The Next Challenges in Software Verification

1
The Next Challenges inSoftware Verification

• Rupak Majumdar
• U.C. Los Angeles

2
Software Validation

• Large scale reliable software is hard to build
  and test
• Different groups write different components
• Integration testing is a nightmare

3
Property Checking

• Programmer gives partial specifications
• Code checked for consistency w/ spec
• Different from program correctness
• Specifications are not complete
• Is there a complete spec for Word ? Emacs ?

4
Interface Usage Rules

• Rules in documentation
• Order of operations data access
• Resource management
• Incomplete, unenforced, wordy
• Violated rules ) bad behavior
• System crash or deadlock
• Unexpected exceptions
• Failed runtime checks

5
Property 1 Double Locking
An attempt to re-acquire an acquired lock or
release a released lock will cause a deadlock.
Calls to lock and unlock must alternate.
6
Property 2 Drop Root Privilege
Chen-Dean-Wagner 02
User applications must not run with root
privilege When execv is called, must have
suid ? 0
7
Property 3 IRP Handler
Fahndrich
8
Does a given usage rule hold?

• Undecidable!
• Equivalent to the halting problem
• Restricted computable versions are
• prohibitively expensive (PSPACE)
• Why bother ?
• Just because a problem is undecidable,
• it doesnt go away!

9
Plan

• Motivation
• Lazy Abstraction
• Some Ugly Secrets
• Some Recent Progress

10
Example
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4 while(new ! old) 5 unlock ()
return
11
What a program really is
State
Transition
3 unlock() new 4
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4 while(new ! old) 5 unlock ()
return
12
The Safety Verification Problem
Error
Safe
Initial
Is there a path from an initial to an error state
? Problem Infinite state graph Solution Set of
states ' logical formula
13
Representing States as Formulas
F states satisfying F s s ² F
F FO fmla over prog. vars
F1 Å F2
F1 Æ F2
F1 F2
F1 Ç F2
F
F
F1 µ F2
F1 implies F2
i.e. F1Æ F2 unsatisfiable
14
Idea 1 Predicate Abstraction

• Predicates on program state
• lock
• old new
• States satisfying same predicates
• are equivalent
• Merged into one abstract state
• abstract states is finite

15
Abstract States and Transitions
State
3 unlock() new 4
Theorem Prover
lock oldnew
lock oldnew
16
Abstraction
State
3 unlock() new 4
Theorem Prover
lock oldnew
lock oldnew
Existential Lifting
17
Abstraction
State
3 unlock() new 4
lock oldnew
lock oldnew
18
Analyze Abstraction
Analyze finite graph Over Approximate Safe )
System Safe No false negatives Problem Spurious
counterexamples
19
Idea 2 Counterex.-Guided Refinement
Solution Use spurious counterexamples to refine
abstraction !
20
Idea 2 Counterex.-Guided Refinement
Solution Use spurious counterexamples to refine
abstraction
1. Add predicates to distinguish states
across cut 2. Build refined abstraction
Imprecision due to merge
21
Iterative Abstraction-Refinement
Solution Use spurious counterexamples to refine
abstraction
1. Add predicates to distinguish states
across cut 2. Build refined abstraction -eliminat
es counterexample 3. Repeat search Till real
counterexample or system proved safe
Kurshan et al 93 Clarke et al
00 Ball-Rajamani 01
22
Lazy Abstraction
Yes
BLAST
Safe
Abstract
C Program
Refine
No
Property
Trace
23
Lazy Abstraction
Yes
BLAST
Safe
C Program
Instrumented C file With ERROR label
spec.opt
Property
No
Trace
24
Problem Abstraction is Expensive
Reachable
Problem abstract states 2predicates Exponentia
l Thm. Prover queries

• Observe
• Fraction of state space reachable
• Preds 100s, States 2100 ,
• Reach 1000s

