ebXML Day (Barcelona 23.5.2002) Implementing ebXML Registry Information Model

1
ebXML Day(Barcelona 23.5.2002)Implementing
ebXML Registry Information Model
2
Some background...

• Technical Architect (Media and Telecom section,
  TietoEnator in Brussels, Belgium).
• Specialising in system architecture development
  of Java/ XML solutions.
• Open-source evangelist.
• New committer on ebxmlrr open-source project.
• Previously worked for Nokia (Finland), IBM Global
  Services (Belgium)

3
Some background...

• TietoEnator
• Staff of 10,000 and annual net sales of 1.1
  billion euros.
• IT Services organization with strong base in
  Scandinavia esp. Finland, Sweden
• Consulting, systems development and integration,
  operation and support, product development
  services, and software services.
• In Belgium, working with both commercial and
  public sector clients.
• http//www.tietoenator.com/

4
Our Project

• Implementation of MIReG metadata model and
  framework
• MIREG Managing Information Resources for
  e-Government
• Sponsored by European Commissions IDA initiative
• IDA Interchange of Data between Administrations
• IDAs mission using advances in information and
  communications technology to support rapid
  electronic exchange of information between Member
  State administrations
• http//europa.eu.int/ISPO/ida/

5
Project Goal

• To implement a system for managing metadata about
  information resources, documents and services.
• To implement a system that facilitates
• content interoperability
• simplification of administrative processes
• improved information flows
• To allow users to
• locate and track documents, metadata and versions
• search and manage content
• search and manage administrative metadata

6
What is Metadata??

• Data about data.
• Metadata describes a resource e.g
• Name
• Title
• Subject
• Date issued
• Version
• Date modified
• Identifier
• Dublin Core standard is simple standard for
  describing a wide range of networked resources.
  See http//dublincore.org

7
Dublin Core Elements
Creator Publisher
Contributor Relation
Coverage Rights
Date Subject
Description Source
Format Title
Identifier Type
Language
8
MIReG Metadata Model Framework

• Metadata management system manages metadata about
  information resources, documents and services
• Describes citizens, enterprises, public servants,
  long-lived information (e.g. archived documents).
• Dublin Core MIReG extensions
• administrative metadata - to describe how the
  resource should be managed and processed
• access rights
• security classification
• disposal
• long-term preservation
• etc

9
Functional requirements

• Metadata management system should support
• Exporting documents and their metadata
• Converting existing metadata to Dublin Core/RDF
• Adding or updating administrative metadata
• Storing metadata
• Providing metadata search capability
• Importing documents and their metadata.

10
Why ebXML?

• Metadata Management System should
• be flexible and evolutionary
• facilitate content interoperability i.e.
  information exchange between organisations
• be standards compliant and open
• provide well defined interfaces, allowing
  Creation, Update, Retrieval and Deletion of
  metadata and content

11
Non-functional requirements

• All open-source solution, adopting best of
  breed solutions (e.g. Apache WS, Apache Tomcat,
  Apache Xindice, Castor Java-XML binding)
• Co-operate with open source community wherever
  possible.
• Delivered system based on standards such as
  ebXML, W3C Schema, RDF, Dublin Core.
• Total XML solution from database to user
  interface.

12
Tools and APIs Requirements

• Open-source!! Ability to see the code and make
  changes if necessary...
• Support open-source community responds quickly
  to bug reports and questions.
• Dont reimplement ebXML Registry from scratch
  co-operate with existing open-source team(s).
• Dont reinvent the wheel reuse best existing
  solutions.
• Use stable and well adopted tools (e.g. Apache
  Web Server 1.3, Apache Tomcat 4.0)

13
Tools and APIs Problems

• Steep learning curve ... many new tools and APIs
  to master.
• Support for full W3C Schema standard not
  available in Castor Java-XML binding.
• No concrete JAXB implementation available that
  supports W3C Schema (only DTD)
• Xindice 1.0 only really supports US-ASCII (UTF-8
  patch now available in Xindice 1.1 development..)
• Xindice XPath contains() search is slow. Must use
  equality tests to gain benefits of indexing.
• Xindices transaction support not yet available
  ...

