An Owned and Lit Fiber Infrastructure for Research and Education: Needs

1
An Owned and Lit Fiber Infrastructure for
Research and Education Needs Feasibility

• Jacqueline Brown for Ron Johnson
• University of Washington,
• Pacific Wave, CENIC,
• N A T I O N A L L I G H T R A I L
• ronj_at_cac.washington.edu
• APAN meeting Fukuoka, Japan, 24 Jan. 2003

2
Main Cost Drivers for owned lit fiber

• Expertise Administration
• Fiber (long lines and metro)
• Fiber maintenance
• Huts, Racks and Power CoLo
• Optronics incl. maintenance/sparing
• NOC(s) remote hands
• Local Loops/Laterals
• MetaPoP capabilities (not unique to fiber)
• Not cheap to create but low marginal costs for
  more ? s.
• Cooperation Essential !

3
Why Fiber?

• The Capacity well need for RE eScience isnt
  otherwise affordable
• The Capabilities our research net. communities
  need are not available!
• It is now Cheaper (in local and regional loop in
  the U.S.) than carriers offerings
• Business reasons - Owned Fiber provides
• Long Term Negotiating Leverage with carriers
• Insurance against new rounds of carrier Monopoly
  Behaviors
• Predictable/Stable Anchor Points Transit to
  catalyze more investment in trans-regional nets.

4
Why Fiber? We are stuck in the past.

• We need to be able to Innovate. We are in the
  research business and shared IP services with
  small packets is not the answer to everything
• "Research can't be held hostage to what industry
  thinks the markets want.
• Infrastructure investments of the past are
  getting in the way of real innovation.
• "The situation is reminiscent of the telco
  infrastructure situation before ARPANET.
• (Bob Kahn, CRA-Snowbird 02)
• We have the Opportunity (albeit perishable) incl.
  current willingness of private sector for
  lit-fiber partnership.

5
We have important drivers and motivations, e.g.,
this Aubrey Bush NSF Slide -)
RESEARCH Network research testbeds EXPERIMENTAL
Experimental network
infrastructure OPERATIONAL 24/7 operational
high performance networks
Chicago 5/DEC/01
Grand Challenges in e-Science
Grand Challenges in e-Science
6
Plus, we are already doing it for RE

• Extended Metro, e.g.
• Pacific NorthWest Gigapop in greater Seattle
• MaX in D.C.
• Many more in 1st stages or in the pipeline
• Regional
• I-Wire
• Indiana
• CENIC ONI
• Network Virginia
• More in the pipeline
• And, increasing fiber from gigapops to research
  oriented campuses, academic medical centers
  labs
• So we have key e2e building blocks

7
PN/W-GP Seattle Metro Fiber in service
e.g.
PACIFIC NORTHWEST GIGAPOP
U of Alaska ARSC Fairbanks
Childrens Hospital
Inst. for Systems Biology
UW
UWMC
Microsoft
Cellular Sciences Inst.
Fred Hutch SCCA
Level3 PoP
KEXP
Westin Bldg Carrier Hotel
PN/W-GP PLR Spokane
ISPs, Abilene, BBs, Pacific Wave (intl.
connects/peerings)
Harborview Research
PN/W-GP PLR Portland
WA Dept. Information Services
Fiber in Service
UW Downtown
8
I-WIRE Background
From Linda Winkler 8-02
e.g.

• State Funded Dark Fiber Optical Infrastructure to
  support Networking and Applications Research
• 7.5M Total Funding
• 4M FY00-01 (in hand)
• 2.5M FY02 (approved 1-June-01)
• Additional 0.5M in FY03, FY04
• Application Driven
• Access Grid Telepresence Media
• Computational Grids Internet Computing
• Data Grids Information Analysis
• New Technologies Proving Ground
• Optical Switching
• Dense Wave Division Multiplexing
• Advanced middleware infrastructure

NU / Starlight
UIC
IIT
ANL
ICN
UC
NCSA/UIUC
For more information see www.iwire.org
9
CalREN Optical
10
Northern California
11
Southern California
12
Industry Windows of Opportunity

• Optronics kit manufacturers (some now with LAN
  PHY, and enterprise network mgmt etc).
• Wave Vendors?, but will competition continue?
  recent rising prices and lessened competition in
  some markets. Wave deals have short lifespan,
  must re-do in new market.
• Fiber Owners but is firesale over?
• Critical Mass in RE community - Existing metro,
  regional (linked!) now interregional/national
  efforts.