25
Solution1 Only Abstract Reachable States
Safe
Solution Build abstraction during search
Problem abstract states 2predicates Exponentia
l Thm. Prover queries
26
Solution2 Dont Refine Error-Free Regions
Error Free
Solution Dont refine error-free regions
Problem abstract states 2predicates Exponentia
l Thm. Prover queries
27
Key Idea 1 Reachability Tree
Initial
Unroll Abstraction 1. Pick tree-node (abs.
state) 2. Add children (abs. successors) 3. On
re-visiting abs. state, cut-off
1
2
3
Find min infeasible suffix - Learn new predicates
locally - And forget predicates that arent
needed - Rebuild subtree with new preds.
5
4
3
28
Key Idea 1 Reachability Tree
Initial
Unroll Abstraction 1. Pick tree-node (abs.
state) 2. Add children (abs. successors) 3. On
re-visiting abs. state, cut-off
1
2
3
6
Find min infeasible suffix - Learn new
predicates - Rebuild subtree with new preds.
4
7
5
3
3
Error Free
29
Key Idea 1 Reachability Tree
Initial
Unroll 1. Pick tree-node (abs. state) 2. Add
children (abs. successors) 3. On re-visiting
abs. state, cut-off
1
2
3
6
Find min spurious suffix - Learn new predicates -
Rebuild subtree with new preds.
4
7
8
5
8
3
1
1
3
Error Free
S1 Only Abstract Reachable States S2 Dont
refine error-free regions
SAFE
30
Predicates grows with program size
while(1) 1 if (p1) lock() if (p1)
unlock() 2 if (p2) lock() if
(p2) unlock() n if (pn) lock()
if (pn) unlock()
T F T
Tracking lock not enough
Problem p1,,pn needed for verification Exponen
tial reachable abstract states
31
Predicates grows with program size
while(1) 1 if (p1) lock() if (p1)
unlock() 2 if (p2) lock() if
(p2) unlock() n if (pn) lock()
if (pn) unlock()
LOCK
LOCK, p1
LOCK, p1
LOCK, p1
LOCK, p1
LOCK
p1p2
p1 p2
p1 p2
p1 p2
2n Abstract States
Problem p1,,pn needed for verification Exponen
tial reachable abstract states
32
Predicates useful locally
while(1) 1 if (p1) lock() if (p1)
unlock() 2 if (p2) lock() if
(p2) unlock() n if (pn) lock()
if (pn) unlock()
LOCK
p1
LOCK , p1
LOCK, p1
LOCK , p1
LOCK
LOCK , p1
LOCK
LOCK
p2
pn
2n Abstract States
Solution Use predicates only where needed Using
Counterexamples - Find predicates - Find where
predicates are needed
33
Key Idea 2 Parsimonious Abstractions

• Abstract Locally
• Find what predicates are required to rule out a
  trace
• Find where predicates can be forgotten