14
Standards Technologies (1)

• Standards
• JAXP Java API for XML Processing
• JAXB Java API for XML Binding
• JAXR Java API for XML Registries
• JAXM Java API for XML Messaging
• SOAP Version 1.1
• W3C XML Schema
• RDF RDF Schema
• XSLT (Version 1.0 )
• XPATH (Version 1.0 )
• XML DB
• Java Servlet specification (Sun Microsystems)
  version 2.3
• JSP specification (Sun Microsystems) version
  1.2

15
Standards Technologies (2)

• Open Source technologies tools
• Apache Web Server 1.3
• Apache Tomcat 4.0.3 servlet engine
• Apache SOAP (XML messaging API)
• Apache Xerces XML parser
• Apache Xalan XSLT processor
• Apache Xindice (DBXML) native XML database
• Castor open source framework for Java XML
  binding
• All software written using the Java programming
• language (Java versions 1.3 and 1.4)

16
Architecture Overview (High Level)
17
Architecture Overview (ebXML Service Layer)
18
Architecture Overview (XML database layer)
19
Xindice v Relational

• Relational database model
• Tables
• Views
• Data is structured, based on pre-defined schema
• Standardised queries via SQL (SELECT, INSERT,
  UPDATE, DELETE etc..)
• Most RDBMS support JOIN operations
• Possible to make XML to Relational mapping (e.g.
  IBM DB2 XML Extender)

20
Xindice v Relational

• Xindice database model
• Hierarchical organisation of data
• The root of the hierarchy is a database instance
• Data managed as XML Documents
• Insert the data as XML and retrieve it as XML
• Sets of documents form a Collection (similar
• idea as file system folder)
• Queries with using standard XPath (Query engine
  built around Apache Xalan)
• Indexation system speeds Xpath query performance

21
Mapping ebXML RIM to Xindice

• Main Concepts
• All ebXML RIM components stored as separate XML
  documents
• In Xindice ebXML RegistryObject id used as
  document id
• Use Association to link two RegistryObjects e.g
• ltrimObjectRef id"urnuuidb2345678-1234-1234-123
  456789077"/gt
• ltrimObjectRef id"urnuuidc2345678-1234-1234-123
  456789012"/gt
• lt! Association describes relationship between
  these two objects --gt
• ltrimAssociation associationType"Packages"
  sourceObject"urnuuidb2345678-1234-1234-12345678
  9077" targetObject"urnuuidc2345678-1234-1234-12
  3456789012"/gt

22
Mapping ebXML RIM to Xindice

• All XML data is wrapped in a custom
  ltRegistryDatagt wrapper.
• ltRegistryDatagt wrapper contains namespace
  declaration
• ltRegistryData xmlns"urnoasisnamestcebxml-reg
  reprimxsd2.0" xmlnsrim"urnoasisnamestcebx
  ml-regreprimxsd2.0gt
• XPath queries include namespace prefix e.g.
  //rimExtrinsicObject
• All ebXML RIM components are stored in same
  collection

23
ebXML RIM and Dublin Core

• Metadata mapped to ExtrinsicObject slots
• e.g creatorArthur C. Clarke maps to
• ltSlot namecreator" slotTypedc-metadata"gt
• ltValueListgt
• ltValuegtArthur C. Clarkelt/Valuegt
• lt/ValueListgt
• lt/Slotgt
• Sub-set of ebXML RIM implemented in short-term
  User, Slot, ExtrinsicObject, AuditableEvent,
  Association, ExternalLink

24
Querying Xindice with XPath (1)

• W3C standard XPath
• Advanced path like expressions, allowing node
  selection and filtering
• Example
• ltrimExtrinsicObject id"urnuuidb089d653-bad1-41
  d6-93ad-9dc93c055339"gt
• ltrimNamegt
• ltrimLocalizedString value"ebXML RIM Schema
  metadata"/gt
• lt/rimNamegt
• ltrimDescriptiongt
• ltrimLocalizedString value"metadata about
  ebXML RIM schema"/gt
• lt/rimDescriptiongt
• lt!-- metadata here as slots --gt
• ltrimSlot name"title" slotType"schema-metadata"
  gt
• ltrimValueListgt
• ltrimValuegtebXML RIM W3C Schemalt/rimValuegt
• lt/rimValueListgt
• lt/rimSlotgt etc . . .

