Title: Danny Ball


1
Danny Ball
  • Design Engineering McCauley Propeller Systems

2
Product Improvements
  • Single Piece Piston Rods
  • C300 and C500 piston rods are currently a 2 piece
    brazed assembly
  • SL2007-5 issued last year due to a faulty braze
    joint causing engine oil leakage into hub
  • Single piece fully machined piston rod now in
    evaluation testing
  • Production implementation in 2009

3
Product Improvements
  • Constant Speed Cylinder Gasket Improvement
  • New molded rubber gasket would eliminate the need
    for Permatex application
  • Benefits
  • Decreased assembly time/simplified installation
  • More consistent cylinder screw torque holding
  • Minimized chance of cylinder leakage
  • Increased reliability
  • Direct field replacement
  • Limited release to the field is in work

4
Product Improvements
  • Installation Examples
  • Clean Surface Oil Residue Present

5
Product Improvements
  • B-4746 Slot Blocks
  • Ongoing issue with the bearing race loading slot
    block tabs being bent deformed
  • Parts are being made from a stronger alloy, and
    will enter service when current stock is
    exhausted (1Q09)

6
Product Improvements
  • Corrosion Resistance Improvements
  • Currently evaluating the current Type I Cadmium
    plating of various hardware
  • Engineering changes underway to change various
    fasteners to Type II for increased corrosion
    resistance
  • Type II hardware will have a gold appearance vs.
    the silver finish of Type I plating

7
Product Improvements
  • Deice Brush Material Change
  • Current compound is being obsoleted for
    environmental reasons due to lead content
  • Working with suppliers to develop/qualify a new
    material
  • Current supply will last
  • through 2009

8
Continued Airworthiness
  • Jetstream 41 (C1101-C1104)
  • Split retainer ends have made slight indentions
    on several of the cracked blade shanks
  • Manufacturing will orient the split retainer ends
    approx. 90 from the counterweight hole
  • SB255A has been sent to FAA for approval
  • 3500 hour life limit, and wear limit
  • Improved split retainers
  • AD coming soon

9
Continued Airworthiness
  • Jetstream 41 (C1101-C1104)
  • Shelf wear limit

10
Product Improvements
  • Threaded to Threadless
  • Currently four TC packages approved by FAA that
    will provide a C200 series threaded propeller
    option for the following models
  • Cessna 207 and T207
  • Cessna A185EF
  • Cessna 210D thru 210L and T210F thru T210L
  • Cessna 206, P206, TU206, U206, and TP206
  • Full TC approval and availability of Cessna
    service kits by the end 2008

11
Permatex Installation
  • Permatex residue has been found in the blade
    o-ring groove, on the ID of the sockets, and on
    the o-ring.

12
Permatex Installation
  • Old Gasket New Gasket
  • Gasket changed to add cutouts for the bearing
    race loading slots.

13
Thank You!
  • Questions/Comments
