2005 AIR FORCE CORROSION PROGRAM CONFERENCE 14 Mar 05

1
2005 AIR FORCECORROSION PROGRAM CONFERENCE14
Mar 05
WING CORROSION MANAGER BRIEFING

• CMSgt David M. Pentecost
• AF Corrosion Program Manager
• AF Corrosion Prevention Control Office

DISTRIBUTION A. Approved for public release
distribution unlimited.
2
First Things First

• Q Why are you here?
• Is it because you like Macon?
• Is it because you like us?
• Is it because you like meeting and mingling?
• Is it because you want to learn something?
• All good, but not good enough

3
First Things First

• A Youre here because

• I Want You in the Fight Against Corrosion

4
Wing Corrosion Manager

• Responsibilities
• AFCPCO
• Wing Corrosion Manager
• Work centers

5
ResponsibilitiesAFCPCO

• AFCPCO responsibilities
• Engineering Authority for 8 General Series TOs
• Evaluate new materials and process technologies
• Transition Corrosion Technologies to Users
• Conduct Command Surveys and take action items
• Support Corrosion Prevention Advisory Boards
• Support Corrosion Training
• Corrosion Control Facilities Reference Guide
• Host Annual AF Corrosion Conference
• Provide on-call technical support and guidance

6
ResponsibilitiesAFCPCO

• A tool to answer your questions and disseminate
  information

https//afcpco.robins.af.mil/
7
ResponsibilitiesAFCPCO

• AFCPCO Website is a valuable information source
• Qualified Products Listings (QPL) and links
• Calla 602LF Information
• New Aircraft Hand Wash Pad (Mr Clean Type)
• Non-Chrome Tie Coat Message
• Process for Corrosion Severity Measurement for
  new locations/recurring deployment locations
• Corrosion Control Reference Guide
• Corrosion Control Facilities Reference Guide
• Command Corrosion Survey Reports
• Much, much more
• Join the New Stuff E-Mail List

8
ResponsibilitiesWing Corrosion Manager

• Duties/responsibilities vary across the MAJCOMs
• Champion Wings Corrosion Program
• Assist Wing organizations to develop and maintain
  effective corrosion control programs
• Oversee development and implementation of Local
  Corrosion Control Training Programs
• Active participant in weapon system(s) CPAB
• Update Operating Instructions/supplements
• Visit HAZMART and shopsknow their business
• Effectiveness of Wings Corrosion Program depends
  on their level of commitment and involvement

9
GENERAL PURPOSE CLEANERS

• Dont even think about using these on your
  aircraft or equipment!

10
Whats wrong with this cleaner?
11
Authorized Spot Cleaners
Consider these AEROSOL CLEANERS
MIL-C-43616 6850-01-005-5305 T.O. 1-1-691, Table
A-2
MIL-PRF-87937 6850-01-461-0070 T.O. 1-1-691 A-2
12
Authorized Spot Cleaners

• Other MIL-PRF-87937 Spot Cleaners
• Type I   6850-01-461-0065
• 24 ounce bottle w/ spray trigger
• Type III 6850-01-514-0105 / 6850-01-521-8883
• 24 ounce bottle / 16 ounce w/ spray trigger
• Type IV 6850-01-461-0070
• 24 ounce bottle w/o spray trigger

• MIL-PRF-85570
• Type III (Abrasive Spot Cleaner)
  6850-01-232-9164
• Use to remove stubborn contaminants on Gloss A/C
  Only!!!

13
Structural Maintenance

• Alodine use
• T.O. 1-1-8 (para. 3-34) added no-rinse process
  using MIL-C-81706
• Alodine 1132 Pen (T.O.1-1-8, para., 3-33.3)

8030-01-460-0246
14
Structural Maintenance

• IOS 1-1-8s-2, PreKote SP Authorization
• Plastic Media Blasting Booths
• T.O. 1-1-8 para. 2-21.13, formerly IOS 1-1-8S-1
• Forego PMB testing in small walk-in/cabinet type
  booths and purge media prior to testing interval
• Walk-in Booths
• Cover floor to protect media from concrete
  contamination
• Seal doors to prevent lose of media from booth