13
N A T I O N A L L I G H T R A I L

• Connecting the dots of opportunity and need
• Owned and lit Dark Fiber National footprint
• Prime Goal Serve very high-end Experimental and
  Research Applications
• 4 x 10GB Wavelengths initially
• Expand to 40 10Gb wavelengths
• Partnership model

14
NLR Goals

• Research! (including Network Research)
• Experimentation in networking and in education
• Regional fiber/ ? efforts in edu research
  sectors
• Education
• Academic Med. Center driven clinical activities
• Development implementation of network
  computing technologies not otherwise likely to be
  generally available commercially as early as
  needed in RE.
• Enabling deterministic and other e2e bandwidth/
  ?s, dark fiber and conduit for Grid, eScience
  etc. for Regionals etc.

15
Governance

• LLC - Equity Partner model
• Joint Research Council
• Joint Technology Council
• Push envelope wrt Distributed Network Operations
• Waves/subdivisions governed by various groups

16
NLR Service offerings

• Waves!!!
• MetaPoP capabilities
• Dedicated OC-192cs or 10GEs (No wave can
  interfere with others)
• Many potential services/uses done by others or in
  partnership with NLR, e.g.
• Shared experimental 10gbs IP service
• Must be able to tolerate outages
• Supports experimental code/packet size etc
• Subdivided waves for dedicated uses
• Probably delivered as gigabit Ethernet

17
National LightRail cost-effective owned lit RE
fiber fabric
Leading-Edge e2e services experimental network
facilities via MetaPoPs and inter-gigapop links
for research next gen. tech., arch., grids, DTF
expansion, content, sensors, apparatus Up to 40
dedicated 10 gigabit waves with up to hundreds of
dedicated gigabit links system-wide.
Initial footprint 6/03
Canarie fabric
SEA
10 gbs Tycom IEEAF donation
BOS
CLV?
10 gbs Tycom IEEAF Donation
CHI
NY
SUN
PIT
DC
DEN
Raleigh
LA
ATL
MetaPoPs Core Nodes ADM sites Desired
Expansion PoPs/ADM National LightRail
(NLR) International Broadband Metro/WAN owned
Fiber Rings' connecting strategic RE endpoints.
10/14/02
18
NLR Footprint and Layer 1 Topology
SEA
POR
SAC
BOS
NYC
CHI
OGD
DEN
SVL
CLE
WDC
PIT
FRE
KAN
RAL
NAS
STR
LAX
PHO
WAL
ATL
SDG
OLG
DAL
19
Lit National NLR Core Fabric Fiber on Level(3)
footprint
A. Starting footprint - operational by Jne 2003.
5,207 miles
A.
B. Multi-Loop core for owned fiber RE net - June
2004?
11,000 miles
B.
Owned lit fiber on a L3 footprint core Note
overlayed on lighter colored full L3 fiber
footprint
Dashed lines for regional not costed
7-28-02 ronj
20
Lit National NLR Core Fabric Fiber (on a Level(3)
fiber core)
Core, L3 Core, Williams
Access, L3 Access, Williams
C. A. stepwise evolution with NY Atlanta
segments.
D. Double Loop NLR core interim step alternative
9,342 miles
C.
D.
E. Triple Loop core w/Williams NY/Bost segment.
F. Triple Loop core plus sample regional access
loops.
F.
E.
7-28-02 ronj
21
N A T I O N A L L I G H T R A I L

• For more information, contact
• Ron Johnson ronj_at_cac.washington.edu
• Tom West twest_at_cenic.org

8-11-02
