Design for Supply Chain Management
Phil Kaminskykaminsky_at_ieor.berkeley.edu
David Simchi-Levi Philip Kaminsky Edith
Simchi-Levi
2
The Manufacturing Environment

• Rapid Changes
• New products rapidly introduced
• Short, unknown product life cycles
• High Variety of Products
• Long Production Lead Times
• Increasing storage and transportation costs
• Difficult to forecast demand

3
The Goals of the Manufacturing Organization

• Responsiveness
• Competitive pricing
• Efficiency
• Customer service

Conflicting Goals!
4
Why Do These Goals Conflict?

• Forces for keeping low inventory
• inventory expensive
• low salvage values
• Forces for keeping high inventory
• long lead times
• customer service is important
• demand is hard to predict
• reduction in transportation quantity

5
Design For Logistics

• Product and process design key cost drivers of
  product cost
• Design for Manufacturing used design to decrease
  manufacturing costs
• Major supply chain costs include transportation
  costs, inventory costs, distribution costs

6
Design For Logistics

• Design for Logistics uses product design to
  address logistics costs
• Key Concepts of Design for Logistics
• Economic packaging and transportation
• Concurrent/Parallel Processing
• Standardization

7
Economic Transportation and Storage

• Design products so that they can be efficiently
  packed and stored
• Design packaging so that products can be
  consolidated at cross docking points
• Design products to efficiently utilize retail
  space

8
Examples

• Ikea
• Worlds largest furniture retailer
• 131 stores in 21 countries
• Large stores, centralized manufacturing,
  compactly and efficiently packed products
• Rubbermaid
• Clear Classic food containers - designed to fit
  14x14 Wal-Mart shelves

9
Concurrent/ Parallel Processing

• Objective is to minimize lead times
• Achieved by redesigning products so that several
  manufacturing steps can take place in parallel
• Modularity/Decoupling is key to implementation
• Enables different inventory levels for different
  parts

10
The Network Printer Example
Board
Printer
Customer (Europe)
Stage 1 (Europe)
Stage 2 Integration (Far East)
Stage 1 (Europe)
Board
Printer
Stage 2 (Far East)
Customer (Europe)
Integration (Europe)
Plastics, motors, etc.
11
Standardization

• Shortening lead times is not always possible
• How else can inventory levels be reduced and
  forecast accuracy improved?
• Standardization of products and processes
• Product commonality
• Process commonality

12
Modularity in Product and Process

• Modular Product
• Can be made by appropriately combining the
  different modules
• It entails providing customers a number of
  options for each module
• Modular Process
• Each product undergo a discrete set of operations
  making it possible to store inventory in
  semi-finished form
• Products differ from each other in terms of the
  subset of operations that are performed on them

13
Modularity in Product and Process

• Semiconductor wafer fabrication is modular since
  the type of chip produced depends on the unique
  set of operations performed
• Oil refining is not modular since it is
  continuous and inventory storage of semi-finished
  product is difficult

14
Modularity in Product and Process

• Are modular products always made from modular
  processes?

15
Modularity in Product and Process

• Modular products are not always made from modular
  processes
• Bio-tech and pharmaceutical industries make
  modular products but use non-modular processes
  many products are made by varying the mix of a
  small number of ingredients

16
Types of Standardization

• Part Standardization
• Common parts are used across many processes
• Product redesign might be necessary
• Process Standardization
• Standardizing as much of the process as possible,
  making a generic or family product
• Delaying differentiation
• Called Delayed differentiation, Postponement

17
Postponement Example

• Demand for black t-shirts
• 50 probability 100
• 50 probability 200
• Same for white t-shirts
• Production alternatives
• Produce 150 of each color ahead of time
• Produce 300 which can be dyed after demand is
  observed

18
Postponement Example

• First Alternative
• 25 probability -- short 50 of each
• 25 probability -- extra 50 of each
• 50 probability -- short 50 of one, extra 50 of
  the other
• Second Alternative
• 25 probability -- short 50 of each
• 25 probability -- extra 50 of each
• 50 probability -- no shortage or extra

19
Postponement Key Concepts

• Delay differentiation of products in the same
  family as late as possible
• Enables the use of aggregate forecasts
• Enables the delay of detailed forecasts
• Reduces scrapped or obsolete inventory, increases
  customer service
• May require new processes or product design with
  associated costs

20
Postponement Considerations

• Tradeoff increased product cost with decreased
  inventory
• Need to decide where to postpone - the push-pull
  boundary
• Position in product lifecycle is factor in
  postponement strategies
• Inventory value may increase
• Consider tariffs and duties

21
Hewlett-Packard LaserJets

• LaserJets are manufactured in Japan
• Previously, the printers had two different power
  supplies (110, 220 volts)
• Differentiation had to happen immediately
• An improved design enables a single power supply
  to work for both voltages.
• 5 Cost Savings

22
Hewlett-Packard Disk DrivesManufacturing Process
Redesign

• HPs disk drive division supplied several
  customers

tests
Customer 1
PCB Insertion
Customer 2
Customer 3
Coupon Insertion
PCB insertion postponed
Customer 1
PCB Insertion
Customer 2
common tests
Customer 3
tests
23
Benetton Background

• A world leader in knitwear
• Massive volume, many stores
• Logistics
• Large, flexible production network
• Many independent subcontractors
• Subcontractors responsible for product movement
• Retailers
• Many, small stores with limited storage

24
Benetton Supply Cycle

• Primary collection in stores in January
• Final designs in March of previous year
• Store owners place firm orders through July
• Production starts in July based on first 10 of
  orders
• August - December stores adjust orders (colors)
• 80-90 of items in store for January sales
• Mini collection based on customer requests
  designed in January for Spring sales
• To refill hot selling items
• Late orders as items sell out
• Delivery promised in less than five weeks

