Geological Oceanography Section II Lecture 3

1
Geological Oceanography Section II Lecture 3

• Continental Shelf Sedimentation 14 February 2008

2
Sedimentation on Continental Shelves and Margins

• Sedimentary Provinces - Shelf
• Beaches and barrier Islands (covered previously)
• Estuaries
• Deltas
• Shelves
• Sedimentary Provinces - Margins
• Slopes
• Submarine Fans
• Sediment Drifts

3
Recommendation

• The following CMS seminars presented last spring
  are pertinent to this lecture!!!
• Charlie Paull (March 2, 2007)
• Detecting and Monitoring Recent Sediment
  Transport Activity in Monterey Canyon
• Mike Blum (March 9, 2007)
• Holocene Sea-Level Change, Northern Gulf of
  Mexico
• Dave Cacchione (March 23, 2007)
• Sediment Movement by Internal Waves and Tides on
  Continental Margins

4
Single most important factor influencing
continental shelf and margin sedimentation

• Rate of sediment supply

5
(No Transcript)
6
Major Mechanisms Influencing Shelf Sedimentation

• Tectonics
• Watershed characteristics
• Shelf/margin characteristics
• Climate
• Weathering mechanisms and rates
• Transport mechanisms and rates
• Biogenic and authigenic processes
• History
• Paleoclimate
• Sealevel history
• Oceanography
• Prevailing winds/fetch
• Oceanic and local geostrophic currents
• Tides and tidal currents

7
Tectonics influence

• Watershed
• Area
• Topography
• Geology
• Climate
• Adiabatic
• Rain shadows
• Shelf and margin
• Area
• Topography
• Geology

8
What do I mean by watershed?
9
Dr. Naar discussed tectonic processes

• Why do continental margins exist?
• Types of continental margins
• Convergent/active
• Divergent/passive/trailing
• Conjugate, shear, etc.
• Margin structures
• How margins form
• How do margins mature
• Isostatic loading

10
(No Transcript)
11
(No Transcript)
12
Tectonic Influence on Climate
13
Primary Mechanisms Influencing Shelf
Sedimentation

• Tectonics
• Watershed characteristics
• Shelf/margin characteristics
• Climate
• Weathering mechanisms and rates
• Transport mechanisms and rates
• Biogenic and authigenic processes
• History
• Sealevel history
• Paleoclimate
• Oceanography
• Prevailing winds/fetch
• Oceanic and local geostrophic currents
• Tides and tidal currents

14
Climate Zones
http//www.blueplanetbiomes.org/climate.htm
15
Weathering and climate chemical weathering and
frost action require moisture
Revised from Peltier 1950, Annals, Association of
American Geographers. v. 40
16
Relative depth of weathering with climate and
vegetation assumes minimal relief.
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
Sediments reflect climatic conditions
(Schopf 1980)
21
Primary Mechanisms Influencing Shelf
Sedimentation

• Tectonics
• Watershed characteristics
• Shelf/margin characteristics
• Climate
• Weathering mechanisms and rates
• Transport mechanisms and rates
• Biogenic and authigenic processes
• History
• Sealevel history
• Paleoclimate
• Oceanography
• Prevailing winds/fetch
• Oceanic and local geostrophic currents
• Tides and tidal currents

22
Sea Level Changes Through Geologic Time
23
James (1997)
24
Last Glacial Maximum18-20,000 ybp
25
Holocene sea-level rise

• Low-moderate rates of sediment supply
• Sediments trapped in estuaries
• Shelf has relict, biogenic or authigenic
  sediments
• Sediment delivery to margins diminished
• Examples much of shelf of eastern US
• High rates of sediment supply
• Deltas prograding over shelf
• Sediments being delivered to margins and deep-sea
  fans
• Examples
• Mississippi delta, Mississippi fan
• Ganges-Brahmaputra delta, Bengal fan