15
Paint Facility

• HVLP (High Volume Low Pressure) Spray Equipment
• T.O. 1-1-8 para., 4-19
• Do not use air hose longer than 50
• Fluid hose from tank to gun no less than 3/8 ID
• Air Hose no less than 5/16 ID
• Contact CTIO for Spray Gun Optimization Tool

Wrong
1/4 hose/fittings
3/8 hose/fittings
Right
16
Paint Facility

• HVLP Spray Equipment
• Paint Gun Washers

17
Paint Facility

• HVLP Spray Equipment
• Paint Gun Washers
• HEPA Vacuum Sanders

18
Paint Facility

• HVLP Spray Equipment
• Paint Gun Washers
• HEPA Vacuum Sanders
• Shelf Life

19
Paint Facility

• HVLP Spray Equipment
• Paint Gun Washers
• HEPA Vacuum Sanders
• Shelf Life
• Non-chromated Tie Coat

20
Paint Facility

• HVLP Spray Equipment
• Paint Gun Washers
• HEPA Vacuum Sanders
• Shelf Life
• Non-chromated Tie Coat
• Sempens/Rollers

21
Paint Facility

• HVLP Spray Equipment
• Paint Gun Washers
• HEPA Vacuum Sanders
• Shelf Life
• Non-chromated Tie Coat
• Sempens/Rollers
• Touch-up kits

22
Paint Facility

• HVLP Spray Equipment
• Paint Gun Washers
• HEPA Vacuum Sanders
• Shelf Life
• Non-chromated Tie Coat
• Sempens/Rollers
• Touch-up kits
• New 2-Component Aerosols

23
Wash Rack

• Need more than one type/class of cleaners
• Aircraft have different soils
• Correct dilution ratio
• Manufacturers recommendation
• If hot water is available, use it

24
Wash Rack

• Need more than one type/class of cleaners
• Aircraft have different soils
• Correct dilution ratio
• Manufacturers recommendation
• If hot water is available, use it
• Ensure correct materials are used
• New Melamine Formaldehyde A/C wash pads
  authorized
• No Technical Objection toGPC local purchases

NSN 6850-01-525-7684 Part /UPC EVO-MC6
25
Wash Rack

• Wash contracts
• Contractor reluctant to use MIL Spec cleaners
• Wrong dilutions
• Unauthorized cleaning supplies
• Equipment
• Contractor qualifications
• Wash scheduling

• See Aircraft Wash Contracts Observations and
  Lessons Learned on website

26
Hydraulics/Pneudralics

• Aqueous Parts Washers (APWs)
• Landing Gear Components (including Wheels
  Brakes)
• Calla 296, 602LF, and SDF-1 only!!!
• For all others (i.e. AGE, Vehicles, etc.)
• Products Qualified to MIL-C-29602

27
Quality Assurance

• All inspectors complete QA Corrosion Course
• Inspect aircraft wash process
• Correct aircraft soap/dilution ratios
• Proper cleaning materials
• How wash is being performed
• Monitor over-due washes
• Determine reasons why
• Corrective actions

28
AGE Maintenance

• Establish Corrosion Control Cycles in Local
  OI's/MOIs
• Touch-up Program
• Unauthorized topcoats/primers

29
AGE Maintenance

• Establish Corrosion Control Cycles in Local
  OI's/MOIs
• Touch-up Program
• Unauthorized topcoats/primers
• Brush/roller
• Sempens
• CPCs
• 35-1-3 para., 2-80(a)
  MIL-C-85054B (Amlguard)
• RTVs- Corrosive / Non-corrosive

8030-01-347-0979
Mil-A-46106 / Mil-A-46146
30
Environmental Management/HazMart

• Too lenient or too stringent--either way, its
  not good
• Ensure only T.O. authorized materials are issued
• A successful ESOHCAMP inspection has no bearing
  on successfully managing corrosion control
  program
• Beware of General Base Approved Materials Lists
• Visit HAZMART periodically

31
Conclusion

• Responsibilities
• AFCPCO
• Wing Corrosion Manager
• Work centers

32
Questions or Comments?

• afcorr_at_robins.af.mil
• https//afcpco.robins.af.mil/
• AFRL/MLS-OLR
• 325 Richard Ray Blvd.
• Robins AFB GA 31098-1639
• DSN 468-3284
