Uses expensive long wavelength lasers
• Long wavelengths can travel very long distances
• Comes in 8/125 µm
• More expensive to implement than MMF

47
Fiber-Optic Cable

• Single-mode fiber
• Carries light pulses along single path
• Multimode fiber
• Many pulses of light generated by LED travel at
  different angles

Figure 4-29 Single-mode and multimode
fiber-optic cables
48
Graded MMF

• Boundary between cladding and core is not abrupt
  so that light rays are bent toward the center
  rather than reflected
• This causes less light loss

49
Fiber Optics

• Advantages
• Noise immunity Totally immune to noise, no
  electrical emissions so almost impossible to tap
• Throughput Capable of very high bandwidths and
  distances
• Size and scalability Capable of very long
  distances
• Disadvantages
• Connectors Fiber connectors require special
  training and care to make
• Cost More expensive cable, more expensive to
  install and much more expensive equipment
