An Optimal and Progressive Algorithm for Skyline Queries

1
An Optimal and Progressive Algorithm for Skyline
Queries

• Presenter Jongwuk Lee
• Information Database Systems Lab.
• POSTECH

2
Contents

• Introduction
• Skyline queries
• Existing solutions
• Motivation
• Algorithms BBS
• Other discussions

3
Finding the Cheapest Closest Hotels
price

• Which one is better?
• i and h?
• i, because its price and distance dominate those
  of h.
• i and k?
• I do not know.

y
10
b
e
9
a
c
8
7
d
6
g
f
5
l
h
n
4
3
2
i
k
m
1
x
o
1
2
3
4
5
6
7
8
9
10
distance
4
Skyline Objects

• A set of objects not dominated by any other
  objects.
• Dominating region

5
Existing Solutions

• Block Nested Loop (BNL)
• Divide-and-Conquer (DC)
• Bitmap method
• Index method
• Nearest Neighbor (NN)

Elementary skyline algorithms
Progressive skyline algorithms
6
Existing Solutions

• Block Nested Loop (BNL)
• Scan the dataset and keep a list of candidate
  skyline points.
• Compare a point p with every other point in the
  list.
• Advantages
• Wide applicability
• Disadvantages
• Numerous comparisons, inadequacy for on-line
  processing

7
Existing Solutions

• Divide-and-Conquer (DC)
• Divide the dataset into several partitions.
• Compute partial skylines in each partition.
• Compute global skylines by merging them.

8
Existing Solutions

• Nearest Neighbor (NN)
• Find nearest neighbor point.
• Divide the space by the nearest neighbor point.
• Compute recursively until empty space.

1
2
3
4
5
6
7
8
9
10
9
Existing Solutions

• NN over three or more dimensions
• Has overlapped partitions in divided subspaces.
• Needs duplicate elimination.

NN partitions for 3 dimensions
10
Motivation

• Advantages of NN algorithm
• Fast running time to finding the first result
• Progressiveness
• Disadvantages of NN algorithm
• Redundant I/O computation
• Explosive to-do list size
• Goal Improve NN algorithm and offer useful
  variations.

Do you think there exists more efficient and
useful skyline algorithm?
11
Contents

• Introduction
• Algorithms BBS
• Preliminary R-Tree
• How BBS works on
• Example
• Other Discussions

12
R-Tree Clustering by Proximity
Root
E
E
1
2
E
E
E
E
E
E
1
E
3
4
5
6
7
2
e
a
c
d
g
b
f
m
j
l
i
h
k
E
E
E
E
E
4
3
5
7
6
13
R-Tree
14
R-Tree
15
Branched and Bound Skyline (BBS)

• Assume all points are indexed in an R-tree.
• Top-down Approach
• mindist the L1 distance between its lower-left
  corner and the origin.

f(x, y) x y
16
Branched and Bound Skyline (BBS)

• Data structure
• Heap by min distance
• List to maintain the current skyline
• Dominance check condition
• Before expanding or inserting, compare to current
  skylines.
• Before inserting an object, also check for
  internal objects.
• Stop condition empty heap

17
Example of BBS

• Each heap entry keeps the mindist of the MBR.

access root
18
Example of BBS

• Process entries in ascending order of their
  mindists.

access root
expand e7
19
Example of BBS
access root
expand e7
expand e3
20
Example of BBS
access root
expand e7
expand e3
remove e6
21
Example of BBS
access root
expand e7
expand e3
remove e6
remove e5
22
Example of BBS
access root
expand e7
expand e3
remove e6
remove e5
expand e1
23
Example of BBS
access root
expand e7
expand e3
remove e6
remove e5
expand e1
expand e4
24
Contents

• Introduction
• Algorithms BBS
• Other Discussions
• Constrained skyline queries
• K-dominating queries

25
Constrained Skyline Queries
26
Constrained Skyline Queries
27
Constrained Skyline Queries
28
Constrained Skyline Queries
29
Constrained Skyline Queries
30
K-dominating Queries

• Retrieve 3 points that dominate the largest
  number of other points.

h and m may dominate at most 7 points. (num(i)
2)
num(i) 9, num(a)2, num(k)2
3-dominating result i
3-dominating result i
31
K-dominating Queries
num(h) 7, num(m)5, num(a)2, num(k)2
c and g may dominate at most 5 points. (num(h)
2)
3-dominating result i, h, m
2-dominating result i, h
32
Thats it.
QA
Thank you!
