Lower Extremity Assessment and Procedures

1
Lower Extremity Assessment and Procedures

• PRA 635

2
Osseous Anatomy of Hip Joint
3
LAE Hip

• There is no palpable joint play that can give
  examiner specific palpatory awareness of loss of
  joint play in LAE, but..
• Patient Supine with leg in neutral abduction and
  neutral external rotation
• Examiner Contacts patients calcaneus and dorsum
  of foot
• Action Impulse and body weight inferiorly
• Do not internally rotate leg as doing so may jam
  femoral head into acetabulum

4
LAE Hip
5
Hip Flexion-Adduction Arc Test

• Patient Supine with knee in flexion
• Examiner Stands perpendicular to patient
• Fingers interlocked over patients knee and
  snugly against chest/sternum
• Action Downward pressure through femur shaft
  into hip joint
• Move hip joint through an arc from 90 of hip
  flexion to full adduction and then from 140 of
  hip flexion to full adduction
• May feel a sticking point within this arc

6
Hip Flexion-Adduction Arc Test
7
Osseous Anatomy of Knee Joint
8
Patellar Superior-Inferior Glide

• Patient Supine with 5 knee flexion and support
• Examiner Holds superior and inferior aspects of
  patella with thumbs/index fingers of both hands
• Action Push patella superior to inferior without
  downward pressure
• Normal glide is 1-2 inches
• Mobilize by several stretching type pushes inot
  fixation

9
Patellar Superior-Inferior Glide
10
Patellofemoral AP Rock

• Patient Supine with 5 knee flexion and support
• Examiner Holds one thumb on superior aspect of
  patella and other thumb on inferior aspect of
  patella
• Action Push AP on superior aspect of patella and
  then on inferior aspect of patella

11
Patellofemoral AP Rock
12
Patellofemoral ML and LM Excursion

• Patient Supine with 5 knee flexion and support
• Examiner Holds medial and lateral aspects of
  patella with thumbs/index fingers of both hands
• Action Push ML or LM, gliding patella on femur
• Fixation is though to be fibrotic restriction

13
Patellofemoral ML and LM Excursion
14
Tibiofemoral Varus Tilt

• Patient Supine with legs extended
• Examiner Stands facing medial aspect of LE
• Superior hand is placed on medial femoral
  condyles
• Inferior hand grasps ankle
• Action Bring knee just-off lock and tilt ML
• Manipulation uses HVLA directed ML

15
Tibiofemoral Varus Tilt
16
Tibiofemoral Valgus Tilt

• Patient Supine with legs extended
• Examiner Stands facing lateral aspect of LE
• Superior hand is placed on lateral femoral
  condyles
• Inferior hand grasps ankle
• Action Bring knee just-off lock and tilt LM
• Manipulation uses HVLA directed LM

17
Tibiofemoral Valgus Tilt
18
Tibiofemoral AP Glide

• Patient Supine with knee flexed 90
• Examiner Seated facing distal aspect of
  patients foot for stabilization
• Grasp posterior aspect of proximal tibia with
  fingers
• Thumbs placed on either side of tibial tuberosity
• Action Short thrust delivered PA then AP

19
Tibiofemoral AP Glide
20
Tibiofemoral LAE

• There is no palpable joint play that can give
  examiner specific palpatory awareness of loss of
  joint play in LAE, but..
• Patient Supine with leg abducted 45 and off
  table
• Examiner Stabilizes patients tibia with inner
  thighs
• Contact both hands on either side of and just
  proximal to femoral condyles
• Action Both knees extend while simultaneously
  pushing cephalad with both hands

21
Tibiofemoral LAE
22
Tibiofemoral Rotational Mobilization

• Patient Supine with hip and knee flexed
• Examiner Standing beside patient grasping
  proximal aspect of tibia just inferior to
  tibiofemoral joint
• Assess rotational joint play in medial and
  lateral rotation
• Action Examiner meets physiological barrier of
  motion, either medial or lateral, and holds this
  end-range
• While holding end play, rotate entire knee joint
  further into range mobilizing fixation