25
Querying Xindice with XPath (2)

• Select ExtrinsicObject with identifier
  urnuuidb089d653-bad1-41d6-93ad-9dc93c055339
• //rimExtrinsicObject_at_identifier'urnuuidb089d
  653-bad1-41d6-93ad-9dc93c055339'
• Case sensitive Select ExtrinsicObject with Slot
  whose name is title and whose value list entry
  contains the word ebXML
• //rimExtrinsicObjectrimSlot_at_name'title'/rim
  ValueList/rimValuecontains(.,'ebXML')

26
Querying Xindice with XPath(3)XPath JOIN

• One Xindice collection can be queried as one
  large document
• Example
• ltrimExternalLink id"acmeLink2"gt
• ltrimNamegt
• ltrimLocalizedString value"Link 2"/gt
• lt/rimNamegt
• ltrimDescriptiongt
• ltrimLocalizedString value"ACME's Link 2"/gt
• lt/rimDescriptiongt
• lt/rimExternalLinkgt
• ltrimAssociation id"acmeLink2-alreadySubmittedCPP
  -Assoc" associationType"ExternallyLinks"
  sourceObject"acmeLink2" targetObject"urnuuida2
  345678-1234-1234-123456789012"/gt

27
Querying Xindice with XPath (4)XPath JOIN

• XPath
• Get the RegistryObject whose id is the same as
  the targetObjects id of the Association whose
  sourceObjects id is acmeLink2
• //_at_id//rimAssociation_at_sourceObject'acmeLink2
  '/_at_targetObject

28
Querying Xindice with XPath (5)XPath JOIN

• Example
• ltExtrinsicObject id"urnuuid548b6bf0-cf77-4450-9
  efe-ee465b504484" status"Submitted"
  xmlns"urnoasisnamestcebxml-regreprimxsd2.0
  "gt
• lt/ExtrinsicObjectgt
• ltAuditableEvent
• id"urnuuid724719b2-6b4f-41ca-b910-af5219ebcdd9
  " objectType"AuditableEvent"
• eventType"Created"
• registryObject"urnuuid548b6bf0-cf77-4450-9efe-
  ee465b504484" timestamp"2002-05-15T113856.980"

• user"urnuuid921284f0-bbed-4a4c-9342-ecaf0625f9
  d7" xmlns"urnoasisnamestcebxml-regreprimxsd
  2.0" /gt

29
Querying Xindice with XPath (6)XPath JOIN

• XPath
• Get all RegistryObjects created by user with id
  'urnuuid921284f0-bbed-4a4c-9342-ecaf0625f9d7
• //_at_id//rimAuditableEvent_at_eventType'Created'
  and _at_user'urnuuid921284f0-bbed-4a4c-9342-ecaf0
  625f9d7'/_at_registryObject

30
XUpdate

• XMLDB initiative specification
  http//www.xmldb.org/xupdate
• Batch modifications against XML document set.
• Example
• ltxupdateupdate select"//rimUser_at_id'urnuuid
  921284f0-bbed-4a4c-9342-ecaf0625f9d7'/rimEmailAd
  dress/_at_address"gtpeter.burgess_at_tietoen
  ator.comlt/xupdateupdategt

31
Castor Java-XML Binding (1)

• Implements majority of W3C Schema recommendation
  (e.g. no Union)
• UnMarshal a java.io.Reader into Java object
• StringReader stringReader new
  StringReader(extObjXML)
• ExtrinsicObject extObj ExtrinsicObject.unmarshal
  (stringReader)
• Marshall Java object to java.io.Writer
• extObject.marshal(stringWriter)
• String extObjXML stringWriter.toString()

32
Castor Java-XML Binding (2)

• Fast, reliable, performant
• Uses SAX
• High level interface.
• Manipulate XML document as Java Object
• No need to walk the DOM tree, or build custom SAX
  handlers

33
Lessons Learned

• Reuse of existing solutions saves much time in
  long term
• Access to all software sources was invaluable
  make own bug fixes on the spot.
• Open-source is a two-way street. Use others
  solutions and also contribute your own.
• Solid architecture because we took time to
  carefully design the system (plus prototyping,
  learning new APIs)
• XML databases offer a very realistic solution for
  projects with XML data storage needs.
• XPath is very powerful even possible to
  implement JOIN in Xindice.

34
References

• ebxmlrr project http//sourceforge.net/projects/eb
  xmlrr
• Apache Xindice http//xml.apache.org/xindice
• XMLDB initiative http//www.xmldb.org
• Castor Java-XML Binding http//castor.exolab.org/
• IDA (European Commission) http//europa.eu.int/ISP
  O/ida
• TietoEnator http//www.tietoenator.com
• Peter Burgess - peter.burgess_at_tietoenator.com