26
Chesapeake Baydrowned valley sea level rise
outpaced sediment supply
27
Mississippi Delta high rate of sediment supply
http//www.ssec.wisc.edu/gumley/modis_gallery/ima
ges/MississippiDelta_20040127_1940_250m.jpg
28
Paleoclimate

• In areas of low-moderate sediment supply
• Shoreline and relict shelf sediments may reflect
  Pleistocene conditions and sea levels
• Examples
• Relict glacial features and sediments
  characterize shelves of northeastern US and
  eastern Canada
• Areas not currently glaciated
• Paleoshorelines and relict barrier islands on
  west Florida shelf
• More discussion later in lecture

29
Primary Mechanisms Influencing Shelf
Sedimentation

• Tectonics
• Watershed characteristics
• Shelf/margin characteristics
• Climate
• Weathering mechanisms and rates
• Transport mechanisms and rates
• Biogenic and authigenic processes
• History
• Sealevel history
• Paleoclimate
• Oceanography
• Prevailing winds/fetch
• Oceanic and local geostrophic currents
• Tides and tidal currents

30
Fetch distance over which winds blow
unobstructed
31
http//www.bergey.com/Maps/World.Wind.Lg.htm
32
Tidal ranges worldwide
Open University Waves, Tides and Shallow-water
Processes (1989)
33
Shelf Sedimentary Provinces

• Beaches/barrier Islands
• covered later by Dr. Hine
• Estuaries
• Deltas
• Reefs (later lecture)
• Shelves

34

• An estuary is an inlet of the sea reaching into a
  river valley as far as the upper limit of tidal
  influence

Open University Waves, Tides and Shallow-water
Processes (1989)
35
Estuary Types

• Salt-wedge estuaries
• River discharge rate much stronger than tidal
  activity
• Sharp halocline with freshwater at surface
• Partially mixed estuaries
• Discharge into moderate tidal range
• Well-mixed estuaries
• Tidal currents strong relative to river discharge
• Negative-circulation estuaries
• Occur in arid regions
• Hypersaline water at the head of the estuary
• Flows seaward along estuary floor

Figures Open University Waves, Tides and
Shallow-water Processes (1989)
36
Salt-wedge estuary
37
Partially mixed estuary
38
Well mixed estuary
39
Well mixed estuary
40
Negative estuarine circulation
Open University Waves, Tides and Shallow-water
Processes (1989)
41
River Deltas

• Main conduit of terrigenous materials to ocean
• Suspended load-muds
• Bedload-sands
• Dissolved load - cations/anions

42
Deltas

• Provide sediments to coastlines, barrier islands
  and marshes
• Huge wetlands--key environment
• Sediments can be transported great distances down
  into ocean basin from deltas
• Deltas can be enormously thick
• undergo compaction, isostatic adjustment
• Deltas impacted by sea-level change.

43
Societal Significance of Deltas

• Modern and ancient deltas are great producers of
  oil/gas
• Ancient deltas are major producers of coal
• Natural hazards -- support huge populations
  impacted by typhoons
• Bangladesh Nov 1970 155 mph typhoon, 7m storm
  surge 400,000 drowned
• Bangladesh Apr 1990, 145 mph typhoon, 6 m
  surge, 140,000 drowned, 500,000 large farm
  animals drowned, 10 million homeless

44
(No Transcript)
45
(No Transcript)
46
Basic structure of a delta
Open University Waves, Tides and Shallow-water
Processes (1989), p. 131
Delta front
Pro-delta
Note error in text
47
(No Transcript)
48
River-dominated delta

• Tidal range is low
• Tidal currents weak
• Wave action relatively weak
• Density stratification may occur
• Speed of river flow is low to moderate
• Distributary mouth deep enough for salt-water
  penetration
• Fresh water plume over salt water
• A type of salt-wedge estuary