25
Benetton Flexibility

• Business goals
• Increase sales of fashion items
• Continue to expand sales network
• Minimize costs
• Flexibility important in achieving these goals
• Hard to predict what items, colors, etc. will
  sell
• Customers make requests once items are in stores
• Small stores may need frequent replenishments

26
It is hard to be flexible when...

• Lead times are long
• Retailers are committed to purchasing early
  orders
• Purchasing plans for raw materials are based upon
  extrapolating from 10 of the orders

How to be flexible?
Postponement
27
BenettonOld Manufacturing Process
Spin or Purchase Yarn
Dye Yarn
Finish Yarn
Manufacture Garment Parts
Join Parts
28
BenettonNew Manufacturing Process
Spin or Purchase Yarn
Manufacture Garment Parts
Join Parts
This step is postponed
Dye Garment
Finish Garment
29
Benetton Postponement

• Why the change?
• The change enables Benetton to start
  manufacturing before color choices are made
• What does the change result in?
• Delayed forecasts of specific colors
• Still use aggregate forecasts to start
  manufacturing early
• React to customer demand and suggestions
• Issues with postponement
• Costs are 10 higher for manufacturing
• New processes had to be developed
• New equipment had to be purchased

30
Procurement Standardization

• Consider a large semiconductor manufacturer
• The wafer fabrication facility produces highly
  customized integrated circuits
• Processing equipment that manufactures these
  wafers are very expensive with long lead time and
  are made to order
• Although there is a degree of variety at the
  final product level, each wafer has to undergo a
  common set of operations
• The firm reduces risk of investing in the wrong
  equipment by pooling demand across a variety of
  products

31
Product Standardization

• Downward Substitution
• Produce only a subset of products (because
  producing each one incurs high setup cost)
• Guide customers to existing products
• Substitute products with higher feature set for
  those with lower feature set
• Which products to offer, how much to keep, how to
  optimally substitute ?

32
A Framework for Standardization
Process Standardization
Part Standardization
Modular
Maximize component commonality across products
Delay customization as late as possible
Product
Product Standardization
Procurement Standardization
Non-Modular
Leverage equipment and part commonality across
products
Carry a limited number of products in inventory
Non-Modular
Modular
Process
33
HP DeskJet Case Background

• High volume, high speed manufacturing in
  Vancouver
• Many different models, all completed in Vancouver
• Three distribution centers
• North American
• Asian
• European
• Manufacturing time one week
• Transportation lead times
• Europe 4-5 weeks
• US
• At distribution centers, simple standardized
  process

34
HP DeskJet Case Analysis

• Problems
• High inventory levels
• Inventory imbalance in Europe
• Causes
• Uncertainty about correct inventory levels
• Many geographic options (localization)
• Long lead times
• Uncertain market
• Difficulty at getting divisions to work together
• What are HPs options?

35
HP DeskJet Case Options

• Short Term
• Rationalize safety stock
• Long Term
• Air shipment
• European factory
• More inventory
• Better forecasting
• DC localization

36
Safety Stock RationalizationExample Europe AB

• Recall Safety Stock z ? STD ?LT

37
Evaluating Alternatives

• Air Shipment
• Expensive
• European Factory
• Not sufficient volume
• Better Forecasting
• How?
• More Inventory
• More problems
• DC Localization
• What will savings be?

38
Evaluating DC Localization

• In DC localization, risk pooling can be used to
  reduce total inventory while maintaining service
  levels
• To evaluate inventory, compare total safety stock
  held if individual localized units are held in
  inventory or if generic units are held
• Other costs must also be evaluated

39
Evaluating DC Localization
40
DC Localization

• Safety Stock Reduction
• Current 19,089 units (3.55 weeks)
• With localization 12,792 units (2.4 weeks)
• Other benefits
• Lower value of transit inventory
• Freight reductions
• Local presence of manufacturing
• Customs implications
• Local procurement of localization materials
• But there are costs
• Product redesign
• DC modifications

41
Implementation

• RD Support
• The product is working, so why bother?
• DC Support
• Not our core competency
• New packaging
• Capital investment

42
Results

• Successful implementation
• Millions saved
• Service levels increased
• Packaging won awards
• Best practice spread to other HP divisions

43
Supplier Integration

• Competitive forces are driving firms to integrate
  suppliers into product development
• Spectrum of Supplier Integration
• None
• White Box Informal integration
• Grey Box Formal integration, with collaborative
  teams
• Black Box Interface requirements are given,
  product is returned

44
Supplier Integration

• What approach is appropriate?
• Determine internal competencies
• Determine product development needs
• Identify external development and manufacturing
  needs
• If future products have components that require
  external expertise and can be separated from
  other components, a black box approach makes
  sense.
• If components cannot be separated, a grey box
  approach makes sense.
• If some expertise can be found in house, a white
  box approach might make sense.

45
The Bookshelf Approach

• Monitor the development of new technologies
• Follow suppliers that have developed expertise
• When appropriate, integrate these new
  technologies
• This balances the advantages and disadvantages of
  being on the cutting edge
• No need to gain experience with the technology,
  because suppliers are doing this for you.
• Can introduce the technologies when needed.

46
Mass Customization

• The delivery of a wide variety of customized
  goods at low cost
• The key is modular products and processes, so
  that customer requests can be met
• According to Pine, companies need to evolve
  towards modular companies, with managers
  ensuring that modules are compatible.
• Consider National Bicycle

47
Mass Customization and Supply Chain Management

• An advanced supply chain is essential
• This is particularly true when modules extend
  beyond a single company.
• Consider
• Postponement for regional customization
• The value of strategic partnerships and supplier
  integration
• Dell