23
Tibiofemoral Rotational Mobilization
24
Superior Tibiofibular AP Shear

• Patient Supine with knee flexed at 90
• Examiner Contacts superior fibular head with
  thumb on anterior surface and index finger bent
  at 45 on posterior surface
• Action AP and PA shear

25
Superior Tibiofibular AP Shear
26
Osseous Anatomy of the Foot
27
Mortise Joint LAE

• Patient Supine with knee and hip flexed at 90
• Examiner Seated with back against patients
  posterior upper leg
• Examiner cradles ankle with both hands
• Lateral hand contacts dorsal surface of foot at
  talus
• Indifferent (medial) thumb contacts posterior
  aspect of ankle joint just above Achilles
  insertion
• Foot should be everted to lock subtalar joint

28
Mortise Joint LAE

• Action Examiner pushes away from body while
  producing slight counterpressure against
  patients upper leg

29
Mortise Joint LAE
30
Mortise Joint AP Glide

• Patient Supine with knee and ankle flexed at 90
• Examiner Contact hand grasps above mortise
• Stabilizing hand holds plantar surface of foot
  until ankle is flexed at 90
• Action Examiner uses push-pull mobilization

31
Mortise Joint AP Glide
32
Subtalar Rock

• Patient Supine with knee and ankle flexed at 90
• Examiner Contacts navicular on dorsal surface
  with thumb web and just above insertion of
  Achilles tendon with indifferent thumb web
• Action Joint distraction then thumb web
  contacting calcaneus pushes with slight wrist
  flexion
• Other thumb web contact pushes in reverse
  direction with same force rocks calcaneus on
  talus

33
Subtalar Rock
34
Subtalar Joint Medial/Lateral Tilt

• Patient Supine with knee and ankle flexed at 90
• Examiner Contacts navicular on dorsal surface
  with thumb web and just above insertion of
  Achilles tendon with indifferent thumb web
• Action Examiner uses LAE to cause medial/lateral
  tilt of joint
• Foot should not be everted

35
Subtalar Joint Medial Tilt
36
AP Glide Metatarsals on Cuneiforms

• Patient Supine with knee flexed at 90
• Examiner Stands laterally to patient and finds
  base of first metatarsal bone
• Examiners superior hand is over cuneiform and
  inferior hand is over first metatarsal
• Action Inferior hand moves such that index
  fingers and knuckles of both hands rub on one
  another as metatarsals are moved in AP glide on
  cuneiforms

37
AP Glide Metatarsals on Cuneiforms
38
Metatarsal-tarsal Mobilization

• Patient Supine position
• Examiner Stabilizes dorsal aspect of cuneiforms
  and cuboid with index finger and thumb web
• Mobilizing hand makes contact with metatarsal
  hand with index finger
• Action Metatarsal heads are lifted slightly, and
  a clockwise force and then a counterclockwise
  mobilizing force are applied

39
Metatarsal-tarsal Mobilization
40
Intermetatarsal Mobilization

• Patient Supine position
• Examiner Seated at foot of patient
• Contacts shaft of fourth and fifth metatarsals
• Index finger is on dorsal aspect and thumb on
  plantar aspect of forefoot proximal to metatarsal
  heads
• Action Mobilize fifth metatarsal while
  stabilizing fourth metatarsal in AP plane
• Progress in same manner for assessment other
  digits/articulations

41
Intermetatarsal Mobilization
42
MTP LAE

• Patient Supine position
• Examiner Contacts the phalanx with platform
  contact
• Platform is a fully flexed index finger acting as
  a platform with thumb holding phalanx
• Action While stabilizing metatarsal head,
  examiner contacts proximal base of phalanx and
  pulls

43
MTP LAE
44
Cuboid AP Glide

• Patient Supine position
• Examiner Contacts dorsal and plantar surfaces of
  cuboid with index and thumb, respectively
• Indifferent hand makes contact on dorsal,
  proximal aspect of fifth metatarsal shaft
• Action Joint play in PD or DP directions
• Manipulation action approximates
  wringing-out-towel action, with both hands moving
  in rotational direction

45
Cuboid AP Glide
46
Cuboid AP Glide