LOCK
LOCK , p1
LOCK, p1
LOCK
Counterexample analysis based on interpolants
34
Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
1
Reachability Tree
Predicates LOCK
35
Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
lock() old new qq-gtnext
2
LOCK
1
2
Reachability Tree
Predicates LOCK
36
Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
2
LOCK
q!NULL
3
LOCK
1
2
3
Reachability Tree
Predicates LOCK
37
Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
2
LOCK
3
LOCK
q-gtdata new unlock() new
4
LOCK
4
1
2
3
Reachability Tree
Predicates LOCK
38
Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
2
LOCK
3
LOCK
4
LOCK
newold
5
LOCK
5
4
1
2
3
Reachability Tree
Predicates LOCK
39
Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
2
LOCK
3
LOCK
4
LOCK
5
LOCK
5
unlock()
4
LOCK
1
2
3
Reachability Tree
Predicates LOCK
40
Analyze Counterexample
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
lock() old new qq-gtnext
2
LOCK
q!NULL
3
LOCK
q-gtdata new unlock() new
4
LOCK
newold
5
LOCK
5
unlock()
4
LOCK
1
2
3
Reachability Tree
Predicates LOCK
41
Analyze Counterexample
What predicates should we track to eliminate
this spurious counterexample?
lock() old new q
1
LOCK
2
LOCK
q0
3
unlock() new
LOCK
4
LOCK
newold
5
LOCK
unlock()
LOCK
42
Analyze Counterexample
Step 1 Construct a logical formula that is
satisfiable iff the trace is executable
1
LOCK
lock() old new q
lock1 1 old1 new1 q1
2
LOCK
q0
q10
3
LOCK
unlock() new
lock2 0 new2 new1 1
4
LOCK
newold
new2old1
What predicate is needed here?
5
LOCK
unlock()
lock3 0
LOCK
43
Analyze Counterexample
lock() old new q
lock1 1 old1 new1 q1
Trace
Trace formula
q0
Interpolant
q10
unlock() new
lock2 0 new2 new1 1
newold
new2old1
unlock()
lock3 0
Relevant Information
Predicate
1. after executing trace prefix 2. has
present values of variables 3. makes trace
suffix infeasible
implied by TF prefix on common variables
TF suffix is unsatisfiable
44
Interpolants Predicates
lock() old new q
lock1 1 old1 new1 q1
q0
old new
q10
unlock() new
lock2 0 new2 new1 1
old ? new
newold
new2old1
unlock()
lock3 0
Construct interpolants at each point in the
trace, and use the interpolants as
predicates For the theory of linear arithmetic
and equality with uninterpreted functions,
interpolants can be computed efficiently
McMillan05
45
Repeat Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
1
Reachability Tree
Predicates LOCK, newold
46
Repeat Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
lock() old new qq-gtnext
2
LOCK , newold
1
2
Reachability Tree
Predicates LOCK, newold
47
Repeat Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
2
LOCK , newold
3
LOCK , newold
q-gtdata new unlock() new
4
LOCK , new old
4
1
2
3
Reachability Tree
Predicates LOCK, newold
48
Repeat Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
2
LOCK , newold
3
LOCK , newold
4
LOCK , new old
newold
4
1
2
3
Reachability Tree
Predicates LOCK, newold
49
Repeat Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
2
LOCK , newold
3
LOCK , newold
4
LOCK , new old
new!old
1
LOCK, new old
4
4
1
2
3
Reachability Tree
Predicates LOCK, newold
50
Repeat Build-and-Search
Example ( ) 1 do lock() old
new q q-gtnext 2 if (q ! NULL) 3
q-gtdata new unlock() new
4while(new ! old) 5 unlock ()
1
LOCK
2
LOCK , newold
SAFE
3
LOCK , newold
4
4
LOCK , newold
LOCK , new old
1
5
5
LOCK, new old
4
4
4
1
LOCK , newold
2
3
Reachability Tree
Predicates LOCK, newold
51
Key Idea Reachability Tree
Initial
Unroll 1. Pick tree-node (abs. state) 2. Add
children (abs. successors) 3. On re-visiting
abs. state, cut-off
1
2
3
6
Find min spurious suffix - Learn new predicates -
Rebuild subtree with new preds.
4
7
8
5
8
3
1
1
3
Error Free
S1 Only Abstract Reachable States S2 Dont
refine error-free regions
SAFE
52
Lazy Abstraction
Yes
Safe
Abstract
C Program
Refine
No
Property
Trace
Problem Abstraction is Expensive
Solution 1. Abstract reachable states,
2. Avoid refining error-free regions
Key Idea Reachability Tree
53
Device Driver Experiments
Property3 IRP Handler Win NT DDK



Pre-processed
54
Plan

• Motivation
• Lazy Abstraction
• Some Ugly Secrets
• Some Recent Progress

55
Device Drivers are a Nice Success Story, But

• They are really the only non-trivial systems and
  specifications model checked
• Other applications
• Lock / unlock in the kernel
• File open / close in open source code
• Is software model checking the right tool?

56
Example Locking Revisited
0 lock 0 1 if (p) 2 assert(lock
0) 3 lock 1 4 5 . . .

• Control Flow Information Stmt 0 dominates Stmt
  2 All paths going to stmt 2 must go through stmt
  0
• Data Flow information Between stmt 0 and stmt 2,
  lock does not get modified the value of lock
  after stmt 0 is same as the value of lock at stmt
  2

57
Two Compiler Algorithms

• Dominator Tree captures control flow information
• For two stmts n, n we say n dominates n, n ?
  D(n) if for every path to n goes through n
• n is a immediate dominator of n, n Idom(n)
  iff for every dominator of n is also a dominator
  of n
• A dominator tree is a tree whose nodes are
  statements where each parent immediate dominates
  its children
• Static Single Assignment captures dataflow
  information
• Each variable is syntactically assigned once
• ?-assignments deal with joins
• x ? (x1, x2 . . . xn)