Figures Open University Waves, Tides and
Shallow-water Processes (1989)
49
(No Transcript)
50
(No Transcript)
51
Turbulent mixingrapid fluvial discharge
precludes density stratification
Into deep water
52
Turbulent mixingrapid fluvial discharge
precludes density stratification
Into shallow water
53
Progradation of sedimentsupply- dominated delta
54
(No Transcript)
55
(No Transcript)
56
Wave-dominated delta
57
Wave-dominated delta
58
Delta classification based on sediment supply and
influence of waves and tides
59
Tidal ranges worldwide
Open University Waves, Tides and Shallow-water
Processes (1989)
60
Recall what I said previously about tidal
transport and deposition
More sand
Channel
Rippled fine, muddy sands
61
Changes in current velocity during a complete
tidal cycle.
Changes in rate of bedload transport during same
tidal cycle. Shaded areas are proportional to
total sediment transported.
Incoming
Outgoing
62
Tide- dominated delta

• Sediments delivered by river are reworked by
  tides
• Form linear, subaqueous ridges
• Former ridges become vegetated, linear islands

63
The Continental Shelf

• Marine terraces that surround continents
• Very narrow (1 km) to very wide (100s km)
• Sediments range from relict to massive deltas
• Dominated by terrigenous or carbonate or mixed
• Wave or tide dominated
• Effects of sea level change enormous
• Coastal plains are exposed continental shelves
• Archeological/paleontological implications
• Sharks teeth and mammoth teeth on west Florida
  shelf

64
(No Transcript)
65
Terrigenous Continental Shelves--Key Features

• Sand ridges
• Cape retreat massifs
• Estuarine retreat massifs
• Paleo-shorelines
• Buried river valleys
• Scarps
• Mid-shelf deltas

66
Relict morphologic elements of the Middle
Atlantic Bight, North America
Estuaries
Sand bodies Sand ridges
Relict deltas
67
Proposed origin of some sand ridges
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
Carbonate Shelves

• Subpolar to tropical
• Absence of terrigenous influences
• Reefal, skeletal, or non-skeletal sediments
• Attached or non-attached
• Rimmed or ramps

78
Schematic section across Great Bahama Bank from a
seismic profile
79
Carbonates can dominate where terrigenous input
is minimal
80
Sediment transport to the deep sea
81
Slopes

• Sediment gravity processes active
• Canyons
• may feed submarine fans
• rivers discharge at canyon heads during sea level
  lowstands
• Slumps, slump blocks, slides
• may generate turbidity currents
• Turbidity flows
• turbidites - primary sedimentary deposit
• predictable vertical sequence of primary
  sedimentary structures--Bouma Sequence

82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
(No Transcript)
88
Submarine Fan

• Major sediment accumulation at base of slope
• Fed by canyon system turbidity currents and
  debris flows can no longer entrain sediments
• Similar features as rivers
• levees, meandering systems
• Repository of great mountain systems
• E.g., Bengal Fan

89
Bengal Fan
90
BENGALFAN
91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94
Sediment Drifts-Contourites

• Western boundary currents rework turbidites,
  which are redeposited as large mounds of
  fine-grained materials
• High sedimentation rates, have great
  paleoceanographic record

95
(No Transcript)
96
(No Transcript)
97
Location Map of ODP Leg 194
NMP Northern Marion Platform SMP Southern
Marion Platform
98
(No Transcript)
99
Food for thought by the end of this series of
lectures

• Given any continental shelf/margin worldwide, you
  should be able to give a first-order explanation
  of
• What kind of margin occurs there
• What kinds of sediments occur there, e.g.,
• Deltaic
• Relict siliciclastic
• Carbonate (lectures on carbonates will come
  later)
• Mixed carbonate/siliciclastic

100
Reading assignments

• The Open University (either edition) Waves, Tides
  and Shallow-Water Processes.
• Chapter 7. Deltas
• Chapter 8. Shelf Seas
• Seibold, E. and W. Berger (any of the 3 editions)
  The Sea Floor
• Chapter 3. Sources and compositions of marine
  sediments
• Chapter 4. Effects of waves and currents

101
Reading assignment for next Tuesday

• Seibold, E. and W. Berger (any of the 3 editions)
  The Sea Floor
• Chapters 6, 7 and Appendix 9