58
Example
0 lock 0 1 if (p) 2 assert(lock
0) 3 lock1 4 5 . . .
n0
n1,true
n5
n1,false
SSA Form
n2
0 locko 0 1 if (p) 2 assert(lock0
0) 3 lock11 4 5 lock2 ?(lock0,
lock1) 6. . .
n3
Dominator Tree
59
Dominator Invariants
n0
lock0 0
n1,true
n5
n1,false
p
lock2 ?(lock0, lock1)
p
n2
assert(lock0 0)
n3
lock1
n0 ? n1,true (lock0 0) ? p
(lock0 0)
gt
60
Dominator Invariants

• Theorem
• For a node n, DInv(n) n ? (?ndominates
  nn)is an
• n-invariant

• After executing a node n, n holds
• If ndominates n then along every path to n, then
  there is a point where n holds
• After the last occurrence of n, the only nodes
  visited are those that are dominated by n
• None of the variables in n are modified

61
Dominator Invariants are Insufficient
n0
00 locko 0 01 if (p) 02 assert(lock0
0) 03 lock11 04 05 lock2
?(lock0, lock1) 06 . . . 07 if (p) 08
assert(lock2 1) 09 lock3 0 10
11 lock4 ?(lock2, lock3)
n5
n1,true
n1,false
n7,true
n7,false
n11
n2
n3
n8
n9
(lock0 0) ? lock2 ?(lock0, lock1) ? p
gt
(lock2 1)
62
?-Strengthening
n0
00 locko 0 01 if (p) 02 assert(lock0
0) 03 lock11 04 05 lock2
?(lock0, lock1) 06 . . . 07 if (p) 08
assert(lock2 1) 09 lock3 0 10
11 lock4 ?(lock2, lock3)
n5
n1,true
n1,false
n7,true
n7,false
n11
n2
n3
n8
n9
(lock0 0) ? lock2 ?(lock0, lock1) ? p
gt
(lock2 1)
63
?-Strengthening
entry
CFG
n
n
Idom(n)
n x3 ?(x1, x2)
n
((x3 x1) ? DInv(Idom(n),n) ? (x3 x2) ?
DInv(Idom(n),n)) ? SI (entry, Idom(n))
n
n
Dominator Tree
64
2-SI is Sufficient
n0
00 locko 0 01 if (p) 02 assert(lock0
0) 03 lock11 04 05 lock2
?(lock0, lock1) 06 . . . 07 if (p) 08
assert(lock2 1) 09 lock3 0 10
11 lock4 ?(lock2, lock3)
n5
n1,true
n1,false
n7,true
n7,false
n11
n2
n8
n3
n9
p ? (lock0 0) ? (lock2 ?(lock0, lock1)) gt
(lock2 1)
65
2-SI is Sufficient
n0
00 locko 0 01 if (p) 02 assert(lock0
0) 03 lock11 04 05 lock2
f(lock0, lock1) 06 . . . 07 if (p) 08
assert(lock2 1) 09 lock3 0 10
11 lock4 f(lock2, lock3)
n5
n1,true
n1,false
n7,true
n7,false
n11
n2
n8
n3
n9
p ? (lock0 0) ? (((lock2 lock0)?p) ? ((lock2
lock1)?p?(lock11)))) gt (lock2 1)
66
k-Structural Invariants (k-SI)
Idom(n)

• k-SI unfolds the nesting structure of the program
• k is the branch-width senstivity of the analysis

k
k-1
n
k-1
k
k-1
k-2
k-1
k-2
k-2
k
n
n
Dominator Tree
67
Experiments

• Precision Tradeoffs
• Path sensitivity 2-SI captures the relevent
  structural idioms
• Past k2, FP does not decrease. Complex control
  flow is rare for these properties

Although 2-SI is simple, 2-SI is sufficient.
68
In Comparison
69
Lesson

• Software verification tools are probably too
  heavy weight for a bunch of applications they
  have been used for
• They should really be applied to deeper
  properties of systems
• But where are the specs?

70
Why were Device Drivers a Success?

• A real problem
• Device drivers have 7X bugs as kernel
• Have to get right!
• Willing to invest time in writing specs
• Narrow and well defined interface
• Finite state protocol
• Control dominated properties
• What are other systems with these
  characteristics?
• And why havent we done anything about them?

71
Other Systems

• OS Kernel
• Low level memory routines
• Software Models of Hardware
• Processors, ASICs,

72
Why Havent we Verified These?

• We tried, but Blast didnt immediately work
• Yet!
• Reasoning about Data Structures
• Reasoning about Bitvectors
• Reasoning about Asynchrony

73
Data Structures
Example ( ) 1 s emptyset () 2 do
lock() old new q 3 if (q
0) 4 s add (s,q) unlock()
new 5 while(new ! old) 6 unlock
() 7 if(! empty (s)) 8 y choose (s) 9
assert( y 0)

• Added a set data structure and an assertion on
  data derived from the set
• Modeling the actual set implementation gives
  imprecise results
• Mainly because of aliasing

74
Bitvectors
Example (u32 a ) 1if (a 0x1 0)
error(Permission) 2 pte (a
0xFFFFF000)gtgt12 3 b tabpte 4 base b
0xFFFFFFFC 5 off a 0xFFC 6 return mbase
off

• What is going on?
• Stumps humans, compilers, verifiers
• What can we do about it?

75
Asynchrony
reqs() if(rNULL) async reqs()
return rc malloc() if (rc NULL)
return ABORT_OUT_OF_MEM async
client(rc,r-gtid) r r-gtnext reqs()
global request_list r

• How can we make the
• model checker aware of
• asynchronous calls?

main() ...//setup request list r async
reqs() ...//dispatch loop
client(client_t c, int id) ...//setup c-gtid
id ...//continue processing return
76
Plan

• Motivation
• Lazy Abstraction
• Some Ugly Secrets
• Some Recent Progress
• Data Structures
• Bitvectors
• Asynchrony

77
Data Structures
Example ( ) 1 s emptyset () 2 do
lock() old new q 3 if (q
0) 4 s add (s,q) unlock()
new 5 while(new ! old) 6 unlock
() 7 if(! empty (s)) 8 y choose (s) 9
assert( y 0)

• Added a set data structure and an assertion on
  data derived from the set
• Modeling the actual set implementation gives
  imprecise results
• Mainly because of aliasing

78
An Old Idea Modular Reasoning
Library
Client
79
An Old Idea Modular Reasoning
Library
Client
Interface Functions emptyset void -gt set add
set X elt -gt set choose set -gt elt
Logical Relations x emptyset() x y
add(x,e) y x e e choose(x) x Ç e 2 x
Replaced reasoning about set implementation
with reasoning about the theory of sets
80
A New Counterexample
1
Example ( ) 1 s emptyset () 2 do
lock() old new q 3 if (q
0) 4 s add (s,q) unlock()
new 5 while(new ! old) 6 unlock
() 7 if(! empty (s)) 8 y choose (s) 9
assert( y 0)
s emptyset()
2
lock() old new q
3
q!0
5
newold
6
unlock()
7
!empty(s)
8
y choose(s) y!0
Infeasible Track s
81
Question Do Interpolants Exist?

• Craigs Theorem guarantees existence for first
  order logic
• But we are interpreting formulas over the theory
  of sets

82
The Good News

• Interpolants always exist for recursively
  enumerable theories
• The proof is a simple application of compactness
• So interpolants exist for theory of sets, theory
  of lists, (quantifier-free) theory of arrays,
  multisets,

83
The Bad News

• The proof is a simple application of
  compactness
• May be algorithmically inefficient
• Daunting engineering task to construct
  interpolating decision procedure for each
  individual theory

84
An Alternate Path Reduction

• Want to compile formulas in a new theory to
  formulas in an old theory such that interpolation
  in the old theory imply interpolation in the new
  theory
• T reduces to R can compile formulas in theory T
  to formulas in theory R
• And use decision procedures for R
• to answer decision questions for T
• Technically Given theories T and R, with Rµ T, a
  reduction is a computable map ? from T formulas
  to R formulas such that for any T-formula ?
• ? and ?(?) are T-equivalent
• ? is T-satisfiable iff ?(?) is R-satisfiable

85
Example Theory of Sets

• Theory of sets reduces to theory of equality with
  uninterpreted functions
• x y 8 e. e2 x , e2 y
• x 8 e.e? x
• xU 8 e.e2 x
• xe e2 x Æ 8 e.e2 x ) e e
• xy z 8 e.e2 x, e2 y Ç e2 z
• xyÅ z 8 e.e2 x, e2 y Æ e2 z

86
Example Theory of Multisets

• Theory of multisets reduces to the combination
  theory of equality with uninterpreted functions
  and linear arithmetic
• x y 8 e. count(x,e) count(y,e)
• x 8 e.count(x,e) 0
• x(e,n) count(x,e)max(0,n)
• Æ 8 e.e? e ) count(x,e)0
• xy z 8 e.count(x,e) count(y,e)count(z,e)
• xy z 8 e. count(x,e) max(count(y,e),
  count(z,e))
• xyÅ z 8 e. count(x,e) min(count(y,e),
  count(z,e))

87
Reduction and Interpolation
?- and ? in Theory T
Reduction from T to R
?- and ? in Theory R
Interpolate in R
Interpolant ? in Theory R as well as T
Eliminate quantifiers in T or R
Quantifier-free interpolant
88
Main Theorem

• Interpolants for the theory of arrays, sets, and
  multisets can be computed by reduction to the
  combination theory of linear arithmetic and
  equality with uninterpreted functions
• We already have interpolating decision procedures
  for this latter theory

89
Analyzing the Counterexample
1
Trace Formula
s emptyset()
s1 lock1 1 old1 new q1 q1 ? 0 new
old1 lock2 0 s1? y 2 s1 y ? 0
2
lock() old new q
3
q!0
5
newold
6
unlock()
7
!empty(s)
8
y choose(s) y!0
90
Analyzing the Counterexample
Trace
Trace Formula

• s emptyset()
• q
• q 0
• s add(s,q)
• q
• q ! 0
• !empty(s)
• y choose(s)
• assert(y0)

s1 q1 q1 0 s2 s1q1 q2 ? 0 s2?
y 2 s2 y ? 0
Example ( ) 1 s emptyset () 2 do
lock() old new q 3 if (q
0) 4 s add (s,q) unlock()
new 5 while(new ! old) 6 unlock
() 7 if(! empty (s)) 8 y choose (s) 9
assert( y 0)
91
Analyzing the Counterexample
Trace
Reduced Formula

• s emptyset()
• q
• q 0
• s add(s,q)
• q
• q ! 0
• !empty(s)
• y choose(s)
• assert(y0)

8 e.e ? s1 q1 q1 0 (8 e.e2s2 , e2s1 Ç e
q1) q2 ? 0 (8 e.e? s2) y 2 s2 y ? 0
Example ( ) 1 s emptyset () 2 do
lock() old new q 3 if (q
0) 4 s add (s,q) unlock()
new 5 while(new ! old) 6 unlock
() 7 if(! empty (s)) 8 y choose (s) 9
assert( y 0)
92
Analyzing the Counterexample
Reduced Formula
Trace
Interpolants

• s emptyset()
• q
• q 0
• s add(s,q)
• q
• q ! 0
• !empty(s)
• y choose(s)
• assert(y0)

8 e.e ? s1 q1 q1 0 (8 e.e2s2 , e2s1 Ç e
q1) q2 ? 0 (8 e.e? s2) y 2 s2 y ? 0
s s Æ q 0 s ? Æ (8 e.e2s ) e
0) y 0
93
Forward Search with All Predicates
Example ( ) 1 s emptyset () 2 do
lock() old new q 3 if (q
0) 4 s add (s,q) unlock()
new 5 while(new ! old) 6 unlock
() 7 if(! empty (s)) 8 y choose (s) 9
assert( y 0)
1
LOCK
2
LOCK, s
3
LOCK, s, newold
LOCK , s, newold
5
4
LOCK, q 0, newold
5
6
LOCK , s, newold
LOCK, s0,new ? old
2
LOCK, s0,new ? old
LOCK, s
7
Predicates LOCK, newold, q0, s
s Æ 8 e.e2 s) e 0
(s0)
94
Forward Search with All Predicates
Example ( ) 1 s emptyset () 2 do
lock() old new q 3 if (q
0) 4 s add (s,q) unlock()
new 5 while(new ! old) 6 unlock
() 7 if(! empty (s)) 8 y choose (s) 9
assert( y 0)
LOCK, s0,new ? old
3
LOCK, s0, newold
LOCK , s0, newold
5
4
LOCK, q 0, newold
5
6
LOCK , s0, newold
LOCK, s0,new ? old
2
LOCK, s0,new ? old
s0
7
8
s0
Predicates LOCK, newold, q0, s ,
y0, sÆ 8 e.e2 s) e 0
(s0)
9
y0
SAFE
95
Plan

• Motivation
• Lazy Abstraction
• Some Ugly Secrets
• Some Recent Progress
• Data Structures
• Bitvectors
• Asynchrony

96
Bitvectors
Example (u32 a ) 1if (a 0x1 0)
error(Permission) 2 pte (a
0xFFFFF000)gtgt12 3 b tabpte 4 base b
0xFFFFFFFC 5 off a 0xFFC 6 return mbase
off

• What is going on?

97
Bitvectors
Example (u32 a ) 1if (a 0x1 0)
error(Permission) 2 pte (a
0xFFFFF000)gtgt12 3 b tabpte 4 base b
0xFFFFFFFC 5 off a 0xFFC 6 return mbase
off
0
1
31
a,32
a
98
Bitvectors
Example (u32 a ) 1if (a 0x1 0)
error(Permission) 2 pte (a
0xFFFFF000)gtgt12 3 b tabpte 4 base b
0xFFFFFFFC 5 off a 0xFFC 6 return mbase
off
11
0
31
a,32
,1
11
20
a
20
pte
12
99
Bitvectors
Example (u32 a ) 1if (a 0x1 0)
error(Permission) 2 pte (a
0xFFFFF000)gtgt12 3 b tabpte 4 base b
0xFFFFFFFC 5 off a 0xFFC 6 return mbase
off

• Bitvector Types
• Sequence of
• ltname, lengthgt

offset,10
w,1
r1
a
index,20
pte
index,20
012
base
02
offset,30
off
offset,10
02
020
100
Bitvectors
Example (u32 a ) 1if (a 0x1 0)
error(Permission) 2 pte (a
0xFFFFF000)gtgt12 3 b tabpte 4 base b
0xFFFFFFFC 5 off a 0xFFC 6 return mbase
off
Example (struct vaddr a ) 1if (a.rd 0)
error(Permission) 2 pte.index a.index 3
b tabpte.index 4 base b.addr 5 off
a.offset 6 return mbase off
offset,10
w,1
r1
a
index,20
pte
index,20
012
base
02
offset,30
off
offset,10
02
020
101
Bitvector Type Inference

• Can set up bitvector inference as a type
  inference problem
• Have a type variable for each expression in the
  program
• Generate constraints for each bitwise operation
• Solve, using a style of ML type inference, by
  splitting bitfields
• Can compute the principal bitvector typing

102
Experiences

• Implemented bitvector inference for C
• Applied to
• pmap, a kernel virtual memory system
• Implements the code for our running example
• Mondrian, a memory protection system
• scull, a Linux device driver
• Bitvector inference takes less than 1s

103
Mondrian

• C implementation with 10 programmer-provided
  assertions
• Uses bit packed structures to represent memory
  and permission bits
• 2600 lines of code, generated 775 constraints
• Translated, after inference, to program without
  bitvector operations
• 18 different bit-packed structures
• Assertions verified using Blast
• 6 safe, 4 false positives
• False positives due to imprecise modeling of
  arrays

104
Next Step An Address Decoder

• Or, things the type system cannot do
• Bitvector operations with non-constants
• x ltlt y, x y,
• (Approximated with a value flow analysis)
• Dependent bitvectors

immediate
reg1
opcode
reg1
reg2
02
105
Plan

• Motivation
• Lazy Abstraction
• Some Ugly Secrets
• Some Recent Progress
• Data Structures
• Bitvectors
• Asynchrony
• Conclusions

106
Combining Strengths
Is Blast a theorem prover manipulating
formulas? A program analysis interpreting
an abstract program? A model checker exploring
states? Its all of the above! Blast is called
a model checker for historical reasons
Program Analysis - Imprecise
Abstraction Shrink state space

• Theorem Proving
• - loop invariants
• Behaviors encoded in logic
• Refine
• Theorem provers
• Computing Successors,Refine

Lazy Abstraction
Model Checking - Finite-state model, state
explosion State Space Exploration Path
Sensitive Analysis Counterexamples Finding
Relevant Facts
107
More generally

• What does it take to get verified software?
• Blast is a small part in the whole process
• How can we make the programmers job easier,
  through a combination of
• Language support
• Process support
• Tool support
• Debugging and visualization support?

108

• Questions?
• http//www.cs.ucla.edu/rupak/

109
Acknowledgments

• Tom Henzinger
• Ranjit Jhala
• RuGang Xu
• Deepak Kapur
• Calogero Zarba
